KOMATSU D51EX/PX-22 BULLDOZERS 706-8H-01110 706-8H-01111 HST MOTOR ROTARY GROUP AND SPARE PARTS

Name: KOMATSU D51EX/PX-22 BULLDOZERS 706-8H-01110 706-8H-01111 HST MOTOR ROTARY GROUP AND SPARE PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

KOMATSU D51EX/PX-22 BULLDOZERS 706-8H-01110 706-8H-01111 HST MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

706-8H-01110 706-8H-01111 D51EX/PX-22

Pos.	Part No	Qty	Parts name	Comments
	706-8H-01111	[1]	MOTOR ASSEMBLY Komatsu	190 kg.
			["SN: B12500-UP"] analogs:["7068H01110"] \|1.
	706-8H-01110	[1]	MOTOR ASSEMBLY Komatsu	190 kg.
			["SN: B10001-B12499"] analogs:["7068H01111"] \|1.
1.	706-8H-41311	[1]	CASE Komatsu China
			["SN: B12500-UP"]
	706-8H-41310	[1]	CASE Komatsu China
			["SN: B10001-B12499"] \|1.
	706-8H-04141	[1]	END COVER SUB ASSEMBLY Komatsu China
			["SN: B10001-UP"] analogs:["7068H04120", "7068H41360", "7068H41390", "7068H41320", "7068H53240", "7068H71111"] \|2.
2	NSS	[1]	COVER, END Komatsu China
			["SN: B10001-UP"]
8.	706-8H-53120	[2]	SPRING Komatsu China
			["SN: B10001-UP"]
9.	706-8H-53130	[2]	SEAT Komatsu China
			["SN: B10001-UP"]
10.	706-77-72170	[2]	PLUG Komatsu	0.115 kg.
			["SN: B10001-UP"]
11.	07002-62434	[2]	O-RING Komatsu	0.001 kg.
			["SN: B10001-UP"] analogs:["7081W28910"]
12.	706-86-71310	[1]	PIN, DOWEL Komatsu	0.022 kg.
			["SN: B10001-UP"]
13.	708-3D-15110	[2]	VALVE Komatsu China
			["SN: B10001-UP"]
14.	708-8E-16160	[2]	PLUG Komatsu	0.01 kg.
			["SN: B10001-UP"]
15.	07002-61023	[2]	O-RING Komatsu	0.22 kg.
			["SN: B10001-UP"] analogs:["7082L23920"]
16.	708-8H-11530	[2]	PLUG Komatsu	0.031 kg.
			["SN: B10001-UP"]
17.	07002-61423	[2]	O-RING Komatsu	0.001 kg.
			["SN: B10001-UP"] analogs:["7082L23950"]
18.	702-77-03500	[1]	VALVE, RELIEF Komatsu China
			["SN: B10001-UP"] analogs:["7068653430"]
20	706-86-53530	[1]	O-RING Komatsu	0.001 kg.
			["SN: B10001-UP"]
21.	706-8H-53230	[1]	ORIFICE Komatsu China
			["SN: B10001-UP"]
	706-8H-04110	[1]	COVER SUB ASSEMBLY Komatsu China
			["SN: B10001-UP"] \|22.
22	706-8H-51130	[1]	COVER Komatsu China
			["SN: B10001-UP"]
23	706-8H-51150	[2]	RING Komatsu China
			["SN: B10001-UP"]
24	706-8H-51120	[1]	SCREW Komatsu China
			["SN: B10001-UP"]
25	07000-B2014	[1]	O-RING Komatsu China	0.001 kg.
			["SN: B10001-UP"]
26	706-8H-51140	[1]	SLEEVE Komatsu China
			["SN: B10001-UP"]
27	07000-B2030	[1]	O-RING Komatsu China
			["SN: B10001-UP"]
28	07001-02030	[1]	RING Komatsu China
			["SN: B10001-UP"]
29	01583-12716	[1]	NUT Komatsu China
			["SN: B10001-UP"]
30	706-86-53230	[1]	SEAL Komatsu China
			["SN: B10001-UP"]
31	01582-11210	[1]	NUT Komatsu	0.015 kg.
			["SN: B10001-UP"]
32.	07000-B2055	[1]	O-RING Komatsu	0.003 kg.
			["SN: B10001-UP"]
33.	07000-B2012	[2]	O-RING Komatsu China	0.001 kg.
			["SN: B10001-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
1.	706-8H-04131	[1]	PISTON SUB ASSEMBLY Komatsu China
			["SN: B10001-UP"]
2.	01252-61445	[4]	BOLT Komatsu	0.081 kg.
			["SN: B10001-UP"] analogs:["7051903470", "7067540360"]
3.	706-8H-51110	[1]	COVER Komatsu China
			["SN: B10001-UP"]
4.	07000-B2055	[1]	O-RING Komatsu	0.003 kg.
			["SN: B10001-UP"]
6.	706-8H-53170	[1]	PIN Komatsu China
			["SN: B10001-UP"]
7.	706-8H-53180	[1]	SCREW Komatsu China
			["SN: B10001-UP"]
8.	07000-B1004	[1]	O-RING Komatsu China
			["SN: B10001-UP"]
9.	07001-01004	[1]	RING Komatsu China
			["SN: B10001-UP"] analogs:["890001685", "KB9571200400"]
10.	706-8H-53190	[1]	SPRING Komatsu China
			["SN: B10001-UP"]
11.	706-8H-53210	[1]	SEAT Komatsu China
			["SN: B10001-UP"]
12.	07000-A5260	[1]	O-RING Komatsu	0.02 kg.
			["SN: B10001-UP"]
13.	07000-B2014	[4]	O-RING Komatsu China	0.001 kg.
			["SN: B10001-UP"]
14.	01252-61850	[6]	BOLT Komatsu China
			["SN: B10001-UP"]
15.	706-8H-41340	[1]	SHAFT, DRIVE Komatsu China
			["SN: B10001-UP"]
16.	706-8H-41350	[1]	BEARING Komatsu China
			["SN: B10001-UP"]
17.	706-7H-41120	[1]	BEARING Komatsu China
			["SN: B10001-UP"]
18.	706-8H-41371	[1]	PLATE Komatsu China
			["SN: B12500-UP"]
	706-8H-41370	[1]	PLATE Komatsu China
			["SN: B10001-B12499"] \|18.
19.	706-7H-05911	[1]	SPACER KIT (17) Komatsu	0.192 kg.
			["SN: B12500-UP"] analogs:["7067H05910"]
	706-7H-05910	[1]	SPACER KIT (5) Komatsu	0.192 kg.
			["SN: B10001-B12499"] analogs:["7067H05911"] \|19.
19A.	706-8H-41870	[1]	RETAINER Komatsu China
			["SN: B12500-UP"]
19B.	706-8H-41810	[1]	SEAL Komatsu China
			["SN: B12500-UP"]
20.	04064-06020	[1]	RING Komatsu China	0.01 kg.
			["SN: B10001-UP"] analogs:["0406406020E", "YM22242000600", "R0406406020"]
21.	706-8H-41880	[1]	SEAL, OIL Komatsu China
			["SN: B12500-UP"]
	708-27-22811	[1]	SEAL, OIL Komatsu	0.101 kg.
			["SN: B10001-B12499"] analogs:["7082722810"] \|21.
22.	706-8H-41120	[1]	SHAFT, CENTER Komatsu China
			["SN: B10001-UP"]
23.	706-8H-41380	[1]	RING,CENTER Komatsu China
			["SN: B10001-UP"]
24.	706-7H-41740	[1]	SPRING Komatsu China
			["SN: B10001-UP"]
25.	706-8H-41260	[1]	RETAINER Komatsu China
			["SN: B10001-UP"]
26.	708-23-12350	[7]	SCREW Komatsu	0.008 kg.
			["SN: B10001-UP"]
27.	706-8H-41160	[7]	PISTON SUB ASSEMBLY Komatsu	0.34 kg.
			["SN: B10001-UP"]
28.	706-8H-91130	[1]	PLATE Komatsu China
			["SN: B10001-UP"]
29.	706-7K-91340	[4]	PLATE Komatsu	1 kg.
			["SN: B10001-UP"]
30.	706-8H-91120	[3]	DISC Komatsu China
			["SN: B10001-UP"]
31.	706-8H-91110	[1]	PISTON, BRAKE Komatsu China
			["SN: B10001-UP"]
32.	07000-B5240	[1]	O-RING Komatsu China
			["SN: B10001-UP"]
33.	706-86-90290	[1]	O-RING Komatsu	0.038 kg.
			["SN: B10001-UP"]
34.	706-8H-91140	[6]	SPRING Komatsu China
			["SN: B10001-UP"]
35.	706-8H-53220	[1]	PLATE Komatsu China
			["SN: B10001-UP"]
36.	01435-00825	[2]	BOLT Komatsu	0.016 kg.
			["SN: B10001-UP"]
37.	07000-B2040	[4]	O-RING Komatsu China
			["SN: B10001-UP"]
38.	729-11-21000	[1]	SENSOR, SPEED Komatsu China
			["SN: B10001-UP"] analogs:["7201L15430", "7291111170", "7291121140", "7291121120", "7291111110", "7291121130", "7291121160", "7291121110", "7291111160", "7291121100"]
39.	706-77-72170	[1]	PLUG Komatsu	0.115 kg.
			["SN: B10001-UP"]
40.	07002-62434	[1]	O-RING Komatsu	0.001 kg.
			["SN: B10001-UP"] analogs:["7081W28910"]
