Kawasaki MX150 travel motor rotary group and spare parts

Kawasaki MX150 travel motor rotary group and spare parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
MX150 4224991 EX200 EX200K EX220
Pos. Part No Qty Parts name Comments
4224991 [1]   MOTOR;OIL 0365300A
11 0365301 [9]   PISTON SUB
011A. +++++++ [1]   PISTON
011B. +++++++ [1]   SHOE
20 0365302 [1]   CASING SUB
020A. +++++++ [1]   CASING
020B. +++++++ [2]   PIN
31 0365303 [1]   VALVE SUB
51 0365304 [2]   VALVE;RELIEF
101 0365305 [1]   SHAFT
106 0365306 [3]   SPACER
111 0365307 [1]   CYL.
113 0365308 [1]   BUSHING
114 0365309 [1]   SPRING
116 0365310 [12]   ROD;PUSH
117 0365311 [1]   SPACER
118 0365312 [1]   SPACER
123 0365313 [1]   PLATE
124 0365314 [1]   PLATE
131 0365315 [1]   PLATE
301 0365316 [1]   CASING
304 0365317 [1]   COVER
351 0236006 [2]   PLUNGER
355 0236009 [2]   SPRING
401 0365318 [4]   BOLT;SOCKET
432 0365319 [2]   RING;RETAINING
433 0365320 [1]   RING;RETAINING
437 0365321 [1]   RING;RETAINING
438 0365322 [1]   RING;RETAINING
443 0365323 [1]   BRG.
444 0365324 [1]   BRG.
464 0236014 [1]   PLUG
468 0236014 [2]   PLUG
469 0236015 [2]   PLUG
471 0365325 [1]   O-RING
472 0365326 [1]   O-RING Y 0365334
472 0365334 [1]   O-RING
485 957366 [1]   O-RING
487 957366 [2]   O-RING
488 0365327 [2]   O-RING
491 0365328 [1]   SEAL;OIL
702 0365329 [1]   PISTON;BRAKE
706 0365330 [1]   O-RING
707 0308623 [1]   O-RING
712 0365331 [20]   SPRING;BRAKE
742 0365332 [2]   PLATE
743 0365333 [3]   PLATE
