KOMATSU 706-75-10400 706-75-10402 TRAVEL MOTOR ROTARY GROUP

KOMATSU 706-75-10400 706-75-10402 TRAVEL MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
706-75-10400 706-75-10402
BP500-3 BR200-1 BR200J-1 BR200R-1 BR200S-1 BR300J-1 BR310JG-1 CS360-1 CS360-2 PC200-3 PC200-5C PC200-5Z PC200LC-3 PC200LC-5C PC220-3 PC220-5C PC220LC-3 PC220LC-5C PC240-3K PC240LC-3K PC300LC-3 PF5-1 PF5LC-1
Pos. Part No Qty Parts name Comments
     706-75-10402   [2]   TRAVEL MOTOR ASS'Y Komatsu 73.301 kg.
  ["SN: .-UP"] analogs:["7067501120", "7067503302", "7067510400"] |$0.
     706-75-10400   [2]   TRAVEL MOTOR ASS'Y Komatsu 73.301 kg.
  ["SN: 12001-."] analogs:["7067501120", "7067503302", "7067510402"] |$1.
   1.   706-75-41091   [1]   BLOCK,CYLINDER Komatsu 2.85 kg.
  ["SN: 12001-UP"]
   2.   706-75-41163   [7]   PISTON SUB ASS'Y Komatsu 0.27 kg.
  ["SN: 12001-UP"]
   3.   706-75-42080   [1]   SHAFT,CENTER Komatsu China
  ["SN: 12001-UP"]
   4.   706-75-41220   [1]   BALL,CENTER Komatsu China
  ["SN: 12001-UP"] analogs:["7067540220"]
   5.   706-75-41110   [1]   SPRING Komatsu 0.05 kg.
  ["SN: 12001-UP"]
   6.   706-75-41130   [1]   RING,CENTER Komatsu China
  ["SN: 12001-UP"]
   7.   706-75-40010   [1]   BEARING Komatsu 0.03 kg.
  ["SN: 12001-UP"]
   8.   706-75-42840   [1]   PLATE,VALVE Komatsu China
  ["SN: 12001-UP"]
   9.   04020-00820   [1]   PIN,DOWEL Komatsu 0.056 kg.
  ["SN: 12001-UP"] analogs:["802540092"]
   10.   706-75-42260   [1]   RETAINER Komatsu 0.201 kg.
  ["SN: .-UP"] analogs:["7067505020"]
   10.   706-75-41263   [1]   RETAINER Komatsu 0.201 kg.
  ["SN: 12001-."] analogs:["7067505020"]
   11.   706-75-42962   [1]   SHAFT,DRIVE Komatsu 4 kg.
  ["SN: .-UP"] analogs:["7067542860", "7067542960"]
   11.   706-75-42960   [1]   SHAFT,DRIVE Komatsu 4 kg.
  ["SN: 12001-."] analogs:["7067542860"]
   12.   706-75-41251   [8]   HOLDER Komatsu China
  ["SN: 12001-."]
   13.   706-75-42270   [7]   SCREW Komatsu 0.003 kg.
  ["SN: .-UP"]
   13.   706-75-41271   [14]   SCREW Komatsu 0.004 kg.
  ["SN: 12001-."]
   14.   706-75-00070   [1]   BRAKE CASE SUB ASS'Y Komatsu China
  ["SN: .-UP"] analogs:["7067542061", "7067542060"]
   14.   706-75-42060   [1]   CASE,BRAKE Komatsu China
  ["SN: 12001-."] analogs:["7067500070", "7067542061"]
   16.   706-75-71420   [1]   PLUG Komatsu China
  ["SN: 12001-."]
   17.   07002-10823   [1]   O-RING Komatsu 0.18 kg.
  ["SN: 12001-."] analogs:["0700200823"]
   18.   706-75-42880   [1]   BEARING Komatsu 2.42 kg.
  ["SN: 12001-UP"]
   19.   706-76-40890   [1]   BEARING Komatsu 0.524 kg.
  ["SN: 12001-UP"]
   20.   706-75-42910   [1]   RING Komatsu China
  ["SN: 12001-UP"]
   21.   706-76-41931   [1]   SEAL,OIL Komatsu 0.15 kg.
  ["SN: .-UP"]
   21.   706-76-40920   [1]   SEAL,OIL Komatsu China
  ["SN: 12001-."]
   22.   07000-03040   [1]   O-RING Komatsu China 0.002 kg.
  ["SN: 12001-UP"] analogs:["0700013040", "0700003040E", "YM24311000400"]
   23.   04065-09030   [1]   RING,SNAP Komatsu 0.03 kg.
  ["SN: 12001-UP"] analogs:["2324013250", "R0406509030"]
   24.   706-75-40940   [1]   WASHER,LOCK Komatsu China
  ["SN: 12001-UP"]
   25.   01530-03912   [1]   NUT Komatsu 0.105 kg.
  ["SN: 12001-UP"] analogs:["0153013912"]
   26.   706-75-91382   [1]   PISTON,BRAKE Komatsu China
  ["SN: 12001-UP"] analogs:["7067591381"]
   27.   706-75-91420   [4]   SPRING Komatsu China
  ["SN: 12001-UP"]
   28.   706-75-91410   [4]   SPRING Komatsu China
  ["SN: 12001-UP"]
   29.   07000-15155   [1]   O-RING Komatsu China 0.017 kg.
  ["SN: 12001-UP"] analogs:["0700005155E", "0700005155"]
   30.   07001-05155   [1]   RING,BACK-UP Komatsu China 0.01 kg.
  ["SN: 12001-UP"]
   31.   07000-15170   [1]   O-RING Komatsu OEM 0.02 kg.
  ["SN: 12001-UP"] analogs:["0700005170"]
   32.   07001-05170   [1]   RING,BACK-UP Komatsu China 0.01 kg.
  ["SN: 12001-UP"]
   33.   706-75-91340   [3]   PLATE Komatsu 0.1 kg.
  ["SN: 12001-UP"]
   34.   706-75-91350   [3]   DISC Komatsu 0.08 kg.
  ["SN: 12001-UP"]
   35.   706-75-91330   [1]   PLATE Komatsu China
  ["SN: 12001-UP"]
   36.   07000-05195   [1]   O-RING Komatsu China 0.038 kg.
  ["SN: 12001-UP"] analogs:["0700015195"]
   37.   07000-12010   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 12001-UP"] analogs:["YM24311240100", "0700002010"]
   38.   706-75-40360   [9]   BOLT Komatsu 0.081 kg.
  ["SN: 12001-UP"] analogs:["0125261445", "7051903470"]
   39.   01602-21442   [9]   WASHER,SPRING Komatsu 0.01 kg.
  ["SN: 12001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-75-10402   [2]   TRAVEL MOTOR ASS'Y Komatsu 73.301 kg.
  ["SN: .-UP"] analogs:["7067501120", "7067503302", "7067510400"] |$0.
1   706-75-10400   [2]   TRAVEL MOTOR ASS'Y Komatsu 73.301 kg.
  ["SN: 12001-."] analogs:["7067501120", "7067503302", "7067510402"]
   1.   706-75-00030   [1]   HOUSING SUB ASS'Y Komatsu China
  ["SN: 12001-UP"] analogs:["7067574150", "7067574530"]
   3.   706-75-74190   [2]   SPRING Komatsu China
  ["SN: 12001-UP"] analogs:["7067574170"]
   4.   706-75-74161   [2]   RETAINER Komatsu China
  ["SN: 12001-UP"]
   5.   706-75-74231   [2]   VALVE Komatsu China
  ["SN: 12001-UP"]
   6.   706-75-74240   [2]   SPRING Komatsu China
  ["SN: 12001-UP"]
   7.   706-75-74261   [2]   SEAT Komatsu China
  ["SN: 12001-UP"]
   8.   07000-13022   [2]   O-RING Komatsu OEM 0.001 kg.
  ["SN: 12001-UP"] analogs:["0700003022"]
   9.   07001-03022   [2]   RING,BACK-UP Komatsu 0.01 kg.
  ["SN: 12001-UP"]
   10.   706-75-74220   [2]   PLATE Komatsu China
  ["SN: 12001-UP"]
   11.   07000-13040   [2]   O-RING Komatsu China 0.002 kg.
  ["SN: 12001-UP"] analogs:["0700003040", "0700003040E", "YM24311000400"]
   12.   01010-51035   [12]   BOLT Komatsu 0.033 kg.
  ["SN: 12001-UP"] analogs:["801015556", "0101081035", "01010D1035"]
   13.   01602-21030   [12]   WASHER,SPRING Komatsu 0.004 kg.
  ["SN: 12001-UP"] analogs:["YM22217100000"]
   14.   706-75-74420   [2]   PLUG Komatsu China
  ["SN: 12001-UP"] analogs:["7067574421"]
   15.   07000-12011   [2]   O-RING Komatsu 0.001 kg.
  ["SN: 12001-UP"] analogs:["YM24315000110", "0700002011"]
   16.   07001-02011   [2]   RING,BACK-UP Komatsu 0.005 kg.
  ["SN: 12001-UP"]
   17.   07002-12034   [2]   O-RING Komatsu China 0.94 kg.
  ["SN: 12001-UP"] analogs:["0700002034", "0700202034", "0700012034"]
   18.   706-77-72170   [7]   PLUG Komatsu 0.115 kg.
  ["SN: 12001-UP"]
   19.   07002-12434   [7]   O-RING Komatsu China 0.01 kg.
  ["SN: 12001-UP"] analogs:["0700202434", "0700213434"]
   20.   706-73-71450   [2]   PLUG Komatsu 0.035 kg.
  ["SN: 12001-UP"]
   21.   07002-11423   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: 12001-UP"] analogs:["0700201423"]
   22.   706-75-71420   [1]   PLUG Komatsu China
  ["SN: 12001-UP"]
   23.   07002-10823   [1]   O-RING Komatsu 0.18 kg.
  ["SN: 12001-UP"] analogs:["0700200823"]
        706-75-85401   [2]   RELIEF VALVE ASS'Y Komatsu China
  ["SN: 12001-UP"] analogs:["7067586300", "7067585400"] |$27.
34   07000-22020   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 12001-UP"] analogs:["07000F2020"]
35   07001-02020   [2]   RING,BACK-UP Komatsu 0.001 kg.
  ["SN: 12001-UP"]
36   07002-13034   [1]   O-RING Komatsu China 0.005 kg.
  ["SN: 12001-UP"] analogs:["0700203034"]
