KOMATSU D51EX/PX-22 BULLDOZERS 720-2L-00020 720-2L-01020 HST PUMP ROTARY GROUP AND SPARE PARTS

Name: KOMATSU D51EX/PX-22 BULLDOZERS 720-2L-00020 720-2L-01020 HST PUMP ROTARY GROUP AND SPARE PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

KOMATSU D51EX/PX-22 BULLDOZERS 720-2L-00020 720-2L-01020 HST PUMP ROTARY GROUP AND SPARE PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

720-2L-00020 720-2L-01020 D51EX/PX-22

Pos.	Part No	Qty	Parts name	Comments
	720-2L-00020	[1]	PUMP ASSEMBLY, HST Komatsu China
			["SN: B10001-UP"] analogs:["7202L01020", "7202L11130", "R7202L00020"] \|1.
	720-2L-01020	[1]	PUMP SUB ASSEMBLY Komatsu China
			["SN: B10001-UP"] analogs:["7202L00020", "7202L11130"] \|1.
	720-2L-04140	[1]	CASE ASSEMBLY, FRONT Komatsu China
			["SN: B10001-UP"] \|1.
1	NSS	[1]	CASE, FRONT Komatsu China
			["SN: B10001-UP"]
3.	07040-12414	[1]	PLUG Komatsu	0.092 kg.
			["SN: B10001-UP"] analogs:["0704002412", "0704012412"]
4.	07002-62434	[1]	O-RING Komatsu	0.001 kg.
			["SN: B10001-UP"] analogs:["7081W28910"]
5.	720-1L-11131	[1]	PLATE Komatsu China
			["SN: B10001-UP"]
6.	07000-A2105	[1]	O-RING Komatsu	0.003 kg.
			["SN: B10001-UP"]
7.	07000-B3028	[1]	O-RING Komatsu	0.001 kg.
			["SN: B10001-UP"]
8.	01010-81025	[4]	BOLT Komatsu	0.36 kg.
			["SN: B10001-UP"] analogs:["0101051025", "0101651025", "801015109"]
9.	01643-31032	[4]	WASHER Komatsu	0.054 kg.
			["SN: B10001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
10.	720-1L-13420	[1]	CAM, ROCKER Komatsu China
			["SN: B10001-UP"]
11.	720-2L-13530	[2]	BEARING Komatsu China
			["SN: B10001-UP"]
12.	720-1L-13631	[2]	PLATE Komatsu China
			["SN: B10001-UP"]
13.	720-2M-13630	[2]	PIN Komatsu	0.01 kg.
			["SN: B10001-UP"]
14.	720-2M-13640	[2]	PIN Komatsu	0.001 kg.
			["SN: B10001-UP"]
15.	720-1L-14180	[1]	SLIDER Komatsu China
			["SN: B10001-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	720-2L-04160	[1]	CAP ASSEMBLY, END Komatsu China
			["SN: B10001-UP"] analogs:["7202L11520"] \|1.
1	NSS	[1]	CAP, END Komatsu China
			["SN: B10001-UP"]
3	720-2L-13510	[2]	BEARING Komatsu China
			["SN: B10001-UP"]
4	04020-01228	[2]	PIN, DOWEL Komatsu	0.026 kg.
			["SN: B10001-UP"] analogs:["21T3016190"]
5	07000-A5170	[2]	O-RING Komatsu China
			["SN: B10001-UP"]
6	01010-81660	[8]	BOLT Komatsu	0.127 kg.
			["SN: B10001-UP"] analogs:["0101061660", "0101031660"]
7	01643-51645	[8]	WASHER Komatsu	0.021 kg.
			["SN: B10001-UP"]
8	720-2M-11550	[1]	PLUG Komatsu China
			["SN: B10001-UP"]
9	07002-62034	[1]	O-RING Komatsu	0.94 kg.
			["SN: B10001-UP"]
10	720-2M-11531	[2]	PLUG Komatsu China
			["SN: B10001-UP"]
11	07002-61223	[2]	O-RING Komatsu	0.001 kg.
			["SN: B10001-UP"] analogs:["7082L23940"]
12	723-56-31630	[2]	PLUG Komatsu	0.02 kg.
			["SN: B10001-UP"]
13	07002-61623	[2]	O-RING Komatsu	0.001 kg.
			["SN: B10001-UP"]
14	07000-B2012	[4]	O-RING Komatsu China	0.001 kg.
			["SN: B10001-UP"]
15	720-2M-15270	[1]	PLUG Komatsu China
			["SN: B10001-UP"]
16	07002-62434	[1]	O-RING Komatsu	0.001 kg.
			["SN: B10001-UP"] analogs:["7081W28910"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
1	720-2L-12140	[1]	SHAFT, FRONT Komatsu China
			["SN: B10001-UP"]
2	708-2L-32150	[1]	BEARING Komatsu	0.6 kg.
			["SN: B10001-UP"] analogs:["7082E12152", "7082L22150", "7082512731"]
3	708-2E-05040	[1]	WASHER KIT Komatsu	0.101 kg.
			["SN: B10001-UP"] analogs:["7082E12190"]
4	708-25-12790	[1]	RING, SNAP Komatsu	0.006 kg.
			["SN: B10001-UP"]
5	720-1L-12220	[1]	COVER Komatsu China
			["SN: B10001-UP"]
6	708-25-52861	[1]	SEAL, OIL Komatsu China	0.078 kg.
			["SN: B10001-UP"] analogs:["7082552860", "7067340920"]
7	04065-09030	[1]	RING, SNAP Komatsu	0.03 kg.
			["SN: B10001-UP"] analogs:["2324013250", "R0406509030"]
8	07000-A2080	[1]	O-RING Komatsu	0.003 kg.
			["SN: B10001-UP"]
	720-2L-04330	[1]	CYLINDER BLOCK ASSEMBLY Komatsu China
			["SN: B10001-UP"] \|9.
9	708-2L-33190	[1]	BLOCK, CYLINDER Komatsu China
			["SN: B10001-UP"]
10	720-2L-13230	[1]	PLATE Komatsu China
			["SN: B10001-UP"]
11	720-68-19610	[1]	PIN Komatsu	0.002 kg.
			["SN: B10001-UP"]
12	04065-04818	[1]	RING, SNAP Komatsu OEM	0.007 kg.
			["SN: B10001-UP"]
13	708-2L-23131	[1]	SEAT Komatsu	0.073 kg.
			["SN: B10001-UP"]
14	708-2L-33160	[1]	SPRING Komatsu	0.12 kg.
			["SN: B10001-UP"] analogs:["7082L23151"]
15	708-7L-13140	[1]	SEAT Komatsu	0.02 kg.
			["SN: B10001-UP"]
16	708-2L-23351	[1]	GUIDE Komatsu OEM	0.14 kg.
			["SN: B10001-UP"]
17	708-2L-23360	[3]	PIN Komatsu	0.003 kg.
			["SN: B10001-UP"]
18	708-2L-33350	[1]	RETAINER Komatsu	0.3 kg.
			["SN: B10001-UP"]
19	720-1L-13310	[9]	PISTON SUB ASSEMBLY Komatsu China
			["SN: B10001-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	720-2L-03110	[1]	VALVE ASSEMBLY Komatsu China
			["SN: B10001-UP"] analogs:["7202L03130", "7202L14110"] \|1.
	720-2L-03130	[1]	PISTON ASSEMBLY Komatsu China
			["SN: B10001-UP"] analogs:["7202L03110", "7202L14110"] \|1.
1	720-2L-14110	[1]	PISTON, SERVO Komatsu China
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	720-2L-04150	[1]	CASE ASSEMBLY, REAR Komatsu China
			["SN: B10001-UP"] analogs:["7202L11140"] \|1.
1	NSS	[1]	CASE, REAR Komatsu China
			["SN: B10001-UP"]
3	07040-12414	[1]	PLUG Komatsu	0.092 kg.
			["SN: B10001-UP"] analogs:["0704002412", "0704012412"]
4	07002-62434	[1]	O-RING Komatsu	0.001 kg.
			["SN: B10001-UP"] analogs:["7081W28910"]
5	720-1L-11131	[1]	PLATE Komatsu China
			["SN: B10001-UP"]
6	07000-A2105	[1]	O-RING Komatsu	0.003 kg.
			["SN: B10001-UP"]
7	07000-B3028	[1]	O-RING Komatsu	0.001 kg.
			["SN: B10001-UP"]
8	01010-81025	[4]	BOLT Komatsu	0.36 kg.
			["SN: B10001-UP"] analogs:["0101051025", "0101651025", "801015109"]
9	01643-31032	[4]	WASHER Komatsu	0.054 kg.
			["SN: B10001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
10	720-1L-13420	[1]	CAM, ROCKER Komatsu China
			["SN: B10001-UP"]
11	720-2L-13530	[2]	BEARING Komatsu China
			["SN: B10001-UP"]
12	720-1L-13631	[2]	PLATE Komatsu China
			["SN: B10001-UP"]
13	720-2M-13630	[2]	PIN Komatsu	0.01 kg.
			["SN: B10001-UP"]
14	720-2M-13640	[2]	PIN Komatsu	0.001 kg.
			["SN: B10001-UP"]
15	720-1L-14180	[1]	SLIDER Komatsu China
			["SN: B10001-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
1	720-2L-12150	[1]	SHAFT, REAR Komatsu China
			["SN: B10001-UP"]
2	708-2L-32150	[1]	BEARING Komatsu	0.6 kg.
			["SN: B10001-UP"] analogs:["7082E12152", "7082L22150", "7082512731"]
3	708-2E-05040	[1]	WASHER KIT Komatsu	0.101 kg.
			["SN: B10001-UP"] analogs:["7082E12190"]
4	708-25-12790	[1]	RING, SNAP Komatsu	0.006 kg.
			["SN: B10001-UP"]
5	720-2L-14230	[1]	WASHER Komatsu China
			["SN: B10001-UP"]
6	04065-09030	[1]	RING, SNAP Komatsu	0.03 kg.
			["SN: B10001-UP"] analogs:["2324013250", "R0406509030"]
	720-2L-04340	[1]	BLOCK ASSEMBLY, CYLINDER Komatsu China
			["SN: B10001-UP"] \|7.
7	708-2L-33190	[1]	BLOCK, CYLINDER Komatsu China
			["SN: B10001-UP"]
8	720-2L-13240	[1]	PLATE Komatsu China
			["SN: B10001-UP"]
9	720-68-19610	[1]	PIN Komatsu	0.002 kg.
			["SN: B10001-UP"]
10	04065-04818	[1]	RING, SNAP Komatsu OEM	0.007 kg.
			["SN: B10001-UP"]
11	708-2L-23131	[1]	SEAT Komatsu	0.073 kg.
			["SN: B10001-UP"]
12	708-2L-33160	[1]	SPRING Komatsu	0.12 kg.
			["SN: B10001-UP"] analogs:["7082L23151"]
13	708-7L-13140	[1]	SEAT Komatsu	0.02 kg.
			["SN: B10001-UP"]
14	708-2L-23351	[1]	GUIDE Komatsu OEM	0.14 kg.
			["SN: B10001-UP"]
15	708-2L-23360	[3]	PIN Komatsu	0.003 kg.
			["SN: B10001-UP"]
16	708-2L-33350	[1]	RETAINER, SHOE Komatsu	0.3 kg.
			["SN: B10001-UP"]
17	720-1L-13310	[9]	PISTON SUB ASSEMBLY Komatsu China
			["SN: B10001-UP"]
