KOMATSU 720-1L-00010  720-1L-01010  HST PUMP PARTS

KOMATSU 720-1L-00010  720-1L-01010  HST PUMP PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
720-1L-00010  720-1L-01010
Pos. Part No Qty Parts name Comments
     720-1L-00010   [1]   PUMP ASS'Y Komatsu 87 kg.
  ["SN: 70001-UP"] |1.
        720-1L-01010   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 70001-UP"] |1.
     720-1L-04150   [1]   CASE ASS'Y Komatsu China
  ["SN: 70001-UP"] |1.
3   07040-12414   [2]   PLUG Komatsu 0.092 kg.
  ["SN: 70001-UP"] analogs:["0704002412", "0704012412"]
4   07002-62434   [2]   O-RING Komatsu 0.001 kg.
  ["SN: 70001-UP"] analogs:["7081W28910"]
5   720-1L-11131   [1]   PLATE Komatsu China
  ["SN: 70001-UP"]
6   07000-A2105   [1]   O-RING Komatsu 0.003 kg.
  ["SN: 70001-UP"]
7   07000-B3028   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 70001-UP"]
8   01010-81025   [4]   BOLT Komatsu 0.36 kg.
  ["SN: 70001-UP"] analogs:["0101051025", "0101651025", "801015109"]
9   720-1L-14310   [2]   BUSHING Komatsu China
  ["SN: 70001-UP"]
10   720-1L-14320   [2]   RING,SNAP Komatsu China
  ["SN: 70001-UP"]
11 720-1L-13410 [1]   CAM,ROCKER Komatsu China
  ["SN: 70001-UP"]
12   720-1L-13620   [2]   BEARING Komatsu China
  ["SN: 70001-UP"]
13   720-1L-13631   [2]   PLATE Komatsu China
  ["SN: 70001-UP"]
14   720-2M-13630   [2]   PIN Komatsu 0.01 kg.
  ["SN: 70001-UP"]
15   720-2M-13640   [2]   PIN Komatsu 0.001 kg.
  ["SN: 70001-UP"]
16   720-1L-14180   [1]   SLIDER Komatsu China
  ["SN: 70001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     720-1L-00010   [1]   PUMP ASS'Y Komatsu 87 kg.
  ["SN: 70001-UP"] |1.
        720-1L-01010   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 70001-UP"] |1.
     720-1L-04160   [1]   CAP ASS'Y,END Komatsu China
  ["SN: 70001-UP"] |1.
3   708-2L-32260   [1]   BEARING Komatsu 0.2 kg.
  ["SN: 70001-UP"] analogs:["7082L22260"]
4   07000-A5170   [1]   O-RING Komatsu China
  ["SN: 70001-UP"]
5   07000-B2022   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 70001-UP"]
6   07000-B2012   [3]   O-RING Komatsu China 0.001 kg.
  ["SN: 70001-UP"]
7   04020-01228   [1]   PIN Komatsu 0.026 kg.
  ["SN: 70001-UP"] analogs:["21T3016190"]
8   01253-61620   [4]   BOLT Komatsu China
  ["SN: 70001-UP"]
9   708-8E-16150   [2]   PLUG Komatsu 0.02 kg.
  ["SN: 70001-UP"]
10   07002-61023   [2]   O-RING Komatsu 0.22 kg.
  ["SN: 70001-UP"] analogs:["7082L23920"]
11   720-1L-13710   [1]   SCREW Komatsu China
  ["SN: 70001-UP"]
12   07000-B2014   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 70001-UP"]
13   01583-11408   [1]   NUT Komatsu 0.4 kg.
  ["SN: 70001-UP"] analogs:["801713411"]
14   01643-31445   [1]   WASHER Komatsu 0.019 kg.
  ["SN: 70001-UP"] analogs:["0164301432"]
15 720-1L-12120 [1]   SHAFT Komatsu China
  ["SN: 70001-UP"]
16   708-2L-32150   [1]   BEARING Komatsu 0.6 kg.
  ["SN: 70001-UP"] analogs:["7082E12152", "7082L22150", "7082512731"]
17   708-2E-05040   [1]   WASHER KIT Komatsu 0.101 kg.
  ["SN: 70001-UP"] analogs:["7082E12190"]
18   708-25-12790   [1]   RING,SNAP Komatsu 0.006 kg.
  ["SN: 70001-UP"]
19   720-1L-12220   [1]   COVER Komatsu China
  ["SN: 70001-UP"]
20   708-25-52861   [1]   SEAL,OIL Komatsu China 0.078 kg.
  ["SN: 70001-UP"] analogs:["7082552860", "7067340920"]
21   04065-09030   [1]   RING,SNAP Komatsu 0.03 kg.
  ["SN: 70001-UP"] analogs:["2324013250", "R0406509030"]
22   07000-A2080   [1]   O-RING Komatsu 0.003 kg.
  ["SN: 70001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     720-1L-00010   [1]   PUMP ASS'Y Komatsu 87 kg.
  ["SN: 70001-UP"] |1.
        720-1L-01010   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 70001-UP"] |1.
   720-1L-04131 [1]   BLOCK ASS'Y,FRONT Komatsu China
  ["SN: 70001-UP"] |1.
3   720-68-19610   [1]   PIN Komatsu 0.002 kg.
  ["SN: 70001-UP"]
4   04065-04818   [1]   RING Komatsu OEM 0.007 kg.
  ["SN: 70001-UP"]
5   708-2L-23131   [1]   SEAT Komatsu 0.073 kg.
  ["SN: 70001-UP"]
6   708-2L-33160   [1]   SPRING Komatsu 0.12 kg.
  ["SN: 70001-UP"] analogs:["7082L23151"]
7   708-7L-13140   [1]   SEAT Komatsu 0.02 kg.
  ["SN: 70001-UP"]
8 708-2L-23351 [1]   GUIDE,RETAINER Komatsu OEM 0.14 kg.
  ["SN: 70001-UP"]
9 708-2L-23360 [3]   PIN Komatsu 0.003 kg.
  ["SN: 70001-UP"]
10 708-2L-33360 [1]   RETAINER,SHOE Komatsu 0.5 kg.
  ["SN: 70001-UP"]
11 720-1L-13310 [9]   PISTON SUB ASS'Y Komatsu China
  ["SN: 70001-UP"]
   720-1L-03111 [1]   PISTON ASS'Y Komatsu China
  ["SN: 70001-UP"] |12.
12   720-1L-14110   [1]   PISTON Komatsu China
  ["SN: 70001-UP"]
13   720-1L-14140   [2]   ROD Komatsu China
  ["SN: 70001-UP"]
14   07000-B1010   [2]   O-RING Komatsu 0.001 kg.
  ["SN: 70001-UP"]
15   720-1L-14170   [2]   RETAINER Komatsu China
  ["SN: 70001-UP"]
16   720-1L-14210   [2]   SPRING Komatsu China
  ["SN: 70001-UP"]
17   720-1L-14220   [2]   SPRING Komatsu China
  ["SN: 70001-UP"]
18   720-1L-14160   [2]   RETAINER Komatsu China
  ["SN: 70001-UP"]
19   720-1L-14190   [2]   RING,SNAP Komatsu China
  ["SN: 70001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     720-1L-00010   [1]   PUMP ASS'Y Komatsu 87 kg.
  ["SN: 70001-UP"] |1.
        720-1L-01010   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 70001-UP"] |1.
1   720-1L-12510   [1]   COUPLING Komatsu China
  ["SN: 70001-UP"]
2   04065-02812   [1]   RING Komatsu 0.005 kg.
  ["SN: 70001-UP"]
     720-2T-03611   [1]   ROTOR ASS'Y Komatsu China
  ["SN: 70001-UP"] analogs:["7202T03610"] |3.
5   720-1L-15610   [1]   RING,OUTER Komatsu China
  ["SN: 70001-UP"]
6   720-2M-15540   [1]   PLATE Komatsu China
  ["SN: 70001-UP"]
7   01252-60635   [6]   BOLT Komatsu 0.011 kg.
  ["SN: 70001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     720-1L-00010   [1]   PUMP ASS'Y Komatsu 87 kg.
  ["SN: 70001-UP"] |1.
        720-1L-03530   [2]   VALVE ASS'Y,RELIEF Komatsu China
  ["SN: 70001-UP"] analogs:["7201L03534", "7201L03532", "7201L03533"] |1.
1   720-2M-15210   [1]   SLEEVE Komatsu China
  ["SN: 70001-UP"]
2   720-2M-15220   [1]   VALVE Komatsu China
  ["SN: 70001-UP"]
3   720-2M-15230   [1]   SPRING Komatsu China
  ["SN: 70001-UP"]
4   723-46-48910   [1]   SEAL Komatsu China
  ["SN: 70001-UP"]
5   720-2M-15240   [1]   SCREW Komatsu China
  ["SN: 70001-UP"]
6   702-72-11170   [1]   NUT Komatsu China
  ["SN: 70001-UP"]
   7.   720-2M-15250   [2]   SPRING Komatsu China
  ["SN: 70001-UP"]
   8.   720-2M-15270   [2]   PLUG Komatsu China
  ["SN: 70001-UP"]
   9.   07002-62434   [2]   O-RING Komatsu 0.001 kg.
  ["SN: 70001-UP"] analogs:["7081W28910"]
Parts on group :
Pos. Part No Qty Parts name Comments
     720-1L-00010   [1]   PUMP ASS'Y Komatsu 87 kg.
  ["SN: 70001-UP"] |1.
        720-1L-03521   [1]   VALVE ASS'Y,CO Komatsu China
  ["SN: 70001-UP"] analogs:["7201L03520"] |1.
1   720-1L-15210   [1]   SLEEVE Komatsu China
  ["SN: 70001-UP"]
2   708-2L-24680   [3]   SEAL Komatsu 0.003 kg.
  ["SN: 70001-UP"]
3   07002-62434   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 70001-UP"] analogs:["7081W28910"]
4   720-1L-15220   [1]   SPOOL Komatsu China
  ["SN: 70001-UP"]
5   720-1L-15270   [1]   SEAT Komatsu China
  ["SN: 70001-UP"]
6   720-1L-15280   [1]   SPRING Komatsu China
  ["SN: 70001-UP"]
7   720-1L-15230   [1]   SCREW Komatsu China
  ["SN: 70001-UP"]
8   07002-62034   [1]   O-RING Komatsu 0.94 kg.
  ["SN: 70001-UP"]
9   01583-11610   [1]   NUT Komatsu 0.028 kg.
  ["SN: 70001-UP"] analogs:["0158301610"]
10   07000-A1010   [1]   O-RING Komatsu China
  ["SN: 70001-UP"]
11   720-1L-15240   [1]   SLEEVE Komatsu China
  ["SN: 70001-UP"]
12   720-1L-15251   [1]   PISTON Komatsu China
  ["SN: 70001-UP"]
13   720-1L-15261   [1]   SEAT Komatsu China
  ["SN: 70001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     720-1L-00010   [1]   PUMP ASS'Y Komatsu 87 kg.
  ["SN: 70001-UP"] |1.
        720-2M-03551   [1]   VALVE ASS'Y,SHUTTLE Komatsu 0.06 kg.
  ["SN: 70001-UP"] |1.
1   07002-61423   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 70001-UP"] analogs:["7082L23950"]
2   720-2M-15412   [1]   SLEEVE Komatsu China
  ["SN: 70001-UP"]
3   720-2M-15421   [1]   HOLDER Komatsu China
  ["SN: 70001-UP"]
4   720-2M-15430   [1]   SEAL Komatsu China
  ["SN: 70001-UP"]
5   700-84-11730   [1]   BALL Komatsu 0.01 kg.
  ["SN: 70001-UP"]
6   720-2M-15440   [1]   SEAL Komatsu China
  ["SN: 70001-UP"]
        720-2T-03311   [1]   VALVE ASS'Y,RELIEF Komatsu China
  ["SN: 70001-UP"] |7.
7   706-86-53511   [1]   SLEEVE Komatsu China
  ["SN: 70001-UP"]
8   706-86-53520   [1]   SLEEVE Komatsu China
  ["SN: 70001-UP"]
9   708-1H-24640   [1]   SPRING Komatsu China
  ["SN: 70001-UP"]
10   720-2M-16310   [1]   VALVE Komatsu China
  ["SN: 70001-UP"]
11   708-1H-24620   [1]   RETAINER Komatsu China
  ["SN: 70001-UP"]
12   700-80-61190   [1]   POPPET Komatsu China
  ["SN: 70001-UP"]
13   708-1H-24650   [1]   SPRING Komatsu China
  ["SN: 70001-UP"]
14   709-10-51560   [1]   SCREW Komatsu China
  ["SN: 70001-UP"]
15   07000-B2011   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 70001-UP"]
16   01582-11411   [1]   NUT Komatsu 0.022 kg.
  ["SN: 70001-UP"] analogs:["0158201411"]
17   07002-62434   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 70001-UP"] analogs:["7081W28910"]
18   706-86-53530   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 70001-UP"]
19   702-21-55760   [1]   FILTER Komatsu China
  ["SN: 70001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     720-1L-00010   [1]   PUMP ASS'Y Komatsu 87 kg.
  ["SN: 70001-UP"] |1.
        720-1L-03561   [1]   VALVE ASS'Y Komatsu China
  ["SN: 70001-UP"] analogs:["7201L03565"] |1.
     720-1L-03571   [1]   SLEEVE ASS'Y Komatsu China
  ["SN: 70001-UP"] analogs:["7201L03574"] |1.
1   720-2M-15731   [1]   PLUG Komatsu China
  ["SN: 70001-UP"]
2   720-1L-15511   [1]   SLEEVE Komatsu China
  ["SN: 70001-UP"]
3   720-2M-15840   [1]   RING Komatsu China
  ["SN: 70001-UP"]
4   720-1L-15540   [1]   ORIFICE Komatsu China
  ["SN: 70001-UP"] analogs:["7201L15560"]
5   720-1L-15520   [1]   VALVE Komatsu China
  ["SN: 70001-UP"]
6   720-1L-15530   [1]   SPRING Komatsu China
  ["SN: 70001-UP"]
7   720-2M-15760   [1]   SPRING Komatsu China
  ["SN: 70001-UP"]
8   720-2M-15772   [1]   PLUG Komatsu China
  ["SN: 70001-UP"]
9   01310-20825   [1]   SCREW Komatsu China
  ["SN: 70001-UP"]
10   720-2M-15790   [1]   PISTON Komatsu China
  ["SN: 70001-UP"]
11   720-2M-15810   [1]   O-RING Komatsu China
  ["SN: 70001-UP"]
12   720-2M-15820   [1]   O-RING Komatsu China
  ["SN: 70001-UP"]
13   720-2M-15830   [1]   O-RING Komatsu China
  ["SN: 70001-UP"]
14   07002-63334   [1]   O-RING Komatsu 1.46 kg.
  ["SN: 70001-UP"]
15   07000-A1006   [1]   O-RING Komatsu China
  ["SN: 70001-UP"]
16   07000-A3024   [1]   O-RING Komatsu 0.005 kg.
  ["SN: 70001-UP"]
17   01580-10806   [1]   NUT Komatsu 0.005 kg.
  ["SN: 70001-UP"] analogs:["801920104"]
18   720-2M-15860   [1]   PIN Komatsu China
  ["SN: 70001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     720-1L-00010   [1]    PUMP ASS'Y Komatsu 87 kg.
  ["SN: 70001-UP"] |1.
   1.   720-1L-03451   [1]   VALVE ASS'Y Komatsu China
  ["SN: 70001-UP"]
   2.   07000-B1009   [2]    O-RING Komatsu China 0.001 kg.
  ["SN: 70001-UP"] analogs:["7082L23910"]
   3.   700-22-11410   [3]   O-RING Komatsu OEM 0.001 kg.
  ["SN: 70001-UP"]
   4.   01252-60625   [4]   BOLT Komatsu China
  ["SN: 70001-UP"] analogs:["890001423", "890001607", "KB9260106251", "0125200625", "0125210625", "0125230625"]
   5.   720-1L-03550   [1]   SOLENOID VALVE Komatsu China
  ["SN: 70001-UP"] analogs:["7201L03551"]
   6.   01252-60635   [2]   BOLT Komatsu 0.011 kg.
  ["SN: 70001-UP"]

Materials

Shipping & Returns

Dimensions

Care Instructions

查看完整資訊

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Kawasaki Best Selling Series

檢視全部

Komatsu Best Selling Series

檢視全部

Caterpillar Best Selling Series

檢視全部
