Hyundai R55-7 R55-7A R60-7 excavator hydraulic pump parts

Hyundai R55-7 R55-7A R60-7 excavator hydraulic pump parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
T5VP2D25 31M8-10010 31M8-10020 XKAH-00783 R55-7 R55-7A
Pos. Part No Qty Parts name Comments
*. 31M8-10020 [1]   MAIN PUMP      STD
*. 31M8-10010 [1]   MAIN PUMP
N*-1. XKAH-00783 [1]   MAIN PUMP UNIT      SEE 4020
1 XKAH-00653 [1]   SHAFT-DRIVE
2 XKAH-00652 [1]   COVER-SEAL
3 XKAH-00651 [1]   BEARING-BALL
4 XKAH-00650 [1]   RING-SNAP
5 XKAH-00649 [1]   RING-SNAP
K6. XKAH-00648 [1]   SEAL-OIL
K7. XKAH-00647 [1]   O-RING
8 XKAH-00646 [1]   RING-SNAP
9 XKAH-00645 [1]   PLATE-SWASH
10 XKAH-00644 [1]   PLATE
11 XKAH-00643 [1]   SPACER-BEARING
12 XKAH-00642 [2]   BEARING-ROLLER
13 XKAH-00641 [4]   BOLT-SOCKET
K14. XKAH-00640 [1]   O-RING
15 XKAH-00639 [1]   PIVOT
16 XKAH-00655 [1]   BLOCK-CYLINDER      STD
16 XKAH-00918 [1]   BLOCK-CYLINDER
17 XKAH-00656 [1]   BUSH-SPHERICAL
18 XKAH-00657 [1]   PLATE-PUSH      STD
18 XKAH-00919 [1]   PLATE-PUSH
19 XKAH-00658 [1]   PLATE-SHOE
20 XKAH-00659 [1]   SPRING
21 XKAH-00660 [3]   PIN-PARALLEL
22 XKAH-00661 [2]   SEAT-SPRING
23 XKAH-00662 [1]   RING-SNAP
24 XKAH-00864 [1]   PISTON SUB ASSY      STD
24 XKAH-00928 [1]   PISTON SUB ASSY
26 XKAH-00673 [1]   CASING
27 XKAH-00675 [1]   SEAT-SPRING(1)
28 XKAH-00676 [1]   SEAT-SPRING(2)
29 XKAH-00677 [1]   COVER-SPRING
30 XKAH-00678 [1]   SCREW-ADJUSTING
31 XKAH-00679 [1]   SPRING
32 XKAH-00680 [1]   SPRING
K33. XKAH-00681 [1]   O-RING
34 XKAH-00682 [2]   BOLT-SOCKET
35 XKAH-00683 [1]   NUT-HEX
36 XKAH-00684 [1]   SHIM(0.3T)
37 XKAH-00685 [1]   SHIM(0.5T)
38 XKAH-00686 [1]   SHIM(1.0T)
39 XKAH-00687 [1]   SHIM(2.0T)
73 XKAH-00716 [1]   AIR BREATHER
74 XKAH-00717 [1]   NAME PLATE      STD
N74. XKAH-00924 [1]   NAME PLATE
75 XKAH-00116 [2]   SCREW-RIVET
K. XKAH-00824 [1]   SEAL KIT
*-2. @ [1]   GEAR PUMP ASSY      4030
Pos. Part No Qty Parts name Comments
*-1. @ [1]   MAIN PUMP UNIT      4010
40 XKAH-00688 [1]   CYLINDER-CONTROL      STD
40 XKAH-00921 [1]   CYLINDER-CONTROL
41 XKAH-00689 [1]   PISTON-CONTROL      STD
41 XKAH-00922 [1]   PISTON-CONTROL
42 XKAH-00690 [2]   PUSH ROD-CONTROL(1)
43 XKAH-00691 [1]   PUSH ROD-CONTROL(2)
44 XKAH-00692 [1]   SEAT-SPRING(1)
45 XKAH-00693 [2]   BOLT-SOCKET
46 XKAH-00694 [3]   WASHER-CON SPRING
K47. XKAH-00695 [1]   O-RING
K48. XKAH-00696 [1]   O-RING
K49. XKAH-00697 [1]   O-RING
50 XKAH-00698 [1]   BLOCK-VALVE
51 XKAH-00699 [1]   PLATE-VALVE      STD
51 XKAH-00923 [1]   PLATE-VALVE
52 XKAH-00700 [2]   PIN-PARALLEL
53 XKAH-00701 [3]   BOLT-SOCKET
K54. XKAH-00702 [1]   O-RING
K55. XKAH-00703 [4]   O-RING
56 XKAH-00208 [10]   PLUG-PT
57 XKAH-00704 [3]   ORIFICE
58 XKAH-00705 [1]   BEARING-NEEDLE
59 XKAH-00706 [2]   PLUG-RO
K60. XKAH-00194 [2]   O-RING
61 XKAH-00707 [1]   BOLT-SOCKET
62 XKAH-00708 [1]   FILTER-RETURN
63 XKAH-00709 [1]   RING-SNAP
64 XKAH-00710 [4]   PLUG-RO
K65. XKAH-00052 [4]   O-RING
K66. XKAH-00194 [1]   O-RING
67 XKAH-00711 [1]   SPOOL
68 XKAH-00712 [1]   SCREW-ADJUSTING
69 XKAH-00703 [1]   O-RING
70 XKAH-00713 [1]   SPRING
71 XKAH-00714 [1]   NUT-HEX
72 XKAH-00715 [1]   SHIM
K. XKAH-00824 [1]   SEAL KIT
*-2. @ [1]   GEAR PUMP ASSY      4030
Pos. Part No Qty Parts name Comments
*. @ [1]   MAIN  PUMP      4010
*-2. XKAH-00855 [1]    GEAR PUMP ASSY      STD
*-2. XKAH-00917 [1]   GEAR PUMP ASSY
7 XKAH-00759 [1]   COUPLING-SPLINE
31M8-10011 31M8-10021 31M8-10022 R55-7 R55-7A R60-7
Pos. Part No Qty Parts name Comments
*. 31M8-10021 [1]   MAIN  PUMP      STD
*. 31M8-10022 [1]   MAIN  PUMP      STD
*. 31M8-10011 [1]   MAIN PUMP
1 XJDD-00786 [1]   SHAFT ASSY
1 XJDD-01294 [1]   SHAFT ASSY
1-1. XJDD-00796 [1]   SHAFT
1-2. XJDD-00797 [1]   SEALCASE
1-3. XJDD-00798 [1]   BEARING
1-6. XJDD-00799 [1]   RETAINING RING(C TYPE)
1-8. XJDD-00800 [1]   OIL SEAL
1-8. XJDD-01295 [1]   OIL SEAL
1-9. XJDD-00801 [1]   O-RING
1-10. XJDD-00802 [1]   RETAINING RING(C TYPE)
2 XJDD-00787 [1]   HANGER ASSY
2-1. XJDD-00803 [1]   HANGER
2-1-1. XJDD-01023 [1]   HANGER
2-1-2. XJDD-01024 [1]   BUSH
2-2. XJDD-00804 [1]   COVER
2-3. XJDD-00805 [1]   SPACER
2-4. XJDD-00806 [2]   BEARING
2-5. XJDD-00807 [4]   SCREW-HEX SO HD CAP
2-6. XJDD-00808 [1]   O-RING
3 XJDD-00865 [1]   ROTARY GROUP      STD
3 XJDD-00788 [1]   ROTARY GROUP
3-1. XJDD-00809 [10]   PISTON ASSY
3-2. XJDD-00810 [1]   BLOCK-CYLINDER
3-4. XJDD-00866 [1]   RETAINER      STD
3-4. XJDD-00811 [1]   RETAINER
3-5. XJDD-00812 [1]   PLATE
3-6. XJDD-00813 [1]   GUIDE
3-7. XJDD-00814 [1]   SPRING
3-8. XJDD-00044 [3]   PIN-PARALLEL
3-9. XJDD-00815 [2]   SPRING SEAT
3-10. XJDD-00816 [1]   RETAINING RING(C TYPE)
5 XJDD-01025 [1]   SPRING SEAT ASSY      STD
5 XJDD-00867 [1]   SPRING SEAT ASSY      STD
5 XJDD-00867 [1]   SPRING SEAT ASSY
5-1. XJDD-00828 [1]   SPRING SEAT
5-2. XJDD-01026 [1]   SPACER-SPRING      STD
5-2. XJDD-00868 [1]   SPRING SEAT      STD
5-2. XJDD-00868 [1]   SPRING SEAT
5-3. XJDD-00830 [1]   COVER
5-4. XJDD-00731 [1]   SCREW-ADJUSTING
5-7. XJDD-00831 [1]   O-RING
5-8. XJDD-00733 [2]   SCREW-HEX S/HD CAP
5-9. XJDD-00734 [1]   NUT-HEX
5-34. XJDD-00832 [2]   SHIM
5-44. XJDD-00833 [2]   SHIM
5-54. XJDD-00834 [2]   SHIM
5-64. XJDD-00835 [2]   SHIM
8 XJDD-00793 [1]   HOUSING
11 XJDD-00010 [1]   VALVE-AIR VENT
13 XJDD-00884 [1]   SPRING
14 XJDD-00885 [1]   SPRING
*. @ [1]   MAIN  PUMP      SEE 4040
4 XJDD-00789 [1]   COVER ASSY
4-1. XJDD-00817 [1]   COVER
4-2. XJDD-00818 [1]   CONTROL PLATE
4-3. XJDD-00819 [2]   PIN-PARALLEL
4-4. XJDD-00820 [3]   SCREW-HEX SO HD CAP
4-5. XJDD-00821 [1]    O RING
4-6. XJDD-00103 [4]    O-RING
4-7. XJDD-00017 [5]   PLUG
4-9. XJDD-00822 [3]   ORIFICE
4-10. XJDD-00823 [1]   BEARING
4-11. XJDD-00021 [1]   PLUG ASSY
4-12. XJDD-01027 [1]    O-RING
4-12. XJDD-00824 [1]   O-RING
4-13. XJDD-00726 [1]   SCREW-HEX S/HD CAP
4-14. XJDD-00825 [1]   FILTER
4-15. XJDD-00826 [1]   RETAINING RING(C TYPE)
4-16. XJDD-00054 [3]   PIN-D/BREAK OFF
4-17. XJDD-00827 [2]   PLUG
6 XJDD-00869 [1]   CONTROL PISTON ASSY      STD
6 XJDD-01032 [1]   CONTROL PISTON ASSY
6-1. XJDD-00870 [1]   CYLINDER      STD
6-1. XJDD-00836 [1]   CYLINDER
6-2. XJDD-00871 [1]   PISTON      STD
6-2. XJDD-01030 [1]   PISTON
6-3. XJDD-00838 [2]   PIN-PARALLEL
6-4. XJDD-00872 [1]   PIN-PARALLEL      STD
6-4. XJDD-00839 [1]   PIN-PARALLEL      LOW NOISE
6-5. XJDD-00840 [1]   SPRING SEAT
6-6. XJDD-00841 [2]   SCREW-HEX SO HD CAP
6-7. XJDD-00842 [4]   SPRING-CONED DISC
6-8. XJDD-00873 [1]   O-RING
6-9. XJDD-00874 [1]    O-RING
6-10. XJDD-00875 [1]   O-RING
10 XJDD-00698 [1]   VALVE ASSY-RELIEF
10-1. XJDD-00101 [1]   SPOOL
10-2. XJDD-00102 [1]   SCREW-ADJUST
10-3. XJDD-00103 [1]    O-RING
10-4. XJDD-00779 [1]   SPRING
10-5. XJDD-00105 [1]   NUT
10-6. XJDD-00780 [1]   SEAT-SPRING
7 XJDD-01033 [1]   GEAR PUMP
*. XJDD-01034 [1]   GEAR PUMP
10 XJDD-00863 [1]

  COUPLING
