2A8-27-00120 2A8-27-00121
706-8J-01470 RH
PC390HRD-11E0 PC390LC-11 PC390LC-11 HRD PC390LC-8M0 PC390LCI-11 PC400-8 PC400-8R PC400LC-8 PC400LC-8R PC430-8 PC450-8 PC450-8R PC450LC-8 PC450LC-8R PC460LC-8 PC490-11 PC490-11E0 PC490HRD-11E0 PC490LC-10 PC490LC-11 PC490LC-11E0 PC490LCI-11 PC500LC-10M0 PC500LC-10R |
|
№
|
Number |
Qty |
Name |
Options |
|
2A8-27-00121
|
1
|
Final Drive Assembly |
SN: 100003-
|
|
2A8-27-00120
|
1
|
Final Drive Assembly |
SN: 100001-100002
|
|
706-8J-01470
|
1
|
Motor Assembly |
SN: 100001-
|
| 1
|
706-8J-42340
|
1
|
Case, Motor |
SN: 100001-
|
|
706-8J-00650
|
1
|
Cover Subassembly |
SN: 100001-
|
| 2
|
|
1
|
Cover, End |
SN: 100001-
|
| 3
|
|
1
|
Plate |
SN: 100001-
|
| 4
|
|
1
|
Cylinder Block |
SN: 100001-
|
| 5
|
|
1
|
Spool |
SN: 100001-
|
| 6
|
|
17
|
Plug, Stocking |
SN: 100001-
|
| 7
|
706-86-71310
|
1
|
Pin |
SN: 100001-
|
| 8
|
706-8E-14191
|
5
|
Plug |
SN: 100001-
|
| 9
|
07002-11823
|
5
|
O-ring |
SN: 100001-
|
| 10
|
706-8J-71550
|
2
|
Piston |
SN: 100001-
|
| 11
|
706-8J-71560
|
1
|
Pin |
SN: 100001-
|
| 12
|
706-8J-71130
|
2
|
Plug |
SN: 100001-
|
| 13
|
07002-12434
|
2
|
O-ring |
SN: 100001-
|
| 14
|
706-8J-71140
|
2
|
Plug |
SN: 100001-
|
| 15
|
07002-12434
|
2
|
O-ring |
SN: 100001-
|
| 16
|
20B-27-11210
|
1
|
Bleeder |
SN: 100001-
|
| 17
|
706-75-74540
|
2
|
Valve |
SN: 100001-
|
| 18
|
706-75-74550
|
2
|
Spring |
SN: 100001-
|
| 19
|
706-75-74850
|
2
|
Plug |
SN: 100001-
|
| 20
|
07002-13334
|
2
|
O-ring |
SN: 100001-
|
| 21
|
708-8F-36120
|
2
|
Ring |
SN: 100001-
|
| 22
|
706-78-71280
|
2
|
Spring |
SN: 100001-
|
| 23
|
706-78-71230
|
2
|
Plug |
SN: 100001-
|
| 24
|
07002-13634
|
2
|
O-ring |
SN: 100001-
|
| 25
|
706-8E-14170
|
1
|
Spring |
SN: 100001-
|
| 26
|
706-8J-71150
|
1
|
Spool |
SN: 100001-
|
| 27
|
706-8J-71160
|
1
|
Plug |
SN: 100001-
|
| 28
|
07002-11823
|
1
|
O-ring |
SN: 100001-
|
| 29
|
708-3D-15110
|
2
|
Valve |
SN: 100001-
|
| 30
|
706-8J-72190
|
2
|
Plug |
SN: 100001-
|
| 31
|
07002-11023
|
2
|
O-ring |
SN: 100001-
|
| 32
|
706-8J-71181
|
2
|
Valve |
SN: 100001-
|
| 33
|
706-8J-71190
|
2
|
Plug |
SN: 100001-
|
| 34
|
07002-11223
|
2
|
O-ring |
SN: 100001-
|
| 35
|
706-8J-72330
|
2
|
Spring |
SN: 100001-
|
| 36
|
07000-15275
|
1
|
O-ring |
SN: 100001-
|
| 37
|
07000-12012
|
1
|
O-ring |
SN: 100001-
|
| 38
|
01252-62060
|
8
|
Bolt, Hexagon Socket Head |
SN: 100001-
|
|
№
|
Number |
Qty |
Name |
Options |
|
2A8-27-00121
|
1
|
Final Drive Assembly |
SN: 100003-
|
|
2A8-27-00120
|
1
|
Final Drive Assembly |
SN: 100001-100002
|
|
706-8J-01470
|
1
|
Motor Assembly |
SN: 100001-
|
| 1
|
706-8J-41610
|
1
|
Shaft, Drive |
SN: 100001-
|
| 2
|
706-8J-41010
|
1
|
Bearing |
SN: 100001-
|
| 3
|
706-77-42890
|
1
|
Bearing |
SN: 100001-
|
| 4
|
706-8J-41810
|
1
|
Retainer |
SN: 100001-
|
| 5
|
706-8J-41660
|
1
|
Spacer Kit |
SN: 100001-
|
|
|
1
|
Spacer, T=2.1mm |
SN: 100001-
|
|
|
1
|
Spacer, T=2.3mm |
SN: 100001-
|
|
|
1
|
Spacer, T=2.5mm |
SN: 100001-
|
|
|
1
|
Spacer, T=2.7mm |
SN: 100001-
|
|
|
1
|
Spacer, T=1.9mm |
SN: 100001-
|
| 6
|
04064-06525
|
1
|
Ring, Snap, for Shaft Side |
SN: 100001-
|
| 7
|
706-8J-42330
|
1
|
Seal, Oil |
SN: 100001-
|
| 8
|
706-8J-41820
|
1
|
Spacer |
SN: 100001-
|
| 9
|
04065-09030
|
1
|
Ring, Snap |
SN: 100001-
|
| 10
|
706-8J-42940
|
1
|
Shaft |
SN: 100001-
|
| 11
|
706-8J-42950
|
1
|
Race |
SN: 100001-
|
| 12
|
706-8J-43360
|
1
|
Spring |
SN: 100001-
|
| 13
|
706-8J-42970
|
1
|
Retainer |
SN: 100001-
|
| 14
|
708-23-12350
|
7
|
Screw |
SN: 100001-
|
| 15
|
706-8J-42170
|
7
|
Piston Subassembly |
SN: 100001-
|
| 16
|
706-7K-91340
|
5
|
Plate |
SN: 100001-
|
| 17
|
706-7K-91350
|
4
|
Disc |
SN: 100001-
|
| 18
|
706-8J-91110
|
1
|
Piston |
SN: 100001-
|
| 19
|
07000-15230
|
1
|
O-ring |
SN: 100001-
|
| 20
|
07001-05230
|
1
|
Ring, Back-up |
SN: 100001-
|
| 21
|
708-8H-15220
|
1
|
O-ring |
SN: 100001-
|
| 22
|
706-8J-91120
|
1
|
Ring, Back-up |
SN: 100001-
|
| 23
|
706-8J-91130
|
6
|
Spring |
SN: 100001-
|
|
№
|
Number |
Qty |
Name |
Options |
|
2A8-27-00121
|
1
|
Final Drive Assembly |
SN: 100003-
|
|
2A8-27-00120
|
1
|
Final Drive Assembly |
SN: 100001-100002
|
|
706-8J-01470
|
1
|
Motor Assembly |
SN: 100001-
|
| 1
|
702-75-04601
|
1
|
Valve Assembly, Relief |
SN: 100001-
|
| 2
|
07000-22018
|
1
|
O-ring |
SN: 100001-
|
| 3
|
702-75-11830
|
2
|
Ring, Back-up |
SN: 100001-
|
| 4
|
07000-12021
|
1
|
O-ring |
SN: 100001-
|
| 5
|
|
1
|
Ring, Back-up |
SN: 100001-
|
| 6
|
702-75-11520
|
1
|
O-ring |
SN: 100001-
|
| 7
|
|
1
|
Ring, Back-up |
SN: 100001-
|
| 8
|
07002-13634
|
1
|
O-ring |
SN: 100001-
|
