HYUNDAI R80-7 R80-7A EXCAVATOR 31Q1-10050 HYDRAULIC PUMP PARTS

HYUNDAI R80-7 R80-7A EXCAVATOR 31Q1-10050 HYDRAULIC PUMP PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
31Q1-10050 R80-7 R80-7A
Pos. Part No Qty Parts name Comments
*. 31Q1-10050 [1]   MAIN PUMP      KPM PUMP
111 XJBN-01743 [1]   SHAFT-DRIVE
114 XJBN-01742 [1]   COUPLING-SPLINE
115 XJBN-01741 [1]   CALLAR
123 XJBN-01740 [1]   BEARING-BALL
124 XJBN-01744 [1]   BEARING-NEEDLE
127 XJBN-00806 [2]   SPACER-BEARING
13 XJBN-01703 [1]   CYLINDER ASSY
141 XJBN-01738 [1]   CYLINDER BLOCK
313 XJBN-01732 [1]   PLATE-VALVE
11 XJBN-01704 [1]   PISTON ASSY
N151. XJBN-01438 [10]   PISTON
N152. XJBN-01278 [10]   SHOE
153 XJBN-01737 [1]   PLATE-SET
156 XJBN-01440 [1]   BUSH-SPHERICAL
157 XJBN-00084 [10]   SPRING-CYLINDER
30 XJBN-01702 [1]   SWASH PLATE ASSY
212 XJBN-01736 [1]   PLATE-SWASH
214 XJBN-00418 [1]   BUSHING-TILTING
490 XJBN-00032 [2]   PLUG
261 XJBN-00416 [1]   COVER(F)-SEAL
271 XJBN-01735 [1]   CASING(F)-PUMP
34 XJBN-01700 [1]   TOP COVER ASSY
273 XJBN-01734 [1]   TOP COVER
656 XJBN-01712 [1]   PIN
363 XJBN-01731 [1]   PIPE-SPACER
404 XJBN-00210 [8]   SCREW-SOCKET
405 XJBN-00445 [5]   SCREW
530 XJBN-01698 [1]   TILTING PIN ASSY
531 XJBN-01725 [1]   TILTING PIN
N548. XJBN-00360 [1]   PIN-FEED BACK
532 XJBN-01724 [1]   PISTON-SERVO
535 XJBN-01723 [1]   STOPPER(L)
536 XJBN-01722 [1]   PLUG
41 XJBN-00072 [2]   CHECK VALVE ASSY 1
610 XJBN-01696 [1]   FEED BACK LEVER ASSY
611 XJBN-01721 [1]   FEED BACK LEVER
653 XJBN-01714 [1]   PIN
654 XJBN-00394 [1]   PIN-VALVE PLATE
620 XJBN-01695 [1]   PISTON-COMPENSATOR
650 XJBN-01694 [1]   SPOOL ASSY
660 XJBN-01693 [1]   PF PISTON ASSY
701 XJBN-00899 [1]   O-RING
706 XJBN-00902 [9]   O-RING
708 XJBN-00917 [1]   O-RING
710 XJBN-00905 [1]   O-RING
712 XJBN-00904 [2]   O-RING
751 XJBN-01709 [1]   PACKING F-SHEET
752 XJBN-01708 [1]   PACKING F-SEAT
774 XJBN-01019 [1]   OIL SEAL
789 XJBN-01706 [1]   BACK UP RING
824 XJBN-00395 [2]   STOP RING
885 XJBN-00365 [1]   SPRING PIN
4 XJBN-01705 [1]   PUMP-GEAR
