Kawasaki K5V140 hydraulic pump parts

Kawasaki K5V140 hydraulic pump parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
K5V140 SK350
R305LC-7 31N8-10070 XJBN-00997
R300LC-9A R300LC-9S R300LC-9SH 31Q8-10030 XJBN-01640
Pos. Part No Qty Parts name Comments
*. 31N8-10070 [1]   MAIN PUMP
*-1. XJBN-00997 [1]   MAIN PUMP UNIT
111 XJBN-00953 [1]   SHAFT(F)-DRIVE
113 XJBN-00952 [1]   SHAFT(R)-DRIVE
116 XJBN-00951 [1]   GEAR-1ST
123 XJBN-00950 [2]   BEARING-ROLLER
124 XJBN-00949 [2]   BEARING-NEEDLE
127 XJBN-00081 [3]   SPACER-BEARING
NS141. XJBN-00948 [2]   BLOCK-CYLINDER
NS151. XJBN-00947 [18]   PISTON
NS152. XJBN-00946 [18]   SHOE
153 XJBN-00945 [2]   PLATE-SET
156 XJBN-00083 [2]   BUSHING-SPHERICAL
157 XJBN-00944 [18]   SPRING-CYLINDER
211 XJBN-00085 [2]   PLATE-SHOE
NS212. XJBN-00943 [2]   PLATE-SWASH
S214. XJBN-00071 [2]   BUSHING-TILTING
251 XJBN-00942 [2]   SUPPORT-SP
261 XJBN-00941 [1]   COVER(F)-SEAL
271 XJBN-00088 [2]   CASING-PUMP
312 XJBN-00940 [1]   BLOCK-VALVE
NS313. XJBN-00939 [1]   PLATE(R)-VALVE
NS314. XJBN-00938 [1]   PLATE(L)-VALVE
S326. XJBN-00937 [1]   COVER
401 XJBN-00090 [8]   SCREW-HEX SOC HD
406 XJBN-00355 [4]   SCREW-HEX SOC HD
414 XJBN-00160 [4]   SCREW-SOCKET
466 XJBN-00356 [2]   PLUG
467 XJBN-00936 [2]   PLUG
468 XJBN-00357 [4]   PLUG
490 XJBN-00032 [32]   PLUG
NS531. XJBN-00956 [2]   PIN-TILTING
532 XJBN-00955 [2]   PISTON-SERVO
534 XJBN-00092 [2]   STOPPER(L)
535 XJBN-00093 [2]   STOPPER(S)
NS541. XJBN-00859 [4]   SEAT
NS543. XJBN-00860 [2]   STOPPER
NS544. XJBN-00861 [2]   STOPPER
S545. XJBN-00359 [4]   BALL-STEEL
NS548. XJBN-00360 [2]   PIN-FEED BACK
702 XJBN-00862 [2]   O-RING
710 XJBN-00878 [2]   O-RING
717 XJBN-00096 [4]   O-RING
724 XJBN-00361 [16]   O-RING
725 XJBN-00362 [4]   O-RING
726 XJBN-00233 [2]   O-RING
728 XJBN-00363 [4]   O-RING
732 XJBN-00863 [2]   O-RING
774 XJBN-00906 [1]   SEAL-OIL
789 XJBN-00864 [2]   RING-BACK UP
792 XJBN-00865 [2]   RING-BACK UP
806 XJBN-00396 [2]   NUT
808 XJBN-00364 [2]   NUT
824 XJBN-00866 [2]   RING-SNAP
885 XJBN-00103 [2]   PIN-VALVE PLATE
886 XJBN-00365 [4]   PIN-SPRING
901 XJBN-00393 [2]   BOLT-EYE
953 XJBN-00954 [2]   SCREW-SET
954 XJBN-00106 [2]   SCREW-SET
981 XJBN-00156 [1]   NAME PLATE
683 XJBN-00341 [2]   PIN
*-2. XJBN-00964 [2]   REGULATOR ASSY      SEE 4020
*-3. XJBN-00935 [1]   PUMP-GEAR      SEE 4030
*-4. XJBN-00014 [1]   CASING ASSY-EPPR VLV      SEE 4040
11 XJBN-00934 [2]   PISTON ASSY
13 XJBN-00933 [1]   CYLINDER(R) ASSY
14 XJBN-00932 [1]   CYLINDER(L) ASSY
30 XJBN-00931 [2]   SWASH PLATE ASSY
41 XJBN-00072 [2]   CHECK VALVE ASSY 1
42 XJBN-00075 [2]   CHECK 2 ASSY
80 XJBN-00014 [1]   CASING ASSY-EPPR VLV
530 XJBN-00930 [2]   TILTING PIN ASSY
Pos. Part No Qty Parts name Comments
*. 31Q8-10030 [1]   MAIN PUMP      *-1,-2,-3
*-1. XJBN-01640 [1]   MAIN PUMP UNIT
111 XJBN-00953 [1]   SHAFT(F)-DRIVE
113 XJBN-00952 [1]   SHAFT(R)-DRIVE
116 XJBN-00951 [1]   GEAR-1ST
123 XJBN-00950 [2]   BEARING-ROLLER
124 XJBN-00949 [2]   BEARING-NEEDLE
127 XJBN-00081 [3]   SPACER-BEARING
NS141. XJBN-00948 [2]   BLOCK-CYLINDER
NS151. XJBN-00947 [18]   PISTON
NS152. XJBN-01633 [18]   SHOE
153 XJBN-00945 [2]   PLATE-SET
156 XJBN-00083 [2]   BUSHING-SPHERICAL
157 XJBN-00944 [18]   SPRING-CYLINDER
211 XJBN-00085 [2]   PLATE-SHOE
NS212. XJBN-00943 [2]   PLATE-SWASH
S214. XJBN-00071 [2]   BUSHING-TILTING
251 XJBN-00942 [2]   SUPPORT-SP
261 XJBN-00941 [1]   COVER(F)-SEAL
271 XJBN-01034 [2]   CASING-PUMP
312 XJBN-00940 [1]   BLOCK-VALVE
NS313. XJBN-01197 [1]   PLATE(R)-VALVE
NS314. XJBN-01198 [1]   PLATE(L)-VALVE
N326. XJBN-00937 [1]   COVER
401 XJBN-00090 [8]   SCREW-HEX SOC HD
406 XJBN-00355 [4]   SCREW
414 XJBN-00160 [4]   SCREW-SOCKET
466 XJBN-00356 [2]   PLUG
467 XJBN-00936 [2]   PLUG
468 XJBN-00031 [4]   PLUG
490 XJBN-00032 [32]   PLUG
NS531. XJBN-00956 [2]   PIN-TILTING
532 XJBN-00955 [2]   PISTON-SERVO
534 XJBN-00092 [2]   STOPPER(L)
535 XJBN-00093 [2]   STOPPER(S)
NS541. XJBN-00859 [4]   SEAT
NS543. XJBN-00860 [2]   STOPPER
NS544. XJBN-00861 [2]   STOPPER
S545. XJBN-00359 [4]   BALL-STEEL
NS548. XJBN-00360 [2]   PIN-FEED BACK
702 XJBN-00862 [2]   O-RING
710 XJBN-00878 [2]   O-RING
717 XJBN-00096 [4]   O-RING
724 XJBN-00361 [16]   O-RING
725 XJBN-00362 [4]   O-RING
726 XJBN-00233 [2]   O-RING
728 XJBN-00363 [4]   O-RING
732 XJBN-00863 [2]   O-RING
774 XJBN-00906 [1]   SEAL-OIL
789 XJBN-00864 [2]   RING-BACK UP
792 XJBN-00865 [2]   RING-BACK UP
806 XJBN-00396 [2]   NUT-HEX
808 XJBN-00364 [2]   NUT
824 XJBN-00866 [2]   RING-SNAP
885 XJBN-00103 [2]   PIN-VALVE PLATE
886 XJBN-00365 [4]   PIN-SPRING
901 XJBN-00393 [2]   BOLT-EYE
953 XJBN-00954 [2]   SCREW-SET
954 XJBN-00106 [2]   SCREW-SET
981 XJBN-00156 [1]   NAME PLATE
983 XJBN-00341 [2]   PIN
*-2. @ [1]   REGULATOR      SEE 4020
*-3. @ [1]   GEAR PUMP      SEE 4040
80 XJBN-00014 [1]   EPPR VALVE ASSY
S011. XJBN-01632 [2]   PISTON ASSY      SEE ILLUST
S013. XJBN-01199 [1]   CYLINDER ASSY-RH      SEE ILLUST
S014. XJBN-01200 [1]   CYLINDER ASSY-LH      SEE ILLUST
S030. XJBN-00931 [2]   SWASH PLATE ASSY      SEE ILLUST
S041. XJBN-00072 [2]   CHECK VALVE ASSY 1      SEE ILLUST
S042. XJBN-00075 [2]   CHECK VALVE ASSY 2      SEE ILLUST
S530. XJBN-00930 [2]   TILTING PIN ASSY      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS

Kobelco SK330-8 SK350-6 SK350-8，
Hyundai R305，
Daewoo DH300-7，
Sumitomo SH330 SH350-3B SH450 excavator
