Kawasaki DNB50 DNB60 hydraulic travel motor rotory group and spare parts

Kawasaki DNB50 DNB60 hydraulic travel motor rotory group and spare parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
401-00440B ROTARY KIT K9000781 ROTARY KIT K9000782 DX300LC DX300LCA
Pos. Part No Qty Parts name Comments
*. K9000780 [1]   SEAL KIT;TRAVEL
-. 401-00440B [1]   TRAVEL MOTOR
1 K9000781 [1]   ROTARY KIT
101 405-00031 [1]   SHAFT
102 2109-8001 [1]   BEARING;ROLLER
103 2109-8003 [1]   BEARING;NEEDLE
106 2114-1598 [1]   BEARING;SPACER
107 S6500500 [1]   RING;STOP
1A. K9000782 [1]   CYLINDER BLOCK KIT
1AA. 2410-1015B [1]   BLOCK;CYLINDER
1AB. K9000783 [1]   PLATE;VALVE
1B. 2129-1315 [9]   SPRING;CYLINDER
1C. 2114-1599A [1]   SPACER
1D. K9000784 [1]   PISTON KIT
1DA. 2409-1021D [9]   PISTON & SHOE ASS'Y
1E. 2408-1039B [1]   BUSH & PUSH PLATE ASS'Y
2 K9000785 [1]   SPOOL ; C.B KIT
201 2412-1030B [1]   SWASH ASS'Y
272 402-00038 [1]   CASING;SHAFT
2A. 424-00146A [1]   SPOOL;C.B VALVE
2B. 2415-1009D1 [2]   SCREW;ORIFICE
3 K9000786 [2]   DAMPING CHECK KIT
303 2402-1035G [1]   CASING;VALVE
350 2420-1081D [2]   RELIEF VALVE ASS'Y
350A. S8000241 [1]   O-RING
350B. S8010301 [1]   O-RING
350C. S8090300 [1]   RING;BACK-UP T2 G30
365 2430-1017B [1]   CAP;C.B. V/V (L)
366 2430-1016B [1]   CAP;C.B. V/V (R)
367 S2212271 [4]   BOLT;SOCKET M10X30
368 S2215271 [8]   BOLT;SOCKET
369 S8000451 [2]   O-RING 1B P45
381 2424-1042F [2]   PLUNGER;C.B V/V
382 2416-1012D [2]   STOPPER;CHECK
383 S8060181 [2]   . RING;BACKUP
384 2129-1322A [2]   SPRING;CHECK
3A. 2129-1321 [1]   SPRING;CYLINDER
3B. 2416-1013C [1]   DAMPING CHECK ASS'Y
4 K9000787 [1]   PISTON RING KIT
401 S2221661 [8]   BOLT;SOCKET M16X50
402 S2223061 [4]   BOLT;SOCKET M16X120
435 S6510700 [1]   RING;SNAP
451 2123-1708D3A [2]   PIN;VALVE PLATE
452 2123-1708D1A [2]   PIN;SUPPORT
461 2181-1854 [5]   PLUG
464 2181-1896D4 [2]   PLUG
472 2180-8003B [1]   O-RING
485 S8000181 [4]   O-RING
491 180-00466 [1]   SEAL;OIL TCN AP2791 GO
4A. 2411-1011 [1]   RING;PISTON
4B. 2411-1012 [1]   RING;PISTON
501 2409-1024C [1]   PISTON;SWASH
502 2409-1057 [1]   PISTON;SWASH
503 2416-1007A [1]   STOPPER(L)
504 S8002731 [1]   O-RING
505 2413-1001 [1]   ROD;SWASH
506 2120-1427A [2]   SCREW;LOCK
507 S4010942 [2]   NUT;HEX M16
508 S8002701 [1]   . O-RING
509 S8000161 [4]   O-RING
512 S8060161 [3]   RING;BACK-UP
513 S8062661 [2]   RING;BACK UP 1B P22A
514 2416-1008A [1]   STOPPER(S)
531 2483-1017B [1]   SPOOL;SWASH
533 2129-1317 [1]   SPRING;SWASH
541 2316-1006A [2]   SEAT
542 2416-1009 [2]   STOPPER
543 2148-1002 [2]   BALL
545 2415-1009D4 [1]   SCREW;ORIFICE
546 2415-1009D1 [2]   SCREW;ORIFICE
567 2181-1896D2 [7]   PLUG
568 S8000111 [7]   O-RING
571 2426-1072 [1]   PLUG
572 S8000141 [1]   O-RING
702 2452-1003 [1]   PISTON;BRAKE
705 2129-1318 [10]   SPRING;BRAKE
709 2123-1708D2A [4]   PIN;BRAKE
741 2352-1004A [1]   PLATE;SEPARATOR
742 2352-1006 [2]   PLATE;FRICTION
