KOMATSU D155AX-6 D155AX-6A D155AX-7 bulldozers 706-7H-01101 hydraulic motor rotary group and spare parts

KOMATSU D155AX-6 D155AX-6A D155AX-7 bulldozers 706-7H-01101 hydraulic motor rotary group and spare parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
  706-7H-01101  D155AX-6 D155AX-6A D155AX-7
Pos. Part No Qty Parts name Comments
     706-7H-01101   [1]   Motor Assembly Komatsu 81.8 kg.
  ["SN: 81028-UP"] |$0.
   1.   07000-15195   [1]   O-ring Komatsu China 0.038 kg.
  ["SN: 81028-UP", "SCC: C2"] analogs:["0700005195"]
   2.   708-18-13230   [2]   Pin Komatsu 0.01 kg.
  ["SN: 81028-UP", "SCC: C2"]
   3.   01010-61655   [4]   Bolt Komatsu 0.119 kg.
  ["SN: 81028-UP", "SCC: C2"] analogs:["801015613", "0101031655", "0101051655", "0101081655"]
   4.   01643-31645   [4]   Washer Komatsu 0.072 kg.
  ["SN: 81028-UP", "SCC: C2"] analogs:["802170005", "0164301645"]
   5.   706-7H-41110   [1]   Shaft Komatsu China
  ["SN: 81028-UP", "SCC: C2"]
   6.   706-8J-41010   [1]   Bearing Komatsu 8.22 kg.
  ["SN: 81028-UP", "SCC: C2"]
   7.   706-7H-41120   [1]   Bearing Komatsu China
  ["SN: 81028-UP", "SCC: C2"]
   8.   706-7H-41210   [1]   Spacer Komatsu China
  ["SN: 81028-UP", "SCC: C2"]
   9.   706-7H-05910   [1]   Spacer Kit Komatsu 0.192 kg.
  ["SN: 81028-UP", "SCC: C2"] analogs:["7067H05911"]
   10.   04064-06020   [1]   Ring, Snap Komatsu China 0.01 kg.
  ["SN: 81028-UP", "SCC: C2"] analogs:["0406406020E", "YM22242000600", "R0406406020"]
   11.   708-27-22811   [1]   Seal, Oil Komatsu 0.101 kg.
  ["SN: 81028-UP", "SCC: C2"] analogs:["7082722810"]
   12.   708-2H-22160   [1]   Spacer Komatsu 0.06 kg.
  ["SN: 81028-UP"]
   13.   04065-08225   [1]   Ring, Snap Komatsu 0.024 kg.
  ["SN: 81028-UP"]
        706-7H-05020   [1]   Block Assembly,Cylinder Komatsu China
  ["SN: 81028-UP", "SCC: C2"] |$19.
   16.   706-8H-41120   [1]   Shaft,Center Komatsu China
  ["SN: 81028-UP", "SCC: C2"]
   17.   706-7H-41730   [1]   Ring,Center Komatsu China
  ["SN: 81028-UP", "SCC: C2"]
   18.   706-7H-41740   [1]   Spring Komatsu China
  ["SN: 81028-UP", "SCC: C2"]
   19.   706-8H-41260   [1]   Retainer Komatsu China
  ["SN: 81028-UP", "SCC: C2"]
   20.   708-23-12350   [7]   Screw Komatsu 0.008 kg.
  ["SN: 81028-UP", "SCC: C2"]
   21.   706-8H-41160   [7]   Piston Subassembly Komatsu 0.34 kg.
  ["SN: 81028-UP", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-7H-01101   [1]   Motor Assembly Komatsu 81.8 kg.
  ["SN: 81028-UP"] |$0.
   1.   702-77-03110   [1]   Valve, Relief Komatsu China
