Hyundai R55-7 R55-7A R55-9 R60-9S R60CR-9 R60CR-9A excavator final drive travel motor rotary group

Hyundai R55-7 R55-7A R55-9 R60-9S R60CR-9 R60CR-9A excavator final drive travel motor rotary group

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
XKAH-00753 R55-7 R55-7A R55-9 R60-9S R60CR-9 R60CR-9A
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL  MOTOR      SEE 4230
N*-2. XKAH-00753 [1]   TRAVEL  MOTOR UNIT
*-21. XKAH-00752 [1]   C/BLOCK & PISTON KIT
4 XKAH-00831 [1]   BLOCK-CYLINDER
5 XKAH-00828 [9]   PISTON ASSY
7 XKAH-00747 [1]   PLATE-RETAINER
8 XKAH-00746 [1]   BALL-THRUST
10 XKAH-00745 [2]   WASHER
11 XKAH-00744 [1]   WASHER-COLLAR
14 XKAH-00743 [1]   SPRING
51 XKAH-00742 [3]   ROLLER
*-22. XKAH-00741 [1]   PISTON ASSY-2 SPEED
60 XKAH-00738 [1]   SPRING
N61. XKAH-00740 [1]   PISTON
N62. XKAH-00739 [1]   SHOE
2 XKAH-00832 [1]   SHAFT-MAIN
3 XKAH-00736 [1]   PLATE-SWASH
9 XKAH-00833 [1]   PLATE-TIMING
12 XKAH-00734 [1]   PISTON-PARKING
13 XKAH-00733 [6]   SPRING
15 XKAH-00732 [2]   PLATE-FRICTION
16 XKAH-00731 [2]   PLATE-MATING
K32. XKAH-00730 [1]   SEAL-OIL
K35. XKAH-00729 [1]   O-RING
K39. XKAH-00728 [1]   O-RING
45 XKAH-00727 [1]   RING-SNAP
K47. XKAH-00726 [1]   RING-BACK UP
K48. XKAH-00725 [1]   RING-BACK UP
49 XKAH-00724 [1]   BEARING-ROLLER
50 XKAH-00723 [1]   BEARING-BALL
67 XKAH-00722 [2]   PIVOT
70 XKAH-00299 [4]   BOLT-SOCKET
K75. XKAH-00262 [2]   O-RING
76 XKAH-00721 [1]   RING-SNAP
K. XKAH-00838 [1]   SEAL KIT
N. @ [AR]   NOT INDIVIDUALLY SUPPLIED
*. @ [1]   TRAVEL MOTOR
*-3. XKAH-00836 [1]   RELIEF VALVE BLOCK KIT
N201. XKAH-00719 [1]   VALVE BLOCK
N*-31. XKAH-00837 [2]   RELIEF VALVE ASSY
XKAH-00753 R55-7 R55-7A R55-9 R60-9S R60CR-9 R60CR-9A
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL  MOTOR      SEE 4230
N*-2. XKAH-00753 [1]   TRAVEL  MOTOR UNIT
*-21. XKAH-00752 [1]   C/BLOCK & PISTON KIT
4 XKAH-00831 [1]   BLOCK-CYLINDER
5 XKAH-00828 [9]   PISTON ASSY
7 XKAH-00747 [1]   PLATE-RETAINER
8 XKAH-00746 [1]   BALL-THRUST
10 XKAH-00745 [2]   WASHER
11 XKAH-00744 [1]   WASHER-COLLAR
14 XKAH-00743 [1]   SPRING
51 XKAH-00742 [3]   ROLLER
*-22. XKAH-00741 [1]   PISTON ASSY-2 SPEED
60 XKAH-00738 [1]   SPRING
N61. XKAH-00740 [1]   PISTON
N62. XKAH-00739 [1]   SHOE
2 XKAH-00832 [1]   SHAFT-MAIN
3 XKAH-00736 [1]   PLATE-SWASH
9 XKAH-00833 [1]   PLATE-TIMING
12 XKAH-00734 [1]   PISTON-PARKING
13 XKAH-00733 [6]   SPRING
15 XKAH-00732 [2]   PLATE-FRICTION
16 XKAH-00731 [2]   PLATE-MATING
K32. XKAH-00730 [1]   SEAL-OIL
K35. XKAH-00729 [1]   O-RING
K39. XKAH-00728 [1]   O-RING
45 XKAH-00727 [1]   RING-SNAP
K47. XKAH-00726 [1]   RING-BACK UP
K48. XKAH-00725 [1]   RING-BACK UP
49 XKAH-00724 [1]   BEARING-ROLLER
50 XKAH-00723 [1]   BEARING-BALL
67 XKAH-00722 [2]   PIVOT
70 XKAH-00299 [4]   BOLT-SOCKET
K75. XKAH-00262 [2]   O-RING
76 XKAH-00721 [1]   RING-SNAP
K. XKAH-00838 [1]   SEAL KIT
N. @ [AR]   NOT INDIVIDUALLY SUPPLIED
*. @ [1]   TRAVEL MOTOR
*-3. XKAH-00836 [1]   RELIEF VALVE BLOCK KIT
N201. XKAH-00719 [1]   VALVE BLOCK
N*-31. XKAH-00837 [2]   RELIEF VALVE ASSY
