KOMATSU HB205-1 HB215LC-1 PC200-8 / PC200LC-8 PC200-8 PC200-8E0 PC200LC-8 PC200LC-8E0 PC210-8K PC210LC-8K PC210NLC-8K EXCAVATOR 708-8F-00250 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

KOMATSU HB205-1 HB215LC-1 PC200-8 / PC200LC-8 PC200-8 PC200-8E0 PC200LC-8 PC200LC-8E0 PC210-8K PC210LC-8K PC210NLC-8K EXCAVATOR 708-8F-00250 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
708-8F-00250  HB205-1 HB215LC-1 PC200-8 / PC200LC-8 PC200-8 PC200-8E0 PC200LC-8 PC200LC-8E0 PC210-8K PC210LC-8K PC210NLC-8K
Pos. Part No Qty Parts name Comments
     708-8F-00250   [1]   MOTOR ASSEMBLY Komatsu 93 kg.
  ["SN: K50001-UP"] |1.
        708-8F-04681   [1]   CASE SUB ASSEMBLY Komatsu 0.000 kg.
  ["SN: K50001-UP"] |1.
        708-8F-04270   [1]   END COVER SUB ASSEMBLY Komatsu China
  ["SN: K50001-UP"] |3.
8   708-8F-34220   [1]   SPRING Komatsu 0.01 kg.
  ["SN: K50001-UP"]
   9.   708-8H-11530   [3]   PLUG Komatsu 0.031 kg.
  ["SN: K50001-UP"]
   10.   07002-11423   [3]   O-RING Komatsu China 0.001 kg.
  ["SN: K50001-UP"] analogs:["0700201423"]
   11.   20B-27-11210   [1]   BLEEDER Komatsu 0.02 kg.
  ["SN: K50001-UP"]
   12.   702-73-02112   [2]   VALVE ASSEMBLY, RELIEF Komatsu 0.18 kg.
  ["SN: K50001-UP"]
   13.   708-8F-36611   [2]   SPRING Komatsu China
  ["SN: K50001-UP"]
   15.   708-8H-36121   [2]   SPRING Komatsu China
  ["SN: K50001-UP"]
   16.   708-8F-36311   [2]   COVER Komatsu 1.6 kg.
  ["SN: K50001-UP"]
   17.   07000-13040   [2]   O-RING Komatsu China 0.002 kg.
  ["SN: K50001-UP"] analogs:["0700003040", "0700003040E", "YM24311000400"]
   18.   700-93-11320   [2]   O-RING Komatsu 0.01 kg.
  ["SN: K50001-UP"]
   19.   07000-11009   [2]   O-RING Komatsu 0.001 kg.
  ["SN: K50001-UP"] analogs:["0700001009"]
   20.   01252-61235   [12]   BOLT Komatsu 0.048 kg.
  ["SN: K50001-UP"] analogs:["801105554", "0125231235"]
   21.   708-8F-34120   [2]   VALVE Komatsu 0.04 kg.
  ["SN: K50001-UP"]
   22.   722-10-91130   [2]   SPRING Komatsu China
  ["SN: K50001-UP"]
   23.   708-8F-34110   [2]   PLUG Komatsu China
  ["SN: K50001-UP"]
   24.   07002-11823   [2]   O-RING Komatsu 0.36 kg.
  ["SN: K50001-UP"] analogs:["0700201823"]
   25.   708-8E-16180   [1]   VALVE Komatsu 0.004 kg.
  ["SN: K50001-UP"]
   26.   708-8F-31650   [1]   PLUG Komatsu China
  ["SN: K50001-UP"]
   27.   07000-11006   [1]   O-RING Komatsu 0.01 kg.
  ["SN: K50001-UP"] analogs:["0700001006"]
   28.   07001-01006   [1]   RING, BACK-UP Komatsu China
  ["SN: K50001-UP"] analogs:["890001737"]
   29.   07002-11223   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: K50001-UP"] analogs:["0700201223"]
   30.   708-8F-31610   [1]   O-RING Komatsu OEM 0.006 kg.
  ["SN: K50001-UP"]
   32.   04020-01228   [1]   PIN, DOWEL Komatsu 0.026 kg.
  ["SN: K50001-UP"] analogs:["21T3016190"]
   33.   708-8F-31210   [4]   BOLT Komatsu 0.432 kg.
  ["SN: K50001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-8F-00250   [1]   MOTOR ASSEMBLY Komatsu 93 kg.
  ["SN: K50001-UP"] |1.
   1.   708-8F-32121   [1]   SHAFT Komatsu China 2 kg.
  ["SN: K50001-UP"] analogs:["7088F32120"]
   2.   708-8F-12151   [1]   BEARING Komatsu 0.386 kg.
  ["SN: K50001-UP"]
   3.   708-7L-12140   [1]   BEARING Komatsu 0.267 kg.
  ["SN: K50001-UP"]
   4.   708-7L-05010   [1]   SPACER KIT Komatsu 0.1 kg.
  ["SN: K50001-UP"]
   5.   706-7G-11291   [1]   SEAL, OIL Komatsu OEM 0.08 kg.
  ["SN: K50001-UP"] analogs:["7067G11290"]
   6.   708-8F-12230   [1]   SPACER, 3.2MM Komatsu 0.046 kg.
  ["SN: K50001-UP"]
   7.   04065-07225   [1]   RING, SNAP Komatsu 0.02 kg.
  ["SN: K50001-UP"]
   11.   708-8F-33360   [3]   PIN Komatsu 0.006 kg.
  ["SN: K50001-UP"]
   12.   708-7L-13140   [2]   SEAT Komatsu 0.02 kg.
  ["SN: K50001-UP"]
   13.   708-8F-33160   [1]   SPRING Komatsu 0.153 kg.
  ["SN: K50001-UP"]
   14.   04065-04818   [1]   RING, SNAP Komatsu OEM 0.007 kg.
  ["SN: K50001-UP"]
   15.   708-8F-33350   [1]   GUIDE, RETAINER Komatsu 0.135 kg.
  ["SN: K50001-UP"]
   16.   708-2L-33350   [1]   RETAINER, SHOE Komatsu 0.3 kg.
  ["SN: K50001-UP"]
        708-8F-33340   [1]   RETAINER, SHOE Komatsu 0.295 kg.
  ["SN: K50001-UP"] |16.
   17. 708-8F-33310 [9]   PISTON SUB ASSEMBLY Komatsu 0.204 kg.
  ["SN: K50001-UP"]
   18.   708-8F-33481   [1]   CAM, ROCKER Komatsu 2.422 kg.
  ["SN: K50001-UP"]
   19.   708-8F-33710   [2]   BALL, RETAINER Komatsu 0.261 kg.
  ["SN: K50001-UP"]
   20.   708-8F-34141   [1]   PISTON Komatsu 0.088 kg.
  ["SN: K50001-UP"]
   21.   708-8F-34150   [1]   SPRING Komatsu China
  ["SN: K50001-UP"]
   22.   708-8F-35220   [1]   PLATE Komatsu China
  ["SN: K50001-UP"]
   23.   708-8F-35230   [3]   PLATE Komatsu 0.102 kg.
  ["SN: K50001-UP"]
   24.   708-8F-35120   [3]   DISC Komatsu 0.1 kg.
  ["SN: K50001-UP"]
   25.   708-8F-35140   [1]   PISTON, BRAKE Komatsu 0.84 kg.
  ["SN: K50001-UP"]
   26.   708-8F-35160   [1]   O-RING Komatsu 0.007 kg.
  ["SN: K50001-UP"]
   27.   708-8F-35170   [1]   RING, BACK-UP Komatsu 0.005 kg.
  ["SN: K50001-UP"]
   28.   708-8F-35180   [1]   O-RING Komatsu 0.002 kg.
  ["SN: K50001-UP"]
   29.   708-8F-35190   [1]   RING, BACK-UP Komatsu 0.005 kg.
  ["SN: K50001-UP"]
   30.   708-8F-35150   [6]   SPRING Komatsu 0.042 kg.
  ["SN: K50001-UP"]
   31.   04025-00324   [1]   PIN, SPRING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
