KOMATSU 708-1W-00042 708-1W-01042 HYDRAULIC PUMP ROTARY GROUP

Name: KOMATSU 708-1W-00042 708-1W-01042 HYDRAULIC PUMP ROTARY GROUP
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

708-1W-00042 708-1W-01042 PC60-7 PC60-7-B PC60-7E PC60-7E-B PC60-7S PC60-7S-B PC70-7 PC70-7-B PC70-7E PC70-7E-B

Pos.	Part No	Qty	Parts name	Comments
	708-1W-00042	[1]	PUMP ASS'Y Komatsu China
			["SN: 45001-52373"] analogs:["7081W01042"] \|1.
1.	708-1W-01042	[1]	PUMP SUB ASS'Y Komatsu China
			["SN: 45001-52373"] analogs:["7081W00042"]
2.	704-24-24430	[1]	GEAR PUMP ASS'Y Komatsu	4.38 kg.
			["SN: 45001-52373"]
3.	708-1L-04310	[1]	VALVE ASS'Y,RELIEF Komatsu	0.28 kg.
			["SN: 45001-52373"]
	07002-02434	[1]	O-RING Komatsu China	0.01 kg.
			["SN: 45001-52373"] analogs:["0700212434", "0700213434"] \|3.
4	700-22-11410	[1]	O-RING Komatsu OEM	0.001 kg.
			["SN: 45001-52373"]
5.	708-1W-28140	[1]	COUPLING Komatsu China
			["SN: 45001-52373"]
6.	07000-02100	[1]	O-RING Komatsu China	0.01 kg.
			["SN: 45001-52373"] analogs:["0700012100"]
7.	04020-00616	[1]	PIN,DOWEL Komatsu	0.004 kg.
			["SN: 45001-52373"]
8.	700-22-11450	[1]	O-RING Komatsu	0.001 kg.
			["SN: 45001-52373"]
9.	01010-50845	[1]	BOLT Komatsu	0.023 kg.
			["SN: 45001-52373"] analogs:["0101080845"]
10.	01010-50830	[3]	BOLT Komatsu	0.017 kg.
			["SN: 45001-52373"] analogs:["0101080830", "6735511120", "0737200830", "1240145H1"]
11.	01643-30823	[4]	WASHER Komatsu	0.004 kg.
			["SN: 45001-52373"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"]
12.	07000-02018	[1]	O-RING Komatsu China	0.001 kg.
			["SN: 45001-52373"] analogs:["0700012018", "KB9511301800", "YM24311000180", "2083811590"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	708-1W-00042	[1]	PUMP ASS'Y Komatsu China
			["SN: 45001-52373"] analogs:["7081W01042"] \|1.
	708-1W-01042	[1]	PUMP SUB ASS'Y Komatsu China
			["SN: 45001-52373"] analogs:["7081W00042"] \|1.
	708-1W-04011	[1]	CASE ASS'Y Komatsu China
			["SN: 45001-52373"] \|1.
3	07044-12412	[1]	PLUG Komatsu	0.09 kg.
			["SN: 45001-52373"] analogs:["0704402412", "R0704412412"]
4	07002-02434	[1]	O-RING Komatsu China	0.01 kg.
			["SN: 45001-52373"] analogs:["0700212434", "0700213434"]
5	04530-11018	[1]	BOLT,EYE Komatsu	0.079 kg.
			["SN: 45001-52373"]
6	720-68-19870	[1]	PLUG Komatsu	0.03 kg.
			["SN: 45001-52373"]
7	07002-01223	[1]	O-RING Komatsu China	0.001 kg.
			["SN: 45001-52373"] analogs:["0700211223"]
8	706-8E-14191	[1]	PLUG Komatsu China
			["SN: 45001-52373"] analogs:["890001288"]
9	07002-11823	[1]	O-RING Komatsu	0.36 kg.
			["SN: 45001-52373"] analogs:["0700201823"]
10	708-1W-24112	[1]	PISTON Komatsu China
			["SN: 45001-52373"]
11	708-1W-24412	[1]	SLIDER Komatsu China
			["SN: 45001-52373"] analogs:["7081W24411"]
12	708-1W-24211	[1]	BOLT,ADJUST Komatsu China
			["SN: 45001-52373"]
13	708-1W-28910	[1]	O-RING Komatsu	0.001 kg.
			["SN: 45001-52373"] analogs:["0700262434"]
14	708-1W-24311	[1]	BOLT,ADJUST Komatsu China
			["SN: 45001-52373"] analogs:["890001321"]
15	708-1W-28920	[1]	O-RING Komatsu	0.001 kg.
			["SN: 45001-52373"] analogs:["0700263034"]
16	708-1W-24320	[1]	SPRING Komatsu China
			["SN: 45001-52373"]
17	708-1W-26121	[1]	LEVER Komatsu China
			["SN: 45001-52373"] analogs:["890001324", "7081W25840"]
18	708-1W-26132	[1]	PIN Komatsu China
			["SN: 45001-52373"] analogs:["890001325"]
19	708-1W-26113	[1]	COVER Komatsu China
			["SN: 45001-52373"] analogs:["890001326"]
20	07000-03045	[1]	O-RING Komatsu China	0.002 kg.
			["SN: 45001-52373"] analogs:["0700013045"]
21	01010-50830	[2]	BOLT Komatsu	0.017 kg.
			["SN: 45001-52373"] analogs:["0101080830", "6735511120", "0737200830", "1240145H1"]
22	01643-30823	[2]	WASHER Komatsu	0.004 kg.
			["SN: 45001-52373"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"]
23	708-1W-26210	[1]	PIN Komatsu China
			["SN: 45001-52373"] analogs:["890001330"]
24	708-1W-26221	[1]	SLIDER Komatsu China
			["SN: 45001-52373"] analogs:["890001331"]
25	708-1W-26230	[1]	WASHER Komatsu China
			["SN: 45001-52373"] analogs:["890001332"]
26	01580-10605	[1]	NUT Komatsu	0.01 kg.
			["SN: 45001-52373"] analogs:["21D0921430", "M018200600006", "801920103"]
27	708-1W-04512	[1]	VALVE ASS'Y,PC SERVO Komatsu	0.812 kg.
			["SN: 45001-52373"]
28	708-1W-25710	[1]	ORIFICE Komatsu China
			["SN: 45001-52373"]
29	708-1W-04712	[1]	VALVE ASS'Y,LS Komatsu China
			["SN: 45001-52373"] analogs:["7081W04711"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	708-1W-00042	[1]	PUMP ASS'Y Komatsu China
			["SN: 45001-52373"] analogs:["7081W01042"] \|1.
	708-1W-01042	[1]	PUMP SUB ASS'Y Komatsu China
			["SN: 45001-52373"] analogs:["7081W00042"] \|1.
1	708-1W-22111	[1]	SHAFT Komatsu China
			["SN: 45001-52373"]
2	708-1W-22140	[1]	BEARING Komatsu	0.431 kg.
			["SN: 45001-52373"]
3	708-23-05011	[1]	WASHER KIT Komatsu	0.05 kg.
			["SN: 45001-52373"]
4	708-23-12840	[1]	RING,SNAP Komatsu China
			["SN: 45001-52373"] analogs:["890001295"]
5	04065-07225	[1]	RING,SNAP Komatsu	0.02 kg.
			["SN: 45001-52373"]
6	708-1D-12130	[1]	BEARING Komatsu	0.25 kg.
			["SN: 45001-52373"] analogs:["7081W22320"]
7	708-8D-12220	[1]	SEAL,OIL Komatsu	0.053 kg.
			["SN: 45001-52373"] analogs:["7088D12221"]
8	708-1W-22160	[1]	SPACER Komatsu China
			["SN: 45001-52373"] analogs:["890001298"]
9	04065-05520	[1]	RING,SNAP Komatsu	0.01 kg.
			["SN: 45001-52373"]
	708-1W-04081	[1]	CYLINDER BLOCK ASS'Y Komatsu China
			["SN: 45001-52373"] \|10.
10	708-1W-23110	[1]	BLOCK,CYLINDER Komatsu	3.721 kg.
			["SN: 45001-52373"]
11	708-1W-23211	[1]	PLATE,VALVE Komatsu China
			["SN: 45001-52373"]
12	720-68-19610	[1]	PIN Komatsu	0.002 kg.
			["SN: 45001-52373"]
13	708-1W-23351	[1]	GUIDE,RETAINER Komatsu	1.2 kg.
			["SN: 45001-52373"]
14	708-1W-23150	[1]	SPRING Komatsu	0.12 kg.
			["SN: 45001-52373"]
15	708-1W-23130	[1]	SEAT Komatsu	0.016 kg.
			["SN: 45001-52373"]
16	708-1W-23140	[1]	SEAT Komatsu	0.05 kg.
			["SN: 45001-52373"]
17	04065-04218	[1]	RING,SNAP Komatsu	0.005 kg.
			["SN: 45001-52373"]
18	708-7L-13360	[3]	PIN Komatsu	0.003 kg.
			["SN: 45001-52373"]
19	708-1W-23340	[1]	RETAINER,SHOE Komatsu China
			["SN: 45001-52373"]
20	708-1W-23311	[9]	PISTON SUB ASS'Y Komatsu China
			["SN: 45001-52373"]
	708-1W-04061	[1]	CRADLE ASS'Y Komatsu China
			["SN: 45001-52373"] \|21.
	708-1W-04050	[1]	CRADLE SUB ASS'Y Komatsu China
			["SN: 45001-52373"] \|21.
23	708-1W-23412	[1]	CAM,ROCKER Komatsu	1.63 kg.
			["SN: 45001-52373"]
24	04020-01024	[1]	PIN,DOWEL Komatsu	0.015 kg.
			["SN: 45001-52373"] analogs:["PZF890001197"]
25	01010-51035	[8]	BOLT Komatsu	0.033 kg.
			["SN: 45001-52373"] analogs:["801015556", "0101081035", "01010D1035"]
26	01643-31032	[8]	WASHER Komatsu	0.054 kg.
			["SN: 45001-52373"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
27	07000-B2011	[1]	O-RING Komatsu	0.001 kg.
			["SN: 45001-52373"]
28	07000-02145	[1]	O-RING Komatsu China	0.03 kg.
			["SN: 45001-52373"] analogs:["0700012145"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	708-1W-00042	[1]	PUMP ASS'Y Komatsu China
			["SN: 45001-52373"] analogs:["7081W01042"] \|1.
	708-1W-01042	[1]	PUMP SUB ASS'Y Komatsu China
			["SN: 45001-52373"] analogs:["7081W00042"] \|1.
	708-1W-04512	[1]	VALVE ASS'Y,PC SERVO Komatsu	0.812 kg.
			["SN: 45001-52373"] \|1.
1	708-1W-25211	[1]	PISTON Komatsu China
			["SN: 45001-52373"]
2	708-1W-25250	[1]	SPRING Komatsu China
			["SN: 45001-52373"]
3	708-1W-25241	[1]	SEAT Komatsu China
			["SN: 45001-52373"]
4	708-1W-25260	[1]	SPRING Komatsu China
			["SN: 45001-52373"]
5	708-1W-25232	[1]	SPOOL Komatsu China
			["SN: 45001-52373"]
6	708-1W-25223	[1]	SLEEVE Komatsu China
			["SN: 45001-52373"] analogs:["7081W25224"]
7	708-1W-25282	[1]	NIPPLE Komatsu China
			["SN: 45001-52373"]
8	708-1W-25292	[1]	PIN Komatsu China
			["SN: 45001-52373"]
9	708-1W-28920	[1]	O-RING Komatsu	0.001 kg.
			["SN: 45001-52373"] analogs:["0700263034"]
10	708-1W-25271	[1]	SEAT Komatsu China
			["SN: 45001-52373"]
11	708-1W-25350	[1]	WASHER Komatsu China
			["SN: 45001-52373"] analogs:["7081W25351"]
12	708-1W-25311	[1]	NUT Komatsu China
			["SN: 45001-52373"]
13	07002-01223	[1]	O-RING Komatsu China	0.001 kg.
			["SN: 45001-52373"] analogs:["0700211223"]
	708-1W-25710	[1]	ORIFICE Komatsu China
			["SN: 45001-52373"] \|14.
14	01583-11006	[1]	NUT Komatsu China
			["SN: 45001-52373"] analogs:["801070053", "801713409", "PZF801070053", "D40K153", "D40Q408", "PZF801713409", "0150151006", "0150111006", "0150131006", "0150141006", "0158331006", "0158301006", "0158211006"]
15	07002-11023	[1]	O-RING Komatsu China	0.025 kg.
			["SN: 45001-52373"] analogs:["0700201023"]
	708-1W-04712	[1]	VALVE ASS'Y,LS Komatsu China
			["SN: 45001-52373"] analogs:["7081W04711"] \|16.
16	708-1W-25523	[1]	SLEEVE Komatsu China
			["SN: 45001-52373"] analogs:["890001351"]
17	708-1W-25513	[1]	SPOOL Komatsu China
			["SN: 45001-52373"]
18	708-1W-25550	[1]	SPRING Komatsu China
			["SN: 45001-52373"] analogs:["890001347"]
19	708-1W-25561	[1]	PLUG Komatsu China
			["SN: 45001-52373"]
20	07000-12010	[1]	O-RING Komatsu	0.001 kg.
			["SN: 45001-52373"] analogs:["YM24311240100", "0700002010"]
21	07001-02010	[1]	RING,BACK-UP Komatsu	0.001 kg.
			["SN: 45001-52373"]
22	01583-11811	[1]	NUT Komatsu China	0.075 kg.
			["SN: 45001-52373"] analogs:["0158301811"]
23	708-1W-28910	[1]	O-RING Komatsu	0.001 kg.
			["SN: 45001-52373"] analogs:["0700262434"]
24	708-1W-25591	[1]	SEAT Komatsu China
			["SN: 45001-52373"]
25	708-1W-25580	[1]	SEAT Komatsu	0.002 kg.
			["SN: 45001-52373"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	708-1W-00042	[1]	PUMP ASS'Y Komatsu China
			["SN: 45001-52373"] analogs:["7081W01042"] \|1.
	704-24-24430	[1]	GEAR PUMP ASS'Y Komatsu	4.38 kg.
			["SN: 45001-52373"] \|1.
1	704-28-24430	[1]	CASE Komatsu China
			["SN: 45001-52373"]
	704-27-00610	[2]	BUSHING,PLANE Komatsu China
			["SN: 45001-52373"] \|1.
2	704-28-00010	[1]	COVER Komatsu China
			["SN: 45001-52373"]
3	704-28-24620	[1]	GEAR,DRIVE Komatsu China
			["SN: 45001-52373"]
4	704-28-24710	[1]	GEAR,DRIVEN Komatsu China
			["SN: 45001-52373"]
5	01252-31025	[4]	BOLT Komatsu	0.028 kg.
			["SN: 45001-52373"] analogs:["0125261025"]
6	04020-00616	[2]	PIN,DOWEL Komatsu	0.004 kg.
			["SN: 45001-52373"]
7	704-28-02751	[1]	STRAINER Komatsu	0.05 kg.
			["SN: 45001-52373"]
