704-23-30600 704-23-30601
708-27-01210 708-27-01211
708-27-02010 708-27-02011
708-27-02012 708-27-02013
708-27-02014 708-27-02015
708-27-10100 708-27-11100
708-27-11101
PC300 PC300-3 PC300-5 PC300-5C PC300-5K PC300HD-5K PC300LC PC300LC-3 PC300LC-5 PC300LC-5K PC300LC-5LC PC300NLC-5K PC310-5 PC310LC-5 PC400 PC400-3 PC400-5 PC400-5C PC400HD-5K PC400LC PC400LC-3 PC400LC-5 PC410-5 PC410LC-5 |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-27-02015
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082702011", "7082702014"] |$0. |
| |
708-27-02014
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13532-.)"] analogs:["7082702011"] |$1. |
| |
708-27-02013
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13424-13531)"] analogs:["7082702011", "7082702014"] |$2. |
| |
708-27-02012
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13075-13423)"] analogs:["7082702011", "7082702014"] |$3. |
| |
708-27-02011
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12968-13074)"] analogs:["7082702014"] |$4. |
| |
708-27-02010
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082702011", "7082702014"] |$5. |
| |
708-27-10100
|
[1] |
PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082702011", "7082702014"] |$6. |
|
1. |
708-27-01211
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082701210", "7082711200", "7082711100", "7082711101"] |
|
1. |
708-27-01210
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12968-.)"] analogs:["7082701211", "7082711200", "7082711100", "7082711101"] |
|
1. |
708-27-11101
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082701210", "7082701211", "7082711200", "7082711100"] |
|
1. |
708-27-11100
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082701210", "7082701211", "7082711200", "7082711101"] |
|
2. |
704-23-30601
|
[1] |
PUMP ASS'Y Komatsu
|
7.4 kg. |
|
["SN: 12001-UP"] analogs:["7042330600"] |
|
2. |
704-23-30600
|
[1] |
PUMP ASS'Y Komatsu
|
7.4 kg. |
|
["SN: (12001-12797)"] analogs:["7042330601"] |
|
3. |
708-27-14700
|
[1] |
VALVE ASS'Y Komatsu China
|
|
|
["SN: 12001-UP"] |
|
3. |
708-23-14800
|
[1] |
VALVE ASS'Y Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082314801"] |
|
4. |
07000-02075
|
[1] |
O-RING Komatsu China
|
0.03 kg. |
|
["SN: 12001-UP"] analogs:["0700012075", "YM24321000750"] |
|
5. |
07000-02020
|
[1] |
O-RING Komatsu OEM
|
0.001 kg. |
|
["SN: 12001-UP"] |
|
6. |
01011-51010
|
[3] |
BOLT Komatsu
|
0.078 kg. |
|
["SN: 12001-UP"] analogs:["0101181010"] |
|
7. |
01602-01030
|
[3] |
WASHER Komatsu
|
0.004 kg. |
|
["SN: 12001-UP"] analogs:["0160211030"] |
|
8. |
07102-20203
|
[1] |
HOSE Komatsu China
|
0.275 kg. |
|
["SN: 12001-UP"] |
|
9. |
07235-10210
|
[2] |
ELBOW Komatsu
|
0.083 kg. |
|
["SN: .-UP"] |
|
9. |
07232-20210
|
[2] |
ELBOW Komatsu China
|
|
|
["SN: 12001-."] analogs:["0723200210", "0723210210"] |
|
10. |
07239-11408
|
[2] |
NUT Komatsu
|
0.034 kg. |
|
["SN: 12001-."] analogs:["0723921408"] |
|
11. |
07002-01423
|
[2] |
O-RING Komatsu China
|
0.001 kg. |
|
["SN: 12001-UP"] analogs:["0700211423"] |
|
12. |
708-27-14210
|
[1] |
ELBOW Komatsu China
|
|
|
["SN: 12001-UP"] |
|
13. |
07000-02021
|
[1] |
O-RING Komatsu China
|
0.01 kg. |
|
["SN: 12001-UP"] analogs:["0700012021"] |
|
14. |
720-68-15240
|
[1] |
FILTER Komatsu
|
0.003 kg. |
|
["SN: 12001-UP"] |
|
15. |
01010-50855
|
[2] |
BOLT Komatsu
|
0.027 kg. |
|
["SN: 12001-UP"] analogs:["0101080855"] |
|
16. |
01643-30823
|
[2] |
WASHER Komatsu
|
0.004 kg. |
|
["SN: 12001-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"] |
|
17. |
07102-20505
|
[1] |
HOSE Komatsu China
|
0.85 kg. |
|
["SN: 12001-UP"] |
|
18. |
207-62-33710
|
[1] |
TEE Komatsu China
|
|
|
["SN: 12001-UP"] |
|
19. |
07040-11409
|
[1] |
PLUG Komatsu
|
0.033 kg. |
|
["SN: 12001-UP"] |
|
21. |
07002-02434
|
[1] |
O-RING Komatsu China
|
0.01 kg. |
|
["SN: 12001-UP"] analogs:["0700212434", "0700213434"] |
|
22. |
04020-00616
|
[4] |
PIN Komatsu
|
0.004 kg. |
|
["SN: 12001-UP"] |
|
23. |
708-25-19130
|
[8] |
BOLT Komatsu China
|
|
|
["SN: 12001-UP"] |
|
24. |
01602-00825
|
[8] |
WASHER Komatsu
|
0.004 kg. |
|
["SN: 12001-UP"] analogs:["0160220825", "0231011020", "6124613790"] |
|
25. |
207-62-31770
|
[1] |
TEE Komatsu China
|
|
|
["SN: 12001-UP"] |
|
26. |
208-27-11210
|
[1] |
BLEEDER Komatsu China
|
|
|
["SN: 12001-UP"] |
|
30. |
708-27-07112
|
[1] |
SERVO VALVE ASS'Y,FRONT Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082707110", "7082707111", "7082715100"] |
|
30. |
708-27-07111
|
[1] |
SERVO VALVE ASS'Y,FRONT Komatsu China
|
|
|
["SN: (13424-13531)"] analogs:["7082707112", "7082707110", "7082715100"] |
|
30. |
708-27-07110
|
[1] |
SERVO VALVE ASS'Y,FRONT Komatsu China
|
|
|
["SN: (13075-13423)"] analogs:["7082707112", "7082707111", "7082715100"] |
|
30. |
708-27-15100
|
[1] |
SERVO VALVE ASS'Y,FRONT Komatsu China
|
|
|
["SN: (12001-13074)"] analogs:["7082707112", "7082707110", "7082707111"] |
|
31. |
708-27-07211
|
[1] |
SERVO VALVE ASS'Y,REAR Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082707210", "7082716100"] |
|
31. |
708-27-07210
|
[1] |
SERVO VALVE ASS'Y,REAR Komatsu China
|
|
|
["SN: (13075-13423)"] analogs:["7082707211", "7082716100"] |
|
31. |
708-27-16100
|
[1] |
SERVO VALVE ASS'Y,REAR Komatsu China
|
|
|
["SN: (12001-13074)"] analogs:["7082707210", "7082707211"] |
| Parts on group : |
|
|
|
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-27-02015
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082702011", "7082702014"] |$0. |
| |
708-27-02014
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13532-.)"] analogs:["7082702011"] |$1. |
| |
708-27-02013
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13424-13531)"] analogs:["7082702011", "7082702014"] |$2. |
| |
708-27-02012
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13075-13423)"] analogs:["7082702011", "7082702014"] |$3. |
| |
708-27-02011
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12968-13074)"] analogs:["7082702014"] |$4. |
| |
708-27-02010
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082702011", "7082702014"] |$5. |
| |
708-27-10100
|
[1] |
PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082702011", "7082702014"] |$6. |
|
1. |
708-27-01211
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082701210", "7082711200", "7082711100", "7082711101"] |
|
1. |
708-27-01210
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12968-.)"] analogs:["7082701211", "7082711200", "7082711100", "7082711101"] |
|
1. |
708-27-11101
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082701210", "7082701211", "7082711200", "7082711100"] |
|
1. |
708-27-11100
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082701210", "7082701211", "7082711200", "7082711101"] |
| 1 |
708-27-00070
|
[1] |
CASE ASS'Y Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082712110"] |
| 3 |
07044-12412
|
[1] |
PLUG Komatsu
|
0.09 kg. |
|
["SN: 12001-UP"] analogs:["0704402412", "R0704412412"] |
| 4 |
07002-02434
|
[1] |
O-RING Komatsu China
|
0.01 kg. |
|
["SN: 12001-UP"] analogs:["0700212434", "0700213434"] |
| 5 |
07040-12414
|
[1] |
PLUG Komatsu
|
0.092 kg. |
|
["SN: 12001-UP"] analogs:["0704002412", "0704012412"] |
| 7 |
708-27-14110
|
[1] |
PISTON Komatsu
|
2.64 kg. |
|
["SN: 12001-UP"] |
| 8 |
708-27-14130
|
[1] |
SPRING Komatsu
|
0.28 kg. |
|
["SN: 12001-UP"] |
| 9 |
708-27-14140
|
[1] |
CAP Komatsu China
|
|
|
["SN: 12001-UP"] |
| 10 |
708-27-14150
|
[1] |
CAP Komatsu China
|
|
|
["SN: 12001-UP"] |
| 11 |
07000-02075
|
[2] |
O-RING Komatsu China
|
0.03 kg. |
|
["SN: 12001-UP"] analogs:["0700012075", "YM24321000750"] |
| 12 |
708-27-05060
|
[2] |
SHIM KIT Komatsu
|
0.032 kg. |
|
["SN: 12001-UP"] |
| 12 |
708-27-14190
|
[2] |
SHIM, 0.1MM Komatsu China
|
|
|
["SN: 12001-UP"] |
| 13 |
01016-51045
|
[8] |
BOLT Komatsu
|
0.039 kg. |
|
["SN: 12001-UP"] analogs:["0101631045", "0101681045"] |
| 14 |
01643-31032
|
[8] |
WASHER Komatsu
|
0.054 kg. |
|
["SN: 12001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] |
| 15 |
708-27-12130
|
[1] |
O-RING Komatsu
|
0.007 kg. |
|
["SN: 12001-UP"] |
| 16 |
708-25-12330
|
[1] |
JOINT Komatsu
|
0.025 kg. |
|
["SN: 12001-UP"] |
| 17 |
07000-12015
|
[1] |
O-RING Komatsu China
|
0.001 kg. |
|
["SN: 12001-UP"] analogs:["0700002015"] |
| Parts on group : |
|
|
|
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-27-02015
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082702011", "7082702014"] |$0. |
| |
708-27-02014
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13532-.)"] analogs:["7082702011"] |$1. |
| |
708-27-02013
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13424-13531)"] analogs:["7082702011", "7082702014"] |$2. |
| |
708-27-02012
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13075-13423)"] analogs:["7082702011", "7082702014"] |$3. |
| |
708-27-02011
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12968-13074)"] analogs:["7082702014"] |$4. |
| |
708-27-02010
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082702011", "7082702014"] |$5. |
| |
708-27-10100
|
[1] |
PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082702011", "7082702014"] |$6. |
|
1. |
708-27-01211
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082701210", "7082711200", "7082711100", "7082711101"] |
|
1. |
708-27-01210
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12968-.)"] analogs:["7082701211", "7082711200", "7082711100", "7082711101"] |
|
1. |
708-27-11101
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082701210", "7082701211", "7082711200", "7082711100"] |
|
1. |
708-27-11100
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082701210", "7082701211", "7082711200", "7082711101"] |
| 1 |
708-27-05010
|
[1] |
SHIM KIT Komatsu
|
0.015 kg. |
|
["SN: 12001-UP"] |
| 2 |
708-27-12761
|
[1] |
SEAL Komatsu
|
0.07 kg. |
|
["SN: 12001-UP"] |
| 2 |
708-27-12760
|
[1] |
SEAL Komatsu
|
0.07 kg. |
|
["SN: (12001-12967)"] analogs:["7082712761"] |
| 3 |
708-27-12770
|
[1] |
HOUSING Komatsu China
|
|
|
["SN: 12001-UP"] |
| 4 |
07000-02105
|
[1] |
O-RING Komatsu OEM
|
0.004 kg. |
|
["SN: 12001-UP"] analogs:["0700012105"] |
| 5 |
01010-50820
|
[4] |
BOLT Komatsu
|
0.013 kg. |
|
["SN: 12001-UP"] analogs:["0101080820", "801014067", "801015086"] |
| 6 |
01643-30823
|
[4] |
WASHER Komatsu
|
0.004 kg. |
|
["SN: 12001-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"] |
| |
708-27-00130
|
[1] |
SHAFT ASS'Y Komatsu China
|
|
|
["SN: 12001-UP"] |$21. |
| 12 |
708-27-14440
|
[1] |
COUPLING Komatsu
|
0.05 kg. |
|
["SN: 12001-UP"] |
| 13 |
708-27-14450
|
[1] |
PIN Komatsu China
|
|
|
["SN: 12001-UP"] |
| 14 |
04065-07225
|
[1] |
RING Komatsu
|
0.02 kg. |
|
["SN: 12001-UP"] |
| 15 |
06030-06207
|
[1] |
BEARING,ROLLER Komatsu
|
0.3 kg. |
|
["SN: 12001-UP"] |
| 16 |
708-27-14480
|
[1] |
COLLAR Komatsu China
|
|
|
["SN: 12001-UP"] |
| 17 |
06030-06307
|
[1] |
BEARING,ROLLER Komatsu
|
0.464 kg. |
|
["SN: 12001-UP"] |
| 18 |
07000-03035
|
[1] |
O-RING Komatsu China
|
0.03 kg. |
|
["SN: 12001-UP"] analogs:["0700013035"] |
| 19 |
708-25-52860
|
[1] |
SEAL Komatsu China
|
0.078 kg. |
|
["SN: 13532-UP"] analogs:["7082552861", "7067340920"] |
| 19 |
708-25-12980
|
[1] |
SEAL Komatsu China
|
0.078 kg. |
|
["SN: .-13531"] analogs:["7082552860", "7082552861", "7067340920"] |
| 19 |
706-73-40920
|
[1] |
SEAL Komatsu China
|
0.078 kg. |
|
["SN: (12001-.)"] analogs:["7082552860", "7082552861"] |
| 20 |
708-27-14460
|
[1] |
HOUSING Komatsu China
|
|
|
["SN: 12001-UP"] |
| 21 |
07000-02085
|
[1] |
O-RING Komatsu China
|
0.03 kg. |
|
["SN: 12001-UP"] analogs:["0700012085", "YM24321000850"] |
| 24 |
04000-01020
|
[1] |
KEY Komatsu China
|
|
|
["SN: 12001-UP"] |
| Parts on group : |
|
|
|
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-27-02015
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082702011", "7082702014"] |$0. |
| |
708-27-02014
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13532-.)"] analogs:["7082702011"] |$1. |
| |
708-27-02013
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13424-13531)"] analogs:["7082702011", "7082702014"] |$2. |
| |
708-27-02012
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13075-13423)"] analogs:["7082702011", "7082702014"] |$3. |
| |
708-27-02011
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12968-13074)"] analogs:["7082702014"] |$4. |
| |
708-27-02010
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082702011", "7082702014"] |$5. |
| |
708-27-10100
|
[1] |
PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082702011", "7082702014"] |$6. |
|
1. |
708-27-01211
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082701210", "7082711200", "7082711100", "7082711101"] |
|
1. |
708-27-01210
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12968-.)"] analogs:["7082701211", "7082711200", "7082711100", "7082711101"] |
|
1. |
708-27-11101
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082701210", "7082701211", "7082711200", "7082711100"] |
|
1. |
708-27-11100
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082701210", "7082701211", "7082711200", "7082711101"] |
| 1 |
708-27-00032
|
[1] |
CRADLE ASS'Y,FRONT Komatsu
|
14.65 kg. |
|
["SN: ..-UP"] analogs:["7082700031"] |
| 1 |
708-27-00031
|
[1] |
CRADLE ASS'Y,FRONT Komatsu
|
14.65 kg. |
|
["SN: .-.."] |
| 1 |
708-27-00030
|
[1] |
CRADLE ASS'Y,FRONT Komatsu China
|
|
|
["SN: 12001-."] |
| 1 |
708-27-00450
|
[1] |
CRADLE SUB ASS'Y,FRONT Komatsu
|
10.381 kg. |
|
["SN: 12001-UP"] analogs:["7082712310"] |
| 3 |
708-27-13412
|
[1] |
CAM Komatsu
|
3.873 kg. |
|
["SN: ..-UP"] analogs:["7082713411"] |
| 3 |
708-27-13411
|
[1] |
CAM Komatsu
|
3.873 kg. |
|
["SN: (.-..)"] analogs:["7082713412"] |
| 3 |
708-27-13410
|
[1] |
CAM Komatsu
|
3.873 kg. |
|
["SN: 12001-."] analogs:["7082713412", "7082713411"] |
| 4 |
01010-51450
|
[12] |
BOLT Komatsu
|
0.085 kg. |
|
["SN: 12001-UP"] analogs:["0101031450", "0101061450", "0101081450"] |
| 5 |
20D-14-11510
|
[12] |
WASHER Komatsu
|
0.013 kg. |
|
["SN: 12001-UP"] |
| 6 |
708-27-12330
|
[2] |
PLATE Komatsu China
|
|
|
["SN: 12001-UP"] |
| 7 |
04020-00820
|
[4] |
PIN Komatsu
|
0.056 kg. |
|
["SN: 12001-UP"] analogs:["802540092"] |
| 8 |
708-27-12340
|
[4] |
SCREW Komatsu China
|
|
|
["SN: 12001-UP"] |
| 9 |
01643-30823
|
[4] |
WASHER Komatsu
|
0.004 kg. |
|
["SN: 12001-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"] |
| 10 |
708-27-12350
|
[1] |
STOPPER Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7062712350", "7067512350"] |
| 12 |
706-75-42270
|
[1] |
SCREW Komatsu
|
0.003 kg. |
|
["SN: 12001-UP"] |
| 13 |
708-27-14121
|
[1] |
SLIDER Komatsu China
|
|
|
["SN: .-UP"] analogs:["7082714120"] |
| 13 |
708-27-14120
|
[1] |
SLIDER Komatsu China
|
|
|
["SN: 12001-."] analogs:["7082714121"] |
| |
708-27-00012
|
[1] |
BLOCK ASS'Y Komatsu
|
7.771 kg. |
|
["SN: .-UP"] analogs:["7082700010"] |$35. |
| |
708-27-00010
|
[1] |
BLOCK ASS'Y Komatsu
|
7.771 kg. |
|
["SN: (12798-.)"] analogs:["7082700012"] |$36. |
| 14 |
708-27-13111
|
[1] |
CYLINDER BLOCK Komatsu
|
6.871 kg. |
|
["SN: 12798-UP"] |
| 14 |
708-27-13110
|
[1] |
BLOCK Komatsu
|
6.871 kg. |
|
["SN: 12001-12797"] analogs:["7082713111"] |
| 15 |
708-27-13212
|
[1] |
PLATE,FRONT Komatsu China
|
|
|
["SN: .-UP"] analogs:["7082713211", "7082713210"] |
| 15 |
708-27-13211
|
[1] |
PLATE,FRONT Komatsu China
|
|
|
["SN: (12798-.)"] analogs:["7082713212", "7082713210"] |
| 15 |
708-27-13210
|
[1] |
PLATE,FRONT Komatsu China
|
|
|
["SN: 12001-12797"] analogs:["7082713211", "7082713212"] |
| 16 |
708-27-13314
|
[9] |
PISTON SUB ASS'Y Komatsu
|
0.32 kg. |
|
["SN: .-UP"] analogs:["7082713311"] |
| 16 |
708-27-13312 |
[9] |
PISTON SUB ASS'Y Komatsu
|
0.32 kg. |
|
["SN: 12968-."] analogs:["7082713314", "7082713311"] |
| 16 |
\4\708-27-13311
|
[9] |
PISTON SUB ASS'Y Komatsu
|
0.32 kg. |
|
["SN: 12798-12967"] analogs:["7082713314"] |
| 16 |
708-27-13310 |
[9] |
PISTON SUB ASS'Y Komatsu
|
0.32 kg. |
|
["SN: 12001-12797"] analogs:["7082713314", "7082713311"] |
| 17 |
708-27-13342
|
[1] |
RETAINER Komatsu
|
0.38 kg. |
|
["SN: .-UP"] analogs:["7082713341"] |
| 17 |
708-27-13341
|
[1] |
RETAINER Komatsu
|
0.38 kg. |
|
["SN: 12798-."] analogs:["7082713342"] |
| 17 |
708-27-13340
|
[1] |
RETAINER Komatsu China
|
|
|
["SN: 12001-12797"] |
| 18 |
708-27-05051
|
[1] |
SPACER KIT Komatsu
|
0.44 kg. |
|
["SN: 12001-UP"] |
| 19 |
708-27-13420
|
[2] |
RETAINER Komatsu
|
0.055 kg. |
|
["SN: 12001-UP"] |
| 20 |
708-27-13480
|
[4] |
SCREW Komatsu China
|
|
|
["SN: 12001-UP"] |
| 22 |
708-27-13120
|
[1] |
WASHER Komatsu
|
0.036 kg. |
|
["SN: 12001-UP"] |
| 23 |
708-27-13140
|
[1] |
SPRING Komatsu
|
0.2 kg. |
|
["SN: 12001-UP"] |
| 24 |
708-27-13130
|
[1] |
RETAINER Komatsu
|
0.034 kg. |
|
["SN: 12001-UP"] |
| 25 |
708-27-13150
|
[1] |
RING Komatsu China
|
|
|
["SN: 12001-UP"] |
| Parts on group : |
|
|
|
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-27-02015
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082702011", "7082702014"] |$0. |
| |
708-27-02014
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13532-.)"] analogs:["7082702011"] |$1. |
| |
708-27-02013
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13424-13531)"] analogs:["7082702011", "7082702014"] |$2. |
| |
708-27-02012
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13075-13423)"] analogs:["7082702011", "7082702014"] |$3. |
| |
708-27-02011
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12968-13074)"] analogs:["7082702014"] |$4. |
| |
708-27-02010
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082702011", "7082702014"] |$5. |
| |
708-27-10100
|
[1] |
PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082702011", "7082702014"] |$6. |
|
|
708-27-01211
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082701210", "7082711200", "7082711100", "7082711101"] |$7. |
|
|
708-27-01210
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12968-.)"] analogs:["7082701211", "7082711200", "7082711100", "7082711101"] |$8. |
|
|
708-27-11101
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082701210", "7082701211", "7082711200", "7082711100"] |$9. |
|
|
708-27-11100
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082701210", "7082701211", "7082711200", "7082711101"] |$10. |
| |
708-27-00111
|
[1] |
END CAP ASS'Y,FRONT Komatsu China
|
|
|
["SN: .-UP"] analogs:["7082712511"] |$11. |
| |
708-27-00110
|
[1] |
END CAP ASS'Y,FRONT Komatsu China
|
|
|
["SN: 12001-."] analogs:["7082712510"] |$12. |
| 3 |
04530-11628
|
[1] |
BOLT Komatsu
|
0.23 kg. |
|
["SN: 12001-UP"] analogs:["0453001628"] |
| |
708-27-00121
|
[1] |
END CAP ASS'Y,REAR Komatsu China
|
|
|
["SN: .-UP"] analogs:["7082700120", "7082712520", "7082712521"] |$20. |
| |
708-27-00120
|
[1] |
END CAP ASS'Y,REAR Komatsu China
|
|
|
["SN: 12001-."] analogs:["7082700121", "7082712520", "7082712521"] |$21. |
| 6 |
720-68-19530
|
[2] |
PLUG Komatsu China
|
|
|
["SN: 12001-UP"] |
| 7 |
07002-11823
|
[2] |
O-RING Komatsu
|
0.36 kg. |
|
["SN: 12001-UP"] analogs:["0700201823"] |
| 8 |
708-27-12540
|
[1] |
O-RING Komatsu
|
0.075 kg. |
|
["SN: 12001-UP"] analogs:["1983033190"] |
| 9 |
04020-01024
|
[1] |
PIN Komatsu
|
0.015 kg. |
|
["SN: 12001-UP"] analogs:["PZF890001197"] |
| 10 |
708-27-12530
|
[2] |
O-RING Komatsu
|
0.005 kg. |
|
["SN: 12001-UP"] |
| 11 |
07000-12012
|
[7] |
O-RING Komatsu China
|
0.001 kg. |
|
["SN: 12001-UP"] analogs:["0700002012", "7082E11790"] |
| 12 |
07000-03025
|
[6] |
O-RING Komatsu China
|
0.001 kg. |
|
["SN: 12001-UP"] analogs:["0700013025"] |
| 13 |
708-25-12330
|
[2] |
JOINT Komatsu
|
0.025 kg. |
|
["SN: 12001-UP"] |
| 14 |
07000-12015
|
[2] |
O-RING Komatsu China
|
0.001 kg. |
|
["SN: 12001-UP"] analogs:["0700002015"] |
| 15 |
708-18-13230
|
[2] |
PIN Komatsu
|
0.01 kg. |
|
["SN: 12001-UP"] |
| 16 |
708-27-12550
|
[7] |
BOLT Komatsu China
|
|
|
["SN: 12001-UP"] |
| 17 |
708-27-12560
|
[6] |
BOLT Komatsu China
|
|
|
["SN: 12001-UP"] |
| 18 |
01141-82040
|
[4] |
STUD Komatsu China
|
|
|
["SN: 12001-UP"] |
| 19 |
708-27-12570
|
[4] |
NUT Komatsu China
|
|
|
["SN: 12001-UP"] |
| 20 |
01643-32060
|
[4] |
WASHER Komatsu China
|
0.044 kg. |
|
["SN: 12001-UP"] analogs:["802170007", "0164322045", "0164302045"] |
| Parts on group : |
|
|
|
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-27-02015
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082702011", "7082702014"] |$0. |
| |
708-27-02014
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13532-.)"] analogs:["7082702011"] |$1. |
| |
708-27-02013
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13424-13531)"] analogs:["7082702011", "7082702014"] |$2. |
| |
708-27-02012
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13075-13423)"] analogs:["7082702011", "7082702014"] |$3. |
| |
708-27-02011
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12968-13074)"] analogs:["7082702014"] |$4. |
| |
708-27-02010
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082702011", "7082702014"] |$5. |
| |
708-27-10100
|
[1] |
PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082702011", "7082702014"] |$6. |
|
|
708-27-01211
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082701210", "7082711200", "7082711100", "7082711101"] |$7. |
|
|
708-27-01210
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12968-.)"] analogs:["7082701211", "7082711200", "7082711100", "7082711101"] |$8. |
|
|
708-27-11101
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082701210", "7082701211", "7082711200", "7082711100"] |$9. |
|
|
708-27-11100
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082701210", "7082701211", "7082711200", "7082711101"] |$10. |
| |
708-27-00080
|
[1] |
CASE ASS'Y Komatsu
|
27.802 kg. |
|
["SN: 12001-UP"] analogs:["7082712120"] |$11. |
| 3 |
07044-12412
|
[1] |
PLUG Komatsu
|
0.09 kg. |
|
["SN: 12001-UP"] analogs:["0704402412", "R0704412412"] |
| 4 |
07002-02434
|
[1] |
O-RING Komatsu China
|
0.01 kg. |
|
["SN: 12001-UP"] analogs:["0700212434", "0700213434"] |
| 5 |
708-27-14110
|
[1] |
PISTON Komatsu
|
2.64 kg. |
|
["SN: 12001-UP"] |
| 6 |
708-27-14130
|
[1] |
SPRING Komatsu
|
0.28 kg. |
|
["SN: 12001-UP"] |
| 7 |
708-27-14140
|
[1] |
CAP Komatsu China
|
|
|
["SN: 12001-UP"] |
| 8 |
708-27-14150
|
[1] |
CAP Komatsu China
|
|
|
["SN: 12001-UP"] |
| 9 |
708-27-05060
|
[2] |
SHIM KIT Komatsu
|
0.032 kg. |
|
["SN: 12001-UP"] |
| 9 |
708-27-14190
|
[2] |
SHIM, 0.1MM Komatsu China
|
|
|
["SN: 12001-UP"] |
| 10 |
07000-02075
|
[2] |
O-RING Komatsu China
|
0.03 kg. |
|
["SN: 12001-UP"] analogs:["0700012075", "YM24321000750"] |
| 11 |
01016-51045
|
[8] |
BOLT Komatsu
|
0.039 kg. |
|
["SN: 12001-UP"] analogs:["0101631045", "0101681045"] |
| 12 |
01643-31032
|
[8] |
WASHER Komatsu
|
0.054 kg. |
|
["SN: 12001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] |
| |
708-27-00042
|
[1] |
CRADLE ASS'Y Komatsu China
|
|
|
["SN: .-UP"] analogs:["7082700041"] |$29. |
| |
708-27-00041
|
[1] |
CRADLE ASS'Y Komatsu China
|
|
|
["SN: (12968-.)"] analogs:["7082700042"] |$30. |
| |
708-27-00040
|
[1] |
CRADLE ASS'Y Komatsu China
|
|
|
["SN: 12001-."] |$31. |
| |
708-27-00460
|
[1] |
CRADLE SUB ASS'Y Komatsu
|
10.28 kg. |
|
["SN: 12001-UP"] analogs:["7082712320"] |$33. |
| 15 |
708-27-13412
|
[1] |
CAM Komatsu
|
3.873 kg. |
|
["SN: .-UP"] analogs:["7082713411"] |
| 15 |
708-27-13411
|
[1] |
CAM Komatsu
|
3.873 kg. |
|
["SN: (12968-.)"] analogs:["7082713412"] |
| 15 |
708-27-13410
|
[1] |
CAM Komatsu
|
3.873 kg. |
|
["SN: 12001-."] analogs:["7082713412", "7082713411"] |
| 16 |
708-27-12130
|
[1] |
O-RING Komatsu
|
0.007 kg. |
|
["SN: 12001-UP"] |
| 17 |
708-25-12330
|
[1] |
JOINT Komatsu
|
0.025 kg. |
|
["SN: 12001-UP"] |
| 18 |
07000-12015
|
[1] |
O-RING Komatsu China
|
0.001 kg. |
|
["SN: 12001-UP"] analogs:["0700002015"] |
| 19 |
708-27-12330
|
[2] |
PLATE Komatsu China
|
|
|
["SN: 12001-UP"] |
| 20 |
04020-00820
|
[4] |
PIN Komatsu
|
0.056 kg. |
|
["SN: 12001-UP"] analogs:["802540092"] |
| 21 |
708-27-12340
|
[4] |
SCREW Komatsu China
|
|
|
["SN: 12001-UP"] |
| 22 |
01643-30823
|
[4] |
WASHER Komatsu
|
0.004 kg. |
|
["SN: 12001-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"] |
| 23 |
708-27-12350
|
[1] |
STOPPER Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7062712350", "7067512350"] |
| 25 |
706-75-42270
|
[1] |
SCREW Komatsu
|
0.003 kg. |
|
["SN: 12001-UP"] |
| 26 |
01010-51450
|
[12] |
BOLT Komatsu
|
0.085 kg. |
|
["SN: 12001-UP"] analogs:["0101031450", "0101061450", "0101081450"] |
| 27 |
01643-31445
|
[12] |
WASHER Komatsu
|
0.019 kg. |
|
["SN: 12001-UP"] analogs:["0164301432"] |
| 28 |
708-27-12790
|
[1] |
COVER Komatsu China
|
|
|
["SN: 12001-UP"] |
| 29 |
07000-02015
|
[1] |
O-RING Komatsu China
|
0.001 kg. |
|
["SN: 12001-UP"] analogs:["0700012015"] |
| 30 |
01010-50820
|
[4] |
BOLT Komatsu
|
0.013 kg. |
|
["SN: 12001-UP"] analogs:["0101080820", "801014067", "801015086"] |
| 32 |
708-27-05010
|
[1] |
SHIM KIT Komatsu
|
0.015 kg. |
|
["SN: 12001-UP"] |
| |
708-27-00022
|
[1] |
CYLINDER BLOCK A. Komatsu
|
8.04 kg. |
|
["SN: .-UP"] analogs:["7082700020"] |$61. |
| |
708-27-00020
|
[1] |
CYLINDER BLOCK A. Komatsu
|
8.04 kg. |
|
["SN: 12798-."] |$62. |
| 33 |
708-27-13111
|
[1] |
CYLINDER BLOCK Komatsu
|
6.871 kg. |
|
["SN: 12798-UP"] |
| 33 |
708-27-13110
|
[1] |
BLOCK Komatsu
|
6.871 kg. |
|
["SN: 12001-12797"] analogs:["7082713111"] |
| 34 |
708-27-13222
|
[1] |
PLATE Komatsu China
|
|
|
["SN: .-UP"] analogs:["7082713221", "7082713220"] |
| 34 |
708-27-13221
|
[1] |
PLATE Komatsu China
|
|
|
["SN: 12798-."] analogs:["7082713220", "7082713222"] |
| 34 |
708-27-13220
|
[1] |
PLATE Komatsu China
|
|
|
["SN: 12001-12797"] analogs:["7082713221", "7082713222"] |
| 35 |
708-27-13314
|
[9] |
PISTON SUB ASS'Y Komatsu
|
0.32 kg. |
|
["SN: .-UP"] analogs:["7082713311"] |
| 35 |
\4\708-27-13312
|
[9] |
PISTON SUB ASS'Y Komatsu
|
0.32 kg. |
|
["SN: 12968-."] analogs:["7082713314", "7082713311"] |
| 35 |
708-27-13311
|
[9] |
PISTON SUB ASS'Y Komatsu
|
0.32 kg. |
|
["SN: 12798-12967"] analogs:["7082713314"] |
| 35 |
708-27-13310
|
[9] |
PISTON SUB ASS'Y Komatsu
|
0.32 kg. |
|
["SN: 12001-12797"] analogs:["7082713314", "7082713311"] |
| 36 |
708-27-13342
|
[1] |
RETAINER Komatsu
|
0.38 kg. |
|
["SN: .-UP"] analogs:["7082713341"] |
| 36 |
\4\708-27-13341
|
[1] |
RETAINER Komatsu
|
0.38 kg. |
|
["SN: 12798-."] analogs:["7082713342"] |
| 36 |
\4\708-27-13340
|
[1] |
RETAINER Komatsu China
|
|
|
["SN: 12001-12797"] |
| 37 |
708-27-05051
|
[1] |
SPACER KIT Komatsu
|
0.44 kg. |
|
["SN: 12001-UP"] |
| 38 |
708-27-13420
|
[2] |
RETAINER Komatsu
|
0.055 kg. |
|
["SN: 12001-UP"] |
| 39 |
708-27-13480
|
[4] |
SCREW Komatsu China
|
|
|
["SN: 12001-UP"] |
| 41 |
708-27-13120
|
[1] |
WASHER Komatsu
|
0.036 kg. |
|
["SN: 12001-UP"] |
| 42 |
708-27-13140
|
[1] |
SPRING Komatsu
|
0.2 kg. |
|
["SN: 12001-UP"] |
| 43 |
708-27-13130
|
[1] |
RETAINER Komatsu
|
0.034 kg. |
|
["SN: 12001-UP"] |
| 44 |
708-27-13150
|
[1] |
RING Komatsu China
|
|
|
["SN: 12001-UP"] |
| 45 |
708-27-14121
|
[1] |
SLIDER Komatsu China
|
|
|
["SN: .-UP"] analogs:["7082714120"] |
| 45 |
708-27-14120
|
[1] |
SLIDER Komatsu China
|
|
|
["SN: 12001-."] analogs:["7082714121"] |
| 46 |
01010-82075
|
[4] |
BOLT Komatsu China
|
0.25 kg. |
|
["SN: 12001-UP"] analogs:["0101062075", "0101032075", "0101052075"] |
| 47 |
708-27-12580
|
[4] |
WASHER Komatsu China
|
|
|
["SN: 12001-UP"] |
| Parts on group : |
|
|
|
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-27-02015
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082702011", "7082702014"] |$0. |
| |
708-27-02014
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13532-.)"] analogs:["7082702011"] |$1. |
| |
708-27-02013
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13424-13531)"] analogs:["7082702011", "7082702014"] |$2. |
| |
708-27-02012
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13075-13423)"] analogs:["7082702011", "7082702014"] |$3. |
| |
708-27-02011
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12968-13074)"] analogs:["7082702014"] |$4. |
| |
708-27-02010
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082702011", "7082702014"] |$5. |
| |
708-27-10100
|
[1] |
PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082702011", "7082702014"] |$6. |
|
1. |
708-27-01211
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082701210", "7082711200", "7082711100", "7082711101"] |
|
1. |
708-27-01210
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12968-.)"] analogs:["7082701211", "7082711200", "7082711100", "7082711101"] |
|
1. |
708-27-11101
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082701210", "7082701211", "7082711200", "7082711100"] |
|
1. |
708-27-11100
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12001-12797)"] analogs:["7082701210", "7082701211", "7082711200", "7082711101"] |
| 1 |
708-27-12710
|
[1] |
SHAFT Komatsu China
|
|
|
["SN: 12001-12797"] |
| 2 |
708-27-12720
|
[1] |
SHAFT Komatsu China
|
|
|
["SN: 12001-12797"] |
| 3 |
708-27-12750
|
[1] |
COLLAR Komatsu China
|
|
|
["SN: 12001-@"] |
| 4 |
708-27-14410
|
[1] |
GEAR Komatsu China
|
|
|
["SN: 12001-@"] |
| 5 |
708-27-12620
|
[1] |
SPACER Komatsu China
|
|
|
["SN: 12001-12797"] |
| 6 |
708-27-00330
|
[2] |
SPACER KIT Komatsu China
|
|
|
["SN: 12001-12797"] |
| 7 |
708-27-12610
|
[1] |
IMPELLER Komatsu China
|
|
|
["SN: 12001-12797"] |
| 8 |
706-75-42270
|
[8] |
SCREW Komatsu
|
0.003 kg. |
|
["SN: 12001-12797"] |
| 9 |
01643-30623
|
[4] |
WASHER Komatsu
|
0.002 kg. |
|
["SN: 12001-12797"] analogs:["0164370623"] |
| 10 |
708-27-12810
|
[1] |
COUPLING Komatsu China
|
|
|
["SN: 12001-12797"] |
| 11 |
708-27-12820
|
[1] |
RING Komatsu China
|
|
|
["SN: 12001-@"] |
| 12 |
04000-01020
|
[1] |
KEY Komatsu China
|
|
|
["SN: 12001-@"] |
| 13 |
708-27-12730
|
[2] |
BEARING Komatsu
|
1.179 kg. |
|
["SN: 12001-@"] |
| 14 |
07000-02060
|
[1] |
O-RING Komatsu China
|
0.002 kg. |
|
["SN: 12001-@"] analogs:["0700012060", "R0700002060"] |
| 15 |
708-27-05030
|
[1] |
SPACER KIT Komatsu China
|
|
|
["SN: 12001-@"] |
| 16 |
708-27-12960
|
[4] |
SCREW Komatsu China
|
|
|
["SN: 12001-@"] |
| 17 |
708-27-12740
|
[2] |
BEARING Komatsu
|
0.24 kg. |
|
["SN: 12001-@"] |
| 18 |
06000-51109
|
[2] |
BEARING Komatsu China
|
|
|
["SN: 12001-@"] |
| 19 |
04000-00515
|
[2] |
KEY Komatsu China
|
|
|
["SN: 12001-@"] |
| 20 |
708-27-12780
|
[1] |
PLATE Komatsu China
|
|
|
["SN: 12001-@"] |
| 21 |
708-27-14490
|
[1] |
BOLT Komatsu China
|
|
|
["SN: 12001-@"] |
| Parts on group : |
|
|
|
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-27-02015
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082702011", "7082702014"] |$0. |
| |
708-27-02014
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13532-.)"] analogs:["7082702011"] |$1. |
| |
708-27-02013
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13424-13531)"] analogs:["7082702011", "7082702014"] |$2. |
| |
708-27-02012
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (13075-13423)"] analogs:["7082702011", "7082702014"] |$3. |
| |
708-27-02011
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12968-13074)"] analogs:["7082702014"] |$4. |
| |
708-27-02010
|
[1] |
HYDRAULIC PUMP ASS'Y,(HPV 160+160) Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082702011", "7082702014"] |$5. |
|
1. |
708-27-01211
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: 12001-UP"] analogs:["7082701210", "7082711200", "7082711100", "7082711101"] |
|
1. |
708-27-01210
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12968-.)"] analogs:["7082701211", "7082711200", "7082711100", "7082711101"] |
|
1. |
708-27-11101
|
[1] |
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: (12798-12967)"] analogs:["7082701210", "7082701211", "7082711200", "7082711100"] |
| 1 |
708-27-12711
|
[1] |
SHAFT Komatsu
|
7.241 kg. |
|
["SN: 12798-UP"] |
| 2 |
708-27-12721
|
[1] |
SHAFT Komatsu
|
4.35 kg. |
|
["SN: 12798-UP"] |
| 3 |
708-27-12750
|
[1] |
COLLAR Komatsu China
|
|
|
["SN: 12001-UP"] |
| 4 |
708-27-14410
|
[1] |
GEAR Komatsu China
|
|
|
["SN: 12001-UP"] |
| 5 |
708-27-12621
|
[2] |
SPACER Komatsu China
|
|
|
["SN: 12798-UP"] |
| 6 |
708-27-05020
|
[2] |
SPACER KIT Komatsu China
|
|
|
["SN: 12798-UP"] |
| 7 |
708-27-12680
|
[2] |
RING Komatsu China
|
|
|
["SN: 12798-UP"] |
| 8 |
708-27-12690
|
[1] |
IMPELLER Komatsu China
|
|
|
["SN: .-UP"] |
| 8 |
708-27-12611
|
[1] |
IMPELLER Komatsu China
|
|
|
["SN: 12798-."] |
| 9 |
708-27-12860
|
[1] |
PLATE Komatsu China
|
|
|
["SN: 12798-UP"] |
| 10 |
708-23-12350
|
[8] |
SCREW Komatsu
|
0.008 kg. |
|
["SN: 12798-UP"] |
| 11 |
01643-30823
|
[8] |
WASHER Komatsu
|
0.004 kg. |
|
["SN: 12798-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"] |
| 12 |
708-27-12811
|
[1] |
COUPLING Komatsu China
|
|
|
["SN: 12798-UP"] |
| 13 |
708-27-12820
|
[1] |
RING Komatsu China
|
|
|
["SN: 12001-UP"] |
| 14 |
04000-01020
|
[1] |
KEY Komatsu China
|
|
|
["SN: 12001-UP"] |
| 15 |
708-27-12730
|
[2] |
BEARING Komatsu
|
1.179 kg. |
|
["SN: 12001-UP"] |
| 16 |
07000-02060
|
[1] |
O-RING Komatsu China
|
0.002 kg. |
|
["SN: 12001-UP"] analogs:["0700012060", "R0700002060"] |
| 17 |
708-27-05030
|
[1] |
SPACER KIT Komatsu China
|
|
|
["SN: 12001-UP"] |
| 18 |
708-27-12960
|
[4] |
SCREW Komatsu China
|
|
|
["SN: 12001-UP"] |
| 19 |
708-27-12740
|
[2] |
BEARING Komatsu
|
0.24 kg. |
|
["SN: 12001-UP"] |
| 20 |
06000-51109
|
[2] |
BEARING Komatsu China
|
|
|
["SN: 12001-UP"] |
| 21 |
04000-00515
|
[2] |
KEY Komatsu China
|
|
|
["SN: 12001-UP"] |
| 22 |
708-27-12780
|
[1] |
PLATE Komatsu China
|
|
|
["SN: 12001-UP"] |
| 23 |
708-27-14490
|
[1] |
BOLT Komatsu China
|
|
|
["SN: 12001-UP"] |
