706-7H-01101 D155AX-6 D155AX-6A D155AX-7 |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
706-7H-01101
|
[1] |
Motor Assembly Komatsu
|
81.8 kg. |
|
["SN: 81028-UP"] |$0. |
|
1. |
07000-15195
|
[1] |
O-ring Komatsu China
|
0.038 kg. |
|
["SN: 81028-UP", "SCC: C2"] analogs:["0700005195"] |
|
2. |
708-18-13230
|
[2] |
Pin Komatsu
|
0.01 kg. |
|
["SN: 81028-UP", "SCC: C2"] |
|
3. |
01010-61655
|
[4] |
Bolt Komatsu
|
0.119 kg. |
|
["SN: 81028-UP", "SCC: C2"] analogs:["801015613", "0101031655", "0101051655", "0101081655"] |
|
4. |
01643-31645
|
[4] |
Washer Komatsu
|
0.072 kg. |
|
["SN: 81028-UP", "SCC: C2"] analogs:["802170005", "0164301645"] |
|
5. |
706-7H-41110
|
[1] |
Shaft Komatsu China
|
|
|
["SN: 81028-UP", "SCC: C2"] |
|
6. |
706-8J-41010
|
[1] |
Bearing Komatsu
|
8.22 kg. |
|
["SN: 81028-UP", "SCC: C2"] |
|
7. |
706-7H-41120
|
[1] |
Bearing Komatsu China
|
|
|
["SN: 81028-UP", "SCC: C2"] |
|
8. |
706-7H-41210
|
[1] |
Spacer Komatsu China
|
|
|
["SN: 81028-UP", "SCC: C2"] |
|
9. |
706-7H-05910
|
[1] |
Spacer Kit Komatsu
|
0.192 kg. |
|
["SN: 81028-UP", "SCC: C2"] analogs:["7067H05911"] |
|
10. |
04064-06020
|
[1] |
Ring, Snap Komatsu China
|
0.01 kg. |
|
["SN: 81028-UP", "SCC: C2"] analogs:["0406406020E", "YM22242000600", "R0406406020"] |
|
11. |
708-27-22811
|
[1] |
Seal, Oil Komatsu
|
0.101 kg. |
|
["SN: 81028-UP", "SCC: C2"] analogs:["7082722810"] |
|
12. |
708-2H-22160
|
[1] |
Spacer Komatsu
|
0.06 kg. |
|
["SN: 81028-UP"] |
|
13. |
04065-08225
|
[1] |
Ring, Snap Komatsu
|
0.024 kg. |
|
["SN: 81028-UP"] |
|
|
706-7H-05020
|
[1] |
Block Assembly,Cylinder Komatsu China
|
|
|
["SN: 81028-UP", "SCC: C2"] |$19. |
|
16. |
706-8H-41120
|
[1] |
Shaft,Center Komatsu China
|
|
|
["SN: 81028-UP", "SCC: C2"] |
|
17. |
706-7H-41730
|
[1] |
Ring,Center Komatsu China
|
|
|
["SN: 81028-UP", "SCC: C2"] |
|
18. |
706-7H-41740
|
[1] |
Spring Komatsu China
|
|
|
["SN: 81028-UP", "SCC: C2"] |
|
19. |
706-8H-41260
|
[1] |
Retainer Komatsu China
|
|
|
["SN: 81028-UP", "SCC: C2"] |
|
20. |
708-23-12350
|
[7] |
Screw Komatsu
|
0.008 kg. |
|
["SN: 81028-UP", "SCC: C2"] |
|
21. |
706-8H-41160
|
[7] |
Piston Subassembly Komatsu
|
0.34 kg. |
|
["SN: 81028-UP", "SCC: C2"] |
| Parts on group : |
|
|
|
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
706-7H-01101
|
[1] |
Motor Assembly Komatsu
|
81.8 kg. |
|
["SN: 81028-UP"] |$0. |
|
1. |
702-77-03110
|
[1] |
Valve, Relief Komatsu China
|
|
