KOMATSU 22P-60-11301 TZ110D200001-H TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

Name: KOMATSU 22P-60-11301 TZ110D200001-H TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

KOMATSU 22P-60-11301 TZ110D200001-H TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

22P-60-11301 TZ110D200001-H PC78US-8 PC78UU-8 PC88MR-8

Pos.	Part No	Qty	Parts name	Comments
	22P-60-11301	[2]	Motor Assembly Komatsu	83 kg.
			["SN: 15001-UP"] \|$0.
	TZ110D200001-H	[1]	Motor Komatsu China
			["SN: 15001-UP"] \|$1.
	TZ277B2205-00	[1]	Cylinder and Piston Kit Komatsu China
			["SN: 15001-UP"] \|$2.
3	TZ263B2070-01	[1]	Piston Assembly Komatsu	0.05 kg.
			["SN: 15001-UP"] analogs:["TZ263B207000"]
6	TZ110D2002-00	[1]	Shaft Komatsu China
			["SN: 15001-UP"]
7	TZ110D200300-H	[1]	Swash Plate Komatsu China
			["SN: 15001-UP"]
8	TZ277B2007-00	[1]	Retainer Plate Komatsu China
			["SN: 15001-UP"]
9	TZ263B2008-01	[1]	Thrust Ball Komatsu China
			["SN: 15001-UP"]
10	TZ110D2009-01	[1]	Timing Plate Komatsu China
			["SN: 15001-UP"]
11	TZ880A2010-00	[2]	Washer Komatsu	0.011 kg.
			["SN: 15001-UP"]
12	TZ263B2011-03	[1]	Washer Komatsu China
			["SN: 15001-UP"]
13	TZ266B2012-00	[1]	Piston Komatsu China
			["SN: 15001-UP"] analogs:["843400050"]
14	TZ500D2013-00	[10]	Spring Komatsu	0.012 kg.
			["SN: 15001-UP"]
15	TZ277B2014-00	[1]	Spring Komatsu China
			["SN: 15001-UP"]
16	TZ800A2015-00	[2]	Plate Komatsu	0.076 kg.
			["SN: 15001-UP"]
17	TZ800A2016-00	[3]	Plate Komatsu	0.06 kg.
			["SN: 15001-UP"]
18	TZTCZ-30-50-9	[1]	Seal, Oil, (Kit : K01) Komatsu China
			["SN: 15001-UP"]
19	TZ266B2035-00	[1]	O-ring, (Kit : K01) Komatsu	0.02 kg.
			["SN: 15001-UP"]
20	TZ266B2039-00	[1]	O-ring, (Kit : K01) Komatsu	0.011 kg.
			["SN: 15001-UP"]
21	TZTH-R-42	[1]	Ring, Snap Komatsu China
			["SN: 15001-UP"] analogs:["843400070", "TZIRT04218", "TZIRTW42"]
22	06000-06206	[1]	Bearing Komatsu	0.214 kg.
			["SN: 15001-UP"] analogs:["805010105"]
23	TZ400G2049-00	[1]	Bearing Komatsu China
			["SN: 15001-UP"]
24	TZ263B2098-00	[3]	Roller Komatsu China
			["SN: 15001-UP"]
25	TZ263B2076-02	[2]	Pivot Komatsu	0.008 kg.
			["SN: 15001-UP"]
26	TZ263B2077-01	[2]	Pin Komatsu	0.005 kg.
			["SN: 15001-UP"]
27	TZ263B2090-00	[1]	Spring Komatsu	0.001 kg.
			["SN: 15001-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	22P-60-11301	[2]	Motor Assembly Komatsu	83 kg.
			["SN: 15001-UP"] \|$0.
	TZ111D400000-F	[1]	Valve Assembly, Control Komatsu China
			["SN: 15001-UP"] \|$1.
	TZ111D410000-F	[1]	Flange Assembly,Rear Komatsu China
			["SN: 15001-UP"] \|$2.
	TZ111D410100-F	[1]	Flange Kit,Rear Komatsu China
			["SN: 15001-UP"] \|$3.
3	TZGM1-8-S	[3]	Plug, Hexagon Head Komatsu China
			["SN: 15001-UP"]
5	TZGDL1-16-S	[4]	Plug, Hexagon Head Komatsu China
			["SN: 15001-UP"]
10	07040-12012	[1]	Plug Komatsu	0.088 kg.
			["SN: 15001-UP"]
11	TZ110D4024-00	[2]	Plug Komatsu China
			["SN: 15001-UP"]
12	TZ869A205200-B	[2]	Retainer Spring Komatsu China
			["SN: 15001-UP"]
13	TZ500D4054-00	[2]	Valve Komatsu China
			["SN: 15001-UP"] analogs:["TA500D405400"]
14	TZ116D4056-00	[2]	Spring Komatsu China
			["SN: 15001-UP"]
15	TZ500D4055-00	[2]	Spring Komatsu China
			["SN: 15001-UP"]
16	TZJB2401-P26-9	[2]	O-ring, (Kit : K01) Komatsu China
			["SN: 15001-UP"] analogs:["843400064", "TZJB2401P2690"]
17	07000-12018	[2]	O-ring, (Kit : K01) Komatsu China	0.001 kg.
			["SN: 15001-UP"] analogs:["KB9511301800", "YM24311000180", "0700002018", "2083811590"]
18	TZ200B2073-00	[1]	Valve Komatsu	0.02 kg.
			["SN: 15001-UP"]
19	TZ300B2039-00	[1]	Stopper Komatsu	0.011 kg.
			["SN: 15001-UP"]
20	TZ300B2042-00	[1]	Ring Komatsu	0.002 kg.
			["SN: 15001-UP"]
21	TZ300B2043-01	[1]	Spring Komatsu	0.017 kg.
			["SN: 15001-UP"] analogs:["TZ300B204300"]
22	07002-12034	[1]	O-ring, (Kit : K01) Komatsu China	0.94 kg.
			["SN: 15001-UP"] analogs:["0700002034", "0700202034", "0700012034"]
23	TZ610B2021-00	[2]	Plug Komatsu China
			["SN: 15001-UP"]
24	TZJB1354-4-10	[1]	Pin Komatsu	0.01 kg.
			["SN: 15001-UP"]
25	01252-31230	[8]	Bolt Komatsu	0.045 kg.
			["SN: 15001-UP"] analogs:["0125201230"]
