KOMATSU 708-1T-00580 708-1T-01581 HYDRAULIC PUMP PARTS

KOMATSU 708-1T-00580 708-1T-01581 HYDRAULIC PUMP PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
708-1T-00580 708-1T-01581
PC490-10 PC490LC-10
Pos. Part No Qty Parts name Comments
     708-2J-00010   [1]   Pump Assembly, Piston Komatsu China
  ["SN: 80001-UP"] |$1.
        708-1T-00580   [1]   Pump Assembly, Piston Komatsu China
  ["SN: 80001-UP"] |$2.
     708-1T-01581   [1]   Pump Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$3.
     708-1T-04630   [1]   Case Assembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$4.
5   708-1T-13430   [1]   Cam, Rocker Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
6   04260-01270   [1]   Ball Komatsu OEM 0.009 kg.
  ["SN: 80001-UP", "SCC: C2"]
7   708-3S-14141   [1]   Spacer Komatsu 0.03 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["7083S14140"]
8   708-1S-13420   [2]   Pin Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
9   01252-60616   [1]   Bolt Komatsu 0.007 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["0125230616"]
10   708-1T-33432   [1]   Ball, Retainer Komatsu 0.000 kg.
  ["SN: 80001-UP", "SCC: C2"]
11   708-1T-33470   [1]   Ball, Retainer Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
12   01252-61235   [4]   Bolt Komatsu 0.048 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["801105554", "0125231235"]
13   04020-01024   [2]   Pin, Dowel Komatsu 0.015 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["PZF890001197"]
14   708-1T-19270   [1]   Plate Komatsu China
  ["SN: 80001-UP"]
15   07000-B2065   [1]   O-Ring Komatsu 0.002 kg.
  ["SN: 80001-UP"]
16   01010-61025   [4]   Bolt Komatsu China 0.03 kg.
  ["SN: 80001-UP"] analogs:["0101031025", "01010E1025", "0104041025"]
17   01643-31032   [4]   Washer Komatsu 0.054 kg.
  ["SN: 80001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
18   07002-61423   [1]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP"] analogs:["7082L23950"]
19   07040-11409   [1]   Plug Komatsu 0.033 kg.
  ["SN: 80001-UP"]
     708-1T-04641   [1]   Cap Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$24.
22   708-1S-12260   [1]   Bearing Komatsu 0.12 kg.
  ["SN: 80001-UP", "SCC: C2"]
23   720-68-19610   [1]   Pin Komatsu 0.002 kg.
  ["SN: 80001-UP", "SCC: C2"]
24   708-7T-05030   [1]   Spacer Kit Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
25   708-1S-12280   [1]   Ring, Wear Komatsu 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
26   708-1S-12330   [1]   Retainer Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
27   07000-B1006   [1]   O-Ring Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
28   07000-B2130   [1]   O-Ring Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
29   708-3T-11310   [1]   Orifice Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
30   708-2L-25480   [1]   Filter Komatsu OEM 0.5 kg.
  ["SN: 80001-UP"]
31   708-2L-25490   [1]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
32   708-1L-25210   [2]   Plug Komatsu 0.3 kg.
  ["SN: 80001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2J-00010   [1]   Pump Assembly, Piston Komatsu China
  ["SN: 80001-UP"] |$0.
        708-1T-00580   [1]   Pump Assembly, Piston Komatsu China
  ["SN: 80001-UP"] |$1.
     708-1T-01581   [1]   Pump Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$2.
1   708-1T-12430   [1]   Shaft Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
2   706-73-40890   [1]   Bearing Komatsu 0.26 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["7088E12141"]
3   708-1S-12340   [1]   Case Komatsu 0.18 kg.
  ["SN: 80001-UP", "SCC: C2"]
4   708-21-12970   [1]   Seal, Oil Komatsu 0.046 kg.
  ["SN: 80001-UP"]
5   708-1S-12350   [1]   O-Ring Komatsu 0.003 kg.
  ["SN: 80001-UP"]
6   04065-06220   [1]   Ring, Snap Komatsu 0.013 kg.
  ["SN: 80001-UP"]
7   708-1T-13440   [1]   Cylinder Block Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
8   708-1T-13450   [1]   Plate, Valve Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
9   708-1T-13710   [2]   Washer Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
10   708-3S-13430   [1]   Spring Komatsu 0.07 kg.
  ["SN: 80001-UP", "SCC: C2"]
11   04065-03515   [1]   Ring, Snap Komatsu 0.003 kg.
  ["SN: 80001-UP", "SCC: C2"]
12   708-1T-13660   [1]   Guide, Retainer Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
13   708-1S-13380   [3]   Pin Komatsu 0.06 kg.
  ["SN: 80001-UP", "SCC: C2"]
14   708-1T-13670   [1]   Retainer, Shoe Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
15   708-1S-13520   [10]   Piston Subassembly Komatsu 0.09 kg.
  ["SN: 80001-UP", "SCC: C2"]
16   708-3S-14290   [1]   Piston Subassembly Komatsu 0.087 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["7081S14230", "7083S14250"]
17   708-1S-14241   [1]   Spring Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2J-00010   [1]   Pump Assembly, Piston Komatsu China
  ["SN: 80001-UP"] |$0.
        708-1T-00580   [1]   Pump Assembly, Piston Komatsu China
  ["SN: 80001-UP"] |$1.
     708-1T-03550   [1]   Valve Assembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$2.
     708-1S-03930   [1]   Body Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] analogs:["7081S15150"] |$3.
3   708-1S-15420   [1]   Piston Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
4   708-1S-15430   [1]   Sleeve Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
5   07002-61623   [1]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP"]
6   07000-B1010   [1]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP"]
7   708-1S-15470   [1]   Spool Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
8   708-1S-15240   [1]   Seat Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
9   708-1S-15441   [1]   Spring Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
10   723-56-31630   [1]   Plug Komatsu 0.02 kg.
  ["SN: 80001-UP", "SCC: C2"]
12   708-1S-15270   [1]   Lever Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
13   708-1S-15480   [1]   Retainer Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
14   708-1S-15280   [1]   Spacer Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
15   708-1S-15490   [1]   Plug Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
16   01582-11210   [1]   Nut Komatsu 0.015 kg.
  ["SN: 80001-UP"]
17   07000-B1006   [1]   O-Ring Komatsu China
  ["SN: 80001-UP"]
18   20B-27-11210   [1]   Bleeder Komatsu 0.02 kg.
  ["SN: 80001-UP"]
19   07040-11007   [2]   Plug Komatsu 0.014 kg.
  ["SN: 80001-UP"]
20   07002-61023   [2]   O-Ring Komatsu 0.22 kg.
  ["SN: 80001-UP"] analogs:["7082L23920"]
21   702-21-61500   [1]   Valve, Pilot Komatsu 0.000 kg.
  ["SN: 80001-UP"]
22   720-1L-15440   [1]   O-Ring Komatsu China
  ["SN: 80001-UP"]
23   720-1L-15430   [1]   O-Ring Komatsu China
  ["SN: 80001-UP"] analogs:["7291111170", "7291121140", "7291121000", "7291121120", "7291111110", "7291121130", "7291121160", "7291121110", "7291111160", "7291121100"]
24   702-21-54180   [2]   Screw Komatsu China
  ["SN: 80001-UP"]
25   702-16-58320   [2]   O-Ring Komatsu China
  ["SN: 80001-UP"]
26   01252-60635   [2]   Bolt Komatsu 0.011 kg.
  ["SN: 80001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2J-00010   [1]   Pump Assembly, Piston Komatsu China
  ["SN: 80001-UP"] |$0.
        708-1T-00580   [1]   Pump Assembly, Piston Komatsu China
  ["SN: 80001-UP"] |$1.
1   708-2L-25480   [2]   Filter Komatsu OEM 0.5 kg.
  ["SN: 80001-UP"]
2   708-2L-25490   [2]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP"]
3   708-1S-19710   [1]   Orifice Komatsu 0.002 kg.
  ["SN: 80001-UP", "SCC: C2"]
4   01252-60635   [3]   Bolt Komatsu 0.011 kg.
  ["SN: 80001-UP"]
5   01252-60650   [1]   Bolt Komatsu China
  ["SN: 80001-UP"]
6   07000-B3040   [1]   O-Ring Komatsu 0.002 kg.
  ["SN: 80001-UP"]
7   04020-00616   [2]   Pin, Dowel Komatsu 0.004 kg.
  ["SN: 80001-UP", "SCC: C2"]
8   708-1S-19930   [1]   Plug Komatsu 0.25 kg.
  ["SN: 80001-UP"]
9   723-60-22230   [1]   Ring, Back-Up Komatsu 0.001 kg.
  ["SN: 80001-UP"]
10   07000-B2016   [1]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP"]
11   07002-62434   [1]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP"] analogs:["7081W28910"]
12   708-3S-14240   [1]   Plug Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
13   708-3S-14261   [1]   Plug Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
14   07002-61223   [2]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["7082L23940"]
   15.   07000-A2110   [1]   O-Ring Komatsu China
  ["SN: 80001-UP"]
   16.   01010-81240   [4]   Bolt Komatsu 0.052 kg.
  ["SN: 80001-UP"] analogs:["801015573", "0101051240"]
   17.   01643-31232   [4]   Washer Komatsu 0.027 kg.
  ["SN: 80001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
