HYUNDAI R80-7 R80-7A EXCAVATOR SWING REDUCTION GEARBOX PARTS

Name: HYUNDAI R80-7 R80-7A EXCAVATOR SWING REDUCTION GEARBOX PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

HYUNDAI R80-7 R80-7A EXCAVATOR SWING REDUCTION GEARBOX PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

Parts on group SWING MOTOR(REDUCTION GEAR, -#1361):

Pos.	Part No	Qty	Parts name	Comments
*.	@	[1]	SWING MOTOR ASSY	4200-4211
*-1.	@	[1]	SWING MOTOR UNIT	4200
*-21.	31N1-10140	[1]	SWING REDUCTION GEAR
1	XKBR-00063	[1]	SHAFT-DRIVE
2	XKBR-00064	[1]	COVER-BEARING
2	XKBR-00094	[1]	BEARING COVER
3	XKBR-00036	[1]	BEARING-TAPER ROLLER
3	XKBR-00003	[1]	BEARING-TAPER ROLLER
4	XKBR-00065	[1]	CASE
4	XKBR-00093	[1]	CASE
5	XKBR-00038	[1]	SEAL-OIL
5	XKBR-00005	[1]	SEAL-OIL
6	XKBR-00039	[1]	BEARING-TAPER ROLLER
6	XKBR-00006	[1]	BEARING-TAPER ROLLER
7	XKBR-00040	[1]	SUN GEAR NO.2
7	XKBR-00007	[1]	SUN GEAR NO.2
8	XKBR-00041	[6]	BOLT-SOCKET
8	XKBR-00103	[6]	BOLT-SOCKET
9	XKBR-00042	[1]	SUN GEAR NO.1
9	XKBR-00102	[1]	SUN GEAR NO.1
10	XKBR-00066	[1]	CARRIER ASSY NO.1
10	XKBR-00108	[1]	CARRIER ASSY NO.1
20	XKBR-00069	[1]	CARRIER NO.1
20	XKBR-00109	[1]	CARRIER NO.1
21	XKBR-00052	[3]	PLANET GEAR NO.1
21	XKBR-00021	[3]	GEAR-PLANET NO.1
22	XKBR-00070	[3]	PIN NO.1
22	XKBR-00110	[3]	PIN NO.1
23	XKBR-00071	[3]	BUSHING NO.1
23	XKBR-00111	[3]	BUSHING NO.1
24	XKBR-00055	[3]	THRUST WASHER NO.1
24	XKBR-00112	[3]	THRUST WASHER NO.1
25	XKBR-00072	[1]	THRUST WASHER NO.3
25	XKBR-00101	[1]	THRUST WASHER NO.3
32	XKBR-00032	[3]	RING-SNAP
33	XKBR-00062	[3]	THRUST WASHER NO.4
33	XKBR-00113	[3]	THRUST WASHER NO.4
11	XKBR-00044	[1]	GEAR-RING
11	XKBR-00107	[1]	GEAR-RING
12	XKBR-00045	[1]	CARRIER ASSY NO.2
12	XKBR-00096	[1]	CARRIER ASSY NO 2
26	XKBR-00057	[3]	THRUST WASHER NO.2
26	XKBR-00100	[3]	THRUST WASHER NO.2
27	XKBR-00073	[1]	CARRIER NO.2
27	XKBR-00097	[1]	CARRIER NO.2
28	XKBR-00059	[3]	PLANET GEAR NO.2
28	XKBR-00028	[3]	PLANET GEAR NO.2
29	XKBR-00074	[3]	PIN NO.2
29	XKBR-00098	[3]	PIN NO 2
30	XKBR-00075	[3]	BUSHING NO.2
30	XKBR-00099	[3]	BUSH NO.2
31	XKBR-00031	[3]	PIN-SPRING
13	XKBR-00046	[2]	PIN-DOWEL
13	XKBR-00013	[2]	PIN-DOWEL
14	XKBR-00047	[1]	COLLAR-HALF
14	XKBR-00095	[1]	HALF COLLAR
15	XKBR-00015	[1]	PLUG
15	XKBR-00016	[1]	PLUG
16	XKBR-00016	[2]	PLUG
18	XKBR-00049	[1]	PIPE
18	XKBR-00105	[1]	PIPE
19	XKBR-00050	[1]	GAUGE-LEVEL
19	XKBR-00106	[1]	LEVEL GAUGE
N.	@	[1]	NOT SUPPLIED PARTS


Parts on group SWING MOTOR(REDUCTION GEAR, #1362-):

Pos.	Part No	Qty	Parts name	Comments
*.	31N1-10141	[1]	SWING REDUCTION GEAR	SB-I-2014-009.PDF
*.	31N1-10141AR	[1]	SWING REDUCTION GEAR
1	XKBR-00093	[1]	CASE
2	XKBR-00063	[1]	SHAFT-DRIVE
3	XKBR-00094	[1]	BEARING COVER
4	XKBR-00003	[1]	BEARING-TAPER ROLLER
5	XKBR-00005	[1]	SEAL-OIL
6	XKBR-00006	[1]	BEARING-TAPER ROLLER
7	XKBR-00095	[1]	HALF COLLAR
8	XKBR-00013	[2]	PIN-DOWEL
9	XKBR-00084	[1]	GEAR-RING
10	XKBR-00096	[1]	CARRIER ASSY NO 2
11	XKBR-00097	[1]	CARRIER NO.2
12	XKBR-00028	[3]	PLANET GEAR NO.2
13	XKBR-00098	[3]	PIN NO 2
14	XKBR-00099	[3]	BUSH NO.2
15	XKBR-00100	[3]	THRUST WASHER NO.2
16	XKBR-00031	[3]	PIN-SPRING
17	XKBR-00007	[1]	SUN GEAR NO.2
18	XKBR-00085	[1]	CARRIER ASSY NO.1
19	XKBR-00086	[1]	CARRIER NO.1
20	XKBR-00087	[3]	PLANET GEAR NO.1
21	XKBR-00088	[3]	PIN NO.1
22	XKBR-00089	[3]	BUSHING NO.1
23	XKBR-00090	[3]	THRUST WASHER NO.1
24	XKBR-00091	[3]	THRUST WASHER NO.4
25	XKBR-00092	[3]	RING-SNAP
26	XKBR-00101	[1]	THRUST WASHER NO.3
27	XKBR-00102	[1]	SUN GEAR NO.1
28	XKBR-00016	[1]	PLUG
29	XKBR-00016	[2]	PLUG
30	XKBR-00103	[6]	BOLT-SOCKET
31	XKBR-00104	[1]	COVER
32	XKBR-00105	[1]	PIPE
33	XKBR-00106	[1]	LEVEL GAUGE
