K5V200DPH ZX450 EX200-5 HPV102 9218005 hydraulic pump gear pump pilot pump 4276918

Name: K5V200DPH ZX450 EX200-5 HPV102 9218005 hydraulic pump gear pump pilot pump 4276918
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

K5V200DPH ZX450 EX200-5 HPV102 9218005 hydraulic pump gear pump pilot pump 4276918

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

HPV102 ZX180W ZX180W-AMS 9217221 9236929 EX200-5 EX200-6

Pos.	Part No	Qty	Parts name	Comments
	+++++++	[1]	PUMP;UNIT
1	1026679	[1]	CASING;PUMP
1	1032319	[1]	CASING;PUMP
3	2036807	[1]	DISC;DRIVING
3	2043207	[1]	DISC;DRIVING
4	2036808	[1]	DISC;DRIVING
4	2043211	[1]	DISC;DRIVING
6	4337419	[2]	BRG.;ROL.
6	4410050	[2]	BRG.;ROL.
7	4348182	[2]	RING
7	4339171	[2]	RING
8	4337483	[2]	BRG.;ROL.
8	4622945	[2]	BRG.;ROL.
9	4178173	[2]	NUT;BRG.
10	4338907	[1]	RING;THRUST
12	4333170	[2]	SEAL;OIL
13	4116290	[2]	RING;RETAINING
15	4233165	[1]	PLUG
16	957366	[1]	O-RING
19	8059452	[14]	PISTON
21	4337035	[2]	SHAFT;CENTER
22	4198956	[2]	PIN
23	4179181	[2]	SPRING;COMPRES.
25	2036744	[2]	ROTOR
27	2036795	[1]	VALVE
28	2036786	[1]	VALVE
29	4179179	[4]	PIN
31	3075674	[2]	LINK;E
32	9724756	[4]	LEVER
33	4179177	[4]	PIN
34	4179176	[2]	PIN
35	4146370	[12]	RING;RETAINING
36	4200227	[2]	PIN
41	1027131	[1]	HEAD
42	3069541	[2]	PISTON;SERVO
43	4338053	[2]	PIN
44	4337812	[2]	SCREW;SET
46	4355085	[2]	O-RING
47	4338060	[2]	STOPPER
50	4355083	[2]	O-RING
51	4338061	[2]	STOPPER
54	4180349	[20]	O-RING
55	M340825	[16]	BOLT;SOCKET
57	3070581	[1]	RING;BACKUP
58	4099290	[2]	PIN;SPRING
59	4342840	[1]	O-RING
60	M341245	[12]	BOLT;SOCKET
64	4436271	[2]	SENSOR;PRES.
64A.	4365826	[1]	O-RING
67	9134110	[2]	PLUG
67A.	957366	[1]	O-RING
69	9224523	[1]	REGULATOR;L	I 9239008 <for assembly of machine>
69	9239008	[1]	REGULATOR;L	<for transportation>
70	9224524	[1]	REGULATOR;R	I 9239009 <for assembly of machine>
70	9239009	[1]	REGULATOR;R	<for transportation>
72	4515041	[4]	PIN;SPRING
73	4343074	[4]	O-RING
74	4348665	[2]	O-RING
80	9134111	[2]	PLUG
80A.	4509180	[1]	O-RING
82	4252767	[1]	BRACKET
83	M340613	[1]	BOLT;SOCKET
84	4169516	[1]	WASHER;SPRING
100	4451039	[1]	KIT;SEAL
Pos.	Part No	Qty	Parts name	Comments
	9217221	[1]	PUMP DEVICE	I 9236929 <for assembly of machine>
	9236929	[1]	PUMP DEVICE	<for transportation>
1	1030682	[1]	CASING;GEAR
3	3100991	[1]	GEAR;PILOT
4	3055594	[1]	SHAFT;GEAR
8	958740	[2]	BRG.;BALL
9	962002	[1]	RING;RETAINING
10	991725	[1]	RING;RETAINING
30	3100993	[1]	GEAR
31	3100994	[1]	GEAR
32	4274552	[2]	RING;RETAINING
34	4099290	[2]	PIN;SPRING
43	4310055	[1]	SEAL;OIL
44	991725	[1]	RING;RETAINING
61	4438059	[1]	GAUGE;LEVEL
62	9743977	[1]	PIPE
63	9742779	[1]	PACKING
64	M340816	[2]	BOLT;SOCKET
68	4265372	[1]	SENSOR;REVOL.
69	4306888	[1]	O-RING
70	A590106	[1]	WASHER;PLANE
71	M340616	[1]	BOLT;SOCKET
86	4234782	[1]	PLUG
87	4092534	[1]	PLUG
87A.	4509180	[1]	O-RING
103	+++++++	[1]	PUMP;UNIT
112	+++++++	[1]	NAME-PLATE
113	M492564	[2]	SCREW;DRIVE
120	4278696	[1]	PUMP;GEAR
121	M341030	[2]	BOLT;SOCKET
122	984054	[2]	WASHER;SPRING
123	4114402	[2]	WASHER
127	4369148	[1]	PIPE;E
130	4293950	[2]	ELBOW;S
130A.	957366	[1]	O-RING
133	4416605	[1]	COUPLING
133A.	4463992	[1]	HUB
133B.	4334899	[2]	SCREW;SET
133C.	4101345	[4]	PIN;SPRING
133D.	4463993	[4]	INSERT
133E.	4334894	[4]	BOLT;SOCKET
133F.	4463994	[1]	ELEMENT
136	8058352	[1]	PACKING
137	J901645	[6]	BOLT
138	A590916	[6]	WASHER;SPRING
143	4613307	[1]	HOSE;OIL
144	A852133	[1]	ADAPTER;S
145	4444381	[1]	PLUG
200	4451036	[1]	KIT;SEAL

Pos.	Part No	Qty	Parts name	Comments
	4633472	[1]	PUMP;PISTON
1	4658831	[2]	REGULATOR;PUMP
5	4654554	[1]	UNIT
05A.	+++++++	[1]	SHAFT
05B.	+++++++	[1]	GEAR
05C.	+++++++	[1]	GEAR
05D.	0978517	[2]	BRG.;BALL
05E.	0878107	[1]	BRG.;ROL.
05F.	0818508	[3]	SPACER
05G.	+++++++	[1]	CASE
05H.	+++++++	[1]	CASE;GEAR
05I.	0195126	[3]	BOLT;SOCKET
05J.	M341236	[8]	BOLT;SOCKET
05K.	988850	[1]	RING;RETAINING
05L.	446751	[1]	RING;RETAINING
05M.	0978512	[1]	O-RING
05N.	0443404	[1]	O-RING
05O.	+++++++	[2]	PIN
05P.	4091248	[1]	BOLT;EYE
11	0820401	[2]	PISTON ASS'Y
011A.	+++++++	[9]	PISTON
011B.	+++++++	[9]	SHOE
13	0820402	[1]	CYL. ASS'Y
013A.	+++++++	[1]	BLOCK;CYL.
013B.	+++++++	[1]	PLATE;VALVE
14	0451003	[1]	CYL. ASS'Y
014A.	+++++++	[1]	BLOCK;CYL.
014B.	+++++++	[1]	PLATE;VALVE
30	0772701	[2]	PLATE ASS'Y
030A.	+++++++	[1]	PLATE
030B.	+++++++	[1]	BUSHING
41	0708004	[2]	VALVE;CHECK ASS'Y
041A.	+++++++	[1]	SEAT
041B.	+++++++	[1]	STOPPER
041C.	+++++++	[1]	BALL;STEEL
111	0978501	[1]	SHAFT
113	0820406	[1]	SHAFT
122	0820407	[1]	BRG.;ROL.
123	0820453	[1]	BRG.;ROL.
124	0978503	[2]	BRG.;NEEDLE
125	0978504	[1]	RING;INNER
126	0820409	[2]	SPACER
127	0820410	[1]	SPACER
128	0820411	[3]	SPACER
129	0820412	[2]	SPACER
130	0978505	[1]	BOOSTER
131	0820414	[1]	COVER
153	0820415	[2]	RETAINER
156	0820416	[2]	BUSHING
157	0451016	[18]	SPRING
171	0978518	[1]	CASING	I 0978519
171	0978519	[1]	CASING
191	0820418	[1]	GEAR;DRIVE
192	0820419	[1]	GEAR
211	0451018	[2]	PLATE
251	0820420	[2]	SUPPORT
261	0978507	[1]	COVER
262	0820422	[1]	COVER
271	0978508	[1]	CASING
312	0978509	[1]	COVER
405	0978510	[8]	BOLT;SOCKET
406	M341236	[8]	BOLT;SOCKET
408	0131103	[11]	BOLT;SOCKET
409	0820425	[2]	BOLT;SOCKET
410	0820426	[9]	BOLT;SOCKET
411	0820427	[2]	BOLT;SOCKET
412	0820428	[1]	BOLT;SOCKET
413	M341025	[5]	BOLT;SOCKET
466	0978511	[2]	PLUG
467	0629404	[2]	PLUG
468	0626901	[2]	PLUG
469	0697911	[3]	PLUG
490	0263019	[20]	PLUG
491	0451028	[12]	PLUG
492	0451027	[4]	SCREW
493	0102440	[2]	PLUG
530	0820438	[2]	PIN ASS'Y
530A.	+++++++	[2]	PIN
530B.	+++++++	[2]	PIN
532	0820429	[2]	PISTON;SERVO
534	0451031	[2]	STOPPER
535	0820430	[2]	STOPPER
536	0820431	[2]	COVER
702	0451033	[2]	O-RING
709	0694604	[2]	O-RING
711	0820432	[1]	O-RING
712	0820433	[1]	O-RING
724	0443801	[9]	O-RING
725	4297379	[2]	O-RING
726	0443405	[2]	O-RING
728	0443408	[5]	O-RING
729	0719402	[2]	O-RING
731	0443407	[2]	O-RING
732	0451035	[2]	O-RING
733	0978512	[1]	O-RING
752	0820439	[2]	PACKING
774	0820443	[1]	SEAL;OIL	I 0978520
774	0978520	[1]	SEAL;OIL
789	0451036	[2]	RING;BACK-UP
792	0451037	[2]	RING;BACK-UP
806	0451038	[2]	NUT
807	0820434	[2]	NUT
823	959499	[1]	RING;RETAINING
824	991345	[3]	RING;RETAINING
825	488075	[2]	RING;RETAINING
827	991728	[1]	RING;RETAINING
828	0820435	[2]	RING;RETAINING
830	0978513	[1]	RING;RETAINING
885	0313404	[2]	PIN
886	0244604	[4]	PIN;SPRING
887	0175240	[1]	PIN
888	0978514	[2]	PIN
889	0978515	[4]	PIN
901	0134458	[2]	BOLT;EYE
953	0978516	[2]	SCREW;SET
954	0682328	[2]	SCREW;SET
981	+++++++	[1]	PLATE
983	0625509	[2]	PIN
	4658831	[1]	REGULATOR;PUMP
	4663481	[1]	PUMP;GEAR
	9218005	[1]	PUMP;GEAR
