JEIL JMF195 hydraulic swing motor rotary group and spare parts For Doosan DX300，Daewoo DH300-7 DH300-9 excavator

JEIL JMF195 hydraulic swing motor rotary group and spare parts For Doosan DX300，Daewoo DH300-7 DH300-9 excavator

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
JMF195 401-00457B
DH300-7 XG822 SWING MOTOR
Pos. Part No Qty Parts name Comments
*. K9000947 [1]   KIT;SEAL
-. 401-00457B [1]   MOTOR;SWING
1 K9000949 [1]   BODY
14 K9000937 [3]   PLATE;FRICTION
15 K9000938 [3]   PLATE
16 K9000939 [1]   PISTON;BRAKE
17 2180-1216D155 [2]   O-RING
18 K9000940 [18]   SPRING
19 K9000941 [1]   COVER
2 K9000403 [1]   SEAL;OIL
20 2.109-00176 [1]   BEARING;NEEDLE
21 S5711031 [2]   PIN;PARALLEL
23 S2227661 [2]   BOLT;SOCKET
24 1.426-00010 [2]   POPPET
25 1.131-00072 [2]   SPRING
26 1.181-00103 [2]   PLUG;DRAIN
27 S8000291 [2]   O-RING
28 K9000942 [2]   VALVE;SWING REACTIONLESS
29 K9000943 [2]   PLUG
3 K9000924 [1]   BEARING;ROLLER
30 S8000121 [2]   O-RING
31 S8000181 [2]   O-RING
32 K9000944 [2]   RING;BACK UP
33 K9000945 [2]   RELIEF VALVE ASS'Y
33A. S8000311 [1]   O-RING
33B. S8060310 [1]   RING;BACK-UP
33C. S8000261 [1]   O-RING
33D. S8000241 [1]   O-RING
33E. S8060240 [1]   RING;BACK-UP
34 K9000946 [1]   TIME DELAY VALVE ASS'Y
34A. S8000071 [1]   O-RING
34B. S8000151 [2]   O-RING
35 S2206161 [3]   BOLT;SOCKET
36 420-00112 [3]   PLUG
37 S8000111 [3]   O-RING
38 2180-1216D154 [1]   O-RING
39 K9000948 [1]   BUSHING
4 S6510850 [1]   RING;LOCK
5 K9000925 [1]   SHAFT
6 K9000926 [1]   PIN;PARALLEL
7 K9000927 [1]   RING;STOP
8 K9000928 [1]   PLATE;SHOE
9 K9000929 [1]   KIT;ROTARY
9A. K9000930 [1]   CYLINDER BLOCK KIT
9Aa. K9000931 [1]   BLOCK;CYLINDER
9Ab. K9000932 [1]   PLATE;VALVE
9B. 1.131-00070 [9]   SPRING
9C. K9000933 [1]   KIT;RETAINER
9Ca. K9000934 [1]   GUIDE;BALL
9Cb. K9000935 [1]   PLATE;SET
9D. K9000936 [1]   PISTON KIT

Model：JEIL JMF195
Part number：
Application：Doosan DX300，Daewoo DH300-7 DH300-9 excavator
Brand：ITRITA
Material：Aluminum and Steel
Place of production：China
Delivey time：within 3 days
Payment：Western Union，T/T
Warranty（in China）：3 months
