KOMATSU 706-77-01311 706-77-01380 706-77-03130 SWING MOTOR ROTARY GROUP AND SPARE PARTS

Name: KOMATSU 706-77-01311 706-77-01380 706-77-03130 SWING MOTOR ROTARY GROUP AND SPARE PARTS
Brand: 13035309093
Price: 5000.0 USD
Availability: InStock

KOMATSU 706-77-01311 706-77-01380 706-77-03130 SWING MOTOR ROTARY GROUP AND SPARE PARTS

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

706-77-01311 706-77-01380 706-77-03130 PC300-6 PC300-6Z PC300LC-6 PC300LC-6LC/HD-6LC/HD-6MH PC300LC-6LE/HD-6LE PC300LC-6Z PC300LL-6 PC300LL-7L PC300SC-6 PC340LC-6K-J PC340NLC-6 PC350-6 PC350-6Z PC350LC-6 PC350LC-6Z PC380LC-6K-J PC400-6 PC400-6Z PC400LC-6 PC400LC-6LK/HD-6LK PC400LC-6LM/HD-6LM PC400LC-6Z PC400ST-6 PC400ST-6LC PC450-6 PC450-6K PC450-6K-J PC450-6K-KE PC450-6Z PC450LC-6 PC450LC-6K PC450LC-6K-J PC450LC-6K-KE PC450LC-6Z PW400MH-6

Pos.	Part No	Qty	Parts name	Comments
	706-77-01380	[1]	MOTOR ASS'Y Komatsu	100.501 kg.
			["SN: 32283-UP"] \|1.
	706-77-01311	[1]	MOTOR ASS'Y Komatsu	100.001 kg.
			["SN: 32001-32282"] \|1.
	706-77-03130	[1]	MOTOR SUB ASS'Y Komatsu China
			["SN: 32001-UP"] \|1.
1	706-77-43210	[1]	CASE,MOTOR Komatsu	21.001 kg.
			["SN: 32001-UP"]
2	706-77-72610	[1]	HOUSING Komatsu	30 kg.
			["SN: 32001-UP"]
3	706-75-42830	[1]	PIN,DOWEL Komatsu	0.02 kg.
			["SN: 32001-UP"]
4	706-77-72170	[2]	PLUG Komatsu	0.115 kg.
			["SN: 32001-UP"]
5	07002-12434	[2]	O-RING Komatsu China	0.01 kg.
			["SN: 32001-UP"] analogs:["0700202434", "0700213434"]
6	706-73-71450	[1]	PLUG Komatsu	0.035 kg.
			["SN: 32001-UP"]
7	07002-11423	[1]	O-RING Komatsu China	0.001 kg.
			["SN: 32001-UP"] analogs:["0700201423"]
8	706-7G-40010	[1]	BEARING Komatsu	0.032 kg.
			["SN: 32001-UP"]
9	706-7E-11440	[1]	O-RING Komatsu	0.008 kg.
			["SN: 32001-UP"]
10	706-77-43180	[8]	BOLT Komatsu China
			["SN: 32001-UP"]
11	706-77-43860	[1]	SHAFT Komatsu	6.581 kg.
			["SN: 32001-UP"]
12	706-77-43880	[1]	BEARING Komatsu	5.5 kg.
			["SN: 32001-UP"] analogs:["7067743890"]
13	706-77-42890	[1]	BEARING Komatsu	1.185 kg.
			["SN: 32001-UP"]
14	706-77-42051	[2]	SPRING Komatsu	0.14 kg.
			["SN: 32001-UP"]
15	706-77-42041	[1]	SEAT Komatsu	0.1 kg.
			["SN: 32001-UP"]
16	706-77-05010	[1]	SPACER KIT Komatsu	0.172 kg.
			["SN: 32001-UP"]
17	04064-06525	[1]	RING,SNAP Komatsu China	0.021 kg.
			["SN: 32001-UP"]
18	706-77-43950	[1]	SEAL,OIL Komatsu China
			["SN: 32001-UP"]
19	706-77-43060	[1]	COVER Komatsu	0.81 kg.
			["SN: 32001-UP"]
20	07000-02125	[1]	O-RING Komatsu OEM	0.005 kg.
			["SN: 32001-UP"] analogs:["0700002125E", "0700012125"]
21	04071-00130	[1]	RING,SNAP Komatsu	0.12 kg.
			["SN: 32001-UP"]
22	706-77-43191	[1]	BLOCK,CYLINDER Komatsu	5.64 kg.
			["SN: 32001-UP"] analogs:["7068740091"]
23	706-77-43840	[1]	PLATE,VALVE Komatsu	1 kg.
			["SN: 32001-UP"] analogs:["7067743850"]
24	708-18-13230	[1]	PIN Komatsu	0.01 kg.
			["SN: 32001-UP"]
25	706-77-43080	[1]	SHAFT,CENTER Komatsu	0.6 kg.
			["SN: 32001-UP"]
26	706-77-42130	[1]	RING,CENTER Komatsu	0.1 kg.
			["SN: 32001-UP"]
27	706-77-42110	[1]	SPRING Komatsu	0.23 kg.
			["SN: 32001-UP"]
	706-77-05050	[1]	RETAINER KIT Komatsu	0.281 kg.
			["SN: 32001-UP"] \|28.
30	706-77-42160	[7]	PISTON SUB ASS'Y Komatsu	0.46 kg.
			["SN: 32001-UP"]
31	706-77-91540	[5]	PLATE Komatsu	0.26 kg.
			["SN: 32001-UP"]
32	706-77-91550	[3]	DISC Komatsu	0.28 kg.
			["SN: 32001-UP"]
33	706-77-91580	[1]	PISTON,BRAKE Komatsu	2.5 kg.
			["SN: 32001-UP"]
34	07000-15180	[1]	O-RING Komatsu China	0.025 kg.
			["SN: 32001-UP"] analogs:["0700005180"]
35	708-8H-15220	[1]	O-RING Komatsu	0.025 kg.
			["SN: 32001-UP"]
36	706-77-91510	[6]	SPRING Komatsu China
			["SN: 32001-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	706-77-01380	[1]	MOTOR ASS'Y Komatsu	100.501 kg.
			["SN: 32283-UP"] \|1.
	706-77-01311	[1]	MOTOR ASS'Y Komatsu	100.001 kg.
			["SN: 32001-32282"] \|1.
	702-77-04401	[2]	VALVE ASS'Y,RELIEF Komatsu	0.69 kg.
			["SN: 32283-UP"] \|1.
	702-77-04800	[2]	VALVE ASS'Y,RELIEF Komatsu	0.7 kg.
			["SN: 32001-32282"] \|1.
11.	706-77-72540	[2]	SPRING Komatsu China
			["SN: 32001-UP"]
12.	706-77-72520	[2]	COVER Komatsu China
			["SN: 32001-UP"]
13.	07000-13042	[2]	O-RING Komatsu China	0.01 kg.
			["SN: 32001-UP"] analogs:["0700003042"]
14.	01010-81275	[8]	BOLT Komatsu	0.082 kg.
			["SN: 32001-UP"] analogs:["0101051275"]
15.	01643-31232	[8]	WASHER Komatsu	0.027 kg.
			["SN: 32001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
16.	706-75-74920	[1]	PLATE Komatsu China
			["SN: 32001-UP"]
17.	07000-11007	[3]	O-RING Komatsu	0.001 kg.
			["SN: 32001-UP"] analogs:["YM24311000070", "0700001007"]
18.	01252-60825	[2]	BOLT Komatsu	0.017 kg.
			["SN: 32001-UP"] analogs:["0125240825", "0125230825"]
