| 708-1T-00551 708-1T-01551 D31EX-22 D31PX-22 D37EX-22 D37EX-22 D37PX-22 D39EX-22 D39PX-22 |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-1T-00551
|
[1] |
Pump Assembly Komatsu China
|
|
|
["SN: 60001-61148"] |$0. |
|
|
708-1T-01551
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 60001-61148", "SCC: C2"] |$1. |
| |
708-1T-04150
|
[1] |
Case Subassembly Komatsu
|
12.3 kg. |
|
["SN: 60001-61148", "SCC: C2"] |$2. |
| 4 |
708-1S-13411
|
[1] |
Cam Komatsu
|
1.2 kg. |
|
["SN: 60001-61148", "SCC: C2"] |
| 5 |
04260-01270
|
[1] |
Ball Komatsu OEM
|
0.009 kg. |
|
["SN: 60001-@", "SCC: C2"] |
| 6 |
708-3S-14140
|
[1] |
Spacer Komatsu
|
0.03 kg. |
|
["SN: 60001-61148", "SCC: C2"] |
| 7 |
708-1S-13420
|
[2] |
Pin Komatsu China
|
|
|
["SN: 60001-@", "SCC: C2"] |
| 8 |
01252-60616
|
[1] |
Bolt, Hexagon Socket Head Komatsu
|
0.007 kg. |
|
["SN: 60001-@", "SCC: C2"] analogs:["0125230616"] |
| 9 |
01252-61235
|
[4] |
Bolt, Hexagon Socket Head Komatsu
|
0.048 kg. |
|
["SN: 60001-61148", "SCC: C2"] analogs:["801105554", "0125231235"] |
| 10 |
04020-01024
|
[2] |
Pin, Dowel Komatsu
|
0.015 kg. |
|
["SN: 60001-@", "SCC: C2"] analogs:["PZF890001197"] |
| 11 |
07000-11006
|
[1] |
O-ring Komatsu
|
0.01 kg. |
|
["SN: 60001-61148", "SCC: C2"] analogs:["0700001006"] |
| 12 |
07000-12125
|
[1] |
O-ring Komatsu OEM
|
0.005 kg. |
|
["SN: 60001-61148", "SCC: C2"] analogs:["0700002125E", "0700002125"] |
| |
708-1T-04560
|
[1] |
Cap Subassembly Komatsu China
|
|
|
["SN: 60001-61148", "SCC: C2"] |$15. |
| 15 |
708-21-12760
|
[1] |
Bearing Komatsu
|
0.086 kg. |
|
["SN: 60001-@", "SCC: C2"] |
| 16 |
720-68-19610
|
[1] |
Pin Komatsu
|
0.002 kg. |
|
["SN: 60001-@", "SCC: C2"] |
| 17 |
708-1S-13430
|
[2] |
Ball, Retainer Komatsu China
|
|
|
["SN: 60001-61148", "SCC: C2"] |
