JMV-155/89 JMV155 travel motor parts

JMV-155/89 JMV155 travel motor parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
JMV-155/89 JMV155
31N8-40050 31N8-40051 31N8-40051BG 31N8-40052 31N8-40053 31N8-40054 31N8-40060 31N8-40061 31N8-40061BG 31N8-40062 31N8-40063
R250LC-7 R290LC-7 R300LC-7 R305LC-7
R250LC-7A R290LC-7A
R290LC-7H
rotary kit XKAY-00218 XKAY-01510 XKAY-00218

31Q8-40040 31Q8-40061 31Q8-40062 31Q8-40063 31Q8-40041
R250LC-9 R260LC-9A R260LC-9S R290LC-9 R290LC-9MH R300LC-9A R300LC-9S R300LC-9SH
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR ASSY      SEE 4130
*-1. @ [1]   TRAVEL MOTOR UNIT      SEE 4130
1 XKAY-01129 [1]   CASING-SHAFT
1 XKAY-02052 [1]   CASING-SHAFT
2 XKAY-01415 [12]   PLUG
3 XKAY-00199 [2]   SCREW-ORIFICE
4 XKAY-00199 [1]   SCREW-ORIFICE
5 XKAY-00201 [2]   PIN-SUPPORT
6 XKAY-00202 [4]   PIN-BRAKE
7 XKAY-00203 [1]   STOPPER(S)
K8. XKAY-00204 [4]   O-RING
K9. XKAY-00205 [3]   RING-BACK UP
10 XKAY-00206 [1]   PISTON-SWASH
K10-4. @ [1]   SEAL      NOT SHOWN
11 XKAY-00207 [1]   SHAFT
12 XKAY-00208 [1]   SPACER-BEARING
13 XKAY-00209 [1]   BEARING-ROLLER
14 XKAY-00210 [1]   RING-STOP
*-11. XKAY-00211 [1]   SUPPORT KIT      INCL 15,16
N15. XKAY-00212 [1]   SUPPORT
N16. XKAY-00213 [1]   PLATE-SWASH
17 XKAY-00214 [1]   PISTON-SWASH
K17-4. @ [1]   SEAL      NOT SHOWN
18 XKAY-00215 [1]   STOPPER(L)
K19. XKAY-00216 [1]   O-RING
K20. XKAY-00217 [2]   RING-BACK UP
*-12. XKAY-00218 [1]   ROTARY KIT      INCL *-A,B,C
*-A. XKAY-00219 [1]   CYLINDER BLOCK KIT      INCL 21~23,67
N21. XKAY-00220 [1]   BLOCK-CYLINDER
22 XKAY-00221 [9]   SPRING-CYLINDER
23 XKAY-00222 [1]   SPACER
67 XKAY-01505 [1]   PLATE-VALVE
*-B. XKAY-00223 [1]   RETAINER KIT      INCL 24,25
24 XKAY-00224 [1]   GUIDE-BALL
25 XKAY-00225 [1]   SET-PLATE
*-C. XKAY-00226 [1]   PISTON KIT      INCL 26
N26. XKAY-00227 [9]   PISTON & SHOE ASSY
27 XKAY-00228 [2]   PLATE-FRICTION
28 XKAY-00229 [1]   PLATE-SEPARATOR
29 XKAY-00973 [1]   BRAKE-PISTON
30 XKAY-00231 [1]   RING-PISTON 252
31 XKAY-00232 [1]   RING-PISTON 278
32 XKAY-00233 [10]   SPRING-BRAKE
34 XKAY-00235 [1]   BEARING-NEEDLE
36 XKAY-00237 [2]   PIN-VALVE PLATE
63 XKAY-00279 [1]   NUT-HEX
K69. XKAY-00270 [3]   O-RING
72 XKAY-00273 [1]   SCREW-LOCK
K73. XKAY-00274 [1]   SEAL-OIL
74 XKAY-00275 [1]   RING-LOCK
*-2. 31Q9-40020 [1]   TRAVEL REDUCTION GEAR      SEE 4135
K. XKAY-00278 [1]   SEAL KIT      SEE ILLUST
Pos. Part No Qty Parts name Comments
*. 31Q8-40061 [1]   TRAVEL MOTOR ASSY
*. 31Q8-40062 [1]   TRAVEL MOTOR ASSY
*. 31Q8-40063 [1]   TRAVEL MOTOR ASSY
*-1. 31Q8-40040 [1]   TRAVEL MOTOR UNIT
*-1. 31Q8-40041 [1]   TRAVEL MOTOR UNIT
2 XKAY-01415 [12]   PLUG
33 XKAY-01506 [1]   CASING-VALVE
K35. XKAY-00236 [1]   O-RING
*-12. XKAY-00238 [1]   SPOOL KIT-C/BLC VALVE      INCL 37, 38
37 XKAY-00239 [1]   SPOOL-C/BLC VALVE
38 XKAY-00240 [2]   SCREW-ORIFICE
39 XKAY-00241 [4]   DAMPING CHECK ASSY
40 XKAY-00242 [2]   SPRING-C/BLC VALVE
K41. XKAY-00243 [2]   O-RING
42 XKAY-00244 [2]   PLUNGER-C/BLC VALVE
43 XKAY-00245 [2]   SPRING-CHECK
44 XKAY-00246 [2]   STOPPER-CHECK
K45. XKAY-00247 [4]   O-RING
K46. XKAY-00248 [1]   RING-BACK UP
47 XKAY-00249 [1]   CAP-C/BLC VALVE(R)
48 XKAY-00250 [1]   CAP-C/BLC VALVE(L)
49 XKAY-00136 [8]   BOLT-SOCKET
50 XKAY-00251 [4]   BOLT-SOCKET
51 XKAY-00252 [2]   SEAT
52 XKAY-00253 [2]   BALL-STEEL
53 XKAY-00254 [2]   STOPPER
54 XKAY-00255 [7]   PLUG-HP
K55. XKAY-00256 [7]   O-RING
56 XKAY-00257 [2]   PLUG-HP
57 XKAY-01516 [1]   RELIEF VALVE ASSY
K58. XKAY-00259 [2]   O-RING
K59. XKAY-00260 [2]   RING-BACK UP
60 XKAY-00261 [1]   ROD-SWASH
K61. XKAY-00262 [1]   O-RING
62 XKAY-00263 [1]   SCREW-LOCK
63 XKAY-00279 [2]   NUT-HEX
64 XKAY-00265 [1]   SPOOL-SWASH
65 XKAY-00266 [1]   PLUG
K66. XKAY-00267 [1]   O-RING
68 XKAY-00269 [1]   SPRING-SWASH
70 XKAY-00271 [8]   BOLT-WRENCH
71 XKAY-00272 [4]   BOLT-SOCKET
76 XKAY-00277 [2]   RIVET
*-2. 31Q9-40020 [1]   TRAVEL REDUCTION GEAR      SEE 4135
K. XKAY-00278 [1]   SEAL KIT      SEE ILLUST
29 XJCK-00121 [1]   BLOCK-CYLINDER
30 XJCK-00042 [1]   RETAINER-SHOE
31 XJCK-00041 [4]   PLATE-FRICTION
32 XJCK-00040 [1]   PISTON-BRAKE
33 XJCK-00039 [5]   PLATE-SEPARATING
34 XJCK-00120 [1]   PLATE-VALVE
35 XJCK-00037 [1]   SHAFT
36 XJCK-00036 [1]   COUPLING
N37. XJCK-00035 [1]   PLATE-SWASH
N38. XJCK-00034 [2]   PIVOT
39 XJCK-00077 [1]   HOLDER-SPRING
40 XJCK-00119 [9]   PISTON ASSY
41 XJCK-00031 [1]   D-RING
42 XJCK-00030 [1]   D-RING
43 XJCK-00029 [3]   VALVE-CHECK
44 XJCK-00028 [1]   RING-RETAINER
45 XJCK-00027 [1]   RING-RETAINER
N46. XJCK-00026 [1]   SHIM
47 XJCK-00025 [1]   PISTON
48 XJCK-00024 [1]   BALL
49 XJCK-00023 [1]   JOINT-BALL
50 XJCK-00022 [1]   SEAL-PISTON
51 XJCK-00021 [1]   RESTRICTOR
52 XJCK-00020 [1]   RESTRICTOR
53 XJCK-00019 [1]   SEAL-OIL
54 XJCK-00018 [3]   SPRING-CHECK VLV
55 XJCK-00017 [9]   SPRING-CYLINDER
56 XJCK-00016 [12]   SPRING-BRAKE
57 XJCK-00015 [1]   BEARING
58 XJCK-00014 [1]   BEARING
59 XJCK-00013 [10]   SCREW-CAP
60 XJCK-00012 [1]   PIN-PARALLEL
61 XJCK-00011 [3]   O-RING
62 XJCK-00010 [2]   O-RING
63 XJCK-00009 [3]   O-RING
64 XJCK-00008 [1]   O-RING
65 XJCK-00007 [1]   O-RING
66 XJCK-00137 [2]   RELIEF VALVE
67 XJCK-00005 [1]   PILOT VALVE
68 XJCK-00138 [1]   BRAKE VALVE
69 XJCK-00003 [2]   PLUG
70 XJCK-00001 [2]   O-RING
71 XJCK-00076 [1]   PLUG-EXPANDER
72 XJCK-00075 [4]   PLUG
73 XJCK-00074 [1]   PLUG
*-2. @ [1]   T/REDUCTION GEAR      SEE 4130
