HYUNDDI R140LC-7 EXCAVATOR SWING REDUCTION GEAR(-#1440)

HYUNDDI R140LC-7 EXCAVATOR SWING REDUCTION GEAR(-#1440)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SWING REDUCTION GEAR(-#1440):
Pos. Part No Qty Parts name Comments
*. @ [1]   SWING MOTOR ASSY      SEE 4100
*-2. 31E6-12030 [1]   SWING REDUCTION GEAR
1 XKAQ-00250 [1]   CASING
2 XKAQ-00249 [1]   SHAFT-DRIVE
3 XKAQ-00102 [1]   GEAR-RING
5 XKAQ-00278 [1]   GEAR-SUN NO.2
*-21. XKAQ-00271 [1]   CARRIER NO.1 ASSY
6 XKAQ-00099 [3]   GEAR-PLANET NO.1
7 XKAQ-00277 [1]   GEAR-SUN NO.1
9 XKAQ-00096 [1]   CARRIER NO.1
11 XKAQ-00094 [3]   PIN ASSY NO.1
12 XKAQ-00093 [6]   WASHER-THRUST(B)
13 XKAQ-00057 [1]   PLATE-SIDE 1
23 XKAQ-00086 [3]   PIN-SPRING
24 XKAQ-00085 [4]   RING-STOP
29 XKAQ-00080 [3]   CAGE-NEEDLE
*-22. XKAQ-00272 [1]   CARRIER NO.2 ASSY
4 XKAQ-00101 [4]   GEAR-PLANET NO.2
8 XKAQ-00097 [1]   CARRIER NO.2
10 XKAQ-00095 [4]   PIN ASSY NO.2
12 XKAQ-00093 [4]   WASHER-THRUST(B)
23 XKAQ-00086 [4]   PIN-SPRING
14 XKAQ-00034 [1]   BAR-GAUGE
15 XKAQ-00035 [1]   PIPE-GAUGE
16 XKAQ-00091 [2]   PIN-KNOCK
17 XKAQ-00090 [1]   BEARING-SPH ROLLER
18 XKAQ-00089 [1]   BEARING-CYL ROLLER
19 XKAQ-00088 [10]   BOLT-SOCKET
20 XKAQ-00087 [1]   SEAL-OIL
21 XKAQ-00049 [1]   PLUG-PRESSURE
22 XKAQ-00066 [2]   PLUG
25 XKAQ-00084 [1]   RING-STOP
26 XKAQ-00083 [1]   SPACER
27 XKAQ-00082 [1]   PLATE-COVER
28 XKAQ-00081 [6]   BOLT-HEX
30 XKAQ-00142 [1]   AIR BREATHER ASSY
30-1. HHI13-WP30 [1]   POST
30-2. HHI13-WP31 [1]   CAP-BREATHER
