KOMATSU 708-7S-00280 708-7S-01270 21W-26-51011 SWING MOTOR ROTARY GROUP AND SPARE PARTS

KOMATSU 708-7S-00280 708-7S-01270 21W-26-51011 SWING MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
708-7S-00280 708-7S-01270 21W-26-51011
PC78US-8 PC78UU-8 PC80MR-3 PW98MR-6
Pos. Part No Qty Parts name Comments
     21W-26-51011   [1]   Swing Machinery Assembly Komatsu China
  ["SN: 15001-15833"] |$0.
        708-7S-00280   [1]   Motor Assembly Komatsu China
  ["SN: 15001-15833"] |$1.
     708-7S-01270   [1]   Motor Subassembly Komatsu China
  ["SN: 15001-15833"] |$2.
1 708-7S-13610 [1]   Plate, Swash Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
2   708-7S-21511   [1]   Housing Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
3   706-73-71450   [1]   Plug Komatsu 0.035 kg.
  ["SN: 15001-15833"]
4   07002-11423   [1]   O-ring Komatsu China 0.001 kg.
  ["SN: 15001-15833"] analogs:["0700201423"]
5   709-25-11650   [2]   Valve, Check Komatsu 0.02 kg.
  ["SN: 15001-15833"]
6   700-80-63230   [2]   Spring Komatsu China
  ["SN: 15001-15833"]
7   708-7S-21610   [2]   Plug Komatsu China
  ["SN: 15001-15833"]
8   07002-12434   [2]   O-ring Komatsu China 0.01 kg.
  ["SN: 15001-15833"] analogs:["0700202434", "0700213434"]
     706-73-72710   [2]   Valve Subassembly Komatsu China
  ["SN: 15001-15833"] |$11.
9   706-73-72720   [1]   Valve Komatsu China
  ["SN: 15001-15833"]
10   706-73-72730   [1]   Poppet Komatsu China
  ["SN: 15001-15833"]
11   706-73-72740   [1]   Plug Komatsu China
  ["SN: 15001-15833"]
12   706-73-72440   [2]   Spring Komatsu China
  ["SN: 15001-15833"]
13   708-7S-21620   [2]   Plug Komatsu China
  ["SN: 15001-15833"]
15   07000-12145   [1]   O-ring Komatsu China 0.03 kg.
  ["SN: 15001-15833", "SCC: C2"] analogs:["0700002145", "R0700012145"]
16   720-68-19610   [2]   Pin Komatsu 0.002 kg.
  ["SN: 15001-15833", "SCC: C2"]
17   01252-61245   [8]   Bolt, Hexagon Socket Head Komatsu 0.057 kg.
  ["SN: 15001-15833", "SCC: C2"] analogs:["0125241245"]
18   708-7S-22110   [1]   Shaft Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
19   708-7S-22140   [1]   Bearing Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
20   708-7S-22150   [1]   Bearing Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
21   708-7T-12230   [1]   Seal, Oil Komatsu 0.04 kg.
  ["SN: 15001-15833"]
22   708-7S-22310   [1]   Cover Komatsu China
  ["SN: 15001-15833"]
23   07000-12055   [1]   O-ring Komatsu China 0.03 kg.
  ["SN: 15001-15833"] analogs:["0700002055"]
24   04065-06020   [1]   Ring, Snap Komatsu 0.011 kg.
  ["SN: 15001-15833"]
25 708-7S-23111 [1]   Cylinder Block Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
26 708-7S-23210 [1]   Plate Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
28   708-2L-23360   [3]   Pin Komatsu 0.003 kg.
  ["SN: 15001-15833", "SCC: C2"]
29   708-7S-13530   [2]   Spacer Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
30   708-7S-23510   [1]   Spring Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
31   04065-03212   [1]   Ring, Snap Komatsu 0.002 kg.
  ["SN: 15001-15833", "SCC: C2"] analogs:["4174317180"]
32   708-1S-13350   [1]   Retainer, Guide Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
33   708-1S-13340   [1]   Retainer Komatsu 0.11 kg.
  ["SN: 15001-15833", "SCC: C2"]
34   708-7S-23310   [7]   Piston Subassembly Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
35   708-7S-23410   [1]   Plate Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
36   708-7S-25130   [4]   Plate Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
37   708-7S-25120   [3]   Disc Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
38   708-7S-25140   [1]   Piston, Brake Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
39   07000-12130   [1]   O-ring Komatsu OEM 0.004 kg.
  ["SN: 15001-15833", "SCC: C2"] analogs:["0700002130E", "0700002130", "0700012030", "R0700012130"]
40   07000-12120   [1]   O-ring Komatsu 0.004 kg.
  ["SN: 15001-15833", "SCC: C2"] analogs:["0700002120"]
41   708-7S-25150   [4]   Spring Komatsu China
  ["SN: 15001-15833", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     21W-26-51011   [1]   Swing Machinery Assembly Komatsu China
  ["SN: 15001-15833"] |$0.
        708-7S-00280   [1]   Motor Assembly Komatsu China
  ["SN: 15001-15833"] |$1.
1   702-73-04350   [1]   Valve, Relief Komatsu China
  ["SN: 15001-15833"]
2   07000-12016   [1]   O-ring Komatsu 0.001 kg.
  ["SN: 15001-15833"] analogs:["YM24311000160", "0700002016"]
3   723-60-22230   [1]   Ring, Back-up Komatsu 0.001 kg.
  ["SN: 15001-15833"]
4   07002-12434   [1]   O-ring Komatsu China 0.01 kg.
  ["SN: 15001-15833"] analogs:["0700202434", "0700213434"]
Parts on group :
Pos. Part No Qty Parts name Comments
     21W-26-51011   [1]   Swing Machinery Assembly Komatsu China
  ["SN: 15001-15833"] |$0.
        708-7S-00280   [1]   Motor Assembly Komatsu China
  ["SN: 15001-15833"] |$1.
     702-15-73000   [1]   Valve Assembly Komatsu China
  ["SN: 15001-15833"] |$2.
7   07000-03042   [1]   O-ring Komatsu China 0.01 kg.
  ["SN: 15001-15833"] analogs:["0700013042"]
8   07000-11007   [2]   O-ring Komatsu 0.001 kg.
  ["SN: 15001-15833"] analogs:["YM24311000070", "0700001007"]
9   01252-60825   [2]   Bolt, Hexagon Socket Head Komatsu 0.017 kg.
  ["SN: 15001-15833"] analogs:["0125240825", "0125230825"]
Parts on group :
Pos. Part No Qty Parts name Comments
     21W-26-51011   [1]   Swing Machinery Assembly Komatsu China
  ["SN: 15001-15833"] |$0.
   1.   708-8F-31610   [1]   O-ring Komatsu OEM 0.006 kg.
  ["SN: 15001-15833"]
   2.   21W-26-41320   [1]   Ring Komatsu China
  ["SN: 15001-15833"]
   3.   01011-81010   [12]   Bolt Komatsu 0.078 kg.
  ["SN: 15001-15833"] analogs:["0101151010"]
   4.   01643-31032   [12]   Washer Komatsu 0.054 kg.
  ["SN: 15001-15833"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
   5.   708-8E-16150   [1]   Plug Komatsu 0.02 kg.
  ["SN: 15001-15833"]
   6.   07002-11023   [1]   O-ring Komatsu China 0.025 kg.
  ["SN: 15001-15833"] analogs:["0700201023"]
   7.   07049-01012   [2]   Plug Komatsu 0.001 kg.
  ["SN: 15001-15833"]
   8.   21W-26-51210   [1]   Filler Komatsu China
  ["SN: 15001-15833"]
   9.   21W-26-51480   [1]   Gauge Komatsu China
  ["SN: 15001-15833"]
   10.   02782-10423   [1]   Elbow Komatsu 0.23 kg.
  ["SN: 15001-15833"]
   11.   07002-12034   [1]   O-ring Komatsu China 0.94 kg.
  ["SN: 15001-15833"] analogs:["0700002034", "0700202034", "0700012034"]
   12.   02896-11012   [1]   O-ring Komatsu China 0.17 kg.
  ["SN: 15001-15833"] analogs:["855051014"]
   13.   02783-10422   [1]   Elbow Komatsu 0.138 kg.
  ["SN: 15001-15833"]
   14.   124-49-51430   [1]   Joint Komatsu China
  ["SN: 15001-15833"]
   17.   02783-10315   [1]   Elbow Komatsu 0.12 kg.
  ["SN: 15001-15833"]
   19.   02896-11009   [1]   O-ring Komatsu China 0.01 kg.
  ["SN: 15001-15833"] analogs:["R0289611009", "0286911009"]
   20.   02782-10210   [1]   Elbow Komatsu 0.08 kg.
  ["SN: 15001-15833"]
   21.   07002-11423   [1]   O-ring Komatsu China 0.001 kg.
  ["SN: 15001-15833"] analogs:["0700201423"]
   22.   02896-11008   [1]   O-ring Komatsu China 0.12 kg.
  ["SN: 15001-15833"]
   23.   02782-10522   [1]   Elbow Komatsu 0.4 kg.
  ["SN: 15001-15833"]
   24.   07002-12434   [1]   O-ring Komatsu China 0.01 kg.
  ["SN: 15001-15833"] analogs:["0700202434", "0700213434"]
   25.   02896-11015   [1]   O-ring Komatsu 0.21 kg.
  ["SN: 15001-15833"] analogs:["21D0969770", "855051016"]
26   01010-81645   [9]   Bolt Komatsu China 0.104 kg.
  ["SN: 15001-15833"] analogs:["0101061645", "801015187", "0101031645", "0101051645", "37A0911184", "801014184"]
27   01643-31645   [9]   Washer Komatsu 0.072 kg.
  ["SN: 15001-15833"] analogs:["802170005", "0164301645"]
