KOMATSU 708-2K-00113  708-2K-01115 HYDRAULIC PUMP ASSY ROTARY GROUP AND SPARE PARTS

KOMATSU 708-2K-00113  708-2K-01115 HYDRAULIC PUMP ASSY ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
708-2K-00113  708-2K-01115
PC800-8E0 PC800LC-8E0 PC800SE-8E0 PC850-8E0 PC850SE-8E0 PC800-8 PC800-8E0 PC800-8R PC800-8R1 PC800LC-8E0 PC800LC-8R PC800LC-8R1 PC800SE-8E0 PC800SE-8R1 PC850-8E0 PC850-8R1 PC850SE-8E0 PC850SE-8R1
Pos. Part No Qty Parts name Comments
     708-2K-00113   [1]   PUMP ASS'Y Komatsu 528 kg.
  ["SN: 55222-UP"] analogs:["7082K00110"] |$1.
        708-2K-01115   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 55222-UP"] |$3.
     708-2K-04330   [1]   CASE ASS'Y,FRONT Komatsu China
  ["SN: 55222-UP"] |$4.
3   708-2K-11170   [3]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
4   708-2K-11190   [1]   O-RING Komatsu 0.002 kg.
  ["SN: 55222-UP"]
5   07040-14220   [1]   PLUG Komatsu 0.325 kg.
  ["SN: 55222-UP"] analogs:["0704114212"]
6   07002-64234   [1]   O-RING Komatsu 1.82 kg.
  ["SN: 55222-UP"]
7   07044-13620   [1]   PLUG Komatsu 0.496 kg.
  ["SN: 55222-UP"] analogs:["0704403620"]
8   07002-63634   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"] analogs:["7082L24620"]
9   04530-12030   [1]   BOLT Komatsu China
  ["SN: 55222-UP"] analogs:["823000172", "0453002030", "0453012039", "4D120A747A", "6101214150", "6110211161"]
10   708-2K-11290   [1]   ORIFICE Komatsu 0.003 kg.
  ["SN: 55222-UP"]
     708-2K-04350   [1]   CAP ASS'Y,END Komatsu China
  ["SN: 55222-UP"] |$15.
13   708-2K-11720   [1]   BUSHING Komatsu China
  ["SN: 55222-UP"]
15   708-2K-12280   [2]   BEARING Komatsu China
  ["SN: 55222-UP"]
16   07000-A5260   [2]   O-RING Komatsu 0.02 kg.
  ["SN: 55222-UP"]
17   04020-01638   [2]   PIN,DOWEL Komatsu 0.064 kg.
  ["SN: 55222-UP"]
18   01010-62275   [16]   BOLT Komatsu 0.304 kg.
  ["SN: 55222-UP"] analogs:["0101052275", "0101082275", "0101032275"]
19   01643-32260   [16]   WASHER Komatsu China 0.042 kg.
  ["SN: 55222-UP"]
20   708-8E-16150   [3]   PLUG Komatsu 0.02 kg.
  ["SN: 55222-UP"]
21   07002-61023   [3]   O-RING Komatsu 0.22 kg.
  ["SN: 55222-UP"] analogs:["7082L23920"]
22   706-77-72150   [1]   PLUG Komatsu 0.52 kg.
  ["SN: 55222-UP"]
24   706-73-71450   [6]   PLUG Komatsu 0.035 kg.
  ["SN: 55222-UP"]
25   07002-61423   [6]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"] analogs:["7082L23950"]
26   708-2K-13160   [1]   PLUG Komatsu China
  ["SN: 55222-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2K-00113   [1]   PUMP ASS'Y Komatsu 528 kg.
  ["SN: 55222-UP"] analogs:["7082K00110"] |$1.
        708-2K-01115   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 55222-UP"] |$3.
1   708-2K-12160   [1]   SHAFT,FRONT Komatsu China
  ["SN: 55222-UP"]
2   708-2K-12260   [1]   BEARING Komatsu China
  ["SN: 55222-UP"]
3   708-2K-05050   [1]   WASHER KIT Komatsu China
  ["SN: 55222-UP"]
4   04064-09030   [1]   RING,RING Komatsu 0.044 kg.
  ["SN: 55222-UP"]
5   708-2K-12360   [1]   SEAL,OIL Komatsu 0.16 kg.
  ["SN: 55222-UP"]
6   708-2K-12310   [1]   PLATE Komatsu China
  ["SN: 55222-UP"]
7   07000-A2130   [1]   O-RING Komatsu 0.02 kg.
  ["SN: 55222-UP"]
8   01252-60820   [4]   BOLT Komatsu 0.015 kg.
  ["SN: 55222-UP"]
     708-2K-04271   [1]   CYLINDER BLOCK ASS'Y,FRONT Komatsu China
  ["SN: 55222-UP"] |$17.
11   708-18-13230   [1]   PIN Komatsu 0.01 kg.
  ["SN: 55222-UP"]
12   708-2K-13361   [3]   PIN Komatsu China
  ["SN: 55222-UP"]
13   708-2K-13130   [1]   SEAT Komatsu China
  ["SN: 55222-UP"]
14   708-2K-13151   [1]   SPRING Komatsu China
  ["SN: 55222-UP"]
15   708-2K-13140   [1]   SEAT Komatsu China
  ["SN: 55222-UP"]
16   04065-08530   [1]   RING Komatsu 0.03 kg.
  ["SN: 55222-UP"]
17   708-2K-13350   [1]   GUIDE,RETAINER Komatsu China
  ["SN: 55222-UP"]
18   708-2K-13371   [1]   RETAINER,SHOE Komatsu China
  ["SN: 55222-UP"] analogs:["7082K13370"]
19   708-2K-13312   [9]   PISTON SUB ASS'Y Komatsu China
  ["SN: 55222-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2K-00113   [1]   PUMP ASS'Y Komatsu 528 kg.
  ["SN: 55222-UP"] analogs:["7082K00110"] |$1.
        708-2K-01115   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 55222-UP"] |$3.
     708-2K-04260   [1]   CRADLE ASS'Y Komatsu China
  ["SN: 55222-UP"] |$4.
3   708-2K-13430   [1]   PLATE Komatsu China
  ["SN: 55222-UP"]
4   04020-01638   [1]   PIN,DOWEL Komatsu 0.064 kg.
  ["SN: 55222-UP"]
5   708-2K-11170   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
6   01252-61445   [8]   BOLT Komatsu 0.081 kg.
  ["SN: 55222-UP"] analogs:["7051903470", "7067540360"]
7   708-2K-14110   [1]   PISTON Komatsu China
  ["SN: 55222-UP"]
8   708-2K-14130   [1]   ROD Komatsu China
  ["SN: 55222-UP"]
9   708-2K-15180   [1]   CAM Komatsu China
  ["SN: 55222-UP"]
10   720-68-19610   [2]   PIN Komatsu 0.002 kg.
  ["SN: 55222-UP"]
11   01252-61030   [1]   BOLT Komatsu China
  ["SN: 55222-UP"] analogs:["7051701370"]
12   708-2K-14250   [1]   SCREW Komatsu China
  ["SN: 55222-UP"]
13   07000-B3039   [1]   O-RING Komatsu 0.008 kg.
  ["SN: 55222-UP"]
14   07001-03039   [1]   RING Komatsu China
  ["SN: 55222-UP"]
15   01643-33080   [1]   WASHER Komatsu China 0.132 kg.
  ["SN: 55222-UP"]
16   01583-13018   [1]   NUT Komatsu 0.17 kg.
  ["SN: 55222-UP"] analogs:["0158303018"]
17   708-2K-14230   [1]   SCREW Komatsu China
  ["SN: 55222-UP"]
18   07000-B3032   [1]   O-RING Komatsu 0.01 kg.
  ["SN: 55222-UP"]
19   07001-03032   [1]   RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2K-00113   [1]   PUMP ASS'Y Komatsu 528 kg.
  ["SN: 55222-UP"] analogs:["7082K00110"] |$1.
        708-2K-01115   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 55222-UP"] |$3.
1   708-2K-12330   [1]   SHAFT,REAR Komatsu China
  ["SN: 55222-UP"]
2   708-2K-12260   [1]   BEARING Komatsu China
  ["SN: 55222-UP"]
3   708-2K-05050   [1]   WASHER KIT Komatsu China
  ["SN: 55222-UP"]
4   04064-09030   [1]   RING Komatsu 0.044 kg.
  ["SN: 55222-UP"]
     708-2K-04281   [1]   CYLINDER BLOCK ASS'Y,REAR Komatsu 17.3 kg.
  ["SN: 55222-UP"] |$13.
7   708-18-13230   [1]   PIN Komatsu 0.01 kg.
  ["SN: 55222-UP"]
8   708-2K-13361   [3]   PIN Komatsu China
  ["SN: 55222-UP"]
9   708-2K-13130   [1]   SEAT Komatsu China
  ["SN: 55222-UP"]
10   708-2K-13151   [1]   SPRING Komatsu China
  ["SN: 55222-UP"]
11   708-2K-13140   [1]   SEAT Komatsu China
  ["SN: 55222-UP"]
12   04065-08530   [1]   RING Komatsu 0.03 kg.
  ["SN: 55222-UP"]
13   708-2K-13350   [1]   GUIDE,RETAINER Komatsu China
  ["SN: 55222-UP"]
14   708-2K-13371   [1]   RETAINER,SHOE Komatsu China
  ["SN: 55222-UP"] analogs:["7082K13370"]
15   708-2K-13312   [9]   PISTON SUB ASS'Y Komatsu China
  ["SN: 55222-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2K-00113   [1]   PUMP ASS'Y Komatsu 528 kg.
  ["SN: 55222-UP"] analogs:["7082K00110"] |$1.
        708-2K-01115   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 55222-UP"] |$3.
     708-2K-04260   [1]   CRADLE ASS'Y Komatsu China
  ["SN: 55222-UP"] |$4.
3   708-2K-13430   [1]   PLATE Komatsu China
  ["SN: 55222-UP"]
4   04020-01638   [1]   PIN,DOWEL Komatsu 0.064 kg.
  ["SN: 55222-UP"]
5   708-2K-11170   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
6   01252-61445   [8]   BOLT Komatsu 0.081 kg.
  ["SN: 55222-UP"] analogs:["7051903470", "7067540360"]
7   708-2K-14110   [1]   PISTON Komatsu China
  ["SN: 55222-UP"]
8   708-2K-14130   [1]   ROD Komatsu China
  ["SN: 55222-UP"]
9   708-2K-15180   [1]   CAM Komatsu China
  ["SN: 55222-UP"]
10   720-68-19610   [2]   PIN Komatsu 0.002 kg.
  ["SN: 55222-UP"]
11   01252-61030   [1]   BOLT Komatsu China
  ["SN: 55222-UP"] analogs:["7051701370"]
12   708-2K-14250   [1]   SCREW Komatsu China
  ["SN: 55222-UP"]
13   07000-B3039   [1]   O-RING Komatsu 0.008 kg.
  ["SN: 55222-UP"]
14   07001-03039   [1]   RING Komatsu China
  ["SN: 55222-UP"]
15   01643-33080   [1]   WASHER Komatsu China 0.132 kg.
  ["SN: 55222-UP"]
16   01583-13018   [1]   NUT Komatsu 0.17 kg.
  ["SN: 55222-UP"] analogs:["0158303018"]
17   708-2K-14230   [1]   SCREW Komatsu China
  ["SN: 55222-UP"]
18   07000-B3032   [1]   O-RING Komatsu 0.01 kg.
  ["SN: 55222-UP"]
19   07001-03032   [1]   RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
22   708-2K-12240   [1]   COUPLING Komatsu China
  ["SN: 55222-UP"]
23   708-2K-11730   [1]   IMPELLER Komatsu China
  ["SN: 55222-UP"]
24   708-2K-11810   [1]   SHAFT Komatsu China
  ["SN: 55222-UP"]
25   01010-E1225   [2]   BOLT Komatsu 0.039 kg.
  ["SN: 55222-UP"] analogs:["0101031225", "0101061225"]
26   708-2K-11820   [2]   WASHER Komatsu China
  ["SN: 55222-UP"]
27   708-2K-11740   [1]   FLANGE Komatsu China
  ["SN: 55222-UP"]
28   07000-A5135   [1]   O-RING Komatsu China
  ["SN: 55222-UP"]
29   708-2K-05020   [1]   SHIM KIT Komatsu China
  ["SN: 55222-UP"]
30   01252-61230   [4]   BOLT Komatsu 0.044 kg.
  ["SN: 55222-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2K-00113   [1]   PUMP ASS'Y Komatsu 528 kg.
  ["SN: 55222-UP"] analogs:["7082K00110"] |$1.
        708-2K-03160   [2]   SERVO VALVE ASS'Y,FRONT Komatsu China
  ["SN: 55222-UP"] analogs:["7082K03150", "7082K03151"] |$3.
1   708-8E-16150   [2]   PLUG Komatsu 0.02 kg.
  ["SN: 55222-UP"]
2   07002-61023   [2]   O-RING Komatsu 0.22 kg.
  ["SN: 55222-UP"] analogs:["7082L23920"]
     708-2K-04211   [1]   BLOCK SUB ASS'Y,FRONT Komatsu China
  ["SN: 55222-UP"] |$6.
5   708-2K-03550   [1]   VALVE ASS'Y Komatsu China
  ["SN: 55222-UP"]
6   07002-62434   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"] analogs:["7081W28910"]
7   07000-B2012   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 55222-UP"]
8   07001-02012   [1]   RING Komatsu 0.002 kg.
  ["SN: 55222-UP"]
9   07000-B2010   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"] analogs:["7082L25990"]
10   07001-02010   [1]   RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
11   702-21-07650   [1]   SOLENOID VALVE Komatsu 0.57 kg.
  ["SN: 55222-UP"]
12   702-21-53610   [1]   O-RING Komatsu China
  ["SN: 55222-UP"]
13   702-21-55620   [1]   PLUG Komatsu 0.05 kg.
  ["SN: 55222-UP"]
14   702-21-53330   [2]   SCREW Komatsu China
  ["SN: 55222-UP"]
15   07002-61423   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"] analogs:["7082L23950"]
16   708-2K-16320   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
17   708-2K-16310   [2]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
18   203-60-62220   [2]   BOLT Komatsu 0.01 kg.
  ["SN: 55222-UP"]
19   708-2K-03820   [1]   PLUG ASS'Y Komatsu China
  ["SN: 55222-UP"]
20   708-2K-03560   [1]   VALVE ASS'Y Komatsu China
  ["SN: 55222-UP"]
21   07002-63634   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"] analogs:["7082L24620"]
   22.   708-2L-25480   [4]   FILTER Komatsu OEM 0.5 kg.
  ["SN: 55222-UP"]
   23.   708-2K-11170   [8]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
   24.   07000-A2110   [2]   O-RING Komatsu China
  ["SN: 55222-UP"]
   25.   04020-01228   [4]   PIN Komatsu 0.026 kg.
  ["SN: 55222-UP"] analogs:["21T3016190"]
   26.   01252-61275   [8]   BOLT Komatsu China
  ["SN: 55222-UP"] analogs:["7051702720"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2K-00113   [1]   PUMP ASS'Y Komatsu 528 kg.
  ["SN: 55222-UP"] analogs:["7082K00110"] |$1.
   1.   07040-12414   [7]   PLUG Komatsu 0.092 kg.
  ["SN: 55222-UP"] analogs:["0704002412", "0704012412"]
   2.   07002-62434   [7]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"] analogs:["7081W28910"]
        708-2K-03250   [1]   FILTER ASS'Y Komatsu China
  ["SN: 55222-UP"] |$5.
3   708-2K-16930   [1]   UNION Komatsu China
  ["SN: 55222-UP"]
4   708-2K-16150   [1]   FILTER Komatsu China
  ["SN: 55222-UP"]
5   07002-63634   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"] analogs:["7082L24620"]
6   708-2K-16920   [1]   PLUG Komatsu China
  ["SN: 55222-UP"]
7   02896-61015   [1]   O-RING Komatsu 0.21 kg.
  ["SN: 55222-UP"]
   8.   708-2K-03411   [1]   VALVE ASS'Y,REDUCE Komatsu China
  ["SN: 55222-UP"] analogs:["7082K16220", "7082K16241"]
9   07000-B2022   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
10   07001-02022   [1]   RING,BACK-UP Komatsu China
  ["SN: 55222-UP"]
11   07000-B3022   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
12   07001-03022   [1]   RING Komatsu 0.01 kg.
  ["SN: 55222-UP"]
   14.   708-2K-03420   [1]   VALVE ASS'Y,RELIEF Komatsu China
  ["SN: 55222-UP"]
15   07000-B2014   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 55222-UP"]
16   723-40-56350   [1]   RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
708-1W-00901  708-1W-00911
708-1W-01916
PC800-8E0 PC800-8 PC800-8E0 PC800-8R1 PC800LC-8 PC800LC-8E0 PC800LC-8R1 PC800SE-8 PC800SE-8E0 PC800SE-8R1 PC850-8 PC850-8E0 PC850-8R1 PC850SE-8 PC850SE-8E0 PC850SE-8R1
Pos. Part No Qty Parts name Comments
     708-2K-00113   [1]   PUMP ASS'Y Komatsu 528 kg.
  ["SN: 55222-UP"] analogs:["7082K00110"] |$1.
        708-1W-00901   [1]   PUMP ASS'Y Komatsu China
  ["SN: 55222-UP"] |$3.
     708-1W-00911   [1]   PUMP ASS'Y Komatsu China
  ["SN: 55222-UP"] |$4.
     708-1W-01916   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 55222-UP"] |$5.
     708-1W-04961   [1]   CASE ASS'Y Komatsu China
  ["SN: 55222-UP"] |$6.
3   708-8E-16160   [2]   PLUG Komatsu 0.01 kg.
  ["SN: 55222-UP"]
4   07002-11023   [2]   O-RING Komatsu China 0.025 kg.
  ["SN: 55222-UP"] analogs:["0700201023"]
5   07040-11409   [1]   PLUG Komatsu 0.033 kg.
  ["SN: 55222-UP"]
6   07002-11423   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 55222-UP"] analogs:["0700201423"]
7   706-73-42370   [1]   O-RING Komatsu 0.005 kg.
  ["SN: 55222-UP"]
8   07000-B1009   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 55222-UP"] analogs:["7082L23910"]
9   04020-01024   [1]   PIN Komatsu 0.015 kg.
  ["SN: 55222-UP"] analogs:["PZF890001197"]
10   01010-61470   [4]   BOLT Komatsu 0.109 kg.
  ["SN: 55222-UP"] analogs:["0101031470", "0101081470", "0101051470"]
11   01643-31445   [4]   WASHER Komatsu 0.019 kg.
  ["SN: 55222-UP"] analogs:["0164301432"]
12   708-1W-41541   [1]   CAP,END Komatsu China
  ["SN: 55222-UP"]
13   708-1W-42120   [1]   BEARING Komatsu 0.2 kg.
  ["SN: 55222-UP"]
14   708-3T-13420   [2]   BALL Komatsu 0.42 kg.
  ["SN: 55222-UP"] analogs:["7083T13421"]
15   708-1W-43420   [1]   CAM,ROCKER Komatsu China
  ["SN: 55222-UP"]
16   04260-01270   [1]   BALL Komatsu OEM 0.009 kg.
  ["SN: 55222-UP"]
17   708-1U-12120   [1]   SHAFT Komatsu 1.7 kg.
  ["SN: 55222-UP"]
18   708-1W-42110   [1]   BEARING Komatsu 0.23 kg.
  ["SN: 55222-UP"]
19   708-1U-12320   [1]   CASE Komatsu 0.2 kg.
  ["SN: 55222-UP"]
20   708-1W-42130   [1]   SEAL Komatsu 0.032 kg.
  ["SN: 55222-UP"]
21   07000-B2065   [1]   O-RING Komatsu 0.002 kg.
  ["SN: 55222-UP"]
22   708-1W-05811   [1]   SPACER KIT Komatsu 0.182 kg.
  ["SN: 55222-UP"] analogs:["7081W05810"]
23   04065-07225   [1]   RING Komatsu 0.02 kg.
  ["SN: 55222-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2K-00113   [1]   PUMP ASS'Y Komatsu 528 kg.
  ["SN: 55222-UP"] analogs:["7082K00110"] |$1.
        708-1W-00901   [1]   PUMP ASS'Y Komatsu China
  ["SN: 55222-UP"] |$3.
     708-1W-00911   [1]   PUMP ASS'Y Komatsu China
  ["SN: 55222-UP"] |$4.
     708-1W-01916   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 55222-UP"] |$5.
1   708-1W-43310   [1]   BLOCK,CYLINDER Komatsu 3.6 kg.
  ["SN: 55222-UP"]
2   708-1W-43220   [1]   PLATE,VALVE Komatsu China
  ["SN: 55222-UP"]
3   720-68-19610   [1]   PIN Komatsu 0.002 kg.
  ["SN: 55222-UP"]
4   708-1W-43130   [2]   SEAT Komatsu China
  ["SN: 55222-UP"]
5   708-1W-43140   [1]   SPRING Komatsu 0.15 kg.
  ["SN: 55222-UP"]
6   04065-04818   [1]   RING Komatsu OEM 0.007 kg.
  ["SN: 55222-UP"]
7   708-1W-43350   [1]   GUIDE,RETAINER Komatsu 0.08 kg.
  ["SN: 55222-UP"]
8   708-3T-13360   [3]   PIN Komatsu 0.006 kg.
  ["SN: 55222-UP"]
9   708-1W-43341   [1]   RETAINER,SHOE Komatsu 0.25 kg.
  ["SN: 55222-UP"]
10   708-1U-13310   [9]   PISTON SUB ASS'Y Komatsu 0.2 kg.
  ["SN: 55222-UP"]
11   708-1W-44120   [1]   PISTON SUB ASS'Y Komatsu 0.095 kg.
  ["SN: 55222-UP"] analogs:["7081W44110", "7081W44130"]
12   708-3T-14120   [1]   SPRING Komatsu 0.002 kg.
  ["SN: 55222-UP"]
13   708-1U-14240   [2]   SCREW Komatsu 0.000 kg.
  ["SN: 55222-UP"]
14   07000-12011   [2]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"] analogs:["YM24315000110", "0700002011"]
15   01643-31232   [2]   WASHER Komatsu 0.027 kg.
  ["SN: 55222-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
16   01582-11210   [2]   NUT Komatsu 0.015 kg.
  ["SN: 55222-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2K-00113   [1]   PUMP ASS'Y Komatsu 528 kg.
  ["SN: 55222-UP"] analogs:["7082K00110"] |$1.
        708-1W-00901   [1]   PUMP ASS'Y Komatsu China
  ["SN: 55222-UP"] |$3.
     708-1W-00911   [1]   PUMP ASS'Y Komatsu China
  ["SN: 55222-UP"] |$4.
     708-1W-03870   [1]   VALVE ASS'Y Komatsu China
  ["SN: 55222-UP"] |$5.
5   07002-21623   [1]   O-RING Komatsu 0.32 kg.
  ["SN: 55222-UP"]
6   07000-B1010   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
10   723-56-31630   [1]   PLUG Komatsu 0.02 kg.
  ["SN: 55222-UP"]
16   01582-11210   [1]   NUT Komatsu 0.015 kg.
  ["SN: 55222-UP"]
18   20B-27-11210   [1]   BLEEDER Komatsu 0.02 kg.
  ["SN: 55222-UP"]
19   07040-11007   [2]   PLUG Komatsu 0.014 kg.
  ["SN: 55222-UP"]
20   07002-21023   [2]   O-RING Komatsu 0.22 kg.
  ["SN: 55222-UP"]
21   702-21-57700   [1]   PILOT VALVE Komatsu 0.45 kg.
  ["SN: 55222-UP"] analogs:["7022155800"]
22   702-21-55870   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
23   702-21-55880   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
24   702-21-54180   [2]   SCREW Komatsu China
  ["SN: 55222-UP"]
25   702-21-55890   [2]   O-RING Komatsu 0.001 kg.
  ["SN: 55222-UP"]
26   01252-60635   [2]   BOLT Komatsu 0.011 kg.
  ["SN: 55222-UP"]
27   07000-13040   [1]   O-RING Komatsu China 0.002 kg.
  ["SN: 55222-UP"] analogs:["0700003040", "0700003040E", "YM24311000400"]
28   01252-60650   [1]   BOLT Komatsu China
  ["SN: 55222-UP"]
30   04020-00616   [2]   PIN,DOWEL Komatsu 0.004 kg.
  ["SN: 55222-UP"]
31   07000-B2014   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: 55222-UP"]
32   708-2L-25480   [2]   FILTER Komatsu OEM 0.5 kg.
  ["SN: 55222-UP"]

Materials

Shipping & Returns

Dimensions

Care Instructions

查看完整資訊

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Kawasaki Best Selling Series

檢視全部

Komatsu Best Selling Series

檢視全部

Caterpillar Best Selling Series

檢視全部
