HYUNDAI R80-7 R80-7A EXCAVATOR 31N1-10010 31N1-10011 HYDRAULIC PUMP PARTS

HYUNDAI R80-7 R80-7A EXCAVATOR 31N1-10010 31N1-10011 HYDRAULIC PUMP PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
31N1-10010 31N1-10011 R80-7 R80-7A
Pos. Part No Qty Parts name Comments
*. 31N1-10010 [1]   MAIN PUMP      REXROTH PUMP
*. 31N1-10011 [1]   MAIN PUMP      REXROTH PUMP
1 XJDD-00002 [1]   SHAFT ASSY
1 XJDD-01296 [1]   SHAFT ASSY
1-1. XJDD-00024 [1]   SHAFT
1-2. XJDD-00025 [1]   RETAINER-SEAL
1-3. XJDD-00026 [1]   BEARING
1-4. XJDD-00027 [2]   RING-RETAINING
1-5. XJDD-00028 [1]   SEAL-OIL
1-5. XJDD-01297 [1]   SEAL-OIL
1-6. XJDD-00029 [1]   O-RING
1-7. XJDD-00030 [1]   RING-RETAINING
2 XJDD-00003 [1]   SWASH PLATE ASSY
2-1. XJDD-00031 [1]   SWASH PLATE
2-2. XJDD-00032 [1]   GUIDE
2-4. XJDD-00033 [1]   GUIDE
2-6. XJDD-00034 [1]   O-RING
2-7. XJDD-00035 [1]   RING-BACK UP
2-8. XJDD-00036 [2]   PIN-D/BREAK OFF
2-9. XJDD-00037 [1]   PIN
2-10. XJDD-00038 [1]   BUSHING
3 XJDD-00004 [1]   ROTARY GROUP
3-1. XJDD-00039 [10]   PISTON
3-2. XJDD-00040 [1]   BLOCK-CYLINDER
3-3. XJDD-00041 [1]   RETAINER
3-5. XJDD-00042 [1]   GUIDE
3-6. XJDD-00043 [1]   SPRING
3-7. XJDD-00044 [3]   PIN-PARALLEL
3-8. XJDD-00045 [2]   SEAT-SPRING
3-9. XJDD-00046 [1]   RING-RETAINING
5 XJDD-00006 [1]   CONTROL SPRING ASSY
5-1. XJDD-00056 [1]   SEAT-SPRING
5-2. XJDD-00057 [1]   SPACER-SPRING
5-3. XJDD-00058 [1]   COVER
5-4. XJDD-00059 [1]   SCREW-ADJUST
5-5. XJDD-00060 [1]   SPRING
5-6. XJDD-00061 [1]   SPRING
5-7. XJDD-00062 [1]   O-RING
5-8. XJDD-00063 [2]   BOLT-SOCKET
5-9. XJDD-00064 [1]   NUT
5-10. XJDD-00065 [1]   GUIDE
5-34. XJDD-00066 [2]   SHIM(0.3T)
5-44. XJDD-00067 [2]   SHIM(0.5T)
5-54. XJDD-00068 [2]   SHIM(1.0T)
6 XJDD-00007 [1]   CONTROL SPRING ASSY
6-1. XJDD-00069 [1]   CYLINDER
6-2. XJDD-00070 [1]   PISTON
6-3. XJDD-00071 [1]   PISTON
6-4. XJDD-00072 [4]   SPRING-CONED DISC
6-5. XJDD-00073 [1]   SPACER
6-6. XJDD-00074 [1]   SPACER
6-7. XJDD-00075 [1]   SPACER
6-8. XJDD-00076 [1]   SPACER
8 XJDD-00009 [1]   HOUSING
9 XJDD-00010 [1]   VALVE-AIR VENT
10 XJDD-00011 [1]   BUSHING
11 XJDD-00012 [1]   BALL-STEEL
12 XJDD-00013 [1]   PLUG
13 XJDD-00014 [1]   PLUG
14 XJDD-00015 [1]   PACKING
15 XJDD-00016 [1]   SHIM
16 XJDD-00017 [1]   PLUG
N17. XJDD-00018 [1]   NAME PLATE ASSY
19 XJDD-00020 [1]   PLUG
22 XJDD-00021 [1]   PLUG ASSY
23 XJDD-00022 [1]   ORIFICE
25 XJDD-00023 [2]   RING-SQUARE
Pos. Part No Qty Parts name Comments
*. @ [1]   MAIN PUMP      SEE 4010
*. @ [1]   MAIN PUMP      SEE 4010
4 XJDD-00005 [1]   PORT PLATE ASSY
4-1. XJDD-00047 [1]   COVER
4-2. XJDD-00048 [1]   PLATE-CONTROL
4-2. XJDD-01175 [1]   PLATE-CONTROL
4-3. XJDD-00049 [2]   PIN-PARALLEL
4-4. XJDD-00050 [2]   BOLT
4-5. XJDD-00051 [2]   SCREW-SOCKET HEAD
4-6. XJDD-00052 [1]   BOLT
4-7. XJDD-00053 [1]   BEARING
4-8. XJDD-00023 [2]   RING-SQUARE
4-9. XJDD-00054 [3]   PIN-D/BREAK OFF
4-10. XJDD-00055 [1]   PACKING
4-11. XJDD-00827 [1]   PLUG
4 XJDD-00005 [1]   PORT PLATE ASSY
4-1. XJDD-00047 [1]   COVER
4-2. XJDD-00048 [1]   PLATE-CONTROL
4-3. XJDD-00049 [2]   PIN-PARALLEL
4-4. XJDD-00050 [2]   BOLT
4-5. XJDD-00051 [2]   SCREW-SOCKET HEAD
4-6. XJDD-00052 [1]   BOLT
4-7. XJDD-00053 [1]   BEARING
4-8. XJDD-00023 [2]   RING-SQUARE
4-9. XJDD-00054 [3]   PLUG
4-10. XJDD-00055 [1]   PACKING
7 XJDD-00008 [1]   PUMP-GEAR
18 XJDD-00019 [1]   PLUG
30 XJDD-00100 [1]   RELIEF VALVE
30-1. XJDD-00101 [1]   SPOOL
30-2. XJDD-00102 [1]   SCREW-ADJUST
30-3. XJDD-00103 [1]   O-RING
30-4. XJDD-00104 [1]   SPRING
30-5. XJDD-00105 [1]   NUT
30-6. XJDD-00106 [1]   SHIM
