706-7K-01150 706-7K-03150
PC240LL-10 PC360LC-10 PC360NLC-10 PC390LC-10 PC390LL-10 PC490-10 PC490-11 PC490-11E0 PC490LC-10 PC490LC-11 PC490LC-11E0 PC490LC1-11 PC490HRD-11E0 PC500LC-10R PC500LC-10MO |
|
№
|
Number |
Qty |
Name |
Options |
|
706-7K-01150
|
1
|
Swing Motor Assembly |
SN: 100001-
|
|
706-7K-03150
|
1
|
Motor Subassembly |
SN: 100001-
|
| 1
|
706-7K-41151
|
1
|
Case |
SN: 100001-
|
| 2
|
706-7K-71120
|
1
|
Housing |
SN: 100001-
|
| 3
|
706-7K-40010
|
1
|
Bearing |
SN: 100001-
|
| 4
|
706-75-42830
|
1
|
Pin, Dowel |
SN: 100001-
|
| 5
|
706-77-72280
|
1
|
Plug |
SN: 100001-
|
| 6
|
07002-62034
|
1
|
O-ring |
SN: 100001-
|
| 7
|
709-74-92810
|
2
|
Valve |
SN: 100001-
|
| 8
|
709-75-92220
|
2
|
Spring |
SN: 100001-
|
| 9
|
709-74-92821
|
2
|
Plug |
SN: 100001-
|
| 10
|
708-2L-23960
|
2
|
O-ring |
SN: 100001-
|
| 11
|
700-93-11330
|
2
|
Ring, Back-up |
SN: 100001-
|
| 12
|
706-77-72130
|
2
|
Valve |
SN: 100001-
|
| 13
|
706-77-72140
|
2
|
Spring |
SN: 100001-
|
| 14
|
706-77-72150
|
2
|
Plug |
SN: 100001-
|
| 15
|
07002-64234
|
2
|
O-ring |
SN: 100001-
|
| 16
|
706-7K-40040
|
1
|
O-ring |
SN: 100001-
|
| 17
|
01252-61450
|
10
|
Bolt, Hexagon Socket Head |
SN: 100001-
|
|
№
|
Number |
Qty |
Name |
Options |
|
706-7K-01150
|
1
|
Swing Motor Assembly |
SN: 100001-
|
|
706-7K-03150
|
1
|
Motor Subassembly |
SN: 100001-
|
| 1
|
706-7K-41610
|
1
|
Shaft |
SN: 100001-
|
| 2
|
706-77-43890
|
1
|
Bearing |
SN: 100001-
|
| 3
|
706-7K-41810
|
1
|
Spacer |
SN: 100001-
|
| 4
|
706-77-42051
|
2
|
Spring |
SN: 100001-
|
| 5
|
706-77-42041
|
1
|
Seat |
SN: 100001-
|
| 6
|
706-77-42890
|
1
|
Bearing |
SN: 100001-
|
| 7
|
706-77-05010
|
1
|
Spacer Kit |
SN: 100001-
|
|
|
2
|
Spacer, T=2.3mm |
SN: 100001-
|
|
|
2
|
Spacer, T=2.5mm |
SN: 100001-
|
|
|
2
|
Spacer, T=2.7mm |
SN: 100001-
|
| 8
|
04064-06525
|
1
|
Ring, Snap, for Shaft Side |
SN: 100001-
|
| 9
|
706-8J-41420
|
1
|
Seal, Oil |
SN: 100001-
|
| 10
|
706-7K-41920
|
1
|
Spacer |
SN: 100001-
|
| 11
|
04065-07525
|
1
|
Ring, Snap, for Hole Side |
SN: 100001-
|
| 12
|
706-7K-41210
|
1
|
Cylinder Block |
SN: 100001-
|
| 13
|
706-7K-41710
|
1
|
Plate |
SN: 100001-
|
| 14
|
708-18-13230
|
1
|
Pin |
SN: 100001-
|
| 15
|
706-7K-41120
|
1
|
Shaft |
SN: 100001-
|
| 16
|
706-77-42130
|
1
|
Ring |
SN: 100001-
|
| 17
|
706-7K-41140
|
1
|
Spring |
SN: 100001-
|
|
706-7K-05010
|
1
|
Retainer Kit |
SN: 100001-
|
| 18
|
|
1
|
Retainer |
SN: 100001-
|
| 19
|
|
7
|
Screw |
SN: 100001-
|
| 20
|
706-7K-41160
|
7
|
Piston Subassembly |
SN: 100001-
|
| 21
|
706-7K-91340
|
5
|
Plate |
SN: 100001-
|
| 22
|
706-7K-91350
|
4
|
Disc |
SN: 100001-
|
| 23
|
706-7K-91111
|
1
|
Brake Piston |
SN: 100001-
|
| 24
|
07000-B5230
|
1
|
O-ring |
SN: 100001-
|
| 25
|
706-86-90290
|
1
|
O-ring |
SN: 100001-
|
| 26
|
706-7K-91360
|
6
|
Spring |
SN: 100001-
|
|
№
|
Number |
Qty |
Name |
Options |
|
706-7K-01150
|
1
|
Swing Motor Assembly |
SN: 100001-
|
| 1
|
702-77-02180
|
1
|
Valve, Relief |
SN: 100001-
|
| 2
|
07000-F3022
|
1
|
O-ring |
SN: 100001-
|
| 3
|
07001-03022
|
1
|
Ring, Back-up |
SN: 100001-
|
| 4
|
07002-63634
|
1
|
O-ring |
SN: 100001-
|
|
702-15-80000
|
1
|
Valve Assembly |
SN: 100001-
|
| 5
|
|
1
|
Body |
SN: 100001-
|
| 6
|
|
2
|
Spool |
SN: 100001-
|
| 7
|
|
2
|
Seal |
SN: 100001-
|
| 8
|
702-15-71130
|
2
|
Spring |
SN: 100001-
|
| 9
|
702-15-71140
|
2
|
Plug |
SN: 100001-
|
| 10
|
07002-61423
|
2
|
O-ring |
SN: 100001-
|
| 11
|
07000-B3042
|
1
|
O-ring |
SN: 100001-
|
| 12
|
07000-B1009
|
2
|
O-ring |
SN: 100001-
|
| 13
|
01252-60825
|
2
|
Bolt, Hexagon Socket Head |
SN: 100001-
|
|
№
|
Number |
Qty |
Name |
Options |
| 1
|
207-26-71240
|
1
|
Ring |
SN: 100001-
|
| 2
|
07040-11209
|
1
|
Plug |
SN: 100001-
|
| 3
|
07002-11223
|
1
|
O-ring |
SN: 100001-
|
| 4
|
02781-00628
|
1
|
Union |
SN: 100001-
|
| 5
|
07002-12434
|
1
|
O-ring |
SN: 100001-
|
| 6
|
02896-11018
|
1
|
O-ring |
SN: 100001-
|
| 7
|
02771-00606
|
1
|
Hose |
SN: 100001-
|
| 8
|
2A8-26-11310
|
1
|
Elbow |
SN: 100001-
|
| 9
|
02896-11018
|
1
|
O-ring |
SN: 100001-
|
| 10
|
07040-12412
|
1
|
Plug |
SN: 100001-
|
| 11
|
07002-12434
|
1
|
O-ring |
SN: 100001-
|
| 12
|
01010-81240
|
10
|
Bolt |
SN: 100001-
|
| 13
|
01643-31232
|
10
|
Washer |
SN: 100001-
|
| 14
|
208-26-71510
|
1
|
Gauge |
SN: 100001-
|
| 15
|
208-26-71520
|
1
|
Filler |
SN: 100001-
|
| 16
|
208-871-5162
|
1
|
Bracket |
SN: 100001-
|
| 17
|
22P-70-12160
|
2
|
Nut |
SN: 100001-
|
| 18
|
01643-31032
|
2
|
Washer |
SN: 100001-
|
| 19
|
07283-32738
|
1
|
Clip, Pipe |
SN: 100001-
|
| 20
|
01010-81030
|
2
|
Bolt |
SN: 100001-
|
| 21
|
01643-31032
|
2
|
Washer |
SN: 100001-
|
| 22
|
07000-15335
|
1
|
O-ring |
SN: 100001-
|
| 23
|
01010-82480
|
17
|
Bolt |
SN: 100001-
|
| 24
|
01643-32460
|
17
|
Washer |
SN: 100001-
|
| 25
|
01010-81240
|
2
|
Bolt |
SN: 100001-
|
| 26
|
01643-31232
|
2
|
Washer |
SN: 100001-
|
