JEIL JMF250 hydraulic swing motor rotary group and spare parts for Daewoo DH360 DH370-7 excavator

JEIL JMF250 hydraulic swing motor rotary group and spare parts for Daewoo DH360 DH370-7 excavator

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
JMF250
SWING MOTOR K1007543A DX340LC DX340LCA  DX350LC DX360LCA  DX420LC ROTARY KIT K9002107 CYLINDER BLOCK KIT K9002108 RETAINER KIT K9002109
JEIL JMF250 hydraulic swing motor parts used for
Volco EC360 EC380 EC700，
Doosan DX340 DX420，
Daewoo DH360-5/7 DH370-7 DH400-7 DH420
Pos. Part No Qty Parts name Comments
*. K9002069 [1]   SEAL KIT;SWING MOTOR
-. K1007543A [1]   MOTOR;SWING
1 1.451-00145 [1]   BODY
10 1.131-00070 [9]   SPRING
11 1.427-00007 [1]   SEAT;BALL GUIDE
12 1.429-00008 [1]   GUIDE;BALL
13 *NA00834 [1]
14 1.409-00175 [1]   PISTON ASS'Y
15 1.412-00063 [4]   PLATE;FRICTION
16 1.412-00025 [4]   PLATE
17 1.409-00187 [1]   PISTON;BRAKE
18 2180-1217D160 [2]   O-RING
19 1.131-00071 [19]   SPRING
2 1.180-00523 [1]   SEAL;OIL
20 *NA00839 [1]   . HEAD
21 1.123-00042 [2]   PIN
22 1.109-00058 [1]   BEARING;NEEDLE
23 K9002105 [1]   COVER;REAR
24 S2218661 [7]   BOLT;SOCKET
25 S2219571 [1]   BOLT;SOCKET
26 1.426-00010 [2]   POPPET
27 1.131-00072 [2]   SPRING
28 1.181-00103 [2]   PLUG;DRAIN
29 S8000291 [2]   O-RING
3 1.109-00066 [1]   BEARING;ROLLER
30 1.420-00122 [2]   RELIEF VALVE ASS'Y
31 K9002106 [1]   VALVE;TIME DELAY
32 S2206161 [3]   BOLT;SOCKET
33 2181-1116D2 [3]   PLUG
34 K9000942 [2]   VALVE;SWING REACTIONLESS
35 K9000943 [2]   PLUG
36 S8000181 [2]   O-RING
37 K9000944 [2]   RING;BACK UP
38 S8000121 [2]   O-RING
39 2180-1217D159 [1]   O-RING
4 1.115-00100 [1]   RING;SNAP
40 1.110-00172 [1]   BUSHING
41 K9002107 [1]   ROTARY KIT
42 K9002108 [1]   CYLINDER BLOCK KIT
43 K9002109 [1]   RETAINER KIT
5 1.405-00025 [1]   SHAFT
6 1.123-00041 [1]   PIN
7 1.115-00371 [1]   RING;STOP
8 1.412-00113 [1]   PLATE;SHOE
9 *NA00427 [1]
RMF250 31NA-10160 31NA-10170 31NA-10172
R360LC-7 R360LC-7A R370LC-7 R800LC-7A
Pos. Part No Qty Parts name Comments
*. 31NA-10170 [1]   SWING UNIT      STD
N*. 31NA-10172 [1]   SWING UNIT      STD
*-1. 31NA-10160 [1]   SWING MOTOR UNIT
1 XKAY-00161 [1]   BODY
2 XKAY-00162 [1]   SEAL-OIL
3 XKAY-00163 [1]   BEARING-ROLLER
4 XKAY-00164 [1]   RING-SNAP
5 XKAY-00165 [1]   SHAFT
6 XKAY-00166 [1]   PIN
7 XKAY-00167 [1]   RING-STOP
8 XKAY-00168 [1]   PLATE-SHOE
9 XKAY-00169 [1]   BLOCK-CYLINDER
10 XKAY-00170 [9]   SPRING
11 XKAY-00171 [1]   GUIDE SEAT-BALL
12 XKAY-00172 [1]   GUIDE-BALL
13 XKAY-00173 [1]   PLATE-SET
14 XKAY-00174 [1]   PISTON ASSY
15 XKAY-00175 [4]   PLATE-FRICTION
16 XKAY-00176 [4]   PLATE
17 XKAY-00177 [1]   PISTON-BRAKE
18 XKAY-00178 [2]   O-RING
19 XKAY-00179 [19]   SPRING
20 XKAY-00180 [1]   PLATE-VALVE
21 XKAY-00181 [2]   PIN
22 XKAY-00182 [1]   BEARING-NEEDLE
23 XKAY-00183 [1]   COVER-REAR
24 XKAY-00184 [7]   BOLT-WRENCH
25 XKAY-00185 [1]   BOLT-WRENCH
26 XKAY-00186 [2]   POPPET
27 XKAY-00187 [2]   SPRING
28 XKAY-00188 [2]   PLUG
29 XKAY-00189 [2]   O-RING
30 XKAY-00190 [2]   RELIEF VALVE ASSY
31 XKAY-00148 [1]   VALVE-TIME DELAY
32 XKAY-00149 [3]   BOLT-WRENCH
33 XKAY-00140 [3]   PLUG
34 XKAY-00191 [2]   O-RING
35 XKAY-00192 [1]   O-RING
36 XKAY-00193 [1]   BUSHING
*-2. @ [1]   TRAVEL REDUCTION GEAR      SEE 4111
