KOMATSU 706-88-00110 706-88-00111  706-88-00112 706-88-00150  706-88-00151 TRAVEL MOTOR ROTARY GROUP

KOMATSU 706-88-00110 706-88-00111  706-88-00112 706-88-00150  706-88-00151 TRAVEL MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
706-88-00110 706-88-00111
706-88-00112 706-88-00150
706-88-00151
BR500JG-1 PC300HD-7L PC300LC-6LC/HD-6LC/HD-6MH PC300LC-6LE/HD-6LE PC300LL-7L PC380LC-6K PC380LC-6K-J PC380LC-7K PC400-6 PC400-6Z PC400LC-6 PC400LC-6LC/HD-6LC PC400LC-6LK/HD-6LK PC400LC-6LM/HD-6LM PC400LC-6Z PC400ST-6 PC400ST-6LC PC450-6 PC450-6K PC450-6K-J PC450-6K-KE PC450-6Z PC450LC-6 PC450LC-6K PC450LC-6K-J PC450LC-6Z
Pos. Part No Qty Parts name Comments
     706-88-00151   [1]   MOTOR ASS'Y Komatsu 273.001 kg.
  ["SN: 30447-UP"] analogs:["7068800150"] |1.
     706-88-00150   [1]   MOTOR ASS'Y Komatsu 273.001 kg.
  ["SN: 30338-30446"] analogs:["7068800151"] |1.
     706-88-00112   [1]   MOTOR ASS'Y Komatsu China
  ["SN: 30338-30338"] analogs:["7068800111", "7068800110"] |1.
     706-88-00111   [1]   MOTOR ASS'Y Komatsu China
  ["SN: 30194-30337"] analogs:["7068800112", "7068800110"] |1.
     706-88-00110   [1]   MOTOR ASS'Y Komatsu China
  ["SN: 30001-30193"] analogs:["7068800111", "7068800112"] |1.
   1.   706-88-40140   [1]   CASE,MOTOR Komatsu 129 kg.
  ["SN: 30338-UP"] analogs:["7068840110"]
        706-88-40110   [1]   CASE,MOTOR Komatsu 129 kg.
  ["SN: 30001-30338"] analogs:["7068840140"] |1.
        706-88-00020   [1]   END COVER SUB ASS'Y Komatsu 58 kg.
  ["SN: 30001-UP"] |2.
3   706-88-00010   [1]   PLATE ASS'Y,VALVE Komatsu 3.14 kg.
  ["SN: 30001-UP"]
   6.   708-8K-15190   [1]   PIN,DOWEL Komatsu China
  ["SN: 30001-UP"]
   7.   706-77-72280   [4]   PLUG Komatsu 0.08 kg.
  ["SN: 30001-UP"]
   8.   07002-12034   [4]   O-RING Komatsu China 0.94 kg.
  ["SN: 30001-UP"] analogs:["0700002034", "0700202034", "0700012034"]
   9.   20B-27-11210   [1]   BLEEDER Komatsu 0.02 kg.
  ["SN: 30001-UP"]
   10.   706-88-50030   [1]   PISTON Komatsu China
  ["SN: 30001-UP"]
   11.   706-88-50010   [1]   PIN Komatsu China
  ["SN: 30001-UP"]
   12.   706-87-51120   [1]   SCREW Komatsu China
  ["SN: 30001-UP"]
   13.   706-75-74540   [2]   VALVE Komatsu 0.134 kg.
  ["SN: 30001-UP"]
   14.   706-75-74550   [2]   SPRING Komatsu 0.012 kg.
  ["SN: 30001-UP"]
   15.   706-75-74850   [2]   PLUG Komatsu China
  ["SN: 30001-UP"]
   16.   07002-13334   [2]   O-RING Komatsu China 0.025 kg.
  ["SN: 30001-UP"] analogs:["0700203334"]
   17.   706-78-71170   [2]   PISTON Komatsu 0.16 kg.
  ["SN: 30194-UP"]
        706-78-71160   [2]   PISTON Komatsu China
  ["SN: 30001-30193"] |17.
   18.   708-8H-36121   [2]   SPRING Komatsu China
  ["SN: 30001-UP"]
   19.   706-78-71140   [2]   PLUG Komatsu China
  ["SN: 30001-UP"]
   20.   07002-13634   [2]   O-RING Komatsu China 0.013 kg.
  ["SN: 30001-UP"] analogs:["0700203634"]
   21.   706-88-50110   [1]   SLEEVE Komatsu China
  ["SN: 30001-UP"]
   22.   07002-15234   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: 30001-UP"] analogs:["855021829", "0700205234"]
   23.   07000-13035   [1]   O-RING Komatsu China 0.03 kg.
  ["SN: 30001-UP"] analogs:["0700003035"]
   24.   07001-03035   [1]   RING,BACK-UP Komatsu 0.01 kg.
  ["SN: 30001-UP"]
   25.   07000-13038   [1]   O-RING Komatsu China 0.03 kg.
  ["SN: 30001-UP"] analogs:["0700213038"]
   26.   07001-03038   [1]   RING,BACK-UP Komatsu 0.001 kg.
  ["SN: 30001-UP"]
   27.   706-8E-14170   [1]   SPRING Komatsu 0.01 kg.
  ["SN: 30001-UP"]
   28.   706-88-50140   [1]   SPOOL Komatsu China
  ["SN: 30001-UP"]
   29.   706-88-50160   [1]   PLUG Komatsu China
  ["SN: 30001-UP"]
   30.   07002-13034   [1]   O-RING Komatsu China 0.005 kg.
  ["SN: 30001-UP"] analogs:["0700203034"]
   31.   706-88-50170   [1]   PLUG Komatsu China
  ["SN: 30001-UP"]
   33.   04260-00793   [2]   BALL Komatsu 0.005 kg.
  ["SN: 30001-UP"]
   34.   706-8E-14110   [2]   PLUG Komatsu China
  ["SN: 30001-UP"] analogs:["7088E14110"]
   35.   07002-11023   [2]   O-RING Komatsu China 0.025 kg.
  ["SN: 30001-UP"] analogs:["0700201023"]
   36.   708-8E-16180   [1]   VALVE Komatsu 0.004 kg.
  ["SN: 30001-UP"]
   37.   706-78-71150   [1]   VALVE Komatsu China
  ["SN: 30001-UP"]
   38.   708-8E-16160   [2]   PLUG Komatsu 0.01 kg.
  ["SN: 30001-UP"]
   40.   706-78-71130   [1]   PLUG Komatsu China
  ["SN: 30001-UP"]
   41.   07002-11423   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 30001-UP"] analogs:["0700201423"]
   42.   07000-11007   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 30001-UP"] analogs:["YM24311000070", "0700001007"]
   43.   07001-01007   [1]   RING,BACK-UP Komatsu 0.001 kg.
  ["SN: 30001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-88-00151   [1]   MOTOR ASS'Y Komatsu 273.001 kg.
  ["SN: 30447-UP"] analogs:["7068800150"] |1.
     706-88-00150   [1]   MOTOR ASS'Y Komatsu 273.001 kg.
  ["SN: 30338-30446"] analogs:["7068800151"] |1.
     706-88-00112   [1]   MOTOR ASS'Y Komatsu China
  ["SN: 30338-30338"] analogs:["7068800111", "7068800110"] |1.
     706-88-00111   [1]   MOTOR ASS'Y Komatsu China
  ["SN: 30194-30337"] analogs:["7068800112", "7068800110"] |1.
     706-88-00110   [1]   MOTOR ASS'Y Komatsu China
  ["SN: 30001-30193"] analogs:["7068800111", "7068800112"] |1.
   1.   706-88-40370   [1]   O-RING Komatsu 0.01 kg.
  ["SN: 30001-UP"]
   2.   07000-12012   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 30001-UP"] analogs:["0700002012", "7082E11790"]
   3.   706-88-40310   [8]   BOLT Komatsu China
  ["SN: 30001-UP"]
   4.   706-88-40660   [1]   SHAFT,DRIVE Komatsu 10.7 kg.
  ["SN: 30001-UP"]
   5.   706-88-40880   [1]   BEARING Komatsu 5.713 kg.
  ["SN: 30001-UP"] analogs:["7068840870"]
   6.   706-88-40890   [1]   BEARING Komatsu 1.745 kg.
  ["SN: 30001-UP"]
   7.   706-88-40810   [1]   RETAINER Komatsu 0.9 kg.
  ["SN: 30001-UP"]
   8.   706-88-05010   [1]   SPACER KIT Komatsu 0.444 kg.
  ["SN: 30001-UP"]
   9.   04064-07525   [1]   RING,SNAP Komatsu 0.026 kg.
  ["SN: 30001-UP"]
   10.   708-8K-12141   [1]   SEAL,OIL Komatsu 0.143 kg.
  ["SN: 30001-UP"]
   11.   706-88-40710   [1]   HOUSING Komatsu 1.2 kg.
  ["SN: 30001-UP"]
   12.   07000-02135   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: 30001-UP"]
   13.   04071-00140   [1]   RING,SNAP Komatsu 0.13 kg.
  ["SN: 30001-UP"]
   14.   706-88-40090   [1]   BLOCK,CYLINDER Komatsu 10.5 kg.
  ["SN: 30001-UP"]
   15.   706-88-40080   [1]   SHAFT,CENTER Komatsu 0.986 kg.
  ["SN: 30001-UP"]
   16.   706-88-40130   [1]   RING,CENTER Komatsu 0.2 kg.
  ["SN: 30001-UP"]
   17.   706-88-40060   [1]   SPRING Komatsu 0.23 kg.
  ["SN: 30001-UP"]
        706-88-05020   [1]   RETAINER KIT Komatsu 0.61 kg.
  ["SN: 30001-UP"] analogs:["7068840260"] |18.
   20.   706-88-40162   [7]   PISTON SUB ASS'Y Komatsu 0.842 kg.
  ["SN: 30447-UP"] analogs:["7068840160", "7068840161"]
        706-88-40160   [7]   PISTON SUB ASS'Y Komatsu 0.842 kg.
  ["SN: 30194-30446"] analogs:["7068840162", "7068840161", "R7068840160"] |20.
        706-88-40161   [7]   PISTON SUB ASS'Y Komatsu 0.842 kg.
  ["SN: 30001-30193"] analogs:["7068840162", "7068840160"] |20.
   21.   706-88-90140   [4]   PLATE Komatsu 0.378 kg.
  ["SN: 30001-UP"]
   22.   706-88-90150   [3]   DISC Komatsu 0.32 kg.
  ["SN: 30001-UP"]
   23.   706-88-90180   [1]   PISTON,BRAKE Komatsu China
  ["SN: 30001-UP"]
   24.   07000-15240   [1]   O-RING Komatsu OEM 0.055 kg.
  ["SN: 30001-UP"] analogs:["0700005240"]
   25.   706-88-90130   [1]   RING,BACK-UP Komatsu 0.03 kg.
  ["SN: 30001-UP"]
   26.   07000-15270   [1]   O-RING Komatsu OEM 0.029 kg.
  ["SN: 30001-UP"] analogs:["0700005270"]
   27.   07001-05270   [1]   RING,BACK-UP Komatsu 0.02 kg.
  ["SN: 30001-UP"]
   28.   706-88-90410   [6]   SPRING Komatsu China
  ["SN: 30001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-88-00151   [1]   MOTOR ASS'Y Komatsu 273.001 kg.
  ["SN: 30447-UP"] analogs:["7068800150"] |1.
     706-88-00150   [1]   MOTOR ASS'Y Komatsu 273.001 kg.
  ["SN: 30338-30446"] analogs:["7068800151"] |1.
     706-88-00112   [1]   MOTOR ASS'Y Komatsu China
  ["SN: 30338-30338"] analogs:["7068800111", "7068800110"] |1.
     706-88-00111   [1]   MOTOR ASS'Y Komatsu China
  ["SN: 30194-30337"] analogs:["7068800112", "7068800110"] |1.
     706-88-00110   [1]   MOTOR ASS'Y Komatsu China
  ["SN: 30001-30193"] analogs:["7068800111", "7068800112"] |1.
        702-75-04200   [1]   VALVE ASS'Y,RELIEF Komatsu 0.85 kg.
  ["SN: 30001-UP"] |1.
18   07002-13034   [1]   O-RING Komatsu China 0.005 kg.
  ["SN: 30001-UP"] analogs:["0700203034"]
21   07000-22018   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 30001-UP"] analogs:["07000F2018"]
22   07001-02018   [2]   RING,BACK-UP Komatsu 0.001 kg.
  ["SN: 30001-UP"]
23   07000-12021   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: 30001-UP"] analogs:["0700002021"]
24   07001-02021   [1]   RING,BACK-UP Komatsu 0.061 kg.
  ["SN: 30001-UP"]
25   702-75-11520   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 30001-UP"]
26   702-75-11530   [1]   RING,BACK-UP Komatsu 0.001 kg.
  ["SN: 30001-UP"]
27   07002-13634   [1]   O-RING Komatsu China 0.013 kg.
  ["SN: 30001-UP"] analogs:["0700203634"]
