| 708-1W-00730 708-1W-00731 708-1W-00951 708-1W-00952 708-1W-01954 708-1W-01955 708-1W-41630 WA500-6 WA500-6R
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-1W-00731
|
[1] |
Pump Assembly Komatsu
|
42.5 kg. |
|
["SN: 55861-UP"] analogs:["7081W00951", "7081W00950", "7081W00820", "7081W00952"] |$0. |
| |
708-1W-00730
|
[1] |
Pump Assembly Komatsu
|
42.5 kg. |
|
["SN: 55546-55860", "SCC: A2"] analogs:["7081W00951", "7081W00950", "7081W00820", "7081W00731", "7081W00952"] |$1. |
| |
708-1W-00952
|
[1] |
Pump Assembly Komatsu
|
42.5 kg. |
|
["SN: 55494-55545", "SCC: A2"] analogs:["7081W00951", "7081W00950", "7081W00820", "7081W00731"] |$2. |
| |
708-1W-00951
|
[1] |
Pump Assembly Komatsu
|
42.5 kg. |
|
["SN: 55479-55493", "SCC: A2"] analogs:["7081W00950", "7081W00820", "7081W00731", "7081W00952"] |$3. |
| |
708-1W-01731
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 55861-UP", "SCC: C2"] |$4. |
| |
708-1W-01730
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 55546-55860", "SCC: C2"] |$5. |
| |
708-1W-01955
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 55494-55545", "SCC: C2"] |$6. |
| |
708-1W-01954
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 55479-55493", "SCC: C2"] |$7. |
| |
708-1W-04131
|
[1] |
Case Assembly Komatsu China
|
|
|
["SN: 55546-UP", "SCC: C2"] |$8. |
| |
708-1W-04130
|
[1] |
Case Assembly Komatsu China
|
|
|
["SN: 55546-55860", "SCC: C2"] |$9. |
| |
708-1W-04941
|
[1] |
Case Assembly Komatsu China
|
|
|
["SN: 55479-55545", "SCC: C2"] |$10. |
| 5 |
708-8E-16160
|
[1] |
Plug Komatsu
|
0.01 kg. |
|
["SN: 55479-55545"] |
| 6 |
07002-11023
|
[1] |
O-ring Komatsu China
|
0.025 kg. |
|
["SN: 55479-55545"] analogs:["0700201023"] |
| 7 |
07040-11409
|
[1] |
Plug Komatsu
|
0.033 kg. |
|
["SN: 55479-UP"] |
| 8 |
07002-11423
|
[1] |
O-ring Komatsu China
|
0.001 kg. |
|
["SN: 55479-UP"] analogs:["0700201423"] |
| 9 |
706-73-42370
|
[1] |
O-ring Komatsu
|
0.005 kg. |
|
["SN: 55479-UP", "SCC: C2"] |
| 10 |
07000-B1009
|
[1] |
O-ring Komatsu China
|
0.001 kg. |
|
["SN: 55479-55545", "SCC: C2"] analogs:["7082L23910"] |
| 11 |
708-1L-29340
|
[1] |
Orifice Komatsu
|
0.001 kg. |
|
["SN: 55546-UP", "SCC: C2"] |
| 12 |
04020-01024
|
[1] |
Pin, Dowel Komatsu
|
0.015 kg. |
|
["SN: 55479-UP", "SCC: C2"] analogs:["PZF890001197"] |
| 13 |
01010-61470
|
[4] |
Bolt Komatsu
|
0.109 kg. |
|
["SN: 55479-UP", "SCC: C2"] analogs:["0101031470", "0101081470", "0101051470"] |
| 14 |
01643-31445
|
[4] |
Washer, Flat Komatsu
|
0.019 kg. |
|
["SN: 55479-UP", "SCC: C2"] analogs:["0164301432"] |
| 15 |
708-1W-03930
|
[1] |
Plug Kit Komatsu China
|
|
|
["SN: 55479-55545"] |
| 16 |
708-1W-41630
|
[1] |
Cap, End Komatsu China
|
|
|
["SN: 55546-UP", "SCC: C2"] |
| 16 |
708-1W-41531
|
[1] |
Cap, End Komatsu China
|
|
|
["SN: 55479-55545", "SCC: C2"] |
| 17 |
708-1W-42120
|
[1] |
Bearing Komatsu
|
0.2 kg. |
|
["SN: 55479-UP", "SCC: C2"] |
| 18 |
708-1W-43150
|
[2] |
Ball, Retainer Komatsu China
|
|
|
["SN: 55546-UP", "SCC: C2"] |
| 18 |
708-3T-13421
|
[2] |
Ball Komatsu
|
0.42 kg. |
|
["SN: 55479-55545", "SCC: C2"] |
| 19 |
708-1W-43160
|
[1] |
Cam, Rocker Komatsu China
|
|
|
["SN: 55546-UP", "SCC: C2"] |
| 19 |
708-1W-43610
|
[1] |
Cam, Rocker Komatsu China
|
|
|
["SN: 55479-55545", "SCC: C2"] |
| 20 |
708-1W-42150
|
[1] |
Shaft Komatsu China
|
|
|
["SN: 55546-UP", "SCC: C2"] |
| 20 |
708-1U-12120
|
[1] |
Shaft Komatsu
|
1.7 kg. |
|
["SN: 55479-55545", "SCC: C2"] |
| 21 |
708-1W-42110
|
[1] |
Bearing Komatsu
|
0.23 kg. |
|
["SN: 55479-UP", "SCC: C2"] |
| 22 |
708-1W-42140
|
[1] |
Case, Seal Komatsu
|
0.2 kg. |
|
["SN: 55479-UP", "SCC: C2"] |
| 23 |
708-1W-42130
|
[1] |
Seal, Oil Komatsu
|
0.032 kg. |
|
["SN: 55479-UP"] |
| 24 |
07000-B2060
|
[1] |
O-ring Komatsu
|
0.002 kg. |
|
["SN: 55479-UP"] |
| 25 |
708-1W-05821
|
[1] |
Spacer Kit Komatsu
|
0.000 kg. |
|
["SN: 55479-UP", "SCC: C2"] analogs:["7081W05820"] |
| 26 |
04065-06825
|
[1] |
Ring, Snap Komatsu
|
0.018 kg. |
|
["SN: 55479-UP"] |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-1W-00731
|
[1] |
Pump Assembly Komatsu
|
42.5 kg. |
|
["SN: 55861-UP"] analogs:["7081W00951", "7081W00950", "7081W00820", "7081W00952"] |$0. |
| |
708-1W-00730
|
[1] |
Pump Assembly Komatsu
|
42.5 kg. |
|
["SN: 55546-55860", "SCC: A2"] analogs:["7081W00951", "7081W00950", "7081W00820", "7081W00731", "7081W00952"] |$1. |
| |
708-1W-00952
|
[1] |
Pump Assembly Komatsu
|
42.5 kg. |
|
["SN: 55494-55545", "SCC: A2"] analogs:["7081W00951", "7081W00950", "7081W00820", "7081W00731"] |$2. |
| |
708-1W-00951
|
[1] |
Pump Assembly Komatsu
|
42.5 kg. |
|
["SN: 55479-55493", "SCC: A2"] analogs:["7081W00950", "7081W00820", "7081W00731", "7081W00952"] |$3. |
| |
708-1W-01731
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 55861-UP", "SCC: C2"] |$4. |
| |
708-1W-01730
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 55546-55860", "SCC: C2"] |$5. |
| |
708-1W-01955
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 55494-55545", "SCC: C2"] |$6. |
| |
708-1W-01954
|
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 55479-55493", "SCC: C2"] |$7. |
| 1 |
708-1W-43110 |
[1] |
Block, Cylinder Komatsu China
|
|
|
["SN: 55546-UP", "SCC: C2"] |
| 1 |
708-1W-43310 |
[1] |
Cylinder Block Komatsu
|
3.6 kg. |
|
["SN: 55479-55545", "SCC: C2"] |
| 2 |
708-1W-43120 |
[1] |
Plate, Valve Komatsu China
|
|
|
["SN: 55546-UP", "SCC: C2"] |
| 2 |
708-1W-43620 |
[1] |
Plate, Valve Komatsu China
|
|
|
["SN: 55479-55545", "SCC: C2"] |
| 3 |
720-68-19610
|
[1] |
Pin Komatsu
|
0.002 kg. |
|
["SN: 55479-UP", "SCC: C2"] |
| 4 |
708-1W-43130 |
[2] |
Seat Komatsu China
|
|
|
["SN: 55479-UP", "SCC: C2"] |
| 5 |
708-1W-43140 |
[1] |
Spring Komatsu
|
0.15 kg. |
|
["SN: 55479-UP", "SCC: C2"] |
| 6 |
04065-04818 |
[1] |
Ring, Snap Komatsu OEM
|
0.007 kg. |
|
["SN: 55479-UP", "SCC: C2"] |
| 7 |
708-1W-43320 |
[1] |
Guide, Retainer Komatsu
|
0.08 kg. |
|
["SN: 55861-UP", "SCC: C2"] analogs:["7081W43350"] |
| 7 |
708-1W-43350 |
[1] |
Guide, Retainer Komatsu
|
0.08 kg. |
|
["SN: 55479-55860", "SCC: C2"] |
| 8 |
708-3T-13360 |
[3] |
Pin Komatsu
|
0.006 kg. |
|
["SN: 55479-UP", "SCC: C2"] |
| 9 |
708-1W-43341 |
[1] |
Retainer, Shoe Komatsu
|
0.25 kg. |
|
["SN: 55479-UP", "SCC: C2"] |
| 10 |
708-1U-13310
|
[9] |
Piston Subassembly Komatsu
|
0.2 kg. |
|
["SN: 55479-UP", "SCC: C2"] |
| 11 |
708-1W-44170 |
[1] |
Piston Komatsu China
|
|
|
["SN: 55546-UP", "SCC: C2"] |
| 11 |
708-1W-44130 |
[1] |
Piston Komatsu
|
0.095 kg. |
|
["SN: 55494-55545", "SCC: C2"] analogs:["7081W44120", "7081W44110"] |
| |
708-1W-44120 |
[1] |
Piston Komatsu
|
0.095 kg. |
|
["SN: 55479-55493", "SCC: C2"] analogs:["7081W44110", "7081W44130"] |$23. |
| 12 |
708-1W-44140 |
[1] |
Spring Komatsu China
|
|
|
["SN: 55546-UP", "SCC: C2"] |
| 12 |
708-3T-14120 |
[1] |
Spring Komatsu
|
0.002 kg. |
|
["SN: 55479-55545", "SCC: C2"] |
| 13 |
708-1U-14240
|
[2] |
Screw Komatsu
|
0.000 kg. |
|
["SN: 55479-UP", "SCC: C2"] |
| 14 |
07000-12011
|
[2] |
O-ring Komatsu
|
0.001 kg. |
|
["SN: 55479-UP", "SCC: C2"] analogs:["YM24315000110", "0700002011"] |
| 15 |
01643-31232
|
[2] |
Washer Komatsu
|
0.027 kg. |
|
["SN: 55479-UP", "SCC: C2"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] |
| 16 |
01582-11210
|
[2] |
Nut Komatsu
|
0.015 kg. |
|
["SN: 55479-UP", "SCC: C2"] |
