HYUNDAI R55-9 R55-9A R55W-9 R55W-9A R60-9S R60W-9S excavator swing motor rotary group and spare parts

HYUNDAI R55-9 R55-9A R55W-9 R55W-9A R60-9S R60W-9S excavator swing motor rotary group and spare parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
31M9-10130 31M9-10131 31M9-10131AR 31M9-10132AR 31M9-10150 31M9-10151 31M9-10152 31M9-10152SG8 R55-9 R55-9A R55W-9 R55W-9A R60-9S R60W-9S
Pos. Part No Qty Parts name Comments
*. 31M9-10150 [1]   SWING UNIT      *-1, *-2
*. 31M9-10151 [1]   SWING UNIT      *-1, *-2
*. 31M9-10152 [1]   SWING UNIT      *-1, *-2
*. 31M9-10152SG8 [1]   SWING UNIT      *-1, *-2
*. 31M9-10151 [1]   SWING UNIT      *-1, *-2
*. 31M9-10152 [1]   SWING UNIT      *-1, *-2
*. 31M9-10152SG8 [1]   SWING UNIT      *-1, *-2
*-1. 31M9-10130 [1]   SWING  MOTOR UNIT
*-1. 31M9-10131 [1]   SWING  MOTOR UNIT
*-1. 31M9-10131AR [1]   SWING MOTOR UNIT
*-1. 31M9-10132AR [1]   SWING MOTOR UNIT
*-1. 31M9-10131 [1]   SWING MOTOR UNIT
*-1. 31M9-10131AR [1]   SWING MOTOR UNIT
1 XKAY-01118 [1]   BODY
1 XKAY-02031 [1]   BODY
1 XKAY-02031 [1]   BODY
K2. XKAY-00116 [1]   SEAL-OIL
*-11. XKAY-00416 [1]   ROTARY KIT
*-11. XKAY-02033 [1]   ROTARY KIT
*-11. XKAY-02033 [1]   ROTARY KIT
*-111. XKAY-00417 [1]   CYLINDER BLOCK KIT
*-111. XKAY-02034 [1]   CYLINDER BLOCK KIT
*-111. XKAY-02034 [1]   CYLINDER BLOCK KIT
N3. XKAY-01119 [1]   CYLINDER BLOCK
N3. XKAY-02035 [1]   CYLINDER BLOCK
N3. XKAY-02035 [1]   CYLINDER BLOCK
8 XKAY-00124 [9]   SPRING
16 XKAY-00125 [1]   PLATE-VALVE
16 XKAY-02036 [1]   PLATE-VALVE
16 XKAY-02036 [1]   PLATE-VALVE
*-112. XKAY-00418 [1]   RETAINER KIT
*-112. XKAY-02037 [1]   RETAINER KIT
*-112. XKAY-02037 [1]   RETAINER KIT
9 XKAY-00160 [1]   PLATE-SET
9 XKAY-02038 [1]   PLATE-SET
9 XKAY-02038 [1]   PLATE-SET
11 XKAY-00129 [1]   GUIDE-BALL
*-113. XKAY-00419 [1]   PISTON KIT
*-113. XKAY-02039 [1]   PISTON KIT
*-113. XKAY-02322 [1]   PISTON KIT
*-113. XKAY-02039 [1]   PISTON KIT
N10. XKAY-00117 [9]   PISTON SHOE ASSY
N10. XKAY-02040 [9]   PISTON SHOE ASSY
N10. XKAY-02324 [9]   PISTON SHOE ASSY
N10. XKAY-02040 [9]   PISTON SHOE ASSY
4 XKAY-00120 [1]   SHAFT
5 XKAY-00121 [1]   BEARING-TAPER
6 XKAY-00122 [1]   BUSHING
7 XKAY-00123 [1]   PLATE-SHOE
12 XKAY-01120 [1]   REAR COVER
13 XKAY-00131 [2]   PIN
K14. XKAY-00420 [1]   O-RING
15 XKAY-00133 [1]   BEARING-TAPER
*-12. XKAY-01121 [2]   RELIEF VALVE ASSY KIT
*-12. XKAY-02029 [2]   RELIEF VLV ASSY KIT
17 XKAY-01122 [1]   RELIEF VALVE ASSY
17 XKAY-01975 [1]   RELIEF VALVE ASSY
K23. XKAY-00141 [1]   RING-BACK UP
K24. XKAY-00310 [1]   O-RING
K38. XKAY-00423 [1]   O-RING
K39. XKAY-00157 [1]   RING-BACK UP
18 XKAY-00136 [4]   BOLT-SOCKET
19 XKAY-00137 [1]   PLUG
20 XKAY-00138 [1]   PLUG
K21. XKAY-00267 [1]   O-RING
22 XKAY-00139 [AR]   SHIM
25 XKAY-00143 [1]   PLATE-FRICTION
26 XKAY-00144 [1]   PLATE
27 XKAY-00145 [1]   PISTON-PARKING
K28. XKAY-00422 [2]   O-RING
29 XKAY-00147 [18]   SPRING
30 XKAY-00148 [1]   VALVE-TIME DELAY
31 XKAY-00149 [3]   BOLT-WRENCH
32 XKAY-00150 [2]   PLUG
K33. XKAY-00256 [2]   O-RING
34 XKAY-00152 [2]   VALVE
35 XKAY-00153 [2]   SPRING
36 XKAY-00154 [2]   PLUG
K37. XKAY-00247 [2]   O-RING
40 XKAY-01123 [1]   NAME PLATE
40 XKAY-02032 [1]   NAME PLATE
41 XKAY-00159 [2]   RIVET
*-2. @ [2]   SWING REDUCTION GEAR      SEE 4220
*-3. XKAQ-00142 [1]   AIR BREATHER ASSY
51 HHI13-WP30 [1]   CAP-RUBBER
52 HHI13-WP31 [1]   CAP-BREATHER
K. XKAY-00414 [1]   SEAL KIT      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
