K5V140 hydraulic pump parts

K5V140 hydraulic pump parts

$1,000.00 USD
$1,000.00 USD
特價 售罄
結帳時計算運費。
K5V140 SK350
R305LC-7 31N8-10070 XJBN-00997
R300LC-9A R300LC-9S R300LC-9SH 31Q8-10030 XJBN-01640
Pos. Part No Qty Parts name Comments
*. 31N8-10070 [1]   MAIN PUMP
*-1. XJBN-00997 [1]   MAIN PUMP UNIT
111 XJBN-00953 [1]   SHAFT(F)-DRIVE
113 XJBN-00952 [1]   SHAFT(R)-DRIVE
116 XJBN-00951 [1]   GEAR-1ST
123 XJBN-00950 [2]   BEARING-ROLLER
124 XJBN-00949 [2]   BEARING-NEEDLE
127 XJBN-00081 [3]   SPACER-BEARING
NS141. XJBN-00948 [2]   BLOCK-CYLINDER
NS151. XJBN-00947 [18]   PISTON
NS152. XJBN-00946 [18]   SHOE
153 XJBN-00945 [2]   PLATE-SET
156 XJBN-00083 [2]   BUSHING-SPHERICAL
157 XJBN-00944 [18]   SPRING-CYLINDER
211 XJBN-00085 [2]   PLATE-SHOE
NS212. XJBN-00943 [2]   PLATE-SWASH
S214. XJBN-00071 [2]   BUSHING-TILTING
251 XJBN-00942 [2]   SUPPORT-SP
261 XJBN-00941 [1]   COVER(F)-SEAL
271 XJBN-00088 [2]   CASING-PUMP
312 XJBN-00940 [1]   BLOCK-VALVE
NS313. XJBN-00939 [1]   PLATE(R)-VALVE
NS314. XJBN-00938 [1]   PLATE(L)-VALVE
S326. XJBN-00937 [1]   COVER
401 XJBN-00090 [8]   SCREW-HEX SOC HD
406 XJBN-00355 [4]   SCREW-HEX SOC HD
414 XJBN-00160 [4]   SCREW-SOCKET
466 XJBN-00356 [2]   PLUG
467 XJBN-00936 [2]   PLUG
468 XJBN-00357 [4]   PLUG
490 XJBN-00032 [32]   PLUG
NS531. XJBN-00956 [2]   PIN-TILTING
532 XJBN-00955 [2]   PISTON-SERVO
534 XJBN-00092 [2]   STOPPER(L)
535 XJBN-00093 [2]   STOPPER(S)
NS541. XJBN-00859 [4]   SEAT
NS543. XJBN-00860 [2]   STOPPER
NS544. XJBN-00861 [2]   STOPPER
S545. XJBN-00359 [4]   BALL-STEEL
NS548. XJBN-00360 [2]   PIN-FEED BACK
702 XJBN-00862 [2]   O-RING
710 XJBN-00878 [2]   O-RING
717 XJBN-00096 [4]   O-RING
724 XJBN-00361 [16]   O-RING
725 XJBN-00362 [4]   O-RING
726 XJBN-00233 [2]   O-RING
728 XJBN-00363 [4]   O-RING
732 XJBN-00863 [2]   O-RING
774 XJBN-00906 [1]   SEAL-OIL
789 XJBN-00864 [2]   RING-BACK UP
792 XJBN-00865 [2]   RING-BACK UP
806 XJBN-00396 [2]   NUT
808 XJBN-00364 [2]   NUT
824 XJBN-00866 [2]   RING-SNAP
885 XJBN-00103 [2]   PIN-VALVE PLATE
886 XJBN-00365 [4]   PIN-SPRING
901 XJBN-00393 [2]   BOLT-EYE
953 XJBN-00954 [2]   SCREW-SET
954 XJBN-00106 [2]   SCREW-SET
981 XJBN-00156 [1]   NAME PLATE
683 XJBN-00341 [2]   PIN
*-2. XJBN-00964 [2]   REGULATOR ASSY      SEE 4020
*-3. XJBN-00935 [1]   PUMP-GEAR      SEE 4030
*-4. XJBN-00014 [1]   CASING ASSY-EPPR VLV      SEE 4040
11 XJBN-00934 [2]   PISTON ASSY
13 XJBN-00933 [1]   CYLINDER(R) ASSY
14 XJBN-00932 [1]   CYLINDER(L) ASSY
30 XJBN-00931 [2]   SWASH PLATE ASSY
41 XJBN-00072 [2]   CHECK VALVE ASSY 1
42 XJBN-00075 [2]   CHECK 2 ASSY
80 XJBN-00014 [1]   CASING ASSY-EPPR VLV
530 XJBN-00930 [2]   TILTING PIN ASSY
Pos. Part No Qty Parts name Comments
*. 31Q8-10030 [1]   MAIN PUMP      *-1,-2,-3
*-1. XJBN-01640 [1]   MAIN PUMP UNIT
111 XJBN-00953 [1]   SHAFT(F)-DRIVE
113 XJBN-00952 [1]   SHAFT(R)-DRIVE
116 XJBN-00951 [1]   GEAR-1ST
123 XJBN-00950 [2]   BEARING-ROLLER
124 XJBN-00949 [2]   BEARING-NEEDLE
127 XJBN-00081 [3]   SPACER-BEARING
NS141. XJBN-00948 [2]   BLOCK-CYLINDER
NS151. XJBN-00947 [18]   PISTON
NS152. XJBN-01633 [18]   SHOE
153 XJBN-00945 [2]   PLATE-SET
156 XJBN-00083 [2]   BUSHING-SPHERICAL
157 XJBN-00944 [18]   SPRING-CYLINDER
211 XJBN-00085 [2]   PLATE-SHOE
NS212. XJBN-00943 [2]   PLATE-SWASH
S214. XJBN-00071 [2]   BUSHING-TILTING
251 XJBN-00942 [2]   SUPPORT-SP
261 XJBN-00941 [1]   COVER(F)-SEAL
271 XJBN-01034 [2]   CASING-PUMP
312 XJBN-00940 [1]   BLOCK-VALVE
NS313. XJBN-01197 [1]   PLATE(R)-VALVE
NS314. XJBN-01198 [1]   PLATE(L)-VALVE
N326. XJBN-00937 [1]   COVER
401 XJBN-00090 [8]   SCREW-HEX SOC HD
406 XJBN-00355 [4]   SCREW
414 XJBN-00160 [4]   SCREW-SOCKET
466 XJBN-00356 [2]   PLUG
467 XJBN-00936 [2]   PLUG
468 XJBN-00031 [4]   PLUG
490 XJBN-00032 [32]   PLUG
NS531. XJBN-00956 [2]   PIN-TILTING
532 XJBN-00955 [2]   PISTON-SERVO
534 XJBN-00092 [2]   STOPPER(L)
535 XJBN-00093 [2]   STOPPER(S)
NS541. XJBN-00859 [4]   SEAT
NS543. XJBN-00860 [2]   STOPPER
NS544. XJBN-00861 [2]   STOPPER
S545. XJBN-00359 [4]   BALL-STEEL
NS548. XJBN-00360 [2]   PIN-FEED BACK
702 XJBN-00862 [2]   O-RING
710 XJBN-00878 [2]   O-RING
717 XJBN-00096 [4]   O-RING
724 XJBN-00361 [16]   O-RING
725 XJBN-00362 [4]   O-RING
726 XJBN-00233 [2]   O-RING
728 XJBN-00363 [4]   O-RING
732 XJBN-00863 [2]   O-RING
774 XJBN-00906 [1]   SEAL-OIL
789 XJBN-00864 [2]   RING-BACK UP
792 XJBN-00865 [2]   RING-BACK UP
806 XJBN-00396 [2]   NUT-HEX
808 XJBN-00364 [2]   NUT
824 XJBN-00866 [2]   RING-SNAP
885 XJBN-00103 [2]   PIN-VALVE PLATE
886 XJBN-00365 [4]   PIN-SPRING
901 XJBN-00393 [2]   BOLT-EYE
953 XJBN-00954 [2]   SCREW-SET
954 XJBN-00106 [2]   SCREW-SET
981 XJBN-00156 [1]   NAME PLATE
983 XJBN-00341 [2]   PIN
*-2. @ [1]   REGULATOR      SEE 4020
*-3. @ [1]   GEAR PUMP      SEE 4040
80 XJBN-00014 [1]   EPPR VALVE ASSY
S011. XJBN-01632 [2]   PISTON ASSY      SEE ILLUST
S013. XJBN-01199 [1]   CYLINDER ASSY-RH      SEE ILLUST
S014. XJBN-01200 [1]   CYLINDER ASSY-LH      SEE ILLUST
S030. XJBN-00931 [2]   SWASH PLATE ASSY      SEE ILLUST
S041. XJBN-00072 [2]   CHECK VALVE ASSY 1      SEE ILLUST
S042. XJBN-00075 [2]   CHECK VALVE ASSY 2      SEE ILLUST
S530. XJBN-00930 [2]   TILTING PIN ASSY      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
401107-02157 400914-00395A DX300LC-5
Pos. Part No Qty Parts name Comments
*. 401107-02157 [1]
-. 400914-00395A [1]
11 K9006418 [2]   PISTON
111 1.405-00055 [1]   SHAFT;DRIVE(F)
113 1.405-00057 [1]   SHAFT;DRIVE(R)
116 1.403-00004 [1]   GEAR;1st
123 1.109-00111 [2]   PALIER
124 1.109-00055 [2]   BEARING;NEEDLE
127 2.109-00228 [3]   BAGUE D'ECARTEMENT
13 K9006419 [1]   CYLINDER ASS'Y(R)
14 K9006420 [1]   CYLINDER ASS'Y(L)
153 1.412-00098 [2]   PLAQUE
156 1.110-00101 [2]   BAGUE
157 1.131-00131 [18]   RESSORT
211 1.412-00110 [2]   PLAQUE
212 K9001177 [1]   PLATE;SWASH
214 2.408-00088 [1]   BUSH;TILTING
251 K9001180 [2]   SUPPORT
261 1.430-00213 [1]   COVER;SEAL(F)
271 K9005964 [2]   CASING;PUMP
30 K9001176 [2]   SWASH PLATE ASS'Y
312 K9001181 [1]   BLOCK;VALVE
325 1.402-00097 [1]   CASING;VALVE
326 K9001182 [1]   COVER;SEAL(F)
401 S2229071 [8]   BOLT;SOCKET
406 S2208871 [4]   BOLT;SOCKET
407 S2205861 [3]   SCREW
41 K9001183 [2]   CHECK VALVE ASS'Y(1)
414 S2211861 [4]   BOLT;SOCKET M10X1.5X20
42 K9001186 [2]   CHECK VALVE ASS'Y(2)
466 2181-1950D1 [3]   PLUG
467 2181-1950D2 [2]   PLUG
468 2181-1950D5 [4]   PLUG PF3/4
490 2.181-00214 [35]   PRISE
530 1.123-00089 [2]   TILTING PIN ASS'Y
531 1.123-00090 [1]   PIN;TILTING
532 1.409-00209 [2]   PISTON
534 1.416-00020 [2]   STOPPER(L)
535 1.416-00021 [2]   STOPPER(S)
541 K9001184 [4]   SEAT
543 K9001185 [2]   STOPPER;1
544 K9001187 [2]   STOPPER;1
545 S6250132 [4]   BALL;STEEL
548 2.123-00154 [1]   PIN;FEED BACK
702 S8010355 [2]   O-RING
710 S8010955 [2]   O-RING
717 S8011455 [4]   O-RING
724 401003-00823 [16]
725 S8000115 [8]   .. O-RING
726 S8000145 [2]   O-RING 1BP14
728 S8000245 [4]   O-RING
732 S8000185 [3]   . O-RING
774 401106-00108 [1]
789 S8060181 [2]   . RING;BACKUP
79 K9001179 [1]   E.P.P.R VALVE
79-1. 2180-1217D13 [1]   . O-RING
79-2. 2180-1217D14 [1]   O-RING
79-3. 2180-1217D15 [1]   . O-RING
792 S8090350 [2]   RING;BACK-UP
80 K9001178 [1]   PROPORTIONAL REDUCING VALVE
806 S4012931 [2]   NUT
808 S4015130 [2]   ECROU
824 S6500400 [2]   RING,RETAINING
885 2.123-00067 [2]   GOUJON
886 S5740870 [4]   PIN,SPRING
901 S3140025 [2]   BOLT,EYE
953 S3527906 [2]   SCREW
954 1.120-00071 [2]   SCREW
-. K9001192 [1]   GEAR PUMP
-. 400825-00037 [2]
