KOMATSU 208-27-00321 706-8J-01030 TRAVEL MOTOR PARTS

KOMATSU 208-27-00321 706-8J-01030 TRAVEL MOTOR PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
208-27-00321 706-8J-01030
PC350LL-7E0 PC350HD-8 PC400-7 PC400LC-7 PC400-8 PC400-8R PC400LC-8 PC400LC-8R PC450-7 PC450-8 PC450-8R PC450LC-7 PC450LC-8 PC450LC-8R PC450LCHD-8 PC490-10 PC490LC-10
Pos. Part No Qty Parts name Comments
     208-27-00321   [2]   Final Drive Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        706-8J-01030   [1]   Motor Assembly Komatsu OEM 220 kg.
  ["SN: 80001-UP"] analogs:["7068J01011", "7068J01012", "7068J01031", "R7068J01031"] |$1.
1   706-8J-41110   [1]   Case, Motor Komatsu 110 kg.
  ["SN: 80001-UP", "SCC: C2"]
     706-8J-00013   [1]   Cover Subassembly Komatsu 57.1 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["7068J00011", "7068J00012", "7068J71112"] |$3.
8   706-86-71310   [1]   Pin, Dowel Komatsu 0.022 kg.
  ["SN: 80001-UP", "SCC: C2"]
9   706-8E-14191   [5]   Plug Komatsu China
  ["SN: 80001-UP"] analogs:["890001288"]
10   07002-11823   [5]   O-Ring Komatsu 0.36 kg.
  ["SN: 80001-UP"] analogs:["0700201823"]
11   706-8J-71550   [2]   Piston Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
12   706-8J-71560   [1]   Pin Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
13   706-8J-71130   [2]   Plug Komatsu China
  ["SN: 80001-UP"]
14   07002-12434   [2]   O-Ring Komatsu China 0.01 kg.
  ["SN: 80001-UP"] analogs:["0700202434", "0700213434"]
15   706-8J-71140   [2]   Plug Komatsu China
  ["SN: 80001-UP"]
17   20B-27-11210   [1]   Bleeder Komatsu 0.02 kg.
  ["SN: 80001-UP"]
18   706-75-74540   [2]   Valve Komatsu 0.134 kg.
  ["SN: 80001-UP"]
19   706-75-74550   [2]   Spring Komatsu 0.012 kg.
  ["SN: 80001-UP"]
20   706-75-74850   [2]   Plug Komatsu China
  ["SN: 80001-UP"]
21   07002-13334   [2]   O-Ring Komatsu China 0.025 kg.
  ["SN: 80001-UP"] analogs:["0700203334"]
22   708-8F-36120   [2]   Ring Komatsu 0.01 kg.
  ["SN: 80001-UP"]
23   706-78-71280   [2]   Spring Komatsu China
  ["SN: 80001-UP"]
24   706-78-71230   [2]   Plug Komatsu China
  ["SN: 80001-UP"]
25   07002-13634   [2]   O-Ring Komatsu China 0.013 kg.
  ["SN: 80001-UP"] analogs:["0700203634"]
26   706-8E-14170   [1]   Spring Komatsu 0.01 kg.
  ["SN: 80001-UP"]
27   706-8J-71150   [1]   Spool Komatsu 0.12 kg.
  ["SN: 80001-UP"]
28   706-8J-71160   [1]   Plug Komatsu 0.16 kg.
  ["SN: 80001-UP"]
30   706-86-53410   [2]   Valve Komatsu China
  ["SN: 80001-UP"]
31   706-8J-71170   [2]   Plug Komatsu China
  ["SN: 80001-UP"]
32   07002-11023   [2]   O-Ring Komatsu China 0.025 kg.
  ["SN: 80001-UP"] analogs:["0700201023"]
33   708-8E-16180   [1]   Valve Komatsu 0.004 kg.
  ["SN: 80001-UP"]
34   706-8J-71181   [1]   Valve Komatsu China
  ["SN: 80001-UP"] analogs:["7068J71180"]
35   708-8E-16160   [1]   Plug Komatsu 0.01 kg.
  ["SN: 80001-UP"]
37   706-8J-71190   [1]   Plug Komatsu China
  ["SN: 80001-UP"]
38   07002-11223   [1]   O-Ring Komatsu China 0.001 kg.
  ["SN: 80001-UP"] analogs:["0700201223"]
39   07000-15275   [1]   O-Ring Komatsu 0.032 kg.
  ["SN: 80001-UP", "SCC: C2"]
40   07000-12012   [1]   O-Ring Komatsu China 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["0700002012", "7082E11790"]
41   01252-62060   [8]   Bolt Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     208-27-00321   [2]   Final Drive Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        706-8J-01030   [1]   Motor Assembly Komatsu OEM 220 kg.
  ["SN: 80001-UP"] analogs:["7068J01011", "7068J01012", "7068J01031", "R7068J01031"] |$1.
1 706-8J-41610 [1]   Shaft, Drive Komatsu 6.402 kg.
  ["SN: 80001-UP", "SCC: C2"]
2   706-8J-41010   [1]   Bearing Komatsu 8.22 kg.
  ["SN: 80001-UP", "SCC: C2"]
3   706-77-42890   [1]   Bearing Komatsu 1.185 kg.
  ["SN: 80001-UP", "SCC: C2"]
4   706-8J-41810   [1]   Retainer Komatsu 1.09 kg.
  ["SN: 80001-UP", "SCC: C2"]
5   706-8J-41660   [1]   Spacer Kit Komatsu 0.23 kg.
  ["SN: 80001-UP", "SCC: C2"]
6   04064-06525   [1]   Ring, Snap, for Shaft Side Komatsu China 0.021 kg.
  ["SN: 80001-UP", "SCC: C2"]
7   706-8J-41620   [1]   Seal, Oil Komatsu 0.15 kg.
  ["SN: 80001-UP"] analogs:["7068J42330"]
8   706-8J-41820   [1]   Spacer Komatsu 0.12 kg.
  ["SN: 80001-UP"]
9   04065-09030   [1]   Ring, Snap, for Hole Side Komatsu 0.03 kg.
  ["SN: 80001-UP"] analogs:["2324013250", "R0406509030"]
10   706-8J-41280   [1]   Shaft Komatsu OEM 1.91 kg.
  ["SN: 80001-UP", "SCC: C2"]
11   706-8J-41270   [1]   Ring Komatsu 0.26 kg.
  ["SN: 80001-UP", "SCC: C2"]
12   706-8J-41290   [1]   Spring Komatsu 0.38 kg.
  ["SN: 80001-UP", "SCC: C2"]
13   706-8J-41260   [1]   Retainer Komatsu OEM 2.22 kg.
  ["SN: 80001-UP", "SCC: C2"]
14   708-23-12350   [7]   Screw Komatsu 0.008 kg.
  ["SN: 80001-UP", "SCC: C2"]
15   706-8J-42170   [7]   Piston Subassembly Komatsu OEM 0.000 kg.
  ["SN: 80001-UP", "SCC: C2"]
16   706-7K-91340   [5]   Plate Komatsu 1 kg.
  ["SN: 80001-UP", "SCC: C2"]
17   706-7K-91350   [4]   Disc Komatsu 0.24 kg.
  ["SN: 80001-UP", "SCC: C2"]
18   706-8J-91110   [1]   Piston Komatsu 9.802 kg.
  ["SN: 80001-UP", "SCC: C2"]
19   07000-15230   [1]   O-Ring Komatsu China 0.03 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["0700005230"]
20   07001-05230   [1]   Ring, Back-Up Komatsu 0.016 kg.
  ["SN: 80001-UP", "SCC: C2"]
21   708-8H-15220   [1]   O-Ring Komatsu 0.025 kg.
  ["SN: 80001-UP", "SCC: C2"]
22   706-8J-91120   [1]   Ring, Back-Up Komatsu 0.02 kg.
  ["SN: 80001-UP", "SCC: C2"]
23   706-8J-91130   [6]   Spring Komatsu 0.24 kg.
  ["SN: 80001-UP", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     208-27-00321   [2]   Final Drive Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        706-8J-01030   [1]   Motor Assembly Komatsu OEM 220 kg.
  ["SN: 80001-UP"] analogs:["7068J01011", "7068J01012", "7068J01031", "R7068J01031"] |$1.
1 702-75-04601 [1]   Valve Assembly, Relief Komatsu 0.85 kg.
  ["SN: 80001-UP"] analogs:["7027504600"]
2   07000-22018   [1]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP"] analogs:["07000F2018"]
3   702-75-11830   [2]   Ring, Back-Up Komatsu China
  ["SN: 80001-UP"]
4   07000-12021   [1]   O-Ring Komatsu China 0.01 kg.
  ["SN: 80001-UP"] analogs:["0700002021"]
5   702-75-11840   [1]   Ring, Back-Up Komatsu China
  ["SN: 80001-UP"]
6   702-75-11520   [1]   O-Ring Komatsu 0.001 kg.
  ["SN: 80001-UP"]
7   702-75-11850   [1]   Ring, Back-Up Komatsu China
  ["SN: 80001-UP"]
8   07002-13634   [1]   O-Ring Komatsu China 0.013 kg.
  ["SN: 80001-UP"] analogs:["0700203634"]
