HYUNDAI R80-7 R80-7A EXCAVATOR XKAY-01864 31N1-40010 31N1-40011 TRAVEL MOTOR ROTARY GROUP

HYUNDAI R80-7 R80-7A EXCAVATOR XKAY-01864 31N1-40010 31N1-40011 TRAVEL MOTOR ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
XKAY-01864 31N1-40010 31N1-40011 R80-7 R80-7A
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL  MOTOR      SEE 4300
*-1. @ [1]   TRAVEL MOTOR ASSY      SEE 4300
1 XKAY-00563 [1]   CASING-SHAFT      NOT USED
1 XKAY-00654 [1]   CASING-SHAFT
1 XKAY-02285 [1]   CASING-SHAFT
K2. XKAY-00564 [1]   SEAL-OIL
3 XKAY-00565 [1]   SHAFT
4 XKAY-00566 [1]   BEARING
*-1. XKAY-00567 [1]   SWASH PISTON KIT
N5. XKAY-00568 [1]   PISTON-SWASH
N6. XKAY-00569 [1]   RING-PISTON
7 XKAY-00570 [2]   STEEL BALL-SWASH
8 XKAY-00571 [1]   PLATE-SWASH
*-2. XKAY-00572 [1]   ROTARY KIT
*-21. XKAY-00573 [1]   CYLINDER BLOCK KIT
N9. XKAY-00574 [1]   BLOCK-CYLINDER
10 XKAY-00575 [6]   SPRING
*-22. XKAY-00576 [1]   RETAINER KIT
N11. XKAY-00577 [1]   GUIDE-BALL
N12. XKAY-00578 [1]   PLATE-SET
N13. XKAY-00579 [1]   PLATE-VALVE
*-23. XKAY-00580 [1]   PISTON KIT
N14. XKAY-00581 [9]   PISTON ASSY
15 XKAY-00582 [3]   PLATE-FRICTION
16 XKAY-00583 [3]   PLATE-PARKING
17 XKAY-00356 [1]   PISTON-PARKING
K18. XKAY-00357 [1]   O-RING
K19. XKAY-00410 [1]   RING-BACK UP
K20. XKAY-00358 [1]   O-RING
K21. XKAY-00411 [1]   RING-BACK UP
54 @ [1]   BEARING      SEE 4300 ITEM54
56 XKAY-00384 [1]   PLATE-SPRING
K57. XKAY-00360 [1]   O-RING
K. XKAY-00595 [1]   SEAL KIT      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
Pos. Part No Qty Parts name Comments
*. 31N1-40010 [1]   TRAVEL MOTOR
*. 31N1-40011 [1]   TRAVEL MOTOR
N*-1. XKAY-01864 [1]   TRAVEL MOTOR ASSY
*-2. XKAY-01992 [1]   REAR COVER ASSY
22 XKAY-00585 [1]   COVER-REAR
23 XKAY-00198 [10]   PLUG
24 XKAY-00362 [1]   SPOOL
25 XKAY-00363 [1]   SPRING
26 XKAY-00364 [1]   STOPPER
27 XKAY-00365 [1]   RING-SNAP
28 XKAY-00366 [1]   CHECK
29 XKAY-00367 [1]   SPRING
30 XKAY-00368 [1]   SEAT
K31. XKAY-00359 [1]   O-RING
32 XKAY-00415 [1]   RING-SNAP
33 XKAY-00369 [2]   CHECK
34 XKAY-00370 [2]   SPRING
35 XKAY-00371 [2]   PLUG
K36. XKAY-00204 [2]   O-RING
K37. XKAY-00205 [2]   RING-BACK UP
38 XKAY-00586 [1]   MAIN SPOOL
39 XKAY-00374 [2]   SEAT-SPRING
40 XKAY-00375 [2]   SPRING
41 XKAY-00376 [2]   PLUG
K42. XKAY-00377 [2]   O-RING
43 XKAY-00587 [2]   RELIEF VALVE
44 XKAY-00588 [2]   SPRING
45 XKAY-00589 [2]   PLUG
K46. XKAY-00590 [2]   O-RING
47 XKAY-00253 [1]   BALL-STEEL
48 XKAY-00379 [1]   SEAT-CHECK
49 XKAY-00140 [1]   PLUG
50 XKAY-00150 [2]   PLUG
K51. XKAY-00256 [2]   O-RING
52 XKAY-00380 [1]   PLUG
K53. XKAY-00267 [1]   O-RING
54 XKAY-00591 [1]   BEARING-ROLLER      SEE 4300 ITEM54
55 XKAY-00382 [4]   PIN
58 XKAY-00385 [8]   BOLT-WRENCH
84 XKAY-00594 [1]   PLATE-NAME
85 XKAY-00277 [2]   RIVET
K. XKAY-00595 [1]   SEAL KIT      SEE ILLUST
