KOMATSU D51EX/PX-22 BULLDOZERS 708-1T-00540 708-1T-00541 708-1T-01540 FAN PUMP PARTS

Name: KOMATSU D51EX/PX-22 BULLDOZERS 708-1T-00540 708-1T-00541 708-1T-01540 FAN PUMP PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

KOMATSU D51EX/PX-22 BULLDOZERS 708-1T-00540 708-1T-00541 708-1T-01540 FAN PUMP PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

708-1T-00540 708-1T-00541 708-1T-01540 D51EX/PX-22

Pos.	Part No	Qty	Parts name	Comments
	708-1T-00541	[1]	PUMP ASSEMBLY Komatsu	57.55 kg.
			["SN: B13143-UP"] analogs:["7081T00540"] \|$33.
	708-1T-00540	[1]	PUMP ASSEMBLY Komatsu	57.55 kg.
			["SN: B10001-B13142"] analogs:["7081T00541"] \|1.
	708-1T-01540	[1]	PUMP SUB ASSEMBLY Komatsu China
			["SN: B10001-UP"] \|1.
	708-1T-04150	[1]	CASE SUB ASSEMBLY Komatsu	12.3 kg.
			["SN: B10001-UP"] \|1.
1	NSS	[1]	CASE Komatsu China
			["SN: B10001-UP"]
4	708-1S-13411	[1]	CAM, ROCKER Komatsu	1.2 kg.
			["SN: B10001-UP"]
5	04260-01270	[1]	BALL Komatsu OEM	0.009 kg.
			["SN: B10001-UP"]
6	708-3S-14140	[1]	SPACER Komatsu	0.03 kg.
			["SN: B10001-UP"]
7	708-1S-13420	[2]	PIN Komatsu China
			["SN: B10001-UP"]
8	01252-60616	[1]	BOLT Komatsu	0.007 kg.
			["SN: B10001-UP"] analogs:["0125230616"]
9	01252-61235	[4]	BOLT Komatsu	0.048 kg.
			["SN: B10001-UP"] analogs:["801105554", "0125231235"]
10	04020-01024	[2]	PIN Komatsu	0.015 kg.
			["SN: B10001-UP"] analogs:["PZF890001197"]
11	07000-11006	[1]	O-RING Komatsu	0.01 kg.
			["SN: B10001-UP"] analogs:["0700001006"]
12	07000-12125	[1]	O-RING Komatsu OEM	0.005 kg.
			["SN: B10001-UP"] analogs:["0700002125E", "0700002125"]
	708-1T-04550	[1]	CAP SUB ASSEMBLY Komatsu China
			["SN: B10001-UP"] analogs:["7081T11550"] \|13.
15	708-21-12760	[1]	BEARING Komatsu	0.086 kg.
			["SN: B10001-UP"]
16	720-68-19610	[1]	PIN Komatsu	0.002 kg.
			["SN: B10001-UP"]
17	708-1S-13430	[2]	BALL Komatsu China
			["SN: B10001-UP"]
18	07040-12412	[1]	PLUG Komatsu	0.092 kg.
			["SN: B10001-UP"] analogs:["0704012414", "0704002412", "R0704012412"]
19	07002-12434	[1]	O-RING Komatsu China	0.01 kg.
			["SN: B10001-UP"] analogs:["0700202434", "0700213434"]
20	708-1T-12160	[1]	SHAFT Komatsu China
			["SN: B10001-UP"]
21	708-3S-12210	[1]	BEARING Komatsu	0.4 kg.
			["SN: B10001-UP"]
22	708-21-12840	[1]	RING, SNAP Komatsu China
			["SN: B10001-UP"]
23	708-3S-12140	[1]	HOLDER Komatsu	0.215 kg.
			["SN: B10001-UP"]
24	207-09-11140	[1]	O-RING Komatsu	0.002 kg.
			["SN: B10001-UP"]
25	708-3S-12150	[1]	SEAL, OIL Komatsu	0.02 kg.
			["SN: B10001-UP"]
26	04065-06220	[1]	RING, SNAP Komatsu	0.013 kg.
			["SN: B10001-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
1	708-1T-13610	[1]	BLOCK, CYLINDER Komatsu China
			["SN: B10001-UP"]
2	708-1T-13620	[1]	PLATE, VALVE Komatsu China
			["SN: B10001-UP"]
3	708-3S-13160	[2]	WASHER Komatsu China
			["SN: B10001-UP"]
4	708-3S-13430	[1]	SPRING Komatsu	0.07 kg.
			["SN: B10001-UP"]
5	04065-03515	[1]	RING, SNAP Komatsu	0.003 kg.
			["SN: B10001-UP"]
6	708-3S-13370	[1]	GUIDE, RETAINER Komatsu	0.14 kg.
			["SN: B10001-UP"] analogs:["7081S13370"]
7	708-1S-13380	[3]	PIN Komatsu	0.06 kg.
			["SN: B10001-UP"]
8	708-3S-13410	[1]	RETAINER, SHOE Komatsu	0.24 kg.
			["SN: B10001-UP"]
9	708-1S-13520	[10]	PISTON SUB ASSEMBLY Komatsu	0.09 kg.
			["SN: B10001-UP"]
10	708-3S-14240	[1]	PLUG Komatsu China
			["SN: B10001-UP"]
11	708-3S-14261	[1]	PLUG Komatsu China
			["SN: B10001-UP"]
12	07002-11223	[2]	O-RING Komatsu China	0.001 kg.
			["SN: B10001-UP"] analogs:["0700201223"]
13	708-3S-14250	[1]	PISTON SUB ASSEMBLY Komatsu	0.087 kg.
			["SN: B10001-UP"] analogs:["7081S14230"]
14	708-1S-14241	[1]	SPRING Komatsu	0.01 kg.
			["SN: B10001-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	708-1T-03770	[1]	VALVE ASSEMBLY Komatsu China
			["SN: B10001-UP"] \|1.
	708-1U-03530	[1]	BODY ASSEMBLY Komatsu China
			["SN: B10001-UP"] analogs:["7081S19810", "7081U15120"] \|1.
1	NSS	[1]	BODY Komatsu China
			["SN: B10001-UP"]
	708-1U-04320	[1]	SLEEVE SUB ASSEMBLY Komatsu China
			["SN: B10001-UP"] analogs:["7081U15360", "7081U15370", "7081U15350"] \|3.
8	708-1S-15470	[1]	SPOOL Komatsu China
			["SN: B10001-UP"]
9	708-1W-45391	[1]	SEAT Komatsu China
			["SN: B10001-UP"]
10	708-1T-15670	[1]	SPRING Komatsu China
			["SN: B10001-UP"]
11	708-1S-15480	[1]	RETAINER Komatsu China
			["SN: B10001-UP"]
12	07000-11006	[1]	O-RING Komatsu	0.01 kg.
			["SN: B10001-UP"] analogs:["0700001006"]
13	708-1S-15490	[1]	PLUG Komatsu China
			["SN: B10001-UP"]
14	01582-11210	[1]	NUT Komatsu	0.015 kg.
			["SN: B10001-UP"]
15	708-1S-15270	[1]	LEVER Komatsu China
			["SN: B10001-UP"]
16	708-1S-15280	[1]	SPACER Komatsu China
			["SN: B10001-UP"]
17	07002-11623	[1]	O-RING Komatsu China	0.001 kg.
			["SN: B10001-UP"] analogs:["0700201623"]
18	723-56-31630	[1]	PLUG Komatsu	0.02 kg.
			["SN: B10001-UP"]
19	708-3S-15860	[1]	PLUG Komatsu China
			["SN: B10001-UP"]
	708-1W-03510	[1]	SPOOL SUB ASSEMBLY Komatsu China
			["SN: B10001-UP"] \|20.
20	708-1W-45610	[1]	SPOOL Komatsu China
			["SN: B10001-UP"]
21	708-1T-15560	[1]	PLUG Komatsu China
			["SN: B10001-UP"]
22	708-1T-15570	[1]	SPRING Komatsu China
			["SN: B10001-UP"]
23	708-1T-15580	[1]	BALL Komatsu China
			["SN: B10001-UP"]
24	708-1U-15640	[1]	PLUG Komatsu China
			["SN: B10001-UP"] analogs:["7081S15520"]
25	07002-11223	[2]	O-RING Komatsu China	0.001 kg.
			["SN: B10001-UP"] analogs:["0700201223"]
26	708-1S-15340	[1]	SPRING Komatsu China
			["SN: B10001-UP"]
27	708-1U-15630	[1]	SEAT Komatsu China
			["SN: B10001-UP"] analogs:["7081S15530"]
28	708-1S-15930	[1]	ORIFICE Komatsu China
			["SN: B10001-UP"]
