K5V200DPH K5V212DPH SK460-8 13T hydraulic pump gear pump pilot pump

K5V200DPH K5V212DPH SK460-8 13T hydraulic pump gear pump pilot pump

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Pos. Part No Qty Parts name Comments
4633472 [1]   PUMP;PISTON
1 4658831 [2]   REGULATOR;PUMP
5 4654554 [1]   UNIT
05A. +++++++ [1]   SHAFT
05B. +++++++ [1]   GEAR
05C. +++++++ [1]   GEAR
05D. 0978517 [2]   BRG.;BALL
05E. 0878107 [1]   BRG.;ROL.
05F. 0818508 [3]   SPACER
05G. +++++++ [1]   CASE
05H. +++++++ [1]   CASE;GEAR
05I. 0195126 [3]   BOLT;SOCKET
05J. M341236 [8]   BOLT;SOCKET
05K. 988850 [1]   RING;RETAINING
05L. 446751 [1]   RING;RETAINING
05M. 0978512 [1]   O-RING
05N. 0443404 [1]   O-RING
05O. +++++++ [2]   PIN
05P. 4091248 [1]   BOLT;EYE
11 0820401 [2]   PISTON ASS'Y
011A. +++++++ [9]   PISTON
011B. +++++++ [9]   SHOE
13 0820402 [1]   CYL. ASS'Y
013A. +++++++ [1]   BLOCK;CYL.
013B. +++++++ [1]   PLATE;VALVE
14 0451003 [1]   CYL. ASS'Y
014A. +++++++ [1]   BLOCK;CYL.
014B. +++++++ [1]   PLATE;VALVE
30 0772701 [2]   PLATE ASS'Y
030A. +++++++ [1]   PLATE
030B. +++++++ [1]   BUSHING
41 0708004 [2]   VALVE;CHECK ASS'Y
041A. +++++++ [1]   SEAT
041B. +++++++ [1]   STOPPER
041C. +++++++ [1]   BALL;STEEL
111 0978501 [1]   SHAFT
113 0820406 [1]   SHAFT
122 0820407 [1]   BRG.;ROL.
123 0820453 [1]   BRG.;ROL.
124 0978503 [2]   BRG.;NEEDLE
125 0978504 [1]   RING;INNER
126 0820409 [2]   SPACER
127 0820410 [1]   SPACER
128 0820411 [3]   SPACER
129 0820412 [2]   SPACER
130 0978505 [1]   BOOSTER
131 0820414 [1]   COVER
153 0820415 [2]   RETAINER
156 0820416 [2]   BUSHING
157 0451016 [18]   SPRING
171 0978518 [1]   CASING I 0978519
171 0978519 [1]   CASING
191 0820418 [1]   GEAR;DRIVE
192 0820419 [1]   GEAR
211 0451018 [2]   PLATE
251 0820420 [2]   SUPPORT
261 0978507 [1]   COVER
262 0820422 [1]   COVER
271 0978508 [1]   CASING
312 0978509 [1]   COVER
405 0978510 [8]   BOLT;SOCKET
406 M341236 [8]   BOLT;SOCKET
408 0131103 [11]   BOLT;SOCKET
409 0820425 [2]   BOLT;SOCKET
410 0820426 [9]   BOLT;SOCKET
411 0820427 [2]   BOLT;SOCKET
412 0820428 [1]   BOLT;SOCKET
413 M341025 [5]   BOLT;SOCKET
466 0978511 [2]   PLUG
467 0629404 [2]   PLUG
468 0626901 [2]   PLUG
469 0697911 [3]   PLUG
490 0263019 [20]   PLUG
491 0451028 [12]   PLUG
492 0451027 [4]   SCREW
493 0102440 [2]   PLUG
530 0820438 [2]   PIN ASS'Y
530A. +++++++ [2]   PIN
530B. +++++++ [2]   PIN
532 0820429 [2]   PISTON;SERVO
534 0451031 [2]   STOPPER
535 0820430 [2]   STOPPER
536 0820431 [2]   COVER
702 0451033 [2]   O-RING
709 0694604 [2]   O-RING
711 0820432 [1]   O-RING
712 0820433 [1]   O-RING
724 0443801 [9]   O-RING
725 4297379 [2]   O-RING
726 0443405 [2]   O-RING
728 0443408 [5]   O-RING
729 0719402 [2]   O-RING
731 0443407 [2]   O-RING
732 0451035 [2]   O-RING
733 0978512 [1]   O-RING
752 0820439 [2]   PACKING
774 0820443 [1]   SEAL;OIL I 0978520
774 0978520 [1]   SEAL;OIL
789 0451036 [2]   RING;BACK-UP
792 0451037 [2]   RING;BACK-UP
806 0451038 [2]   NUT
807 0820434 [2]   NUT
823 959499 [1]   RING;RETAINING
824 991345 [3]   RING;RETAINING
825 488075 [2]   RING;RETAINING
827 991728 [1]   RING;RETAINING
828 0820435 [2]   RING;RETAINING
830 0978513 [1]   RING;RETAINING
885 0313404 [2]   PIN
886 0244604 [4]   PIN;SPRING
887 0175240 [1]   PIN
888 0978514 [2]   PIN
889 0978515 [4]   PIN
901 0134458 [2]   BOLT;EYE
953 0978516 [2]   SCREW;SET
954 0682328 [2]   SCREW;SET
981 +++++++ [1]   PLATE
983 0625509 [2]   PIN
4658831 [1]   REGULATOR;PUMP
4663481 [1]   PUMP;GEAR
9218005 [1]   PUMP;GEAR
