708-3T-00280 708-3T-00281 708-3T-01131 708-3T-01140
PC78US-8 |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-3T-00281
|
[1] |
Pump Assembly Komatsu China
|
|
|
["SN: 15488-15940"] |$0. |
| |
708-3T-00280
|
[1] |
Pump Assembly Komatsu China
|
|
|
["SN: 15001-15487"] |$1. |
|
|
708-3T-01140
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 15488-15940"] |$2. |
|
|
708-3T-01131
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 15001-15487"] |$3. |
| |
708-3T-04171
|
[1] |
Case Assembly Komatsu China
|
|
|
["SN: 15001-15940"] |$4. |
| 3 |
07044-12412
|
[1] |
Plug Komatsu
|
0.09 kg. |
|
["SN: 15001-@"] analogs:["0704402412", "R0704412412"] |
| 4 |
07002-62434
|
[1] |
O-ring Komatsu
|
0.001 kg. |
|
["SN: 15001-@"] analogs:["7081W28910"] |
| 5 |
04530-11018
|
[1] |
Bolt, Eye Komatsu
|
0.079 kg. |
|
["SN: 15001-@"] |
| 6 |
720-68-19610
|
[1] |
Pin Komatsu
|
0.002 kg. |
|
["SN: 15001-@", "SCC: C2"] |
| 7 |
708-3T-14151
|
[2] |
Plug Komatsu China
|
|
|
["SN: 15001-@", "SCC: C2"] analogs:["7083T14150"] |
| 8 |
708-3T-14170
|
[2] |
Ball Komatsu China
|
|
|
["SN: 15001-@", "SCC: C2"] |
| 9 |
708-3T-14160
|
[2] |
Seat Komatsu China
|
|
|
["SN: 15001-@", "SCC: C2"] |
| 10 |
07002-61023
|
[2] |
O-ring Komatsu
|
0.22 kg. |
|
["SN: 15001-@"] analogs:["7082L23920"] |
| 11 |
708-8E-16150
|
[2] |
Plug Komatsu
|
0.02 kg. |
|
["SN: 15001-@"] |
| 12 |
708-3T-04190
|
[1] |
Plug Subassembly Komatsu China
|
|
|
["SN: 15001-@"] |
| 16 |
07002-11223
|
[1] |
O-ring Komatsu China
|
0.001 kg. |
|
["SN: 15001-@"] analogs:["0700201223"] |
| 17 |
708-1L-25210
|
[2] |
Plug Komatsu
|
0.3 kg. |
|
["SN: 15001-@"] |
| 18 |
07002-11423
|
[2] |
O-ring Komatsu China
|
0.001 kg. |
|
["SN: 15001-@"] analogs:["0700201423"] |
| 19 |
708-3T-12250
|
[1] |
Shaft Komatsu China
|
|
|
["SN: 15488-@", "SCC: C2"] |
| 20 |
708-1W-22140
|
[1] |
Bearing Komatsu
|
0.431 kg. |
|
["SN: 15001-@", "SCC: C2"] |
| 21 |
708-23-05011
|
[1] |
Washer Kit Komatsu
|
0.05 kg. |
|
["SN: 15001-@", "SCC: C2"] |
| 22 |
708-23-12840
|
[1] |
Ring, Snap Komatsu China
|
|
|
["SN: 15001-@", "SCC: C2"] analogs:["890001295"] |
| 23 |
708-1W-22320
|
[1] |
Bearing Komatsu
|
0.25 kg. |
|
["SN: 15001-@", "SCC: C2"] |
| 24 |
708-8D-12221
|
[1] |
Seal, Oil Komatsu
|
0.053 kg. |
|
["SN: 15001-@"] analogs:["7088D12220"] |
| 25 |
708-3T-12210
|
[1] |
Case Komatsu China
|
|
|
["SN: 15001-@"] |
| 26 |
07000-12065
|
[1] |
O-ring Komatsu
|
0.03 kg. |
|
["SN: 15001-@"] analogs:["YM24321000650"] |
| 27 |
04065-07225
|
[1] |
Ring, Snap Komatsu
|
0.02 kg. |
|
["SN: 15001-@"] |
| Parts on group : |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-3T-00281
|
[1] |
Pump Assembly Komatsu China
|
|
|
["SN: 15488-15940", "SCC: A2"] |$0. |
| |
708-3T-00280
|
[1] |
Pump Assembly Komatsu China
|
|
|
["SN: 15001-15487"] |$1. |
| |
708-3T-04210 |
[1] |
Block Assembly Komatsu
|
4.08 kg. |
|
["SN: 15001-@"] |$2. |
| 3 |
708-1W-23130
|
[2] |
Seat Komatsu
|
0.016 kg. |
|
["SN: 15001-@", "SCC: C2"] |
| 4 |
708-3T-13150
|
[1] |
Spring Komatsu China
|
|
|
["SN: 15001-@", "SCC: C2"] |
| 5 |
04065-04218
|
[1] |
Ring, Snap Komatsu
|
0.005 kg. |
|
["SN: 15001-@", "SCC: C2"] |
| 6 |
708-3T-13351
|
[1] |
Guide, Retainer Komatsu China
|
|
|
["SN: 15001-@", "SCC: C2"] |
| 7 |
708-3T-13360
|
[3] |
Pin Komatsu
|
0.006 kg. |
|
["SN: 15001-@", "SCC: C2"] |
| 8 |
708-3T-13340
|
[1] |
Retainer, Shoe Komatsu China
|
|
|
["SN: 15001-@", "SCC: C2"] |
| 9 |
708-3T-13312 |
[10] |
Piston Subassembly Komatsu
|
0.15 kg. |
|
["SN: 15001-@", "SCC: C2"] |
| |
708-3T-04220
|
[1] |
Flange Assembly Komatsu China
|
|
|
["SN: 15001-15940"] |$12. |
| 12 |
708-3T-13421
|
[2] |
Ball Komatsu
|
0.42 kg. |
|
["SN: 15001-15940", "SCC: C2"] |
| 13 |
708-3T-13412
|
[1] |
Cam, Rocker Komatsu China
|
|
|
["SN: 15001-@", "SCC: C2"] |
| 14 |
708-3T-13451
|
[1] |
Stud Komatsu China
|
|
|
["SN: 15001-@", "SCC: C2"] analogs:["7083T13450"] |
| 15 |
04020-01024
|
[1] |
Pin, Dowel Komatsu
|
0.015 kg. |
|
["SN: 15001-@", "SCC: C2"] analogs:["PZF890001197"] |
| 16 |
01252-61235
|
[8] |
Bolt, Hexagon Socket Head Komatsu
|
0.048 kg. |
|
["SN: 15001-@"] analogs:["801105554", "0125231235"] |
| 17 |
07000-B2012
|
[1] |
O-ring Komatsu China
|
0.001 kg. |
|
["SN: 15001-@"] |
| 18 |
708-7T-51210
|
[1] |
O-ring Komatsu
|
0.01 kg. |
|
["SN: 15001-@"] |
| 19 |
708-3T-14222
|
[2] |
Plug Komatsu China
|
|
|
["SN: 15001-15940"] |
| 20 |
07000-12010
|
[2] |
O-ring Komatsu
|
0.001 kg. |
|
["SN: 15001-@"] analogs:["YM24311240100", "0700002010"] |
| 21 |
01643-51232
|
[2] |
Washer Komatsu
|
0.024 kg. |
|
["SN: 15001-@"] |
| 22 |
01582-11210
|
[2] |
Nut Komatsu
|
0.015 kg. |
|
["SN: 15001-@"] |
| 23 |
708-3T-14114
|
[2] |
Piston Subassembly Komatsu
|
0.112 kg. |
|
["SN: 15001-15940", "SCC: C2"] |
| 24 |
708-3T-14120
|
[2] |
Spring Komatsu
|
0.002 kg. |
|
["SN: 15001-@", "SCC: C2"] |
