K5V200 hydraulic pump spring

K5V200 hydraulic pump spring

$20.00 USD
$20.00 USD
特價 售罄
結帳時計算運費。

K5V200DPH
4633472
ZX120-3 ZX130K-3
ZX200-3 ZX210K-3
ZX225USR-3 ZX225USRK-3
ZX240-3 ZX250H-3
ZX250K-3 ZX330-3
ZX350H-3 ZX350K-3
ZX450-3 ZX450-3F
ZX470H-3F ZX500LC-3
ZX520LC-3

K5V200DT
Pos. Part No Qty Parts name Comments
*. 31NB-10020 [1]   MAIN PUMP      *-1,-2
*. 31NB-10022 [1]   MAIN PUMP      *-1,-2
*-1. @ [1]   MAIN PUMP UNIT
S012. XJBN-00680 [2]   BLOCK-CYLINDER
111 XJBN-00976 [1]   SHAFT-DRIVE(R)
113 XJBN-00977 [1]   SHAFT-DRIVE(L)
114 XJBN-00572 [1]   COUPLING-SPLINE
123 XJBN-00571 [2]   BEARING-ROLLER
124 XJBN-00978 [2]   BEARING-NEEDLE
127 XJBN-00569 [3]   SPACER-BEARING
130 XJBN-00568 [1]   BOOSTER
NS151. XJBN-00681 [18]   PISTON
NS152. XJBN-00682 [18]   SHOE
153 XJBN-00683 [2]   PLATE-SET
156 XJBN-00564 [2]   BUSHING-SPHERICAL
157 XJBN-00541 [18]   SPRING-CYLINDER
211 XJBN-00023 [2]   PLATE-SHOE
S212. XJBN-00012 [2]   PLATE-SWASH
S214. XJBN-00013 [2]   BUSHING-TILTING
251 XJBN-00560 [2]   SUPPORT-S.P.
261 XJBN-00025 [1]   COVER(FR)-SEAL
263 XJBN-00979 [1]   COVER(RR)-SEAL
N271. XJBN-00980 [2]   CASING-PUMP
271 XJBN-01524 [2]   CASING-PUMP
311 XJBN-00559 [1]   COVER-VALVE(F)
312 XJBN-00558 [1]   COVER-VALVE(R)
S313. XJBN-00557 [1]   PLATE-VALVE(R)
S314. XJBN-00556 [1]   PLATE-VALVE(L)
401 XJBN-00028 [4]   SCREW
402 XJBN-00555 [4]   SCREW-HEX SOC HD
406 XJBN-00355 [8]   SCREW-HEX SOC HD
466 XJBN-00356 [4]   PLUG-VP
468 XJBN-00357 [4]   PLUG-VP
490 XJBN-00032 [32]   PLUG
492 XJBN-00234 [5]   PLUG
NS531. XJBN-00981 [2]   PIN-TILTING
532 XJBN-00703 [2]   PISTON-SERVO
534 XJBN-00034 [2]   STOPPER(L)
535 XJBN-00035 [2]   STOPPER(S)
NS548. XJBN-00360 [2]   PIN-FEED BACK
702 XJBN-00040 [2]   O-RING
706 XJBN-00982 [1]   O-RING
710 XJBN-00983 [2]   O-RING
717 XJBN-00984 [2]   O-RING
719 XJBN-00985 [3]   O-RING
724 XJBN-00902 [15]   O-RING
725 XJBN-00903 [10]   O-RING
728 XJBN-00905 [4]   O-RING
732 XJBN-00047 [2]   O-RING
774 XJBN-00906 [1]   SEAL-OIL
789 XJBN-00049 [2]   RING-BACK UP
792 XJBN-00050 [2]   RING-BACK UP
808 XJBN-00364 [4]   NUT-HEX
824 XJBN-00052 [2]   RING-SNAP
885 XJBN-00053 [2]   PIN 2
886 XJBN-00365 [5]   PIN-SPRING
901 XJBN-00055 [2]   BOLT-EYE
953 XJBN-00056 [2]   SCREW-SET
954 XJBN-00553 [2]   SCREW-SET
981 XJBN-00156 [1]   NAME PLATE
983 XJBN-00341 [2]   PIN
984 XJBN-01181 [8]   SCREW-SET
*-2. @ [1]   REGULATOR-FRONT      SEE 4020
*-3. @ [1]   REGULATOR-REAR      SEE 4030
S011. XJBN-00664 [2]   PISTON ASSY      SEE ILLUST
S013. XJBN-00665 [1]   CYLINDER ASSY-RH      SEE ILLUST
S014. XJBN-00666 [1]   CYLINDER ASSY-LH      SEE ILLUST
S030. XJBN-00011 [2]   SWASH PLATE ASSY      SEE ILLUST
S530. XJBN-00986 [2]   TILTING PIN SUB ASSY      SEE ILLUST
Pos. Part No Qty Parts name Comments
4633472 [1]   PUMP;PISTON
1 4658831 [2]   REGULATOR;PUMP
5 4654554 [1]   UNIT
05A. +++++++ [1]   SHAFT
05B. +++++++ [1]   GEAR
05C. +++++++ [1]   GEAR
05D. 978517 [2]   BRG.;BALL
05E. 878107 [1]   BRG.;ROL.
05F. 818508 [3]   SPACER
05G. +++++++ [1]   CASE
05H. +++++++ [1]   CASE;GEAR
05I. 195126 [3]   BOLT;SOCKET
05J. M341236 [8]   BOLT;SOCKET
05K. 988850 [1]   RING;RETAINING
05L. 446751 [1]   RING;RETAINING
05M. 978512 [1]   O-RING
05N. 443404 [1]   O-RING
05O. +++++++ [2]   PIN
05P. 4091248 [1]   BOLT;EYE
11 820401 [2]   PISTON ASS'Y
011A. +++++++ [9]   PISTON
011B. +++++++ [9]   SHOE
13 820402 [1]   CYL. ASS'Y
013A. +++++++ [1]   BLOCK;CYL.
013B. +++++++ [1]   PLATE;VALVE
14 451003 [1]   CYL. ASS'Y
014A. +++++++ [1]   BLOCK;CYL.
014B. +++++++ [1]   PLATE;VALVE
30 772701 [2]   PLATE ASS'Y
030A. +++++++ [1]   PLATE
030B. +++++++ [1]   BUSHING
41 708004 [2]   VALVE;CHECK ASS'Y
041A. +++++++ [1]   SEAT
041B. +++++++ [1]   STOPPER
041C. +++++++ [1]   BALL;STEEL
111 978501 [1]   SHAFT
113 820406 [1]   SHAFT
122 820407 [1]   BRG.;ROL.
123 820453 [1]   BRG.;ROL.
124 978503 [2]   BRG.;NEEDLE
125 978504 [1]   RING;INNER
126 820409 [2]   SPACER
127 820410 [1]   SPACER
128 820411 [3]   SPACER
129 820412 [2]   SPACER
130 978505 [1]   BOOSTER
131 820414 [1]   COVER
153 820415 [2]   RETAINER
156 820416 [2]   BUSHING
157 451016 [18]   SPRING
171 978518 [1]   CASING I 0978519
171 978519 [1]   CASING
191 820418 [1]   GEAR;DRIVE
192 820419 [1]   GEAR
211 451018 [2]   PLATE
251 820420 [2]   SUPPORT
261 978507 [1]   COVER
262 820422 [1]   COVER
271 978508 [1]   CASING
312 978509 [1]   COVER
405 978510 [8]   BOLT;SOCKET
406 M341236 [8]   BOLT;SOCKET
408 131103 [11]   BOLT;SOCKET
409 820425 [2]   BOLT;SOCKET
410 820426 [9]   BOLT;SOCKET
411 820427 [2]   BOLT;SOCKET
412 820428 [1]   BOLT;SOCKET
413 M341025 [5]   BOLT;SOCKET
466 978511 [2]   PLUG
467 629404 [2]   PLUG
468 626901 [2]   PLUG
469 697911 [3]   PLUG
490 263019 [20]   PLUG
491 451028 [12]   PLUG
492 451027 [4]   SCREW
493 102440 [2]   PLUG
530 820438 [2]   PIN ASS'Y
530A. +++++++ [2]   PIN
530B. +++++++ [2]   PIN
532 820429 [2]   PISTON;SERVO
534 451031 [2]   STOPPER
535 820430 [2]   STOPPER
536 820431 [2]   COVER
702 451033 [2]   O-RING
709 694604 [2]   O-RING
711 820432 [1]   O-RING
712 820433 [1]   O-RING
724 443801 [9]   O-RING
725 4297379 [2]   O-RING
726 443405 [2]   O-RING
728 443408 [5]   O-RING
729 719402 [2]   O-RING
731 443407 [2]   O-RING
732 451035 [2]   O-RING
733 978512 [1]   O-RING
752 820439 [2]   PACKING
774 820443 [1]   SEAL;OIL I 0978520
774 978520 [1]   SEAL;OIL
789 451036 [2]   RING;BACK-UP
792 451037 [2]   RING;BACK-UP
806 451038 [2]   NUT
807 820434 [2]   NUT
823 959499 [1]   RING;RETAINING
824 991345 [3]   RING;RETAINING
825 488075 [2]   RING;RETAINING
827 991728 [1]   RING;RETAINING
828 820435 [2]   RING;RETAINING
830 978513 [1]   RING;RETAINING
885 313404 [2]   PIN
886 244604 [4]   PIN;SPRING
887 175240 [1]   PIN
888 978514 [2]   PIN
889 978515 [4]   PIN
901 134458 [2]   BOLT;EYE
953 978516 [2]   SCREW;SET
954 682328 [2]   SCREW;SET
981 +++++++ [1]   PLATE
983 625509 [2]   PIN
 295-9674 310-9486 322-8733 327-7263
434-8188 477-8794
CAT330D CAT330DFM CAT330DL CAT330DLN CAT330DMH CAT336D CAT336DL CAT336DLN CAT336D2 CAT336D2L CAT340DL CAT340D2L
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 342-1882 [1] PUMP GP-GEAR
246-9867 [1] SEAL-O-RING
247-8841 M [2] BOLT (M10X1.5X30-MM)
2 252-9167 M [8] BOLT-SOCKET HEAD (M8X1.25X30-MM)
3 247-8985 [4] DOWEL
4 247-8729 [2] COVER
5 242-6919 M [2] SETSCREW (M20X2.5X56-MM)
6 451-2184 M [2] NUT (M20X2.5-THD)
7 6V-8200 M [8] BOLT-SOCKET HEAD (M12X1.75X35-MM)
8 7I-8166 [2] STOPPER
9 109-1296 [2] SEAL-O-RING
10 7I-8172 [2] RING-BACKUP
11 242-6914 [2] PISTON-SERVO
12 488-4578 [2] PIN AS
13 7I-8152 [18] SPRING-CYLINDER
14 109-1294 [2] SEAL-O-RING
15 7I-8171 [2] RING-BACKUP
16 242-6915 [2] STOPPER
17 095-0965 [11] PLUG
18 095-0966 [2] PLUG
19 242-6918 M [2] NUT (M20X2.5-THD)
20 200-3292 M [2] SETSCREW (M20X2.5X90-MM)
21 264-8266 M [1] BOLT-SOCKET HEAD (M22X2.5X130-MM)
22 234-4539 [2] DOWEL
23 249-1306 M [10] BOLT-SOCKET HEAD (M22X2.5X60-MM)
24 326-4415 [2] GASKET
25 110-5525 [4] PLUG
26 214-7568 [4] SEAL-O-RING
27 295-9656 [2] PISTON AS
28 7I-8154 [2] PLATE
29 242-6912 [2] PLATE
30 242-6913 [2] RETAINER-BALL
31 289-8172 [2] SWASHPLATE AS
32 7I-8084 [21] PLUG
33 311-9548 [4] PLUG
34 247-8725 [2] PLATE
35 095-0882 [4] PIN-SPRING
36 247-8786 [2] DOWEL
37 347-6530 [9] SEAL-RECTANGULAR
38 295-9695 [1] SEAL-LIP TYPE
39 095-0944 [1] RING-RETAINING
40 249-6657 [1] SEAL-O-RING
41 289-8174 [1] GEAR-DRIVE
42 289-8175 [1] GEAR-DRIVEN
43 6V-5204 [1] RING-RETAINING
44 247-8718 [1] SPACER (44.5X68X3-MM THK)
45 289-8173 [1] FLANGE
46 8T-0343 M [11] BOLT-SOCKET HEAD (M12X1.75X55-MM)
47 8T-4241 [3] RING-RETAINING
48 247-8787 [2] RING-RETAINING
49 247-8719 [3] SPACER (50X64X3-MM THK)
50 322-8734 [1] BODY
51 295-9658 [1] BARREL AS
52 259-0832 [1] SHAFT-DRIVEN
53 247-8715 [2] BEARING-NEEDLE
54 295-9659 [1] BLOCK-PORT
55 295-9657 [1] BARREL AS
56 249-1307 M [2] BOLT-SOCKET HEAD (M22X2.5X95-MM)
57 247-8713 [2] BEARING-ROLLER
58 8T-9080 M [8] BOLT-SOCKET HEAD (M12X1.75X20-MM)
59 295-9512 [1] COVER
60 249-6670 [1] SEAL-O-RING
61 247-8720 [2] SPACER (95X110X3.2-MM THK)
62 247-8717 [2] SPACER (65X90X1-MM THK)
63 095-0929 [2] RING-RETAINING
64 247-8726 [1] COVER
65 259-0831 [1] SHAFT-DRIVE
66 206-9291 [2] SEAL-O-RING
67 295-9660 Y [2] HEAD GP-PUMP
68 225-4518 Y [1] VALVE GP-SOLENOID (PUMP CONTROL)
M   METRIC PART
Y   SEPARATE ILLUSTRATION
2 259-0815 Y [1] PUMP GP-PISTON (HYDRAULIC FAN)
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 342-1882 [1] PUMP GP-GEAR
246-9867 [1] SEAL-O-RING
247-8841 M [2] BOLT (M10X1.5X30-MM)
2 252-9167 M [8] BOLT-SOCKET HEAD (M8X1.25X30-MM)
3 247-8985 [4] DOWEL
4 247-8729 [2] COVER
5 242-6919 M [2] SETSCREW (M20X2.5X56-MM)
6 451-2184 M [2] NUT (M20X2.5-THD)
7 6V-8200 M [8] BOLT-SOCKET HEAD (M12X1.75X35-MM)
8 7I-8166 [2] STOPPER
9 109-1296 [2] SEAL-O-RING
10 7I-8172 [2] RING-BACKUP
11 242-6914 [2] PISTON-SERVO
12 247-8712 [2] PIN AS
13 7I-8152 [18] SPRING-CYLINDER
14 109-1294 [2] SEAL-O-RING
15 7I-8171 [2] RING-BACKUP
16 242-6915 [2] STOPPER
17 095-0965 [11] PLUG
18 095-0966 [2] PLUG
19 242-6918 M [2] NUT (M20X2.5-THD)
20 200-3292 M [2] SETSCREW (M20X2.5X90-MM)
21 264-8266 M [1] BOLT-SOCKET HEAD (M22X2.5X130-MM)
22 234-4539 [2] DOWEL
23 249-1306 M [10] BOLT-SOCKET HEAD (M22X2.5X60-MM)
24 326-4415 [2] GASKET
25 110-5525 [4] PLUG
26 214-7568 [4] SEAL-O-RING
27 295-9656 [2] PISTON AS
28 7I-8154 [2] PLATE
29 242-6912 [2] PLATE
30 242-6913 [2] RETAINER-BALL
31 289-8172 [2] SWASHPLATE AS
32 7I-8084 [20] PLUG
33 311-9548 [4] PLUG
34 247-8725 [2] PLATE
35 095-0882 [4] PIN-SPRING
36 247-8786 [2] DOWEL
37 347-6530 [9] SEAL-RECTANGULAR
38 295-9695 [1] SEAL-LIP TYPE
39 095-0944 [1] RING-RETAINING
40 249-6657 [1] SEAL-O-RING
41 289-8174 [1] GEAR-DRIVE
42 289-8175 [1] GEAR-DRIVEN
43 6V-5204 [1] RING-RETAINING
44 247-8718 [1] SPACER (44.5X68X3-MM THK)
45 289-8173 [1] FLANGE
46 8T-0343 M [11] BOLT-SOCKET HEAD (M12X1.75X55-MM)
47 8T-4241 [3] RING-RETAINING
48 247-8787 [2] RING-RETAINING
49 247-8719 [3] SPACER (50X64X3-MM THK)
50 322-8734 [1] BODY
51 295-9658 [1] BARREL AS
52 259-0832 [1] SHAFT-DRIVEN
53 247-8715 [2] BEARING-NEEDLE
54 295-9659 [1] BLOCK-PORT
55 295-9657 [1] BARREL AS
56 249-1307 M [2] BOLT-SOCKET HEAD (M22X2.5X95-MM)
57 247-8713 [2] BEARING-ROLLER
58 8T-9080 M [8] BOLT-SOCKET HEAD (M12X1.75X20-MM)
59 295-9512 [1] COVER
60 249-6670 [1] SEAL-O-RING
61 247-8720 [2] SPACER (95X110X3.2-MM THK)
62 247-8717 [2] SPACER (65X90X1-MM THK)
63 095-0929 [2] RING-RETAINING
64 247-8726 [1] COVER
65 259-0831 [1] SHAFT-DRIVE
66 206-9291 [2] SEAL-O-RING
67 225-4518 Y [1] VALVE GP-SOLENOID (PUMP CONTROL)
68 295-9660 Y [2] HEAD GP-PUMP
M   METRIC PART
Y   SEPARATE ILLUSTRATION
1 289-7917 [1] PUMP GP-GEAR

Materials

Shipping & Returns

Dimensions

Care Instructions

查看完整資訊

Kawasaki Best Selling Series

檢視全部

Komatsu Best Selling Series

檢視全部

Caterpillar Best Selling Series

檢視全部
