KMF125 PC200-7 swing motor valve plate

KMF125 PC200-7 swing motor valve plate

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
KMF125
706-7G-01040 706-7G-01041 706-7G-03040 706-7G-03041
PC228US-3 PC308USLC-3
PC200-7 PC210-7 PC210LC-7 PC210LC-7-DG PC210NLC-7K PC220-7 PC220LC-7 PC230-7-AA PC230-7-CG PC230LC-7-BA PC270-7 PC270LC-7L
PC210-7K PC210LC-7K PC210NLC-7K PC230NHD-7K PC240LC-7K PC240NLC-7K PC290LC-7K PC290NLC-7K

706-7G-01130 706-7G-01170 706-7G-03130
PC200-8 PC200LC-8 PC220-8 PC220LC-8 PC228US-8 PC240-8 PC270-8 PC270LC-8 PC270LC-8-W1
PC200-8MO PC220-8MO
PC210-8K PC210LC-8K PC210NLC-8K PC230NHD-8K PC240-8K PC240LC-8K PC240NLC-8K PC290-8K PC290LC-8K PC290NLC-8K
PC210-10 PC240-10 PC290-10
Pos. Part No Qty Parts name Comments
     706-7G-01041   [1]   MOTOR ASS'Y Komatsu 57.5 kg.
  ["SN: 258354-UP"] analogs:["7067G03040", "7067G01040", "7067G01130", "7067G03041"] |$2.
     706-7G-01040   [1]   MOTOR ASS'Y Komatsu 57.5 kg.
  ["SN: 200001-258353"] analogs:["7067G03040", "7067G01130", "7067G03041", "7067G01041"] |$3.
        [-1]   THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 TO Y1640-03A0.
  |$$3.
        706-7G-03041   [1]   MOTOR SUB ASS'Y Komatsu 57.5 kg.
  ["SN: 258354-UP"] analogs:["7067G03040", "7067G01040", "7067G01130", "7067G01041"] |$5.
        706-7G-03040   [1]   MOTOR SUB ASS'Y Komatsu 57.5 kg.
  ["SN: 200001-258353"] analogs:["7067G01040", "7067G01130", "7067G03041", "7067G01041"] |$6.
1   706-7G-41610   [1]   SHAFT,DRIVE Komatsu 3.9 kg.
  ["SN: 200001-UP"]
2   706-75-42880   [1]   BEARING Komatsu 2.42 kg.
  ["SN: 200001-UP"]
3   706-75-43810   [1]   SPACER Komatsu 0.635 kg.
  ["SN: 200001-UP"]
4   706-7E-11260   [2]   SPRING Komatsu 0.03 kg.
  ["SN: 200001-UP"]
5   706-7E-11270   [1]   SEAT Komatsu 0.05 kg.
  ["SN: 200001-UP"]
6   706-76-40890   [1]   BEARING Komatsu 0.524 kg.
  ["SN: 200001-UP"]
7   706-75-05040   [1]   SPACER KIT Komatsu 0.091 kg.
  ["SN: 200001-UP"]
8   04064-04518   [1]   RING,SNAP Komatsu China 0.007 kg.
  ["SN: 200001-UP"] analogs:["20Y3029190"]
9   706-7E-11280   [1]   SEAL,OIL Komatsu 0.15 kg.
  ["SN: 200001-UP"]
10   706-7G-41910   [1]   SPACER Komatsu 0.042 kg.
  ["SN: 200001-UP"]
11   04065-06220   [1]   RING Komatsu 0.013 kg.
  ["SN: 200001-UP"]
12   706-7G-41210   [1]   BLOCK,CYLINDER Komatsu 2.402 kg.
  ["SN: 200001-UP"]
13   706-7G-41710   [1]   PLATE,VALVE Komatsu 0.38 kg.
  ["SN: 200001-UP"]
14   706-75-43750   [1]   PIN,DOWEL Komatsu China
  ["SN: 200001-UP"]
15   706-7G-41120   [1]   SHAFT,CENTER Komatsu 0.37 kg.
  ["SN: 200001-UP"]
16   706-7G-41130   [1]   RING,CENTER Komatsu China
  ["SN: 200001-UP"]
17   706-7G-41140   [1]   SPRING Komatsu 0.06 kg.
  ["SN: 200001-UP"]
     706-7G-05010   [1]   RETAINER KIT Komatsu 0.22 kg.
  ["SN: 200001-UP"] |$27.
20   706-7G-41160   [7]   PISTON SUB ASS'Y Komatsu 0.22 kg.
  ["SN: 200001-UP"]
21   706-7G-91340   [5]   PLATE Komatsu 0.12 kg.
  ["SN: 200001-UP"]
22   706-7G-91350   [4]   DISC Komatsu 0.083 kg.
  ["SN: 200001-UP"]
23   706-7G-91111   [1]   PISTON Komatsu OEM 2.7 kg.
  ["SN: 258354-UP"] analogs:["7067G91110"]
23   706-7G-91110   [1]   PISTON,BRAKE Komatsu OEM 2.7 kg.
  ["SN: 200001-258353"]
24   706-77-40370   [1]   O-RING Komatsu OEM 0.01 kg.
  ["SN: 200001-UP"]
25   708-8F-31610   [1]   O-RING Komatsu OEM 0.006 kg.
  ["SN: 200001-UP"]
26   706-7G-91360   [6]   SPRING Komatsu China
  ["SN: 200001-UP"]
Pos. Part No Qty Parts name Comments
     706-7G-01040   [1]   MOTOR ASS'Y Komatsu 57.5 kg.
  ["SN: C70001--UP"] analogs:["7067G03040", "7067G01130", "7067G03041", "7067G01041"] |$1.
        [-1]   THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 TO Y1640-03A0.
  |$2.
        702-75-01250   [1]   VALVE ASS'Y, RELIEF Komatsu OEM 0.64 kg.
  ["SN: C70001--UP"] analogs:["7027501270"] |$3.
11   07000-F2020   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: C70001--UP"] analogs:["0700022020"]
12   07001-02020   [1]   RING, BACK-UP Komatsu 0.001 kg.
  ["SN: C70001--UP"]
13   07002-13034   [1]   O-RING Komatsu China 0.005 kg.
  ["SN: C70001--UP"] analogs:["0700203034"]
14   706-7G-71191   [1]   PLATE Komatsu China
  ["SN: C70001--UP"]
   20.   07000-03042   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: C70001--UP"] analogs:["0700013042"]
   21.   07000-11009   [2]   O-RING Komatsu 0.001 kg.
  ["SN: C70001--UP"] analogs:["0700001009"]
   22.   01252-60825   [2]   BOLT Komatsu 0.017 kg.
  ["SN: C70001--UP"] analogs:["0125240825", "0125230825"]
Pos. Part No Qty Parts name Comments
     706-7G-01170   [1]   Motor Assembly Komatsu 53 kg.
  ["SN: 315646-UP"] |$0.
        702-75-01310   [1]   Valve, Relief Komatsu 1.92 kg.
  ["SN: 315646-UP"] |$1.
11   07000-F2020   [1]   O-ring Komatsu China 0.001 kg.
  ["SN: 315646-UP"] analogs:["0700022020"]
12   07001-02020   [1]   Ring, Back-up Komatsu 0.001 kg.
  ["SN: 315646-UP"]
13   07002-13034   [1]   O-ring Komatsu China 0.005 kg.
  ["SN: 315646-UP"] analogs:["0700203034"]
        702-15-77000   [1]   Valve Assembly Komatsu 1.17 kg.
  ["SN: 315646-UP"] |$15.
16   709-70-71610   [2]   Seal Komatsu China
  ["SN: 315646-UP"]
17   702-15-71130   [2]   Spring Komatsu 0.005 kg.
  ["SN: 315646-UP"]
18   702-15-71140   [2]   Plug Komatsu China
  ["SN: 315646-UP"]
19   07002-01423   [2]   O-ring Komatsu China 0.001 kg.
  ["SN: 315646-UP"] analogs:["0700211423"]
   20.   07000-13042   [1]   O-ring Komatsu China 0.01 kg.
  ["SN: 315646-UP"] analogs:["0700003042"]
   21.   07000-11009   [2]   O-ring Komatsu 0.001 kg.
  ["SN: 315646-UP"] analogs:["0700001009"]
   22.   01252-60825   [2]   Bolt, Hexagon Socket Head Komatsu 0.017 kg.
  ["SN: 315646-UP"] analogs:["0125240825", "0125230825"]
Pos. Part No Qty Parts name Comments
     706-7G-01170   [1]   MOTOR ASS'Y Komatsu 53 kg.
  ["SN: B30001-B32252"] |1.
        [-1]   THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-01A1 T0 Y1640-03A1.
  |$32.
        706-7G-03130   [1]   MOTOR SUB ASS'Y Komatsu China
  ["SN: B30001-B32252"] |1.
1   706-7G-41630   [1]   SHAFT,DRIVE Komatsu 3 kg.
  ["SN: B30001-B32252"]
2   706-75-42880   [1]   BEARING Komatsu 2.42 kg.
  ["SN: B30001-B32252"]
3   706-7G-41660   [1]   SPACER Komatsu China
  ["SN: B30001-B32252"]
4   706-76-40890   [1]   BEARING Komatsu 0.524 kg.
  ["SN: B30001-B32252"]
5   706-7G-41510   [1]   SPACER KIT Komatsu China
  ["SN: B30001-B32252"]
6   04064-04518   [1]   RING,SNAP Komatsu China 0.007 kg.
  ["SN: B30001-B32252"] analogs:["20Y3029190"]
7   706-7E-11280   [1]   SEAL,OIL Komatsu 0.15 kg.
  ["SN: B30001-B32252"]
8   706-7G-41910   [1]   SPACER Komatsu 0.042 kg.
  ["SN: B30001-B32252"]
9   04065-06220   [1]   RING,SNAP Komatsu 0.013 kg.
  ["SN: B30001-B32252"]
10   706-7G-41310   [1]   BLOCK,CYLINDER Komatsu 2.3 kg.
  ["SN: B30001-B32252"]
11   706-7G-41720   [1]   PLATE,VALVE Komatsu 0.38 kg.
  ["SN: B30001-B32252"]
12   706-75-43750   [1]   PIN,DOWEL Komatsu China
  ["SN: B30001-B32252"]
13   706-7G-41320   [1]   SHAFT,CENTER Komatsu China
  ["SN: B30001-B32252"]
14   706-7G-41130   [1]   RING,CENTER Komatsu China
  ["SN: B30001-B32252"]
15   706-7G-41140   [1]   SPRING Komatsu 0.06 kg.
  ["SN: B30001-B32252"]
     706-7G-05010   [1]   RETAINER KIT Komatsu 0.22 kg.
  ["SN: B30001-B32252"] |16.
18   706-7G-41410   [7]   PISTON SUB ASS'Y Komatsu 0.000 kg.
  ["SN: B30001-B32252"]
19   706-7G-91441   [5]   PLATE Komatsu 0.11 kg.
  ["SN: B30001-B32252"]
20   706-7G-91450   [4]   DISC Komatsu 0.08 kg.
  ["SN: B30001-B32252"]
21   706-7G-91120   [1]   PISTON,BRAKE Komatsu China
  ["SN: B30001-B32252"]
22   706-75-92310   [1]   O-RING Komatsu 0.012 kg.
  ["SN: B30001-B32252"]
23   708-8F-31610   [1]   O-RING Komatsu OEM 0.006 kg.
  ["SN: B30001-B32252"]
24   706-7G-91360   [6]   SPRING Komatsu China
  ["SN: B30001-B32252"]
