20U-60-42111 TZ419D200000-F
BR100JG-2 PC45MR-1 PC45MRX-1 PC58UU-3 |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
20U-60-42111
|
[2] |
MOTOR ASS'Y Komatsu
|
65 kg. |
|
["SN: 20001-UP"] |$1. |
|
|
TZ419D400000-I
|
[1] |
CONTROL VALVE Komatsu China
|
|
|
["SN: 20001-UP"] |$3. |
| |
TZ419D410000-I
|
[1] |
FRANGE ASS'Y,REAR Komatsu China
|
|
|
["SN: 20001-UP"] |$4. |
| |
TZ419D410100-I
|
[1] |
FRANGE KIT,REAR Komatsu China
|
|
|
["SN: 20001-UP"] |$5. |
| 3 |
TZ312A2018-00
|
[1] |
SEAT,VALVE Komatsu China
|
|
|
["SN: 20001-UP"] |
| 4 |
TZ411D4019-01
|
[1] |
VALVE Komatsu China
|
|
|
["SN: 20001-UP"] |
| 5 |
TZ312A2020-00
|
[1] |
SPRING Komatsu China
|
|
|
["SN: 20001-UP"] |
| 6 |
TZGM1-4-K-S
|
[1] |
PLUG Komatsu China
|
|
|
["SN: 20001-UP"] |
| 7 |
TZ312A2022-00
|
[1] |
RING Komatsu China
|
|
|
["SN: 20001-UP"] |
| 8 |
TZ410D4024-00
|
[2] |
PLUG Komatsu China
|
|
|
["SN: 20001-UP"] |
| 9 |
TZ411D4025-00
|
[2] |
STOPPER Komatsu China
|
|
|
["SN: 20001-UP"] |
| 10 |
TZ300A2053-00
|
[2] |
PLUG Komatsu
|
0.04 kg. |
|
["SN: 20001-UP"] |
| 11 |
TZ300A2054-00
|
[2] |
VALVE Komatsu
|
0.011 kg. |
|
["SN: 20001-UP"] |
| 12 |
TZ410D4056-00
|
[2] |
SPRING Komatsu China
|
|
|
["SN: 20001-UP"] |
| 13 |
TZ300A2055-00
|
[2] |
SPRING Komatsu
|
0.005 kg. |
|
["SN: 20001-UP"] |
| 14 |
07000-11007
|
[1] |
O-RING (K1) Komatsu
|
0.001 kg. |
|
["SN: 20001-UP"] analogs:["YM24311000070", "0700001007"] |
| 15 |
TZJB2401-P22-9
|
[2] |
O-RING (K1) Komatsu
|
0.01 kg. |
|
["SN: 20001-UP"] |
| 16 |
07000-12012
|
[2] |
O-RING (K1) Komatsu China
|
0.001 kg. |
|
["SN: 20001-UP"] analogs:["0700002012", "7082E11790"] |
| 17 |
TZGM1-8-S
|
[4] |
PLUG Komatsu China
|
|
|
["SN: 20001-UP"] |
| 18 |
TZGDL1-16-S
|
[3] |
PLUG Komatsu China
|
|
|
["SN: 20001-UP"] |
| 19 |
TZ200B207300-A
|
[1] |
VALVE Komatsu China
|
|
|
["SN: 20001-UP"] |
| 20 |
TZ300B2039-00
|
[1] |
STOPPER Komatsu
|
0.011 kg. |
|
["SN: 20001-UP"] |
| 21 |
TZ300B2042-00
|
[1] |
RING Komatsu
|
0.002 kg. |
|
["SN: 20001-UP"] |
| 22 |
TZ300B2043-01
|
[1] |
SPRING Komatsu
|
0.017 kg. |
|
["SN: 20001-UP"] analogs:["TZ300B204300"] |
| 23 |
TZJB1501-3-16
|
[1] |
BALL Komatsu China
|
|
|
["SN: 20001-UP"] |
| 24 |
TZS0505
|
[3] |
ORIFICE Komatsu China
|
|
|
["SN: 20001-UP"] |
| 25 |
TZ263B2079-01
|
[2] |
FILTER Komatsu China
|
|
|
["SN: 20001-UP"] |
| 26 |
TZ571B2079-00
|
[1] |
PLUG Komatsu China
|
|
|
["SN: 20001-UP"] |
| 27 |
TZ850A0006-00
|
[1] |
PLATE, NAME Komatsu
|
0.01 kg. |
|
["SN: 20001-UP"] |
|
28. |
TZJB1354-4-10
|
[2] |
PIN Komatsu
|
0.01 kg. |
|
["SN: 20001-UP"] |
|
29. |
01252-30820
|
[6] |
BOLT Komatsu
|
0.015 kg. |
|
["SN: 20001-UP"] |
| Parts on group : |
|
|
|
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
20U-60-42111
|
[2] |
MOTOR ASS'Y Komatsu
|
65 kg. |
|
["SN: 20001-UP"] |$1. |
|
|
TZ419D200000-F
|
[1] |
HYDRAULIC MOTOR Komatsu China
|
|
|
["SN: 20001-UP"] |$3. |
| |
TZ419D2105-00
|
[1] |
PISTON KIT Komatsu China
|
|
|
["SN: 20001-UP"] |$4. |
| |
TZ410D2070-01
|
[1] |
PISTON ASS'Y Komatsu China
|
|
|
["SN: 20001-UP"] |$8. |
| 5 |
TZ410D2002-00
|
[1] |
SHAFT Komatsu China
|
|
|
["SN: 20001-UP"] |
| 6 |
TZ410D200300-F
|
[1] |
PLATE,SWASH Komatsu China
|
|
|
["SN: 20001-UP"] |
| 7 |
TZ510B2004-01 |
[1] |
BLOCK,CYLINDER Komatsu
|
0.7 kg. |
|
["SN: 20001-UP"] |
| 8 |
TZ310B2007-01
|
[1] |
PLATE,RETAINER Komatsu
|
0.036 kg. |
|
["SN: 20001-UP"] |
| 9 |
TZ310B2008-00
|
[1] |
BOWL,THRUST Komatsu
|
0.02 kg. |
|
["SN: 20001-UP"] |
| 10 |
TZ410D2009-00
|
[1] |
PLATE,TIMING Komatsu China
|
|
|
["SN: 20001-UP"] |
| 11 |
TZ310B2010-00
|
[2] |
WASHER Komatsu
|
0.01 kg. |
|
["SN: 20001-UP"] |
| 12 |
TZ410D2012-01
|
[1] |
PISTON Komatsu China
|
|
|
["SN: 20001-UP"] |
| 13 |
TZ410D2013-00
|
[8] |
SPRING Komatsu China
|
|
|
["SN: 20001-UP"] |
| 14 |
TZ510B2014-00
|
[1] |
SPRING Komatsu
|
0.044 kg. |
|
["SN: 20001-UP"] analogs:["TZ550A201401"] |
| 15 |
TZ571B2015-00
|
[2] |
PLATE Komatsu China
|
|
|
["SN: 20001-UP"] |
| 16 |
TZ550A2016-00
|
[2] |
PLATE Komatsu
|
0.033 kg. |
|
["SN: 20001-UP"] |
| 17 |
TZ15Z-17-35-8
|
[1] |
SEAL,OIL (K1) Komatsu
|
0.012 kg. |
|
["SN: 20001-UP"] analogs:["TZ01703508"] |
| 18 |
TZ571B2035-01
|
[1] |
O-RING (K1) Komatsu
|
0.01 kg. |
|
["SN: 20001-UP"] |
| 19 |
TZ410D2039-00
|
[1] |
O-RING (K1) Komatsu China
|
|
|
["SN: 20001-UP"] |
| 20 |
TZIRTW-32
|
[1] |
RING Komatsu
|
0.01 kg. |
|
["SN: 20001-UP"] |
| 21 |
TZ510B2029-00
|
[1] |
BEARING Komatsu
|
0.072 kg. |
|
["SN: 20001-UP"] |
| 22 |
06000-06201
|
[1] |
BEARING Komatsu
|
0.063 kg. |
|
["SN: 20001-UP"] |
| 23 |
TZJB15062-208F
|
[3] |
PIN Komatsu China
|
|
|
["SN: 20001-UP"] |
| 24 |
TZ534B2076-00
|
[2] |
PIVOT Komatsu
|
0.000 kg. |
|
["SN: 20001-UP"] |
| 25 |
TZ310B2074-00
|
[1] |
PLATE Komatsu
|
0.001 kg. |
|
["SN: 20001-UP"] |
| 26 |
TZ410D2077-00
|
[2] |
PIN Komatsu China
|
|
|
["SN: 20001-UP"] |
| 27 |
TZ410D2090-01
|
[1] |
SPRING Komatsu China
|
|
|
["SN: 20001-UP"] |
