Komatsu D31 hydraulic pump rotary group

Komatsu D31 hydraulic pump rotary group

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
720-2M-00081 720-2M-01081 D31EX-22 D31PX-22 D37EX-22 D37EX-22
Pos. Part No Qty Parts name Comments
     720-2M-00081   [1]   Pump Assembly Komatsu 136.5 kg.
  ["SN: 60001-UP"] |$0.
        720-2M-01081   [1]   Pump Subassembly Komatsu China
  ["SN: 60001-UP"] |$1.
     720-2M-04210   [1]   Case Assembly, Front Komatsu 19.8 kg.
  ["SN: 60001-UP", "SCC: C2"] |$2.
3   720-2M-13412   [1]   Cam Komatsu 1.502 kg.
  ["SN: 60001-UP", "SCC: C2"]
4   720-2M-14280   [1]   Slider Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
5   720-2M-13611   [2]   Bearing Komatsu 0.12 kg.
  ["SN: 60001-UP", "SCC: C2"] analogs:["7202M13610"]
6   720-2M-13620   [2]   Plate Komatsu 0.001 kg.
  ["SN: 60001-UP", "SCC: C2"]
7   720-2M-13630   [2]   Pin Komatsu 0.01 kg.
  ["SN: 60001-UP", "SCC: C2"]
8   720-2M-13640   [2]   Pin Komatsu 0.001 kg.
  ["SN: 60001-UP", "SCC: C2"]
9   720-2M-11150   [1]   Plate Komatsu China
  ["SN: 60001-UP"]
10   07000-A2080   [1]   O-ring Komatsu 0.003 kg.
  ["SN: 60001-UP"]
11   07000-A3028   [1]   O-ring Komatsu 0.001 kg.
  ["SN: 60001-UP"]
12   01010-81025   [4]   Bolt Komatsu 0.36 kg.
  ["SN: 60001-UP"] analogs:["0101051025", "0101651025", "801015109"]
13   07040-12414   [1]   Plug Komatsu 0.092 kg.
  ["SN: 60001-UP"] analogs:["0704002412", "0704012412"]
14   07002-62434   [1]   O-ring Komatsu 0.001 kg.
  ["SN: 60001-UP"] analogs:["7081W28910"]
Pos. Part No Qty Parts name Comments
     720-2M-00081   [1]   Pump Assembly Komatsu 136.5 kg.
  ["SN: 60001-UP"] |$0.
        720-2M-01081   [1]   Pump Subassembly Komatsu China
  ["SN: 60001-UP"] |$1.
     720-2M-04250   [1]   Cap Assembly, End Komatsu China
  ["SN: 60001-UP", "SCC: C2"] |$2.
3   708-2M-12250   [2]   Bearing Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
4   720-2M-11520   [1]   Collar Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
5   04020-01228   [2]   Pin, Dowel Komatsu 0.026 kg.
  ["SN: 60001-UP", "SCC: C2"] analogs:["21T3016190"]
6   07000-A5150   [2]   O-ring Komatsu 0.79 kg.
  ["SN: 60001-UP", "SCC: C2"]
7   01010-81650   [8]   Bolt Komatsu China 0.113 kg.
  ["SN: 60001-UP", "SCC: C2"] analogs:["0101061650", "0101051650", "0101031650"]
8   01643-51645   [8]   Washer Komatsu 0.021 kg.
  ["SN: 60001-UP", "SCC: C2"]
9   720-2M-15270   [1]   Plug Komatsu China
  ["SN: 60001-UP"]
10   07002-62434   [1]   O-ring Komatsu 0.001 kg.
  ["SN: 60001-UP"] analogs:["7081W28910"]
11   720-2M-11531   [2]   Plug Komatsu China
  ["SN: 60001-UP"]
12   07002-61223   [2]   O-ring Komatsu 0.001 kg.
  ["SN: 60001-UP"] analogs:["7082L23940"]
13   07000-B2012   [2]   O-ring Komatsu China 0.001 kg.
  ["SN: 60001-UP", "SCC: C2"]
14   708-2M-12110   [1]   Shaft, Front Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
15   708-2M-12150   [1]   Bearing Komatsu 0.6 kg.
  ["SN: 60001-UP", "SCC: C2"]
16   708-2M-05110   [1]   Washer Kit Komatsu 0.24 kg.
  ["SN: 60001-UP", "SCC: C2"]
17   708-2M-12160   [1]   Ring, Snap Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
18   708-2M-12310   [1]   Seal, Oil Komatsu 0.07 kg.
  ["SN: 60001-UP"]
19   708-2M-12320   [1]   Cover Komatsu China
  ["SN: 60001-UP"]
20   07000-A2075   [1]   O-ring Komatsu 0.002 kg.
  ["SN: 60001-UP"]
21   04065-08225   [1]   Ring, Snap Komatsu 0.024 kg.
  ["SN: 60001-UP"]
Pos. Part No Qty Parts name Comments
     720-2M-00081   [1]   Pump Assembly Komatsu 136.5 kg.
  ["SN: 60001-UP"] |$0.
        720-2M-01081   [1]   Pump Subassembly Komatsu China
  ["SN: 60001-UP"] |$1.
     720-2M-04350   [1]   Block Assembly, Front Komatsu China
  ["SN: 60001-UP", "SCC: C2"] |$2.
3   720-68-19610   [1]   Pin Komatsu 0.002 kg.
  ["SN: 60001-UP", "SCC: C2"]
4   04065-04518   [1]   Ring, Snap Komatsu 0.006 kg.
  ["SN: 60001-UP", "SCC: C2"]
5   708-2M-13120   [1]   Seat Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
6   708-2M-13140   [1]   Spring Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
7   708-2M-13130   [1]   Seat Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
8   708-2M-13510   [1]   Guide, Retainer Komatsu 0.16 kg.
  ["SN: 60001-UP", "SCC: C2"]
9   708-7L-13360   [3]   Pin Komatsu 0.003 kg.
  ["SN: 60001-UP", "SCC: C2"]
10   708-2M-13340   [1]   Retainer, Shoe Komatsu 0.182 kg.
  ["SN: 60001-UP", "SCC: C2"]
11   708-2M-13311   [9]   Piston Subassembly Komatsu 0.142 kg.
  ["SN: 60001-UP", "SCC: C2"]
Pos. Part No Qty Parts name Comments
     720-2M-00081   [1]   Pump Assembly Komatsu 136.5 kg.
  ["SN: 60001-UP"] |$0.
        720-2M-01081   [1]   Pump Subassembly Komatsu China
  ["SN: 60001-UP"] |$1.
     720-2M-04240   [1]   Case Assembly, Rear Komatsu China
  ["SN: 60001-UP", "SCC: C2"] |$2.
3   720-2M-13412   [1]   Cam Komatsu 1.502 kg.
  ["SN: 60001-UP", "SCC: C2"]
4   720-2M-14280   [1]   Slider Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
5   720-2M-13611   [2]   Bearing Komatsu 0.12 kg.
  ["SN: 60001-UP", "SCC: C2"] analogs:["7202M13610"]
6   720-2M-13620   [2]   Plate Komatsu 0.001 kg.
  ["SN: 60001-UP", "SCC: C2"]
7   720-2M-13630   [2]   Pin Komatsu 0.01 kg.
  ["SN: 60001-UP", "SCC: C2"]
8   720-2M-13640   [2]   Pin Komatsu 0.001 kg.
  ["SN: 60001-UP", "SCC: C2"]
9   720-2M-11150   [1]   Plate Komatsu China
  ["SN: 60001-UP"]
10   07000-A2080   [1]   O-ring Komatsu 0.003 kg.
  ["SN: 60001-UP"]
11   07000-A3028   [1]   O-ring Komatsu 0.001 kg.
  ["SN: 60001-UP"]
12   01010-81025   [4]   Bolt Komatsu 0.36 kg.
  ["SN: 60001-UP"] analogs:["0101051025", "0101651025", "801015109"]
13   07040-12414   [1]   Plug Komatsu 0.092 kg.
  ["SN: 60001-UP"] analogs:["0704002412", "0704012412"]
14   07002-62434   [1]   O-ring Komatsu 0.001 kg.
  ["SN: 60001-UP"] analogs:["7081W28910"]
15   708-2M-12181   [1]   Shaft Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
16   708-2M-12150   [1]   Bearing Komatsu 0.6 kg.
  ["SN: 60001-UP", "SCC: C2"]
17   708-2M-05110   [1]   Washer Kit Komatsu 0.24 kg.
  ["SN: 60001-UP", "SCC: C2"]
18   708-2M-12160   [1]   Ring, Snap Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
19   720-2M-12511   [1]   Washer Komatsu China
  ["SN: 60001-UP"]
20   04065-08225   [1]   Ring, Snap Komatsu 0.024 kg.
  ["SN: 60001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     720-2M-00081   [1]   Pump Assembly Komatsu 136.5 kg.
  ["SN: 60001-UP"] |$0.
        720-2M-01081   [1]   Pump Subassembly Komatsu China
  ["SN: 60001-UP"] |$1.
     720-2M-04360   [1]   Block Assembly, Rear Komatsu China
  ["SN: 60001-UP", "SCC: C2"] |$2.
3   720-68-19610   [1]   Pin Komatsu 0.002 kg.
  ["SN: 60001-UP", "SCC: C2"]
4   04065-04518   [1]   Ring, Snap Komatsu 0.006 kg.
  ["SN: 60001-UP", "SCC: C2"]
5   708-2M-13120   [1]   Seat Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
6   708-2M-13140   [1]   Spring Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
7   708-2M-13130   [1]   Seat Komatsu China
  ["SN: 60001-UP", "SCC: C2"]
8   708-2M-13510   [1]   Guide, Retainer Komatsu 0.16 kg.
  ["SN: 60001-UP", "SCC: C2"]
9   708-7L-13360   [3]   Pin Komatsu 0.003 kg.
  ["SN: 60001-UP", "SCC: C2"]
10   708-2M-13340   [1]   Retainer, Shoe Komatsu 0.182 kg.
  ["SN: 60001-UP", "SCC: C2"]
11   708-2M-13311   [9]   Piston Subassembly Komatsu 0.142 kg.
  ["SN: 60001-UP", "SCC: C2"]
