KOMATSU 706-7K-01170 706-7K-03140 SWING MOTOR ROTARY GROUP AND SPARE PARTS

KOMATSU 706-7K-01170 706-7K-03140 SWING MOTOR ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
706-7K-01170 706-7K-03140
PC300-7 PC300LC-7 PC350-7 PC400-7 PC400LC-7 PC450-7 PC450LC-7
PC220LL-8 PC300-8 PC350-8 PC350LC-8 PC350HD-8 PC350NLC-8 PC400-8 PC400LC-8 PC400-8R PC400LC-8R PC450-8 PC450-8R PC450LC-8R PC450LCHD-8
Pos. Part No Qty Parts name Comments
     706-7K-01170   [1]   MOTOR ASS'Y Komatsu 123.8 kg.
  ["SN: 50001-UP"] analogs:["7067K01040", "7067K01070"] |$1.
        706-7K-03140   [1]   MOTOR SUB ASS'Y Komatsu China
  ["SN: 50001-UP"] |$4.
1   706-7K-41150   [1]   CASE,MOTOR Komatsu 32 kg.
  ["SN: 50001-UP"] analogs:["7067K41151"]
2   706-7K-71110   [1]   HOUSING Komatsu 37 kg.
  ["SN: 50001-UP"]
3   706-7K-40010   [1]   BEARING Komatsu 0.15 kg.
  ["SN: 50001-UP"]
4   706-75-42830   [1]   PIN,DOWEL Komatsu 0.02 kg.
  ["SN: 50001-UP"]
5   706-77-72280   [1]   PLUG Komatsu 0.08 kg.
  ["SN: 50001-UP"]
6   07002-62034   [1]   O-RING Komatsu 0.94 kg.
  ["SN: 50001-UP"]
7   709-74-92810   [2]   VALVE Komatsu 0.063 kg.
  ["SN: 50001-UP"]
8   709-75-92220   [2]   SPRING Komatsu 0.001 kg.
  ["SN: 50001-UP"]
9   709-74-92821   [2]   PLUG Komatsu 0.4 kg.
  ["SN: 50001-UP"]
10   708-2L-23960   [2]   O-RING Komatsu 0.001 kg.
  ["SN: 50001-UP"]
11   700-93-11330   [2]   RING,BACK-UP Komatsu 0.01 kg.
  ["SN: 50001-UP"]
12   706-77-72130   [2]   VALVE Komatsu 0.31 kg.
  ["SN: 50001-UP"]
13   706-77-72140   [2]   SPRING Komatsu 0.02 kg.
  ["SN: 50001-UP"]
14   706-77-72150   [2]   PLUG Komatsu 0.52 kg.
  ["SN: 50001-UP"]
15   07002-64234   [2]   O-RING Komatsu 1.82 kg.
  ["SN: 50001-UP"]
16   706-7K-40040   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 50001-UP"]
17   01252-61450   [10]   BOLT Komatsu 0.087 kg.
  ["SN: 50001-UP"] analogs:["7051703370"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-7K-01170   [1]   MOTOR ASS'Y,(SEE FIG. Y1640-01A0) Komatsu 123.8 kg.
  ["SN: 50001-UP"] analogs:["7067K01040", "7067K01070"] |$1.
        706-7K-03140   [1]   MOTOR SUB ASS'Y,(SEE FIG. Y1640-01A0) Komatsu China
  ["SN: 50001-UP"] |$3.
1   706-7K-41610   [1]   SHAFT Komatsu 8.062 kg.
  ["SN: 50001-UP"]
2   706-77-43890   [1]   BEARING Komatsu 5.5 kg.
  ["SN: 50001-UP"] analogs:["7067743880"]
3   706-7K-41810   [1]   SPACER Komatsu 0.8 kg.
  ["SN: 50001-UP"]
4   706-77-42051   [2]   SPRING Komatsu 0.14 kg.
  ["SN: 50001-UP"]
5   706-77-42041   [1]   SEAT Komatsu 0.1 kg.
  ["SN: 50001-UP"]
6   706-77-42890   [1]   BEARING Komatsu 1.185 kg.
  ["SN: 50001-UP"]
7   706-77-05010   [1]   SPACER KIT Komatsu 0.172 kg.
  ["SN: 50001-UP"]
8   04064-06525   [1]   RING,SNAP Komatsu China 0.021 kg.
  ["SN: 50001-UP"]
9   706-8J-41420   [1]   SEAL,OIL Komatsu 0.662 kg.
  ["SN: 50001-UP"]
10   706-7K-41920   [1]   SPACER Komatsu 0.04 kg.
  ["SN: 50001-UP"]
11   04065-07525   [1]   RING Komatsu 0.021 kg.
  ["SN: 50001-UP"]
12   706-7K-41210   [1]   BLOCK,CYLINDER Komatsu 5.2 kg.
  ["SN: 50001-UP"]
13   706-7K-41710   [1]   PLATE,VALVE Komatsu 0.9 kg.
  ["SN: 50001-UP"]
14   708-18-13230   [1]   PIN Komatsu 0.01 kg.
  ["SN: 50001-UP"]
15   706-7K-41120   [1]   SHAFT,CENTER Komatsu 0.62 kg.
  ["SN: 50001-UP"]
16   706-77-42130   [1]   RING,CENTER Komatsu 0.1 kg.
  ["SN: 50001-UP"]
17   706-7K-41140   [1]   SPRING Komatsu 0.21 kg.
  ["SN: 50001-UP"]
     706-7K-05010   [1]   RETAINER KIT Komatsu 0.45 kg.
  ["SN: 50001-UP"] |$24.
20   706-7K-41160   [7]   PISTON SUB ASS'Y Komatsu 6.78 kg.
  ["SN: 50001-UP"]
21   706-7K-91340   [5]   PLATE Komatsu 1 kg.
  ["SN: 50001-UP"]
22   706-7K-91350   [4]   DISC Komatsu 0.24 kg.
  ["SN: 50001-UP"]
23   706-7K-91111   [1]   PISTON,BRAKE Komatsu 3.99 kg.
  ["SN: 50001-UP"]
24   07000-B5230   [1]   O-RING Komatsu 0.033 kg.
  ["SN: 50001-UP"]
25   706-86-90290   [1]   O-RING Komatsu 0.038 kg.
  ["SN: 50001-UP"]
26   706-7K-91360   [6]   SPRING Komatsu 0.17 kg.
  ["SN: 50001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-7K-01170   [1]   MOTOR ASS'Y,(SEE FIG. Y1640-01A0) Komatsu 123.8 kg.
  ["SN: 50001-UP"] analogs:["7067K01040", "7067K01070"] |$1.
   1.   702-77-02170   [1]   VALVE ASS'Y,RELIEF Komatsu China
  ["SN: 50001-UP"]
2   07000-F3022   [1]   O-RING Komatsu China 0.002 kg.
  ["SN: 50001-UP"] analogs:["0700023022"]
3   07001-03022   [1]   RING,BACK-UP Komatsu 0.01 kg.
  ["SN: 50001-UP"]
4   07002-63634   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 50001-UP"] analogs:["7082L24620"]
        702-15-80000   [1]   VALVE ASS'Y Komatsu China
  ["SN: 50001-UP"] |$7.
7   706-7K-40050   [2]   SEAL Komatsu China
  ["SN: 50001-UP"]
8   702-15-71130   [2]   SPRING Komatsu 0.005 kg.
  ["SN: 50001-UP"]
9   702-15-71140   [2]   PLUG Komatsu China
  ["SN: 50001-UP"]
10   07002-61423   [2]   O-RING Komatsu 0.001 kg.
  ["SN: 50001-UP"] analogs:["7082L23950"]
   11.   07000-B3042   [1]   O-RING Komatsu 0.002 kg.
  ["SN: 50001-UP"]
   12.   07000-B1009   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: 50001-UP"] analogs:["7082L23910"]
   13.   01252-60825   [2]   BOLT Komatsu 0.017 kg.
  ["SN: 50001-UP"] analogs:["0125240825", "0125230825"]
