KOMATSU 21W-60-41201 TZ500D200000-K TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

KOMATSU 21W-60-41201 TZ500D200000-K TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
21W-60-41201 TZ500D200000-K
PC78MR-6 PC78US-6 PC78UU-6
Pos. Part No Qty Parts name Comments
1   21W-27-41110   [2]   SPROCKET Komatsu 19.05 kg.
  ["SN: 4001-UP"]
2   201-27-61230   [28]   BOLT Komatsu 0.1 kg.
  ["SN: 4001-UP"]
3   01643-31445   [28]   WASHER Komatsu 0.019 kg.
  ["SN: 4001-UP"] analogs:["0164301432"]
4   21W-60-41201   [2]   MOTOR ASS'Y Komatsu 81 kg.
  ["SN: 4001-UP"] analogs:["21W6041202"]
5   01010-81640   [28]   BOLT Komatsu 0.264 kg.
  ["SN: 4001-UP"] analogs:["0101061640", "801015186", "0101031640", "0101051640"]
6   01643-31645   [28]   WASHER Komatsu 0.072 kg.
Parts on group :
Pos. Part No Qty Parts name Comments
     21W-60-41201   [1]   MOTOR ASS'Y Komatsu 81 kg.
  ["SN: 4001-UP"] analogs:["21W6041202"] |1.
        TZ500D200000-K   [1]   MOTOR Komatsu China
  ["SN: 4001-UP"] |1.
     TZ500D2105-00   [1]   PISTON KIT Komatsu 0.6 kg.
  ["SN: 4001-UP"] |1.
     TZ500D2070-00   [1]   PISTON ASS'Y Komatsu China
  ["SN: 4001-UP"] |3.
5 TZ500D2002-00 [1]   SHAFT Komatsu 0.55 kg.
  ["SN: 4001-UP"]
6   TZ500D200300-K   [1]   PLATE,SWASH Komatsu China
  ["SN: 4001-UP"]
7   TZ500D2004-00   [1]   BLOCK,CYLINDER Komatsu China
  ["SN: 4001-UP"]
8   TZ500D2007-00   [1]   PLATE,RETAINER Komatsu China
  ["SN: 4001-UP"]
9   TZ500D2008-00   [1]   BOWL,THRUST Komatsu China
  ["SN: 4001-UP"]
10   TZ500D2009-00   [1]   PLATE,TIMING Komatsu China
  ["SN: 4001-UP"]
11   TZ500D2010-00   [2]   WASHER Komatsu China
  ["SN: 4001-UP"]
12   TZ500D2012-00   [1]   PISTON Komatsu China
  ["SN: 4001-UP"]
13   TZ500D2013-00   [8]   SPRING Komatsu 0.012 kg.
  ["SN: 4001-UP"]
14   TZ500D2014-00   [1]   SPRING Komatsu China
  ["SN: 4001-UP"]
15   TZ500D2015-00   [2]   DISC Komatsu China
  ["SN: 4001-UP"]
16   TZ500D2016-00   [2]   PLATE Komatsu China
  ["SN: 4001-UP"]
17   TZ15Z-22-42-10   [1]   SEAL,OIL (KIT) Komatsu 0.023 kg.
  ["SN: 4001-UP"] analogs:["TZ02204210"]
18   TZ500D2035-00   [1]   O-RING (KIT) Komatsu China
  ["SN: 4001-UP"]
19   TZ500D2039-00   [1]   O-RING (KIT) Komatsu 0.01 kg.
  ["SN: 4001-UP"]
20   TZIRTW-36   [1]   RING,SNAP Komatsu China
  ["SN: 4001-UP"]
21   TZ880A2029-00   [1]   BEARING Komatsu 0.15 kg.
  ["SN: 4001-UP"]
22   06000-06301   [1]   BEARING Komatsu 0.08 kg.
  ["SN: 4001-UP"]
23   TZ500D2098-00   [3]   PIN Komatsu China
  ["SN: 4001-UP"]
24   TZ500D2076-00   [2]   PIVOT Komatsu China
  ["SN: 4001-UP"]
25   TZ263B2077-01   [2]   PIN Komatsu 0.005 kg.
  ["SN: 4001-UP"]
26   TZ844B2085-00   [1]   SPRING Komatsu China
  ["SN: 4001-UP"] analogs:["843400086"]
K.   TZ505D9000-00   [1]   SEAL KIT,TRAVEL MOTOR Komatsu 1.68 kg.
  ["SN: 4001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     21W-60-41201   [1]   MOTOR ASS'Y Komatsu 81 kg.
  ["SN: 4001-UP"] analogs:["21W6041202"] |1.
        TZ505D400002-Q   [1]   MOTOR Komatsu China
  ["SN: 4001-UP"] |1.
     TZ505D410002-Q   [1]   FLANGE ASS'Y,REAR Komatsu China
  ["SN: 4001-UP"] |1.
     TZ505D410102-Q   [1]   FLANGE KIT,REAR Komatsu China
  ["SN: 4001-UP"] |1.
     TZ502D4110-00   [1]   SPOOL KIT Komatsu China
  ["SN: 4001-UP"] |3.
3   TZ502D4069-00   [1]   SPOOL Komatsu China
  ["SN: 4001-UP"]
4   TZAOS-4   [1]   STOPPER Komatsu China
  ["SN: 4001-UP"]
5   TZ100A2021-00   [1]   PLUG Komatsu China
  ["SN: 4001-UP"] analogs:["843400055", "R100A20210", "TZR100A20210"]
6   TZ810B2021-00   [1]   PLUG Komatsu 0.03 kg.
  ["SN: 4001-UP"]
7   TZ860A2051-00   [2]   PLUG Komatsu 0.183 kg.
  ["SN: 4001-UP"]
8   TZ869A205200-B   [2]   RETAINER,SPRING Komatsu China
  ["SN: 4001-UP"]
9   TA500D4054-00   [2]   VALVE Komatsu China
  ["SN: 4001-UP"] analogs:["TZ500D405400"]
10   TZ860A2056-00   [2]   SPRING Komatsu China
  ["SN: 4001-UP"] analogs:["843400060", "R860A20560"]
11   TZ500D4055-00   [2]   SPRING Komatsu China
  ["SN: 4001-UP"]
12   TZJB2401-P26-9   [2]   O-RING (KIT) Komatsu China
  ["SN: 4001-UP"] analogs:["843400064", "TZJB2401P2690"]
13   07000-12018   [2]   O-RING (KIT) Komatsu China 0.001 kg.
  ["SN: 4001-UP"] analogs:["KB9511301800", "YM24311000180", "0700002018", "2083811590"]
14   TZGM1-8-S   [3]   PLUG Komatsu China
  ["SN: 4001-UP"]
15   TZJB1501-3-16   [1]   BALL Komatsu China
  ["SN: 4001-UP"]
16   07002-12034   [1]   O-RING (KIT) Komatsu China 0.94 kg.
  ["SN: 4001-UP"] analogs:["0700002034", "0700202034", "0700012034"]
17   TZGDL1-16-S   [5]   PLUG Komatsu China
  ["SN: 4001-UP"]
18   TZ976B2079-00   [1]   FILTER Komatsu 0.000 kg.
  ["SN: 4001-UP"]
19   TZS0505   [1]   ORIFICE Komatsu China
  ["SN: 4001-UP"]
20   TZ500D4089-00   [1]   SPRING Komatsu China
  ["SN: 4001-UP"]
21   TZ610B2021-00   [2]   PLUG Komatsu China
  ["SN: 4001-UP"]
22   TZ571B2079-00   [1]   PLUG Komatsu China
  ["SN: 4001-UP"]
23   07000-12014   [1]   O-RING (KIT) Komatsu China 0.01 kg.
  ["SN: 4001-UP"] analogs:["0700002014"]
24   TZ850A0006-00   [1]   PLATE¤ NAME Komatsu 0.01 kg.
  ["SN: 4001-UP"]
25   TZJB1354-4-10   [2]   PIN Komatsu 0.01 kg.
  ["SN: 4001-UP"]
26   01252-31230   [6]   BOLT Komatsu 0.045 kg.
  ["SN: 4001-UP"] analogs:["0125201230"]
K.   TZ505D9000-00   [1]   SEAL KIT,TRAVEL MOTOR Komatsu 1.68 kg.
  ["SN: 4001-UP"]
