KOMATSU D155A-6 D155A-6R D155AX-6 D155AX-6A bulldozers 708-1T-00470 708-1T-01470 fan pump rotary group

Name: KOMATSU D155A-6 D155A-6R D155AX-6 D155AX-6A bulldozers 708-1T-00470 708-1T-01470 fan pump rotary group
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

KOMATSU D155A-6 D155A-6R D155AX-6 D155AX-6A bulldozers 708-1T-00470 708-1T-01470 fan pump rotary group

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

708-1T-00470 708-1T-01470 D155A-6 D155A-6R D155AX-6 D155AX-6A

Pos.	Part No	Qty	Parts name	Comments
	708-1T-00470	[1]	Pump Assembly Komatsu	27.57 kg.
			["SN: 81028-UP"] \|$0.
	708-1T-01470	[1]	Pump Subassembly Komatsu	27.57 kg.
			["SN: 81028-UP", "SCC: C2"] analogs:["7081T00470"] \|$1.
	708-1T-04610	[1]	Case Subassembly Komatsu China
			["SN: 81028-UP", "SCC: C2"] \|$2.
4	708-1T-13580	[1]	Cam, Rocker Komatsu China
			["SN: 81028-UP", "SCC: C2"]
5	04260-01270	[1]	Ball Komatsu OEM	0.009 kg.
			["SN: 81028-UP", "SCC: C2"]
6	708-1T-14610	[1]	Spacer Komatsu China
			["SN: 81028-UP", "SCC: C2"]
7	708-1S-13420	[2]	Pin Komatsu China
			["SN: 81028-UP", "SCC: C2"]
8	01252-60616	[1]	Bolt, Hexagon Socket Head Komatsu	0.007 kg.
			["SN: 81028-UP", "SCC: C2"] analogs:["0125230616"]
9	708-1S-13430	[2]	Ball, Retainer Komatsu China
			["SN: 81028-UP", "SCC: C2"]
10	01252-61240	[4]	Bolt, Hexagon Socket Head Komatsu	0.053 kg.
			["SN: 81028-UP", "SCC: C2"] analogs:["0125231240"]
11	04020-01024	[2]	Pin, Dowel Komatsu	0.015 kg.
			["SN: 81028-UP", "SCC: C2"] analogs:["PZF890001197"]
12	708-2L-25490	[2]	O-ring Komatsu	0.001 kg.
			["SN: 81028-UP"]
13	708-2L-25480	[2]	Filter Komatsu OEM	0.5 kg.
			["SN: 81028-UP"]
14	708-1S-19710	[2]	Orifice Komatsu	0.002 kg.
			["SN: 81028-UP", "SCC: C2"]
15	708-1S-19920	[1]	Plate Komatsu China
			["SN: 81028-UP"]
16	07000-E2065	[1]	O-ring Komatsu	0.003 kg.
			["SN: 81028-UP"]
17	01010-81025	[4]	Bolt Komatsu	0.36 kg.
			["SN: 81028-UP"] analogs:["0101051025", "0101651025", "801015109"]
18	01643-31032	[4]	Washer Komatsu	0.054 kg.
			["SN: 81028-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
	708-1T-04620	[1]	Cap Subassembly Komatsu China
			["SN: 81028-UP", "SCC: C2"] \|$21.
21	720-68-19610	[1]	Pin Komatsu	0.002 kg.
			["SN: 81028-UP", "SCC: C2"]
22	07000-F1006	[2]	O-ring Komatsu	0.001 kg.
			["SN: 81028-UP", "SCC: C2"] analogs:["0700021006"]
23	07000-E2125	[1]	O-ring Komatsu	0.006 kg.
			["SN: 81028-UP", "SCC: C2"]
24	702-21-55620	[1]	Plug Komatsu	0.05 kg.
			["SN: 81028-UP"]
25	07040-11409	[1]	Plug Komatsu	0.033 kg.
			["SN: 81028-UP"]
26	07002-21423	[2]	O-ring Komatsu China	0.28 kg.
			["SN: 81028-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	708-1T-00470	[1]	Pump Assembly Komatsu	27.57 kg.
			["SN: 81028-UP"] \|$0.
	708-1T-01470	[1]	Pump Subassembly Komatsu	27.57 kg.
			["SN: 81028-UP", "SCC: C2"] analogs:["7081T00470"] \|$1.
1	708-1T-12410	[1]	Shaft Komatsu China
			["SN: 81028-UP", "SCC: C2"]
2	706-73-40890	[1]	Bearing Komatsu	0.26 kg.
			["SN: 81028-UP", "SCC: C2"] analogs:["7088E12141"]
3	708-1T-12420	[1]	Bearing Komatsu	0.26 kg.
			["SN: 81028-UP", "SCC: C2"]
4	708-7T-05010	[1]	Spacer Kit Komatsu	0.052 kg.
			["SN: 81028-UP", "SCC: C2"]
5	708-1S-12280	[1]	Ring, Wear Komatsu	0.001 kg.
			["SN: 81028-UP", "SCC: C2"]
6	708-1S-12330	[1]	Retainer Komatsu	0.01 kg.
			["SN: 81028-UP", "SCC: C2"]
7	708-1S-12340	[1]	Case Komatsu	0.18 kg.
			["SN: 81028-UP", "SCC: C2"]
8	708-21-12970	[1]	Seal, Oil Komatsu	0.046 kg.
			["SN: 81028-UP"]
9	708-1S-12350	[1]	O-ring Komatsu	0.003 kg.
			["SN: 81028-UP"]
10	04065-06220	[1]	Ring, Snap Komatsu	0.013 kg.
			["SN: 81028-UP"]
11	708-1T-13510	[1]	Block, Cylinder Komatsu	2.2 kg.
			["SN: 81028-UP", "SCC: C2"]
12	708-1T-13590	[1]	Plate, Valve Komatsu	0.8 kg.
			["SN: 81028-UP", "SCC: C2"]
13	708-3S-13160	[2]	Washer Komatsu China
			["SN: 81028-UP", "SCC: C2"]
14	708-3S-13150	[1]	Spring Komatsu	0.15 kg.
			["SN: 81028-UP", "SCC: C2"]
15	04065-03515	[1]	Ring, Snap Komatsu	0.003 kg.
			["SN: 81028-UP", "SCC: C2"]
16	708-1T-13540	[1]	Guide, Retainer Komatsu	0.05 kg.
			["SN: 81028-UP", "SCC: C2"]
17	708-1S-13380	[3]	Pin Komatsu	0.06 kg.
			["SN: 81028-UP", "SCC: C2"]
18	708-1T-13550	[1]	Retainer, Shoe Komatsu	0.2 kg.
			["SN: 81028-UP", "SCC: C2"]
19	708-1T-13310	[7]	Piston Subassembly Komatsu	0.12 kg.
			["SN: 81028-UP", "SCC: C2"]
20	708-1S-14210	[1]	Plug Komatsu China
			["SN: 81028-UP", "SCC: C2"]
21	708-1S-14220	[1]	Plug Komatsu China
			["SN: 81028-UP", "SCC: C2"]
22	07002-21223	[2]	O-ring Komatsu	0.25 kg.
			["SN: 81028-UP", "SCC: C2"]
23	708-1S-14230	[1]	Piston Subassembly Komatsu	0.087 kg.
			["SN: 81028-UP", "SCC: C2"] analogs:["7083S14250"]
24	708-1S-14241	[1]	Spring Komatsu	0.01 kg.
			["SN: 81028-UP", "SCC: C2"]
