KOMATSU 201-60-73601 TZ500D200000-G TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

Name: KOMATSU 201-60-73601 TZ500D200000-G TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

KOMATSU 201-60-73601 TZ500D200000-G TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

201-60-73601 TZ500D200000-G PC60-7 PC60-7-B PC70-7 PC70-7-B

Pos.	Part No	Qty	Parts name	Comments
	201-60-73601	[2]	MOTOR ASS'Y Komatsu	81 kg.
			["SN: 59900-UP"] \|$1.
	TZ500D200000-G	[1]	MOTOR ASS'Y Komatsu China
			["SN: 59900-UP"] \|$3.
	TZ505D400002-D	[1]	CONTROL VALVE ASS'Y Komatsu China
			["SN: 59900-UP"] \|$5.
	TZ505D410002-D	[1]	FLANGE ASS'Y,REAR Komatsu China
			["SN: 59900-UP"] \|$6.
	TZ505D410102-D	[1]	FLANGE KIT,REAR Komatsu China
			["SN: 59900-UP"] \|$7.
	TZ502D4110-00	[1]	SPOOL KIT Komatsu China
			["SN: 59900-UP"] \|$10.
5	TZ100A2021-00	[1]	PLUG Komatsu China
			["SN: 59900-UP"] analogs:["843400055", "R100A20210", "TZR100A20210"]
6	TZ810B2021-00	[1]	PLUG Komatsu	0.03 kg.
			["SN: 59900-UP"]
7	TZ860A2051-00	[2]	PLUG Komatsu	0.183 kg.
			["SN: 59900-UP"]
8	TZ869A205200-B	[2]	RETAINER,SPRING Komatsu China
			["SN: 59900-UP"]
9	TZ500D4054-00	[2]	VALVE Komatsu China
			["SN: 59900-UP"] analogs:["TA500D405400"]
10	TZ860A2056-00	[2]	SPRING Komatsu China
			["SN: 59900-UP"] analogs:["843400060", "R860A20560"]
11	TZ500D4055-00	[2]	SPRING Komatsu China
			["SN: 59900-UP"]
12	TZJB2401-P26-9	[2]	O-RING (KIT) Komatsu China
			["SN: 59900-UP"] analogs:["843400064", "TZJB2401P2690"]
13	07000-12018	[2]	O-RING (KIT) Komatsu China	0.001 kg.
			["SN: 59900-UP"] analogs:["KB9511301800", "YM24311000180", "0700002018", "2083811590"]
14	TZGM1-8-S	[3]	PLUG Komatsu China
			["SN: 59900-UP"]
15	TZJB1501-3-16	[1]	BALL Komatsu China
			["SN: 59900-UP"]
16	07002-12034	[1]	O-RING (KIT) Komatsu China	0.94 kg.
			["SN: 59900-UP"] analogs:["0700002034", "0700202034", "0700012034"]
17	TZGDL1-16-S	[5]	PLUG Komatsu China
			["SN: 59900-UP"]
18	TZ976B2079-00	[1]	FILTER Komatsu	0.000 kg.
			["SN: 59900-UP"]
19	TZS0505	[1]	ORIFICE Komatsu China
			["SN: 59900-UP"]
20	TZ500D4089-00	[1]	SPRING Komatsu China
			["SN: 59900-UP"]
21	TZ610B2021-00	[2]	PLUG Komatsu China
			["SN: 59900-UP"]
22	TZ571B2079-00	[1]	PLUG Komatsu China
			["SN: 59900-UP"]
23	07000-12014	[1]	O-RING (KIT) Komatsu China	0.01 kg.
			["SN: 59900-UP"] analogs:["0700002014"]
24	TZ850A0006-00	[1]	PLATE, NAME Komatsu	0.01 kg.
			["SN: 59900-UP"]
25	TZJB1354-4-10	[2]	PIN Komatsu	0.01 kg.
			["SN: 59900-UP"]
26	01252-31230	[6]	BOLT Komatsu	0.045 kg.
			["SN: 59900-UP"] analogs:["0125201230"]
K.	TZ516D9000-00	[2]	SEAL KIT,TRAVEL MOTOR Komatsu China
			["SN: 59900-UP"]
Pos.	Part No	Qty	Parts name	Comments
	201-60-73601	[2]	MOTOR ASS'Y Komatsu	81 kg.
			["SN: 59900-UP"] \|$1.
	TZ500D200000-G	[1]	MOTOR ASS'Y Komatsu China
			["SN: 59900-UP"] \|$3.
	TZ500D2105-00	[1]	PISTON KIT Komatsu	0.6 kg.
			["SN: 59900-UP"] \|$5.
2	TZ500D2070-00	[1]	PISTON ASS'Y Komatsu China
			["SN: 59900-UP"]
3	TZ500D2002-00	[1]	SHAFT Komatsu	0.55 kg.
			["SN: 59900-UP"]
4	TZ500D200300-G	[1]	PLATE,SWASH Komatsu China
			["SN: 59900-UP"]
5	TZ500D2004-00	[1]	BLOCK,CYLINDER Komatsu China
			["SN: 59900-UP"]
6	TZ500D2007-00	[1]	PLATE,RETAINER Komatsu China
			["SN: 59900-UP"]
7	TZ500D2008-00	[1]	BOWL,THRUST Komatsu China
			["SN: 59900-UP"]
8	TZ500D2009-00	[1]	PLATE,TIMING Komatsu China
			["SN: 59900-UP"]
9	TZ500D2010-00	[2]	WASHER Komatsu China
			["SN: 59900-UP"]
10	TZ500D2012-00	[1]	PISTON Komatsu China
			["SN: 59900-UP"]
11	TZ500D2013-00	[8]	SPRING Komatsu	0.012 kg.
			["SN: 59900-UP"]
12	TZ500D2014-00	[1]	SPRING Komatsu China
			["SN: 59900-UP"]
13	TZ500D2015-00	[2]	DISC Komatsu China
			["SN: 59900-UP"]
14	TZ500D2016-00	[2]	PLATE Komatsu China
			["SN: 59900-UP"]
15	TZ15Z-22-42-10	[1]	SEAL,OIL (KIT) Komatsu	0.023 kg.
			["SN: 59900-UP"] analogs:["TZ02204210"]
16	TZ500D2035-00	[1]	O-RING (KIT) Komatsu China
			["SN: 59900-UP"]
17	TZ500D2039-00	[1]	O-RING (KIT) Komatsu	0.01 kg.
			["SN: 59900-UP"]
18	TZIRTW-36	[1]	RING,SNAP Komatsu China
			["SN: 59900-UP"]
19	TZ880A2029-00	[1]	BEARING Komatsu	0.15 kg.
			["SN: 59900-UP"]
20	06000-06301	[1]	BEARING Komatsu	0.08 kg.
			["SN: 59900-UP"]
21	TZ500D2098-00	[3]	PIN Komatsu China
			["SN: 59900-UP"]
22	TZ500D2076-00	[2]	PIVOT Komatsu China
			["SN: 59900-UP"]
23	TZ263B2077-01	[2]	PIN Komatsu	0.005 kg.
			["SN: 59900-UP"]
24	TZ844B2085-00	[1]	SPRING Komatsu China
			["SN: 59900-UP"] analogs:["843400086"]
K.	TZ516D9000-00	[2]	SEAL KIT,TRAVEL MOTOR Komatsu China
			["SN: 59900-UP"]
