KOMATSU 706-7K-01150 706-7K-03150 SWING MOTOR ROTARY GROUP

KOMATSU 706-7K-01150 706-7K-03150 SWING MOTOR ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
706-7K-01150 706-7K-03150
PC360LC-10 PC360NLC-10 PC390LC-10 PC390LL-10 PC490-10 PC490LC-10
Pos. Part No Qty Parts name Comments
   706-7K-01150 [1]   Swing Motor Assembly Komatsu China
  ["SN: 80001-UP"] analogs:["R7067K01150"] |$0.
        706-7K-03150   [1]   Motor Subassembly Komatsu China
  ["SN: 80001-UP"] |$1.
1   706-7K-41150   [1]   Case Komatsu 32 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["7067K41151"]
2   706-7K-71120   [1]   Housing Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
3   706-7K-40010   [1]   Bearing Komatsu 0.15 kg.
  ["SN: 80001-UP", "SCC: C2"]
4   706-75-42830   [1]   Pin, Dowel Komatsu 0.02 kg.
  ["SN: 80001-UP", "SCC: C2"]
5   706-77-72280   [1]   Plug Komatsu 0.08 kg.
  ["SN: 80001-UP"]
6   07002-62034   [1]   O-Ring Komatsu 0.94 kg.
  ["SN: 80001-UP"]
7   709-74-92810   [2]   Valve Komatsu 0.063 kg.
  ["SN: 80001-UP"]
8   709-75-92220   [2]   Spring Komatsu 0.001 kg.
  ["SN: 80001-UP"]
9   709-74-92821   [2]   Plug Komatsu 0.4 kg.
  ["SN: 80001-UP"]
10   708-2L-23960   [2]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP"]
11   700-93-11330   [2]   Ring, Back-Up Komatsu 0.01 kg.
  ["SN: 80001-UP"]
12   706-77-72130   [2]   Valve Komatsu 0.31 kg.
  ["SN: 80001-UP"]
13   706-77-72140   [2]   Spring Komatsu 0.02 kg.
  ["SN: 80001-UP"]
14   706-77-72150   [2]   Plug Komatsu 0.52 kg.
  ["SN: 80001-UP"]
15   07002-64234   [2]   O-Ring Komatsu 1.82 kg.
  ["SN: 80001-UP"]
16   706-7K-40040   [1]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
17   01252-61450   [10]   Bolt Komatsu 0.087 kg.
  ["SN: 80001-UP"] analogs:["7051703370"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-7K-01150   [1]   Swing Motor Assembly Komatsu China
  ["SN: 80001-UP"] analogs:["R7067K01150"] |$0.
        706-7K-03150   [1]   Motor Subassembly Komatsu China
  ["SN: 80001-UP"] |$1.
1   706-7K-41610   [1]   Shaft Komatsu 8.062 kg.
  ["SN: 80001-UP", "SCC: C2"]
2   706-77-43890   [1]   Bearing Komatsu 5.5 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["7067743880"]
3   706-7K-41810   [1]   Spacer Komatsu 0.8 kg.
  ["SN: 80001-UP", "SCC: C2"]
4   706-77-42051   [2]   Spring Komatsu 0.14 kg.
  ["SN: 80001-UP", "SCC: C2"]
5   706-77-42041   [1]   Seat Komatsu 0.1 kg.
  ["SN: 80001-UP", "SCC: C2"]
6   706-77-42890   [1]   Bearing Komatsu 1.185 kg.
  ["SN: 80001-UP", "SCC: C2"]
7   706-77-05010   [1]   Spacer Kit Komatsu 0.172 kg.
  ["SN: 80001-UP", "SCC: C2"]
8   04064-06525   [1]   Ring, Snap, for Shaft Side Komatsu China 0.021 kg.
  ["SN: 80001-UP", "SCC: C2"]
9   706-8J-41420   [1]   Seal, Oil Komatsu 0.662 kg.
  ["SN: 80001-UP"]
10   706-7K-41920   [1]   Spacer Komatsu 0.04 kg.
  ["SN: 80001-UP"]
11   04065-07525   [1]   Ring, Snap, for Hole Side Komatsu 0.021 kg.
  ["SN: 80001-UP"]
12 706-7K-41210 [1]   Cylinder Block Komatsu 5.2 kg.
  ["SN: 80001-UP", "SCC: C2"]
13   706-7K-41710   [1]   Plate Komatsu 0.9 kg.
  ["SN: 80001-UP", "SCC: C2"]
14   708-18-13230   [1]   Pin Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
15   706-7K-41120   [1]   Shaft Komatsu 0.62 kg.
  ["SN: 80001-UP", "SCC: C2"]
16   706-77-42130   [1]   Ring Komatsu 0.1 kg.
  ["SN: 80001-UP", "SCC: C2"]
17   706-7K-41140   [1]   Spring Komatsu 0.21 kg.
  ["SN: 80001-UP", "SCC: C2"]
17   706-7K-05010   [1]   Retainer Kit Komatsu 0.45 kg.
  ["SN: 80001-UP", "SCC: C2"]
20   706-7K-41160   [7]   Piston Subassembly Komatsu 6.78 kg.
  ["SN: 80001-UP", "SCC: C2"]
21   706-7K-91340   [5]   Plate Komatsu 1 kg.
  ["SN: 80001-UP", "SCC: C2"]
22   706-7K-91350   [4]   Disc Komatsu 0.24 kg.
  ["SN: 80001-UP", "SCC: C2"]
23   706-7K-91111   [1]   Brake Piston Komatsu 3.99 kg.
  ["SN: 80001-UP", "SCC: C2"]
24   07000-B5230   [1]   O-Ring Komatsu 0.033 kg.
  ["SN: 80001-UP", "SCC: C2"]
25   706-86-90290   [1]   O-Ring Komatsu 0.038 kg.
  ["SN: 80001-UP", "SCC: C2"]
26   706-7K-91360   [6]   Spring Komatsu 0.17 kg.
  ["SN: 80001-UP", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-7K-01150   [1]   Swing Motor Assembly Komatsu China
  ["SN: 80001-UP"] analogs:["R7067K01150"] |$0.
   1.   702-77-02180   [1]   Valve, Relief Komatsu China
  ["SN: 80001-UP"]
2   07000-F3022   [1]   O-Ring Komatsu China 0.002 kg.
  ["SN: 80001-UP"] analogs:["0700023022"]
3   07001-03022   [1]   Ring, Back-Up Komatsu 0.01 kg.
  ["SN: 80001-UP"]
4   07002-13634   [1]   O-Ring Komatsu China 0.013 kg.
  ["SN: 80001-UP"] analogs:["0700203634"]
        702-15-80000   [1]   Valve Assembly Komatsu China
  ["SN: 80001-UP"] |$5.
8   702-15-71130   [2]   Spring Komatsu 0.005 kg.
  ["SN: 80001-UP"]
9   702-15-71140   [2]   Plug Komatsu China
  ["SN: 80001-UP"]
10   07002-61423   [2]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP"] analogs:["7082L23950"]
   11.   07000-B3042   [1]   O-Ring Komatsu 0.002 kg.
  ["SN: 80001-UP"]
   12.   07000-B1009   [2]   O-Ring Komatsu China 0.001 kg.
  ["SN: 80001-UP"] analogs:["7082L23910"]
   13.   01252-60825   [2]   Bolt Komatsu 0.017 kg.
  ["SN: 80001-UP"] analogs:["0125240825", "0125230825"]
Parts on group :
Pos. Part No Qty Parts name Comments
1   02781-00522   [1]   Union Komatsu 0.16 kg.
  ["SN: 80001-UP"]
2   02896-11015   [1]   O-Ring Komatsu 0.21 kg.
  ["SN: 80001-UP"] analogs:["21D0969770", "855051016"]
3   07002-12434   [1]   O-Ring Komatsu China 0.01 kg.
  ["SN: 80001-UP"] analogs:["0700202434", "0700213434"]
4   21W-62-42640   [1]   Elbow Komatsu 1.25 kg.
  ["SN: 80001-UP"]
5   207-62-64740   [1]   O-Ring Komatsu 0.01 kg.
  ["SN: 80001-UP"]
6   07002-13334   [1]   O-Ring Komatsu China 0.025 kg.
  ["SN: 80001-UP"] analogs:["0700203334"]
7   11Y-62-12510   [1]   Elbow Komatsu 0.2 kg.
  ["SN: 80001-UP"]
8   02896-11009   [1]   O-Ring Komatsu China 0.01 kg.
  ["SN: 80001-UP"] analogs:["R0289611009", "0286911009"]
9   07002-11423   [1]   O-Ring Komatsu China 0.001 kg.
  ["SN: 80001-UP"] analogs:["0700201423"]
10   02781-0021D   [1]   Union Komatsu 0.04 kg.
  ["SN: 80001-UP"]
11   02896-11008   [1]   O-Ring Komatsu China 0.12 kg.
  ["SN: 80001-UP"]
13   208-62-41572   [-1]   Hose Komatsu China
14   208-62-72131   [-1]   Hose Komatsu China 0.4 kg.
15   02762-005A9   [-1]   Hose, Face Seal Type Komatsu China 0.867 kg.
16   02762-002A8   [-1]   Hose, Face Seal Type Komatsu China 0.5 kg.
