KOMATSU 708-3T-00283 708-3T-01142 HYDRAULIC PUMP PARTS

Name: KOMATSU 708-3T-00283 708-3T-01142 HYDRAULIC PUMP PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

708-3T-00283 708-3T-01142 PC78US-8

Pos.	Part No	Qty	Parts name	Comments
	708-3T-00283	[1]	Pump Assembly Komatsu China
			["SN: 15941-UP"] \|$0.
	708-3T-01142	[1]	Pump Subassembly Komatsu China
			["SN: 15941-UP"] \|$1.
	708-3T-04250	[1]	Case Subassembly Komatsu China
			["SN: 15941-UP"] \|$2.
4	07044-12412	[1]	Plug Komatsu	0.09 kg.
			["SN: 15001-UP"] analogs:["0704402412", "R0704412412"]
5	07002-62434	[1]	O-ring Komatsu	0.001 kg.
			["SN: 15001-UP"] analogs:["7081W28910"]
6	04530-11018	[1]	Bolt, Eye Komatsu	0.079 kg.
			["SN: 15001-UP"]
7	720-68-19610	[1]	Pin Komatsu	0.002 kg.
			["SN: 15001-UP", "SCC: C2"]
8	708-3T-14151	[2]	Plug Komatsu China
			["SN: 15001-UP", "SCC: C2"] analogs:["7083T14150"]
9	708-3T-14170	[2]	Ball Komatsu China
			["SN: 15001-UP", "SCC: C2"]
10	708-3T-14160	[2]	Seat Komatsu China
			["SN: 15001-UP", "SCC: C2"]
11	07002-61023	[2]	O-ring Komatsu	0.22 kg.
			["SN: 15001-UP"] analogs:["7082L23920"]
12	708-8E-16150	[2]	Plug Komatsu	0.02 kg.
			["SN: 15001-UP"]
13	708-3T-04190	[1]	Plug Subassembly Komatsu China
			["SN: 15001-UP"]
17	07002-11223	[1]	O-ring Komatsu China	0.001 kg.
			["SN: 15001-UP"] analogs:["0700201223"]
18	708-1L-25210	[2]	Plug Komatsu	0.3 kg.
			["SN: 15001-UP"]
19	07002-11423	[2]	O-ring Komatsu China	0.001 kg.
			["SN: 15001-UP"] analogs:["0700201423"]
20	708-3T-12250	[1]	Shaft Komatsu China
			["SN: 15488-UP", "SCC: C2"]
21	708-1W-22140	[1]	Bearing Komatsu	0.431 kg.
			["SN: 15001-UP", "SCC: C2"]
22	708-23-05011	[1]	Washer Kit Komatsu	0.05 kg.
			["SN: 15001-UP", "SCC: C2"]
23	708-23-12840	[1]	Ring, Snap Komatsu China
			["SN: 15001-UP", "SCC: C2"] analogs:["890001295"]
24	708-1W-22320	[1]	Bearing Komatsu	0.25 kg.
			["SN: 15001-UP", "SCC: C2"]
25	708-8D-12221	[1]	Seal, Oil Komatsu	0.053 kg.
			["SN: 15001-UP"] analogs:["7088D12220"]
26	708-3T-12210	[1]	Case Komatsu China
			["SN: 15001-UP"]
27	07000-12065	[1]	O-ring Komatsu	0.03 kg.
			["SN: 15001-UP"] analogs:["YM24321000650"]
28	04065-07225	[1]	Ring, Snap Komatsu	0.02 kg.
			["SN: 15001-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	708-3T-00283	[1]	Pump Assembly Komatsu China
			["SN: 15941-UP"] \|$0.
	708-3T-01142	[1]	Pump Subassembly Komatsu China
			["SN: 15941-UP"] \|$1.
	708-3T-04210	[1]	Block Assembly Komatsu	4.08 kg.
			["SN: 15001-UP"] \|$2.
3	708-1W-23130	[2]	Seat Komatsu	0.016 kg.
			["SN: 15001-UP", "SCC: C2"]
4	708-3T-13150	[1]	Spring Komatsu China
			["SN: 15001-UP", "SCC: C2"]
5	04065-04218	[1]	Ring, Snap Komatsu	0.005 kg.
			["SN: 15001-UP", "SCC: C2"]
6	708-3T-13351	[1]	Guide, Retainer Komatsu China
			["SN: 15001-UP", "SCC: C2"]
7	708-3T-13360	[3]	Pin Komatsu	0.006 kg.
			["SN: 15001-UP", "SCC: C2"]
8	708-3T-13340	[1]	Retainer, Shoe Komatsu China
			["SN: 15001-UP", "SCC: C2"]
9	708-3T-13312	[10]	Piston Subassembly Komatsu	0.15 kg.
			["SN: 15001-UP", "SCC: C2"]
	708-3T-04230	[1]	Flange Assembly Komatsu China
			["SN: 15941-UP"] \|$12.
14	708-1U-13461	[2]	Ball, Retainer Komatsu	0.000 kg.
			["SN: 15941-UP", "SCC: C2"]
15	708-3T-13412	[1]	Cam, Rocker Komatsu China
			["SN: 15001-UP", "SCC: C2"]
16	708-3T-13451	[1]	Stud Komatsu China
			["SN: 15001-UP", "SCC: C2"] analogs:["7083T13450"]
17	04020-01024	[1]	Pin, Dowel Komatsu	0.015 kg.
			["SN: 15001-UP", "SCC: C2"] analogs:["PZF890001197"]
18	01252-61235	[8]	Bolt, Hexagon Socket Head Komatsu	0.048 kg.
			["SN: 15001-UP"] analogs:["801105554", "0125231235"]
19	07000-B2012	[1]	O-ring Komatsu China	0.001 kg.
			["SN: 15001-UP"]
20	708-7T-51210	[1]	O-ring Komatsu	0.01 kg.
			["SN: 15001-UP"]
21	708-3T-14130	[2]	Plug Komatsu China
			["SN: 15941-UP"]
22	07000-12010	[2]	O-ring Komatsu	0.001 kg.
			["SN: 15001-UP"] analogs:["YM24311240100", "0700002010"]
23	01643-51232	[2]	Washer Komatsu	0.024 kg.
			["SN: 15001-UP"]
24	01582-11210	[2]	Nut Komatsu	0.015 kg.
			["SN: 15001-UP"]
25	708-3T-14190	[2]	Piston Komatsu China
			["SN: 15941-UP", "SCC: C2"]
26	708-3T-14120	[2]	Spring Komatsu	0.002 kg.
			["SN: 15001-UP", "SCC: C2"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	708-3T-00283	[1]	Pump Assembly Komatsu China
			["SN: 15941-UP"] \|$0.
	708-3T-03281	[1]	Valve Assembly Komatsu China
			["SN: 15941-UP", "SCC: C2"] \|$1.
	708-3T-03280	[1]	Valve Assembly Komatsu China
			["SN: 15001-15940", "SCC: C2"] \|$2.
	708-3T-04360	[1]	Body Assembly Komatsu China
			["SN: 15001-UP"] \|$3.
2	708-3T-04320	[1]	Piston Subassembly Komatsu China
			["SN: 15001-UP", "SCC: C2"]
5	708-1S-15390	[3]	Seal Komatsu	0.001 kg.
			["SN: 15001-UP", "SCC: C2"]
5	708-3T-04340	[1]	Piston Subassembly Komatsu China
			["SN: 15001-UP", "SCC: C2"]
9	07002-11623	[1]	O-ring Komatsu China	0.001 kg.
			["SN: 15001-UP", "SCC: C2"] analogs:["0700201623"]
10	708-3T-15280	[1]	Spool Komatsu China
			["SN: 15001-UP", "SCC: C2"]
11	708-3T-15310	[1]	Seat Komatsu China
			["SN: 15001-UP", "SCC: C2"]
12	708-3T-15420	[1]	Spring Komatsu China
			["SN: 15001-UP", "SCC: C2"]
13	708-3T-15290	[1]	Retainer Komatsu China
			["SN: 15001-UP", "SCC: C2"]
14	708-3T-15250	[1]	Plug Komatsu China
			["SN: 15001-UP", "SCC: C2"]
15	07000-11006	[1]	O-ring Komatsu	0.01 kg.
			["SN: 15001-UP", "SCC: C2"] analogs:["0700001006"]
16	01583-11207	[1]	Nut Komatsu	0.013 kg.
			["SN: 15001-UP", "SCC: C2"] analogs:["0158301207"]
17	708-3T-15260	[1]	Lever Komatsu China
			["SN: 15001-UP", "SCC: C2"]
18	708-1S-15280	[1]	Spacer Komatsu China
			["SN: 15001-UP", "SCC: C2"]
20	708-1S-15290	[1]	Plug Komatsu China
			["SN: 15001-UP", "SCC: C2"]
21	708-3T-15560	[1]	Plug Komatsu China
			["SN: 15001-UP", "SCC: C2"]
22	07002-11223	[1]	O-ring Komatsu China	0.001 kg.
			["SN: 15001-UP", "SCC: C2"] analogs:["0700201223"]
23	708-3T-03711	[1]	Spool Subassembly Komatsu China
			["SN: 15001-UP", "SCC: C2"]
24	708-3T-15521	[1]	Plug Komatsu China
			["SN: 15001-UP", "SCC: C2"]
25	07000-11008	[1]	O-ring Komatsu China	0.01 kg.
			["SN: 15001-UP", "SCC: C2"] analogs:["0700001008", "2016018950"]
26	07001-01008	[1]	Ring, Back-up Komatsu	0.001 kg.
			["SN: 15001-UP", "SCC: C2"]
27	01583-51408	[1]	Nut Komatsu	0.016 kg.
			["SN: 15001-UP", "SCC: C2"]
28	708-3T-15530	[1]	Spring Komatsu China
			["SN: 15001-UP", "SCC: C2"] analogs:["7081W45430"]
29	708-1S-15350	[1]	Seat Komatsu China
			["SN: 15001-UP", "SCC: C2"] analogs:["7083S15870"]
30	708-1S-15360	[1]	Seat Komatsu China
			["SN: 15001-UP", "SCC: C2"]
31	708-3T-15811	[1]	Orifice Komatsu China
			["SN: 15001-UP", "SCC: C2"]
32	702-21-60700	[1]	Valve, Pilot Komatsu China
			["SN: 15941-UP"]
32	702-21-57400	[1]	Valve, Pilot Komatsu OEM	0.442 kg.
			["SN: 15001-15940"] analogs:["7022155901"]
33	700-80-61260	[1]	O-ring Komatsu	0.006 kg.
			["SN: 15001-UP"]
34	723-11-19960	[1]	O-ring Komatsu	0.001 kg.
			["SN: 15001-UP"]
35	702-21-54180	[2]	Screw Komatsu China
			["SN: 15001-UP"]
36	702-16-55610	[2]	O-ring Komatsu China
			["SN: 15941-UP"]
37	01252-60635	[2]	Bolt, Hexagon Socket Head Komatsu	0.011 kg.
			["SN: 15001-UP"]
38	708-8E-16150	[1]	Plug Komatsu	0.02 kg.
			["SN: 15001-UP"]
39	07002-11023	[1]	O-ring Komatsu China	0.025 kg.
			["SN: 15001-UP"] analogs:["0700201023"]
40	20B-27-11210	[1]	Bleeder Komatsu	0.02 kg.
			["SN: 15001-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	708-3T-00283	[1]	Pump Assembly Komatsu China
			["SN: 15941-UP"] \|$0.
1.	708-2L-25480	[4]	Filter Komatsu OEM	0.5 kg.
			["SN: 15001-UP"]
2.	708-2L-25490	[4]	O-ring Komatsu	0.001 kg.
			["SN: 15001-UP"]
3.	04020-00616	[2]	Pin, Dowel Komatsu	0.004 kg.
			["SN: 15001-UP"]
4.	07000-11008	[3]	O-ring Komatsu China	0.01 kg.
			["SN: 15001-UP"] analogs:["0700001008", "2016018950"]
5.	01252-60855	[3]	Bolt, Hexagon Socket Head Komatsu China
			["SN: 15001-UP"] analogs:["0125230855"]
6.	01252-60840	[1]	Bolt, Hexagon Socket Head Komatsu China
			["SN: 15001-UP"] analogs:["0125200840", "0125230840", "0125210840", "0125240840"]
7.	07000-13042	[1]	O-ring Komatsu China	0.01 kg.
			["SN: 15001-UP"] analogs:["0700003042"]
8.	708-3T-04520	[1]	Pump Assembly Komatsu China
			["SN: 15001-UP"] analogs:["7083T04512"]
9.	708-1T-19230	[1]	Ring Komatsu China
			["SN: 15001-UP"] analogs:["890001675", "7081T19220"]
10.	07000-12014	[1]	O-ring Komatsu China	0.01 kg.
			["SN: 15001-UP"] analogs:["0700002014"]
11.	07000-12060	[1]	O-ring Komatsu China	0.002 kg.
			["SN: 15001-UP"] analogs:["0700002060"]
12.	01010-80830	[4]	Bolt Komatsu	0.017 kg.
			["SN: 15001-UP"] analogs:["6735511120", "0101050830", "0737200830", "1240145H1"]
13.	01643-30823	[4]	Washer Komatsu	0.004 kg.
			["SN: 15001-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"]
	708-3T-04160	[2]	Plug Assembly Komatsu China
			["SN: 15001-UP"] \|$14.
14	708-3S-15810	[1]	Plug Komatsu China
			["SN: 15001-UP"]
15	07000-11003	[1]	O-ring Komatsu	0.001 kg.
			["SN: 15001-UP"] analogs:["0700001003"]
16	07001-01003	[1]	Ring, Back-up Komatsu	0.001 kg.
			["SN: 15001-UP"]
17.	708-3S-15820	[2]	Nut Komatsu China
			["SN: 15001-UP"]
18.	708-1T-19210	[1]	Coupling Komatsu China
			["SN: 15001-UP"] analogs:["890001673"]
19.	700-30-63140	[1]	Ring, Snap Komatsu China
			["SN: 15001-UP"] analogs:["890001674"]
20.	708-3T-12170	[1]	Coupling Komatsu China
			["SN: 15001-UP"]
21.	04065-03212	[1]	Ring, Snap Komatsu	0.002 kg.
			["SN: 15001-UP"] analogs:["4174317180"]
22.	708-3T-12180	[1]	Retainer Komatsu China
			["SN: 15001-UP"]
23.	01010-80825	[1]	Bolt Komatsu	0.015 kg.
			["SN: 15001-UP"] analogs:["0101050825", "01010D0825", "801015087"]
