| 708-1T-00552 708-1T-01552 D31EX-22 D31PX-22 D37EX-22 D37EX-23 D37PX-22 D37PX-23 D39EX-22 D39EX-23 D39PX-22 D39PX-23 |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-1T-00552
|
[1] |
Pump Assembly Komatsu China
|
|
|
["SN: 61149-UP"] |$0. |
|
|
708-1T-01552
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 61149-UP", "SCC: C2"] |$1. |
| |
708-1T-04151
|
[1] |
Case Assembly Komatsu China
|
|
|
["SN: 61149-UP", "SCC: C2"] |$2. |
| 5 |
708-3S-13480
|
[1] |
Cam, Rocker Komatsu
|
0.000 kg. |
|
["SN: 61149-UP", "SCC: C2"] |
| 6 |
04260-01270
|
[1] |
Ball Komatsu OEM
|
0.009 kg. |
|
["SN: 60001-UP", "SCC: C2"] |
| 7 |
708-3S-14141
|
[1] |
Spacer Komatsu
|
0.03 kg. |
|
["SN: 61149-UP", "SCC: C2"] analogs:["7083S14140"] |
| 8 |
708-1S-13420
|
[2] |
Pin Komatsu China
|
|
|
["SN: 60001-UP", "SCC: C2"] |
| 9 |
01252-60616
|
[1] |
Bolt, Hexagon Socket Head Komatsu
|
0.007 kg. |
|
["SN: 60001-UP", "SCC: C2"] analogs:["0125230616"] |
| 10 |
708-1T-33432
|
[1] |
Ball, Retainer Komatsu
|
0.000 kg. |
|
["SN: 61149-UP", "SCC: C2"] |
| 11 |
708-1T-33470
|
[1] |
Ball, Retainer Komatsu China
|
|
|
["SN: 61149-UP", "SCC: C2"] |
| 12 |
01252-61235
|
[2] |
Bolt, Hexagon Socket Head Komatsu
|
0.048 kg. |
|
["SN: 61149-UP", "SCC: C2"] analogs:["801105554", "0125231235"] |
| 13 |
01252-61255
|
[2] |
Bolt, Hexagon Socket Head Komatsu China
|
|
|
["SN: 61149-UP", "SCC: C2"] analogs:["0125201255", "0125211255", "0125241255", "0125231255", "7051702670"] |
| 14 |
04020-01024
|
[2] |
Pin, Dowel Komatsu
|
0.015 kg. |
|
["SN: 60001-UP", "SCC: C2"] analogs:["PZF890001197"] |
| 15 |
708-3T-11310
|
[1] |
Orifice Komatsu China
|
|
|
["SN: 61149-UP", "SCC: C2"] |
| |
708-1T-04561
|
[1] |
Cap Assembly Komatsu China
|
|
|
["SN: 61149-UP", "SCC: C2"] |$18. |
| 18 |
708-21-12760
|
[1] |
Bearing Komatsu
|
0.086 kg. |
|
["SN: 60001-UP", "SCC: C2"] |
| 19 |
720-68-19610
|
[1] |
Pin Komatsu
|
0.002 kg. |
|
["SN: 60001-UP", "SCC: C2"] |
| 20 |
07000-B1006
|
[1] |
O-ring Komatsu China
|
|
|
["SN: 61149-UP", "SCC: C2"] |
| 21 |
07000-B2130
|
[1] |
O-ring Komatsu
|
0.01 kg. |
|
["SN: 61149-UP", "SCC: C2"] |
| 22 |
708-2L-25480
|
[1] |
Filter Komatsu OEM
|
0.5 kg. |
|
["SN: 61149-UP", "SCC: C2"] |
| 23 |
708-2L-25490
|
[1] |
O-ring Komatsu
|
0.001 kg. |
|
["SN: 61149-UP", "SCC: C2"] |
| Parts on group : |
|
|
|
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-1T-00552
|
[1] |
Pump Assembly Komatsu China
|
|
|
["SN: 61149-UP"] |$0. |
|
|
708-1T-01552
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 61149-UP", "SCC: C2"] |$1. |
| 1 |
708-1T-12171
|
[1] |
Shaft Komatsu China
|
|
|
["SN: 60001-UP", "SCC: C2"] |
| 2 |
708-3S-12210
|
[1] |
Bearing Komatsu
|
0.4 kg. |
|
["SN: 60001-UP", "SCC: C2"] |
| 3 |
708-21-12840
|
[1] |
Ring, Snap Komatsu China
|
|
|
["SN: 60001-UP", "SCC: C2"] |
| 4 |
708-3S-12140
|
[1] |
Holder Komatsu
|
0.215 kg. |
|
["SN: 60001-UP", "SCC: C2"] |
| 5 |
708-1S-12350
|
[1] |
O-ring Komatsu
|
0.003 kg. |
|
["SN: 61149-UP", "SCC: C2"] |
| 5 |
207-09-11140
|
[1] |
O-ring Komatsu
|
0.002 kg. |
|
["SN: 60001-61148", "SCC: C2"] |
| 6 |
708-7T-12330
|
[1] |
Seal, Oil Komatsu
|
0.042 kg. |
|
["SN: 61149-UP", "SCC: C2"] |
| 6 |
708-3S-12150
|
[1] |
Seal, Oil Komatsu
|
0.02 kg. |
|
["SN: 60001-61148", "SCC: C2"] |
| 7 |
04065-06220
|
[1] |
Ring, Snap Komatsu
|
0.013 kg. |
|
["SN: 60001-UP", "SCC: C2"] |
| 8 |
708-1T-13440 |
[1] |
Cylinder Block Komatsu China
|
|
|
["SN: 61149-UP", "SCC: C2"] |
| 8 |
708-1T-13610 |
[1] |
Cylinder Block Komatsu China
|
|
|
["SN: 60001-61148", "SCC: C2"] |
| 9 |
708-1T-13450
|
[1] |
Plate, Valve Komatsu China
|
|
|
["SN: 61149-UP", "SCC: C2"] |
| 9 |
708-1T-13620
|
[1] |
Plate, Valve Komatsu China
|
|
|
["SN: 60001-61148", "SCC: C2"] |
| 10 |
708-1T-13710
|
[2] |
Spacer Komatsu China
|
|
|
["SN: 61149-UP", "SCC: C2"] |
| 10 |
708-3S-13160
|
[2] |
Washer Komatsu China
|
|
|
["SN: 60001-61148", "SCC: C2"] |
| 11 |
708-3S-13430
|
[1] |
Spring Komatsu
|
0.07 kg. |
|
["SN: 60001-UP", "SCC: C2"] |
| 12 |
04065-03515
|
[1] |
Ring, Snap Komatsu
|
0.003 kg. |
|
["SN: 60001-UP", "SCC: C2"] |
| 13 |
708-1S-13370
|
[1] |
Guide, Retainer Komatsu
|
0.045 kg. |
|
["SN: 61149-UP", "SCC: C2"] analogs:["7083S13370", "R7081S13370"] |
| |
708-3S-13370
|
[1] |
Guide, Retainer Komatsu
|
0.14 kg. |
|
["SN: 60001-61148", "SCC: C2"] analogs:["7081S13370"] |$20. |
| 14 |
708-1S-13380
|
[3] |
Pin Komatsu
|
0.06 kg. |
|
["SN: 60001-UP", "SCC: C2"] |
| 15 |
708-1T-13670 |
[1] |
Retainer, Shoe Komatsu China
|
|
|
["SN: 61149-UP", "SCC: C2"] |
| 15 |
708-3S-13410 |
[1] |
Retainer, Shoe Komatsu
|
0.24 kg. |
|
["SN: 60001-61148", "SCC: C2"] |
| 16 |
708-1S-13520 |
[10] |
Piston Subassembly Komatsu
|
0.09 kg. |
|
["SN: 60001-UP", "SCC: C2"] |
| 17 |
708-3S-14240
|
[1] |
Plug Komatsu China
|
|
|
["SN: 60001-UP", "SCC: C2"] |
| 18 |
708-3S-14261
|
[1] |
Plug Komatsu China
|
|
|
["SN: 60001-UP", "SCC: C2"] |
| 19 |
07002-11223
|
[2] |
O-ring Komatsu China
|
0.001 kg. |
|
["SN: 60001-UP", "SCC: C2"] analogs:["0700201223"] |
| 20 |
708-3S-14290
|
[1] |
Piston Subassembly Komatsu
|
0.087 kg. |
|
["SN: 61149-UP", "SCC: C2"] analogs:["7081S14230", "7083S14250"] |
| 20 |
708-3S-14250
|
[1] |
Piston Subassembly Komatsu
|
0.087 kg. |
|
["SN: 60001-61148", "SCC: C2"] analogs:["7081S14230"] |
| 21 |
708-1S-14241
|
[1] |
Spring Komatsu
|
0.01 kg. |
|
["SN: 60001-UP", "SCC: C2"] |
